RKP1615 / RKP1617 / RKP1619
1.
2.
3.
4.
5.
6.
7.
8.
Rev. : 1.0

Structure Diagram

8.
PS/2 keyboard
Aluminium front panel
Class A active matrix TFT LCD panel
Rear metal case
Analog to digital signal converter board
LCD inverter
LCD membrane
Adjustable mounting bracket
‚ ƒ „
•
... †
‡
P.6
User Manual
ˆ
