Dark Wood / Black 44" x 24" Electric Desk
Instruction Manual
SKU: DESK-E144D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-e144d
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo DESK-E144D
Summary of Contents for Vivo DESK-E144D
- Page 1 Dark Wood / Black 44" x 24" Electric Desk Instruction Manual SKU: DESK-E144D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-e144d GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Electrical Safety Instructions
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble the crossbar (6) to the legs (8, 9) using M8x47 bolts (A) and tighten with the 5mm Allen wrench (E). S=5mm M8×47 (x4) - Page 4 STEP 2 Place the feet (4) on the legs as shown, then insert and tighten M6x35 bolts (C) using the 4mm Allen wrench (E). Screw the foot pads (G) into the feet. M6×35 (x8) S=4mm STEP 3 Assemble the side brackets (5) to the legs using M6x10 bolts (B) and tighten with the 4mm Allen wrench (E).
- Page 5 STEP 4 Insert the sync rod (7) into the leg (9). Loosen the knob on the sync rod, then extend the rod onto the motor leg (8) and tighten the knob. Tighten the set screw on the end of the sync rod using the 2mm Allen wrench (E).
- Page 6 STEP 6 Hang the cable tray (3) over the crossbar (6), opposite from the sync rod (7), then carefully place the assembled frame upside down on the desktop (11). Secure the frame to the desktop using M5x16 screws (D) and a Phillips screwdriver. 5x16(x10) STEP 7 Mount the control panel (1) to the desktop (11) using M5x16 screws (D) with a Phillips screwdriver.
- Page 7 STEP 8 Carefully turn the desk right side up and connect the AC adapter (2) to a wall outlet. If necessary, adjust foot pads (G) to level the desk. The desk is now ready for use. Please refer to the Controller User Guide for operating instructions.
