Use the 2455/CV30 Adapter Plate to install the CV30 Fixed Mount
Computer onto an existing Trakker Antares 2455 Vehicle Mount using the
same screw hardware.
The shipping box contains the adapter plate and these instructions.
Items not provided:
•
A vehicle mounting kit to attach the CV30 to the adapter plate.
•
A DC/DC power supply. Here are the options:
•
A DC/DC power supply (P/N 203-779-001).
•
A DC/DC non-heated converter (P/N 203-780-001).
•
A DC/DC heated converter (P/N 203-780-002).
To install the adapter
1 Remove the bracket by unscrewing the wing nuts, washers, and screws.
Bracket
2455/CV30 Adapter Plate Instructions
CV30
Screw
(4 places)
Washer
(4 places)
Wing nut
(4 places)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Intermec CV30
Summary of Contents for Intermec CV30
- Page 1 The shipping box contains the adapter plate and these instructions. Items not provided: • A vehicle mounting kit to attach the CV30 to the adapter plate. • A DC/DC power supply. Here are the options: • A DC/DC power supply (P/N 203-779-001).
- Page 2 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2006 Intermec Technologies Corporation. All rights reserved. 2455/CV30 Adapter Plate Instructions *931-026-001* P/N 931-026-001 Screw (4 places) Adapter plate Washer (4 places) Wing nut (4 places)
