INDUSTRIAL DRYER
MODEL T-20SWD ON-PREMISE
B-SERIES CONTROL, ELECTRIC-HEATED
OPERATOR'S MANUAL
INSTALLATION & OPERATION INSTRUCTIONS
The dryer must not be stored or installed where it will be exposed to water and/or weather
and is suitable for use in room temperatures between 40F and 105F (5C and 45C.)
Post the following "For Your Safety" caution in a prominent location:
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any
other appliance or machine.
It is important that you read this Manual and retain it for future reference. For service or
replacement parts, contact the Dexter Distributor in your area or the manufacturer.
WARNING / Avertissement
WARNING - Risk of Fire / Avertissement: Risque d'incendie
Clothes dryer installation must be performed by a qualified installer. / L'installation de la
sécheuse doit être effectuée par un spécialiste qualifié.
Install the clothes dryer according to the manufacturer's instructions and local codes.
Do not install a clothes dryer with flexible plastic venting materials. If flexible metal (foil type)
duct is installed, use duct that has been investigated and found acceptable for use with clothes
dryers. Flexible venting materials are known to collapse, be easily crushed, and trap lint.
These conditions will obstruct clothes dryer airflow and increase the risk of fire. / Ne pas
installer une sécheuse avec des matériaux de ventilation en plastique. Dans le cas où un
conduit en métal flexible (du genre à feuille) est installé, il doit être d'un type spécifique
identifié par le fabricant de l'appareil comme acceptable pour les sécheuses. Les matériaux de
ventilation flexibles sont réputés pour s'aplatir, se déformer facilement et collecter de la
peluche. Ces conditions vont obstruer l'écoulement d'air de la sécheuse et augmenter le risque
d'incendie.
To reduce the risk of severe injury or death, follow all installation instructions. / Pour réduire le
risque de blessures graves ou mortelles, suivre toutes les instructions d'installation.
Save these instructions. / Garder les instructions.
Dexter Laundry, Inc.
2211 West Grimes Avenue
Fairfield, Iowa 52556, USA
8514-288-001 REV A PAGE 1
Advertisement
Table of Contents
Related Manuals for Dexter Laundry T-20SWD
Summary of Contents for Dexter Laundry T-20SWD
- Page 1 INDUSTRIAL DRYER MODEL T-20SWD ON-PREMISE B-SERIES CONTROL, ELECTRIC-HEATED OPERATOR’S MANUAL INSTALLATION & OPERATION INSTRUCTIONS The dryer must not be stored or installed where it will be exposed to water and/or weather and is suitable for use in room temperatures between 40F and 105F (5C and 45C.) Post the following “For Your Safety”...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page No. Warnings about use and operation Dryer Specifications Dryer Dimensions (Figure 1) Uncrating Dryer Exhaust Dryer Shutdown Dryer Controller Interface (Figure 2) Dryer Controller Factory Default Program Setting Dryer Fault Codes Touch Pad Description Operating Instructions Temporary Dryer Controller Programming Permanent Dryer Controller Programming Servicing and Troubleshooting... - Page 3 SPECIFICATIONS 20 lb. Commercial Dryer: T-20 SWD DNS020E_-(84/85)_B_ Cabinet Height 34 3/4” 883 mm. (Assumes minimum leveling leg adjustment) Cabinet Width 27” 686 mm. Overall Depth 44 5/8” 1133 mm. Floor to Bottom of Door 8 1/2” 215 mm. Door Opening 18 1/8”...
-
Page 4: Dryer Dimensions (Figure 1)
DRYER DIMENSIONS- FIGURE 1A 8514-288-001 REV A PAGE 4... - Page 5 DRYER DIMENSIONS- FIGURE 1B 8514-288-001 REV A PAGE 5...
- Page 6 DRYER DIMENSIONS- FIGURE 1C 8514-288-001 REV A PAGE 6...
- Page 7 INSTALLATION AND OPERATING INSTRUCTIONS This dryer may have been supplied as part of a washer/dryer stacked appliance. If so, refer to the washer instructions for uncrating and hard mounting the stacked unit to a concrete floor and observe the dryer clearances listed below. STACK WASHER / DRYER INSTALLATION (when necessary): 1.
- Page 8 3. MAKE-UP AIR. Adequate make-up air must be supplied to replace air exhausted by dryers on all types of installations. Refer to specifications for the minimum amount of make-up air opening to outside for each dryer. This is a net requirement of effective area. Screens, grills or louvers, which will restrict the flow of air, must be considered.
- Page 9 HEATING SUPPLY VOLTAGE MINIMUM DUAL ELEMENT MINIMUM WIRE SIZE FROM FUSED ELEMENT SIZE TIME DELAY FUSE SIZE AT DISCONNECT TO DRYER TERMINAL PHASE / V. (kW) FUSED DISCONNECT (A.) BLOCK (75 C COPPER WIRE) 3 / 208 3 / 240 For 240V power supplies, an earthed mid-point of a phase is required.
-
Page 10: Dryer Shutdown
elbows with screws or other fastening means that will extend in to the pipe or elbows and catch lint. The addition of an exhaust pipe tends to reduce the amount of air the blower can exhaust. This does not affect the dryer operation if held within practical limits. - Page 11 8514-288-001 REV A PAGE 11...
-
Page 12: Dryer Controller Factory Default Program Setting
DRYER CONTROLLER FACTORY DEFAULT PROGRAM SETTINGS COOL DOWN TOTAL CYCLE DRYING TIME TIME TEMPERATURE DRYER LOAD CYCLE (MINUTES) (MINUTES) Towels, pads, heavy cotton Sheets, blended materials Cotton Synthetic materials Blended materials DRYER FAULT CODES FAULT FAULT# ACTION DESCRIPTION Shorted Dryer stops and “F1” flashes on the 4-digit display. When thermostat short circuit on sensor input is removed, “LOAd”... -
Page 13: Touch Pad Description
TOUCH PAD DESCRIPTION INDICATOR LIGHTS (LEDs) Description Cycle (1 through 5) These LEDs are on solid when a particular cycle is chosen for operation or programming. Heating Elements This LED is part of the 4-digit numeric display and will be on solid during the drying part of a cycle when the heating elements do not need to be on. - Page 14 4-DIGIT NUMERICAL DISPLAY MESSAGES Message Description LOAd This message is displayed after a dry cycle is complete and the dryer loading door has been opened or the STOP touch pad switch on the dryer controller has been pressed and released twice. donE This message blinks immediately after completion of the dry cycle and continues to blink until the stop key on the dryer controller touch pad is...
-
Page 15: Operating Instructions
OPERATING INSTRUCTIONS To dry a load of items, you must choose one of the five-programmed dry cycles. Each of these five dry cycles may be modified in two different ways to match your load. Please refer to the “Permanent Dryer Controller Programming” or “Temporary Dryer Controller Programming”... -
Page 16: Temporary Dryer Controller Programming
During the wrinkle free cycle, the heating elements will not be operated and there will be no heat applied to the load. The word “donE” will also continue to flash and do so even after the wrinkle free cycle is finished. When the dryer loading door is opened, or the STOP touch pad switch is pressed, the word “donE”... - Page 17 If you press and release the STOP touch pad switch on the dryer controller, when the 4- digit numeric display is not flashing, the temporary changes to the dry cycle program will be cancelled. The stored dry cycle settings that existed before the temporary change will then be restored.
- Page 18 7) Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once the SELECT/ENTER touch pad switch is pressed and released, the temperature LED will switch off, the dry cycle LED and programming LED will remain on, the cool down LED will illuminate, and the cool down time will be shown on the 4-digit numeric display.
-
Page 19: Permanent Dryer Controller Programming
time, the number “36” will be flashing on the dryer controller display. Each number after that will also flash. 4) Now, press and release the SELECT/ENTER touch pad switch on the dryer controller. The number “45” will stop flashing and the dry time LED will turn off. The dryer controller display will now show “180”, the temperature LED will illuminate, and the programming LED and dry cycle 1 LED will remain on. - Page 20 2) Press and release the PROG touch pad switch on the dryer controller. 3) Press and release the UP touch pad switch on the dryer controller. The programming LED will illuminate and the 4-digit numeric display on the dryer controller will change to “Prog”. 4) Press and release the UP or DOWN touch pad switch on the dryer controller to choose the dry cycle you want to change (dry cycle 1 through 5).
- Page 21 11) Press and release the SELECT/ENTER touch pad switch on the dryer controller. Once the SELECT/ENTER touch pad switch is pressed and released, the cool down LED will turn off, the dry cycle LED and programming LED will remain on, and the 4-digit numeric display will change to “Prog”.
- Page 22 7) Press and release the UP touch pad switch on the dryer controller three times until the dryer controller display shows the number “195”. 8) Press and release the SELECT/ENTER touch pad switch on the dryer controller. The dry time LED and the programming LED will remain on, the temperature LED will turn off, the cool down LED will illuminate, and the dryer controller display will show the number “5”.
-
Page 23: Preventative Maintenance Instructions
9040-073-013 LINT SCREEN FILTER 9555-057-011 For service and parts information, contact your local Dexter agent. If a Dexter agent is not available, contact Dexter Laundry, Inc. directly as listed below: Mailing Address: 2211 West Grimes Avenue Phone: 1-800-524-2954 Fairfield, IA 52556 USA Website: www.dexter.com...
