- Page 1 Manufacturing Instructions for YewdaleDefiant cassetted blinds ® (C57-90/120T) yewdale.co.uk Part no: 1062...
- Page 2 Manufacturing Instructions YewdaleDefiant cassetted blinds (C57-90/120T) ® C57-90T Cassetted Blinds - Deduction Chart: Recess to blind size - 1.5mm on the width and 1.5mm on the drop Description Chart Part No. Deduction Headbox Cut 940090 Blind width –6mm Headbox cover/fascia cut 940091 Blind width –6.5mm...
- Page 3 C57-90/120T Fabric diagram: Folded pocket with 70163 insert Call: +44 (0)1268 570900 Fax: +44 (0)1268 732509 Email: enquiries@yewdale.co.uk Visit: www.yewdale.co.uk...
- Page 4 Manufacturing Instructions YewdaleDefiant cassetted blinds (C57-90/120T) ® C57-90T Cassetted Blinds: 940094 End plates (set) 918252 65mm Barrel Sleeve 940010 Transition plate (set) 918246 End plug 940090 918240 Headbox fascia 53mm Barrel 918240 53mm Barrel 933010 Screws for End Caps Barrel Sleeve...
- Page 5 C57-90/120T Cassetted Blinds: Ensuring the head box/fascia profile is square within the saw, cut the head box to size. Ensuring the head box cover is square within the saw, cut the cover to size making sure there is no distortion. N.B It is critical that the profile is cut square to enable the cover to close.
- Page 6 Manufacturing Instructions YewdaleDefiant cassetted blinds (C57-90/120T) ® Make a small incision in the welded pocket in order to slide in the fabric insert. Attach the bottom bar to the fabric using the fabric insert. Once complete insert the end caps.
- Page 7 Call: +44 (0)1268 570900 Fax: +44 (0)1268 732509 Email: enquiries@yewdale.co.uk Visit: www.yewdale.co.uk...
- Page 8 Yewdale, Enterprise Way, Wickford, Essex SS11 8DH Call +44 (0)1268 570900 +44 (0)1268 732509 Email enquires@yewdale.co.uk Visit yewdale.co.uk For more information on all Yewdale products, please call the sales department. ® ® ® ® ® A comprehensive range The only fail-safe range of The industry’s preferred A dedicated range of privacy A concise approach to...
