MOLEAER KINGFISHER Quick Start Manual

NANOBUBBLE GENERATOR
Quick Start Guide
Notes
For safety, follow all local electrical codes. Kingfisher comes
standard with ozone generation, though it can be bypassed.
See the Owner's Manual for instructions. EPA Establishment Number 94231-CA-1
1
Unpacking
1.1
1.2
2
Installation
Unit Position & Location:
Install the unit on a
2.1
level surface. Pavers
can be used to provide
a level surface.
Position unit within three
2.2
feet of a standard three-
prong 120-volt outlet
(15-amps). Extension
cords should not be used.
Position the unit on the
2.3
shore as close to the
body of water as possible.
Scan to Download the Owner's Manual
and access warranty information for the
Kigfisher Nanobubble Generator.
Ensure all accessories were
provided with your Kingfisher. Contact
Moleaer for replacement parts. Inspect
outer surfaces for shipping damage.
Open the lid and remove packaging and
accessories from the inside.
Inspect components inside of the
unit for any loose tubing or damaged
components and tighten any loose
fittings or tubing.
A Cleaning Kit (Syringe, Tube, Connector),
B
1.3
E Basket Strainer O-Ring,
A
G
3
Attach Piping
Using PVC glue (not included), attach hard or flexible PVC piping
3.1
to the two included connectors, taking note of the orientation of the
intake and discharge and the location of the tank. Connection size is
1.5" and hard PVC piping should be 1.5" for inlet and discharge.
Note 1: The intake and discharge piping should
be as short as possible. Do not exceed 20 feet for
either the intake or discharge pipes.
Note 2: The unit should not be placed more than
six feet above the nominal water level.
Refer to owner's manual piping placement
and pump restrictions.
Included glue-able connections should be hand
3.2
tightened only, do not use tools to tighten onto
the pump or discharge. Ensure all connections
are tight before beginning startup steps.
Pump Union, C Pipe Union,
D Pump Union O-Rings,
F Suction Strainer,
G Set of Cabinet Keys
B
C
F
D
www.moleaer.com
+1.424.558.3567
E
