- Page 1 Fitting Instructions YewdaleDefiant roller blinds ® (R20, Fascia, R20C, R20D, R20S, R20W) Fitting Instructions YewdaleDefiant roller blinds ® (R20, Fascia, R20C, R20D, R20S, R20W) Part no: 936 yewdale.co.uk...
-
Page 2: Safety Instructions
Cords may become wrapped around a child’s neck Move beds, cots and furniture away from window covering cords Do not tie cords together. Make sure cords do not twist and create a loop R20 Sidewinder control N.B. For more information and child safety device fitting instructions, see Point 7 on Page 5 &... - Page 3 R20 Sidewinder control: N.B. This blind should be installed by a person competent in DIY. If in doubt please consult a professional. The standard universal metal brackets supplied with the blind may be top, face or side-fixed. Check that the blind fits correctly. The pin-end is sprung for easy fitting, but the pin should be depressed once in place.
- Page 4 Fitting Instructions YewdaleDefiant roller blinds (R20, Fascia, R20C, R20D, R20S, R20W) ® Ensure the relevant child safety device is used to comply with BS EN13120:2009+A1:2014, BS EN16433:2014 and BS EN16434:2014 as follows: *You will have been provided with either a chain tidy or easy break chain connector (also see page 8 &...
- Page 5 Easy Break Chain Connectors Two easy break chain connectors are connected to the operating chain 200mm apart. This ensures that at least one of them will be in the vertical position ensuring they perform as required. If excessive weight is applied within the loop a connector will come apart.
- Page 6 Fitting Instructions YewdaleDefiant roller blinds (R20, Fascia, R20C, R20D, R20S, R20W) ® R20 Sidewinder control: 926325W Back bar top fix bracket 938031W Aluminium back bar 926325W Back bar top fix bracket OPTIONAL 933010W Back bar screw 933019W 933016W Bracket cover 32mm...
- Page 7 R20 with Fascia: N.B. This blind should be installed by a person competent in DIY. If in doubt please consult a professional. If the blind is top fix, fix through the fascia profile using the indent to position the screws. If face fix, use the brackets supplied to fix the brackets securely to the wall.
- Page 8 Fitting Instructions YewdaleDefiant roller blinds (R20, Fascia, R20C, R20D, R20S, R20W) ® R20C Crank Control: N.B. This blind should be installed by a person competent in DIY. If in doubt please consult a professional. The standard universal metal brackets supplied with the blind may be top, face or side-fixed.
- Page 9 R20C Crank Control: 926325W Back bar top fix bracket 938031W Aluminium back bar 926325W Back bar top fix bracket OPTIONAL 933039W Bracket cover 45mm 933010W 933401 Back bar screw Crank support set 933036W Control bracket 938027 45mm (back bar) 45mm Barrel 911769 End Plug with Square Pin 70401...
- Page 10 Fitting Instructions YewdaleDefiant roller blinds (R20, Fascia, R20C, R20D, R20S, R20W) ® R20D Double roller: N.B. This blind should be installed by a person competent in DIY. If in doubt please consult a professional. The standard universal metal brackets supplied with the blind may be top or face-fixed.
- Page 11 R20D Double roller: 933022W Double bracket cover 40mm 940025W 40mm control mechanism set 933023W 40mm Double bracket set 938024 Barrel 40mm 938170W Bottom bar end cap 913680S Metal chain 938280 P-clip 938120W Bottom bar plastic OPTIONAL OPTIONAL 938311W/B/S 938311W/B/S Tear drop bottom bar Tear drop bottom bar 938312W/B/S Endcap 938312W/B/S...
- Page 12 N.B. This blind should be installed by a person competent in DIY. If in doubt please consult a professional. Fit as per the R20 Sidewinder instructions but please see parts diagram to right (back bar is optional). Spring must be on the right-hand side unless fabric is reverse rolled.
- Page 13 R20S Spring Control: 926325W Back bar top fix bracket 938031W Aluminium back bar 926325W Back bar top fix bracket OPTIONAL 933010W Back bar screw 941001W Braked Spring Bracket Set (Standard) 941002W Braced Spring Bracket Set (Back Bar) 941010 Spring limit stop 938021 Barrel 32mm 941006...
- Page 14 Fitting Instructions YewdaleDefiant roller blinds (R20, Fascia, R20C, R20D, R20S, R20W) ® R20W Light Duty Crank Control: N.B. This blind should be installed by a person competent in DIY. If in doubt please consult a professional. The standard universal metal brackets supplied with the blind may be top, face or side-fixed.
- Page 15 R20W Light Duty Crank Control: 926325W Back bar top fix bracket 938031W Aluminium back bar 926325W Back bar top fix bracket OPTIONAL 933010W Back bar screw 942004 933026W Crank and Control bracket bracket set 40mm (back bar) 942004 Crank and bracket set 938024 40mm Barrel 942003...
- Page 16 Yewdale, Enterprise Way, Wickford, Essex SS11 8DH Call +44 (0)1268 570900 +44 (0)1268 732509 Email enquires@yewdale.co.uk Visit yewdale.co.uk For more information on all Yewdale products, please call the sales department.
