- Page 1 Buffalo Pro U7 Projector V.22.7.13...
-
Page 2: Table Of Contents
Support@yabertech.com aftersales@yabertech.com aftersales@yabertech.com CONTENTS ..................YABER Lifetime Professional Support ................................. TIPS ............................. PACKAGE LIST ....................PROJECTOR SPECIFICATIONS ........................ PROJECTOR OVERVIEW .......................... REMOTE CONTROL ........................... INSTALLATION ........................1.Installation Method ...................... 2.Projection Distance and Size ........................3.Install on the Ceiling ......................STARTING PROJECTOR ........................ -
Page 3: Yaber Lifetime Professional Support
Support@yabertech.com aftersales@yabertech.com YABER Lifetime Professional Support Dear customer, Thank you very much for supporting YABER! Please read this manual thoroughly before using the projector. If you have any issues, email your order number and the problem to aftersales@yabertech.com . We will provide a fast solution in 24 hours. -
Page 4: Package List
Buffalo Pro U7 Projector*1 Remote Control*1 Power Cord*1 HDMI Cable*1 3-in-1 AV Cable Lens Cover*1 Cleaning Kit*1 Quick Start Guide*1 Carry Bag*1 PROJECTOR SPECIFICATIONS Model No. Buffalo Pro U7 Native Keystone Manual Vertical & 1920*1080P Resolution Correction Horizontal Display Light Source... -
Page 5: Projector Overview
Support@yabertech.com aftersales@yabertech.com PROJECTOR OVERVIEW 9 10... - Page 6 Support@yabertech.com aftersales@yabertech.com 1/18 Height Adjustment Screw Adjust the height of the projector IR Window Infrared signal receiver Projector lens Optical coated glass lens Power Cord Port Power Cord Port Headphone Jack 3.5mm Headphone Output 7/10 HDMI Ports HDMI 1 input / HDMI 2 input USB Ports USB 1 port / USB 2 port AV Port...
-
Page 7: Remote Control
Support@yabertech.com aftersales@yabertech.com REMOTE CONTOL 1. Power 2. Source 3. Arrow keys 4. Menu 5. Homepape 6. Volume + 7. Volume - 8. Mute 9. Picture flip 10. Confirmation key (Play and Pause) 11. Back 12. Previous 13. Next Turn on/off the power Select the input signal source Used to adjust the parameter of the projector in the menu mode... -
Page 8: Installation
Support@yabertech.com aftersales@yabertech.com Note: 1).Install 2 pieces of AAA batteries into the remote controller before using it. Do not combine new batteries with old ones in remote controller, which can cause operation failure due to insufficient power supply. 2).When using the remote controller, please make sure that the signal transmitter of the remote controller aims at infrared signal receiver of the projector. -
Page 9: Projection Distance And Size
Support@yabertech.com aftersales@yabertech.com Aspect Ratio: 16:9 Distance (ft.) Screen Size 35" 50" 70" 10.8 100" 120" 13.1 150" 16.3 200" 22.3 The recommended projection distance is about 10.8ft,the shortest projection distance is 4.0ft. The image size depends on the distance between projector and screen, there may be 3% deviation among above listed data. -
Page 10: Starting Projector
Support@yabertech.com aftersales@yabertech.com STARTING PROJECTOR 1)Press the power key on the remote controller or projector, the indicator light will turn blue; 2)Adjust the focus ring of the projector to get the best image performance; (If it is still blurry, please try to adjust the projection distance.) 3)Use the keystone function of the projector to get a rectangle projection screen;... -
Page 11: Digital 4D Keystone Correction
Support@yabertech.com aftersales@yabertech.com Rotate the focus ring or lens slowly. At the same time, check the focus point carefully. The best focus point for the lens would be where the image most clear. Note: If it is still blurry, please try to adjust the projection distance. 2.Digital 4D Keystone Correction. -
Page 12: Setting Up The Projector
[ OK ] button to play it. External Device a.Buffalo Pro U7 upgraded projector supports U disk to directly play PPT, Word, Excel files. b.If you enter from the [Movie] menu, you can only play the video, The same... - Page 13 Support@yabertech.com aftersales@yabertech.com 2.2.Play Interface Menu Function Select play mode (directory play/single cycle/directory loop) Switch to the previous video Fast Backward,rewinds the video back quickly while playing it. The rewinding speed ranges from 2X to 32X Play or pause the current video Fast Forward, pushes the video to move forward quickly while playing it.
- Page 14 Support@yabertech.com aftersales@yabertech.com Menu Content Mode Function Brightness User/Standard/Vivid/ Modify the picture Contrast Picture Mode Sport/Movie/Game/ parameters in the Saturation Energy Saving range 0-100 Sharpness Balance Modify the sound User/Standard/Vivid/ Sound Style parameters in the Bass Sports/Movie/Music/News range 0-100 Treble 2.3.Music Play Interface Menu Function Switch to the previous music.
-
Page 15: Wifi Setting
Support@yabertech.com aftersales@yabertech.com 2.4.Picture Play Interface Menu Function Switch to the previous picture. Pause the auto - play mode of a picture. Switch to the next picture. Flip picture 90°to the left. Flip picture 90°to the right. Set the picture information. -
Page 16: Ios Cast(For Ios Devices)
-- Open the WiFi function -- Select your home WiFi from the list -- Connect the Buffalo Pro U7 projector to your home WiFi. 2.Back to home page -- Select [ iOS Cast ] menu -- Press the OK button to enter the [ iOS Cast ] menu. -
Page 17: Miracast(For Android Devices)
Support@yabertech.com aftersales@yabertech.com 3.2.Miracast (for Android Devices) 1.Go to home page -- Select the [ Miracast ] menu -- Press the OK button to enter the [ Miracast ] interface. 2.Select the [ Settings ] menu on your Android device -- Select the [ Screen mirroring ] function -- Select your Miracast receiver named [ U7-AnCast-XX ] -- your Android device screen will be displayed on the projection screen after 3 seconds. -
Page 18: Bluetooth Setting
-- it will be paired and connected automatically. WIFI Note: 1.The Buffalo Pro U7 projector is compatible with the Bluetooth headsets, Bluetooth speakers and Airpods, but not the Bluetooth keyboards or Bluetooth phones.2.If you have any question, please feel free to email YABER via: aftersales@yabertech.com... -
Page 19: Keystone Advanced & 4-Point Keystone
Support@yabertech.com aftersales@yabertech.com 1.Front projection Ceiling mount 2.Rear projection Ceiling mount 3.Front projection Desk mount 4.Rear projection Desk mount 5.2.Keystone Advanced & 4-Point Keystone 5.2.1.Vertical Keystone Correction Step 1: Select the [ Front ] option in the [ Keystone Advanced ] menu, then press the button to enter the [ Manual Keystone ] menu. - Page 20 Support@yabertech.com aftersales@yabertech.com Step 3: If the projection image shows as (3), then press the button on the remote controller or projector, and decrease the vertical parameter (0~50), until to achieve the projection image (4). 5.2.2.Horizontal & Vertical Keystone Correction When the projection screen is not rectangular, it can be adjusted by 4-point keystone correction.
-
Page 21: Digital Zoom
Support@yabertech.com aftersales@yabertech.com :Keep pressing the OK button on the remote controller or Pick point projector, until the positioning icon appears at the point desired, then release the button immediately. Adjustment :Press the arrow keys on the remote controller or projector to adjust the horizontal or vertical parameters. -
Page 22: Other Setting
Support@yabertech.com aftersales@yabertech.com Function Menu Online Update Online update Local update Local Update Restore user operation application configuration Restore Factory and system setting 7.Other Setting Function Menu Boot Source Option Off/HDMI1/HDMI2/AV Power On Option Direct/Standby Set up the language Language Setting Scheduled Off/10min/20min/30min/60min/120min Shutdown... -
Page 23: About
MAC Address SIGNAL LINES CONNECTION Buffalo Pro U7 projector has 6 interfaces, HDMI ports*2/ USB ports*2/ 3.5mm headphone output/ AV in. Please select the correct connecting port to connect your device (PC, Phone, DVD Player, Sound bar, USB, PS4 etc.) 1.Connect USB Disk... -
Page 24: Connect To The Soundbar/Speaker
3.Cover the lens and store the projector in a cool and dry place. WARRANTY Thank you so much for your purchase and support! We provide 3-year warranty for Buffalo Pro U7 projector. If you have any questions, please feel free to contact us via aftersales@yabertech.com. -
Page 25: Troubleshooting
Support@yabertech.com aftersales@yabertech.com TROUBLESHOOTING Problems listed below might occur during the operation of your projector. Please refer to the possible factors which might cause the issue to do troubleshooting. 1. When turning on the power switch, the indicator light does not work. 1) The power might not be connected well. - Page 26 FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 27 Should this unit be operated under conditions other than those recommend- ed or at voltages other than the voltage indicated on the unit, or any attempts made to service or modify the unit, this will render WARRANTY VOID. The product you buy may sometimes differ slightly from illustration. DISPOSAL: This marking indicates that this product should not be disposed with other household wastes throughout the EU.
- Page 28 Trade name: Yaber Equipment: Entertainment Projector Model No. : Buffalo Pro U7 to which this declaration relates is in conformity with the essential requirement set out in the Council Directive on the Approximation of the laws of the Member States relating to LVD Directive(2014/35/EU) &...
- Page 29 @Yaber Entertainment Projector @Yaber Entertainment Projector...
