- Page 1 Manufacturing Instructions for YewdaleDefiant cassetted blinds ® (C47-90) yewdale.co.uk Part no: 2009...
- Page 2 Manufacturing Instructions YewdaleDefiant cassetted blinds (C47-90) ® C47-90 Cassetted Blinds - Deduction Chart: Recess to blind size - 3mm on the width and 2mm on the drop Description Chart Part No. Deduction Headbox Cut 940090 Blind width –6mm Headbox cover/fascia cut 940091 Blind width –6.5mm...
- Page 3 Call: +44 (0)1268 570900 Fax: +44 (0)1268 732509 Email: enquiries@yewdale.co.uk Visit: www.yewdale.co.uk...
- Page 4 Manufacturing Instructions YewdaleDefiant cassetted blinds (C47-90) ® C47-90 Cassetted Blinds: 940092 End plates (set) 940010 Transition plate (set) 918246 End plug 940090 Headbox fascia 918240 53mm Barrel 980000 940002 230v AC motor Safety Cover Screw 980001 230v AC motor with built-in receiver...
- Page 5 C47-90 Cassetted Blinds: Ensuring the head box/fascia profile is square within the saw, cut the head box to size. Ensuring the head box cover is square within the saw, cut the cover to size making sure there is no distortion.
- Page 6 Manufacturing Instructions YewdaleDefiant cassetted blinds (C47-90) ® Insert the motor into the barrel making sure the grooves are aligned with the adaptors and then insert the pin end (918246) into the barrel. Threading the cable through the 12mm hole, place barrel and fabric into the head box by locating the pin end first into the transition plate.
- Page 7 Call: +44 (0)1268 570900 Fax: +44 (0)1268 732509 Email: enquiries@yewdale.co.uk Visit: www.yewdale.co.uk...
- Page 8 Yewdale, Enterprise Way, Wickford, Essex SS11 8DH Call +44 (0)1268 570900 +44 (0)1268 732509 Email enquires@yewdale.co.uk Visit yewdale.co.uk For more information on all Yewdale products, please call the sales department. ® ® ® ® ® A comprehensive range The only fail-safe range of The industry’s preferred A dedicated range of privacy A concise approach to...
