Specifications And Options - Icom IC-R2 Instruction Manual

13

SPECIFICATIONS AND OPTIONS

D General
• Frequency coverage
U.S.A. version
Non-U.S.A. versions
• Mode
• No. of memory channels
• Usable temp. range
• Tuning steps
* Fixed tuning step while 0.495–1.620 MHz is selected except
for U.S.A. and Canada versions.
• Frequency stability
• Power supply requirement : 2 AA(R6) Ni-Cd or
(negative ground)
• Current drain
(at 3.0 V DC)
Rated audio
Standby
Power saved
• Antenna connector
• Dimensions
(projections not included)
• Weight
(w/antenna and battery)
34
: (unit: MHz)
0.495–823.995, 849–868.995,
894–1309.995
0.495–1309.995
: FM, AM, WFM
: 450
(400 regular, 50 scan edges)
: –10°C to +60°C;
+14°F to +140°F
: 5, 6.25, 9,* 10, 12.5, 15, 20,
25, 30, 50 and 100 kHz
: ±6 ppm (–10°C to +60°C)
alkaline cells
:
170 mA typ.
100 mA typ.
41 mA typ.
: SMA (50 Ω)
: 58(W) 86(H) 27(D) mm;
9 3 1
2 ⁄ (W) 3 ⁄ (H) 1 ⁄ (D) in
32 8 16
: 170 g; 6 oz
D Receiver
• Receive system
• Intermediate frequencies
• Sensitivity
(except spurious points; typical)
FM
(at 12 dB SINAD)
WFM
(at 12 dB SINAD)
AM
(at 10 dB S/N)
: Triple-conversion
superheterodyne
: 1st 266.7 MHz
2nd 19.65 MHz
3rd 450 kHz
:
1.625–5.000 MHz 0.4 µV
5.005–29.995 MHz 0.25 µV
30–117.995 MHz 0.2 µV
118–174.995 MHz 0.18 µV
175–329.995 MHz 0.22 µV
330–429.995 MHz 0.25 µV
430–450 MHz 0.22 µV
450.005–469.995 MHz 0.25 µV
470–999.995 MHz 0.28 µV
1000–1309.995 MHz 0.45 µV
76–108.0 MHz 0.71 µV
175–221.995 MHz 0.71 µV
470–770.0 MHz 1.0 µV
0.495–5.0 MHz 1.3 µV
5.005–30.0 MHz 0.79 µV
118–136.0 MHz 0.63 µV
222–246.995 MHz 0.63 µV
247–329.995 MHz 0.71 µV
