4 Zone DMX and RF wall panel
for RGB and RGBW LED strip
WP-4RGBWN
Product Description
The WP-4RGBWN wall panel enables control of 1 to 4 zones of RGB/RGBW LED strip, featuring a simple to
use back lit touch control slider for easy colour adjustment .
Technical Specification
Controller
Order Code
Type
Input Voltage
Operation Frequency 2.4GHz
Dimension
Compatible RGB receivers and DMX decoders
Technical Specification
Order code
Channels
Type
Input Voltage 12-24V DC
Current
Output
Note
Dimension
WP-4RGBWN
RF and DMX wall panel
AC85-265V
86x86x36.5mm (WxLxH)
R3C
3 (RGB)
RF receiver
3x4A
3X(48-96W)
Constant
voltage
33x97x18mm
(WxLxH)
R3C
Features
•
Easy control of RGB/RGBW LED strips for up to 4
zones independently or simultaneously
•
Touch sensitive glass
•
5%-100% smooth dimming
•
Backlit buttons for night time use
•
Designed to fit into your existing switch back box
•
DMX512 signal output for wired control of RGB/
RGBW DMX decoders
•
Receiver Auto-Transmitting function to achieve
greater distances between receivers and the
remote
•
Built-in dynamic play modes with receiver auto-
synchronization
R4C
DIM-DMX1CH(N)
4 (RGBW)
4 (RGBW)
RF receiver
DMX decoder
12-36V DC
12-24V DC
4x5A
4x5A
4X(60-180W)
4x(60-120)W
Constant
Constant voltage
voltage
45x175x27mm
50x170x23mm
(WxLxH)
(WxLxH)
R4C
DIM-DMX1CH(N)
V002-11-2019
www.teucerled.co.uk
Advertisement
Table of Contents
Related Manuals for TEUCER WP-4RGBWN
Summary of Contents for TEUCER WP-4RGBWN
- Page 1 RGB and RGBW LED strip WP-4RGBWN Product Description The WP-4RGBWN wall panel enables control of 1 to 4 zones of RGB/RGBW LED strip, featuring a simple to use back lit touch control slider for easy colour adjustment . Technical Specification Features •...
- Page 2 4 Zone DMX and RF wall panel for RGB and RGBW LED strip Controller layout FRONT BACK RGB colour slide ON/OFF ZONE POWER WP-4RGBWN Play mode Zones ZONE MODE Brightness INPUT DMX OUTPUT 85-265VAC ZONE BRT/SPEED / speed ZONE WHITE...
- Page 3 4 Zone DMX and RF wall panel for RGB and RGBW LED strip RGB Receiver wiring diagram Power supply RGB LED strip RGBW Receiver wiring diagram RGBW LED strip Power supply www.teucerled.co.uk V002-11-2019...
- Page 4 4 Zone DMX and RF wall panel for RGB and RGBW LED strip DMX Decoder wiring diagram (RGBW) WP-4RGBWN INPUT DMX OUTPUT 85-265VAC Power input AC85-265V DMX Signal AC110-230V AC110-230V RGBW LED strip RGBW LED strip Synchronising the remote to receiver 1) Ensure the receiver has power.
- Page 5 4 Zone DMX and RF wall panel for RGB and RGBW LED strip 2) Choose the zone you wish to allocate on the panel within 5 seconds after pressing the match button. The LED indicator on the receiver will flash rapidly 5 times and then stop flashing. The controller is now synchronised with the receiver.
- Page 6 • Always ensure products are mounted in areas Teucer, as well as subsequent return of the faulty with adequate ventilation to avoid overheating. unit. Teucer does not accept responsibility for any Back box mounting Compatible •...
