This quick reference guide describes how to assemble and use the
vehicle-mount scanner holder with a 1550 series laser scanner.
1550 Series Vehicle-Mount Scanner Holder
Quick Reference Guide
The 1550 series vehicle-mount holder is a convenient way to
store your scanner when it is not in use. It is designed to securely
hold your scanner on a moving vehicle. The vehicle mount
holder is shipped with:
Scanner holder
Mounting bracket
Double-stick tape (2)
Tie-wrap (2)
Screw (2)
Scanner
holder
If any items are damaged or missing, please call your local
Intermec representative.
Assembling the Vehicle-Mount Scanner Holder
The vehicle-mount scanner holder comes in two pieces: the
mounting bracket that attaches to the vehicle and the scanner
holder that holds the scanner.
Tie-wrap
(2 places)
Mounting
bracket
155XQ.003
Screw
(2 places)
Double-stick tape
(2 places)
