Dexter Laundry T-20 SWD Operator's Manual

COMMERCIAL DRYER
MODEL T-20 SWD VENDED
C-SERIES CONTROL, ELECTRC-HEATED
The dryer will operate correctly in ambient temperatures of +5°C to +45°C, in relative humidity up to
50% at +40°C and above 50% when below +40°C, and at altitudes up to 1000m above sea level,
must be transported and stored from -40°C to +140°C, and has been packaged to prevent damage
from humidity, vibration, and shock. Take measures to avoid harmful effects of occasional
condensation.
Post the following "For Your Safety" caution in a prominent location:
Do not store or use petrol or other flammable vapours and liquids or dry cleaning solvents in the
vicinity of this or any other appliance.
THIS MACHINE IS FOR DRYING ONLY FABRICS WASHED IN WATER.
To avoid possibility of fire, including spontaneous combustion, do not dry oiled floor mops, items
containing foam rubber or similarly textured rubberlike materials or any material on which you have
used a cleaning solvent or which contains flammable liquids or solids (such as petrol, kerosene, waxes,
etc.) Fabric softeners, or similar products, should be used per the fabric softener instructions. Remove
all objects from pockets such as lighters and matches.
WARNING – Risk of Fire
Clothes dryer installation must be performed by a qualified installer.
Install the clothes dryer according to the manufacturer's instructions and local codes.
Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil type) duct is
installed, use duct that has been investigated and found acceptable for use with clothes dryers.
Flexible venting materials are known to collapse, be easily crushed, and trap lint. These conditions will
obstruct clothes dryer airflow and increase the risk of fire.
To reduce the risk of severe injury or death, follow all installation instructions.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision. Children of less than 3 years should be kept away
unless continuously supervised.
It is important that you read this Manual and retain it for future reference. For service or
replacement parts, contact the distributor in your area or manufacturer:
8514-292-001 REV A PAGE 1
OPERATOR'S MANUAL
INSTALLATION & OPERATION INSTRUCTIONS
FOR YOUR SAFETY
FOR YOUR SAFETY
Dexter Laundry, Inc.
2211 West Grimes Avenue
Fairfield, Iowa 52556, USA
Original Instructions
For GB & IE
