Cisco ICS 7750 System Description
Release 2.3.0
Corporate Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel:
408 526-4000
800 553-NETS (6387)
Fax:
408 526-4100
Customer Order Number: DOC-7810360=
Text Part Number: 78-10360-02

Advertisement

Table of Contents
loading

Related Manuals for Cisco ICS-7750

Summary of Contents for Cisco ICS-7750

  • Page 1 Cisco ICS 7750 System Description Release 2.3.0 Corporate Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 526-4100 Customer Order Number: DOC-7810360= Text Part Number: 78-10360-02...
  • Page 2 Net Readiness Scorecard, Networking Academy, and ScriptShare are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn, The Fastest Way to Increase Your Internet Quotient, and iQuick Study are service marks of Cisco Systems, Inc.; and Aironet, ASIST, BPX,...

  • Page 3: Table Of Contents

    Preface Audience Organization Related Documentation Cisco ICS 7750 Documentation Backup Power Supply Documentation VIC, WIC, and VWIC Documentation Catalyst 3500 Series XL Documentation Cisco IP Phone Documentation Obtaining Documentation World Wide Web Documentation CD-ROM Ordering Documentation Documentation Feedback Obtaining Technical Assistance Cisco.com Technical Assistance Center Overview...
  • Page 4 Making Converged Networks a Reality Processor Cards Feature Summary C H A P T E R System Processing Engine Card System Switch Processor Card System Alarm Processor Card Multiservice Route Processor Card Analog Station Interface Cards Voice and WAN Interface Cards...
  • Page 5 Summary of Power and Cooling System Features C H A P T E R Cisco ICS 7750 Chassis, Backplane, and Fan Tray Power Supply Module Power Protection Component Summary of System Software Features C H A P T E R ICSConfig Program Cisco ICS System Manager 78-10360-02...
  • Page 6 Contents Fault Management Module Cisco IOS Cisco CallManager Summary of Software Applications Features C H A P T E R Internal Software Applications External Software Applications Cisco ICS 7750 System Description 4-13 Key Features 4-15 System Capabilities 4-17 Specifications 4-18 Cisco CallManger Extended Services Cisco CallManager Extension Mobility Cisco CallManager Auto Attendant...
  • Page 7 Features of Cisco IP Phones C H A P T E R Cisco IP Phone 7960 and Cisco IP Phone 7940 Cisco IP Phone 7910 and 7910+SW Cisco IP Phone Expansion Module 7914 Cisco IP Conference Station 7935 Cisco IP SoftPhone Cisco CallManager Attendant Console 78-10360-02 CiscoWorks2000...
  • Page 8 Contents Features of LAN-Based Switching Technologies C H A P T E R Catalyst 3524-PWR XL Switch Catalyst 4000 Switches Catalyst 6000 Switches Features of Other Compatible Cisco Devices C H A P T E R Cisco 1750 Modular Access Router...

  • Page 9: Preface

    Preface The Cisco Integrated Communications System (ICS) 7750 (referred to from this point on as the Cisco ICS 7750 or the system) is an integrated communications platform designed to enable easy, rapid deployment and management of key data and converged voice/data applications and services, including IP telephony, content delivery networking, and multiservice routing.

  • Page 10: Organization

    Cisco IP Phones and the Cisco IP SoftPhone and WebAttendant applications. Chapter 7, “Features of LAN-Based Switching Technologies,” • features of the Catalyst 3524-PWR XL switch, the Catalyst 4000 switch, and the Catalyst 6000 switch. • “Chapter 8, “Features of Other Compatible Cisco Devices,”...

  • Page 11: Related Documentation

    Cisco Interface Cards Installation Catalyst 3500 Series XL Documentation For information about the Catalyst 3500 series XL switches, including the Catalyst 3524-PWR XL switch, refer to the following publications: • Quick Start Guide: Catalyst 3500 Series XL Switches Catalyst 3500 Series XL Hardware Installation Guide •...

  • Page 12: Cisco Ip Phone Documentation

    Cisco IP Phone Administration Guide for Cisco CallManager • Obtaining Documentation The following sections explain how to obtain documentation from Cisco Systems. World Wide Web You can access the most current Cisco documentation on the World Wide Web at the following URL: http://www.cisco.com...

  • Page 13: Ordering Documentation

    You can e-mail your comments to bug-doc@cisco.com. To submit your comments by mail, use the response card behind the front cover of your document, or write to the following address: Cisco Systems Attn: Document Resource Connection 170 West Tasman Drive San Jose, CA 95134-9883 We appreciate your comments.

  • Page 14: Obtaining Technical Assistance

    Obtaining Technical Assistance Obtaining Technical Assistance Cisco provides Cisco.com as a starting point for all technical assistance. Customers and partners can obtain documentation, troubleshooting tips, and sample configurations from online tools by using the Cisco Technical Assistance Center (TAC) Web Site. Cisco.com registered users have complete access to the technical support resources on the Cisco TAC Web Site.

  • Page 15: Cisco Tac Web Site

    Preface Inquiries to Cisco TAC are categorized according to the urgency of the issue: Priority level 4 (P4)—You need information or assistance concerning Cisco • product capabilities, product installation, or basic product configuration. Priority level 3 (P3)—Your network performance is degraded. Network •...

  • Page 16: Cisco Tac Escalation Center

    Preface Obtaining Technical Assistance Cisco TAC Escalation Center The Cisco TAC Escalation Center addresses issues that are classified as priority level 1 or priority level 2; these classifications are assigned when severe network degradation significantly impacts business operations. When you contact the TAC Escalation Center with a P1 or P2 problem, a Cisco TAC engineer will automatically open a case.

  • Page 17: Overview

    The Cisco ICS 7750 also supports the Cisco IP Phone 7900 series, a new generation of display-based intelligent communication devices that can be powered from Catalyst 3524-PWR XL switches, an integrated Catalyst switch card, or the Catalyst inline power patch panel.
  • Page 18 Introduction Figure 1-1 Cisco ICS 7750 and Catalyst 3524-PWR XL Switches SLOT 1 SLOT 2 SLOT 3 IN USE IN USE IN USE IN USE Cisco ICS 7750 System Description 11 12 13 14 15 16 17 18 19 20 21 22 23 24 11 12...

  • Page 19: Processor Cards

    (MRP) • Analog station interface (ASI) Single-board System processing computer/ engine (SPE) application server Ethernet switch System switch processor (SSP) Hardware System alarm monitor processor (SAP) For additional information about processor cards, see Note Cards Feature Summary.” 78-10360-02 lists the processor cards that are available for use in the Cisco ICS 7750...

  • Page 20: Making Converged Networks A Reality

    Making Converged Networks a Reality Making Converged Networks a Reality The Cisco ICS 7750 is a new offering in the Cisco Architecture for Integrated Voice, Video, and Data (AVVID) product line. By combining the elements needed to build a complete IP telephony system, including data and voice networking, the Cisco ICS 7750 provides a truly “converged”...
  • Page 21 Chapter 1 Overview Figure 1-2 Separate Voice and Data Networks Network servers IP network Printers Figure 1-3 Voice and Data Networks Integrated with the Cisco ICS 7750 IP network Printers Circuit-switched 78-10360-02 Telephone network POTS-phone or fax Phone or Centrex PSTN Cisco ICS 7750 POTS-phone or fax...

  • Page 22: Advantages Of Converged Networks

    Making Converged Networks a Reality Advantages of Converged Networks Because converged networks use a single, packet-based infrastructure for all data, voice, and video communications, implementing such networks reduces costs. The following are additional advantages of converged networks: Budget leverage. You can reduce your telecom budget and devote the money •...

  • Page 23: Processor Cards Feature Summary

    Processor Cards Feature Summary Processor cards supported by the Cisco ICS 7750 include the following: System Processing Engine Card, page 2-2 • System Switch Processor Card, page 2-7 • System Alarm Processor Card, page 2-12 • Multiservice Route Processor Card, page 2-16 •...

  • Page 24: System Processing Engine Card

    System Processing Engine Card Figure 2-1 Cisco ICS 7750 System Cards SLOT 1 SLOT 2 SLOT 3 SLOT 4 IN USE IN USE IN USE IN USE System Processing Engine Card The system processing engine (SPE) card for the Cisco ICS 7750 is a single-board, Windows 2000–based computer that runs Cisco CallManager, Cisco ICS 7700 System Manager, embedded fault-management services, and other system software applications.

  • Page 25: Chapter 2 Processor Card Feature Summary

    Chapter 2 Processor Cards Feature Summary System Processing Engine Card System redundancy is highly recommended. You can easily build in redundancy by adding SPEs for additional call-processing capabilities. For recovery, you should regularly perform a backup of all applications installed on the SPE, using the backup mechanisms that are recommended in the documentation for each application.
  • Page 26 Chapter 2 Processor Cards Feature Summary System Processing Engine Card Figure 2-2 SPE310 Card Status LED Alarm LED Port for keyboard and mouse Hot-swap button USB 0 port USB 1 port Monitor port Cisco ICS 7750 System Description 78-10360-02...

  • Page 27: Feature Summary

    Chapter 2 Processor Cards Feature Summary Feature Summary Key features and benefits of the SPE310 include the following: This card has a 700-MHz Pentium III processor, a 32-KB Level 1 cache, and • a 256-KB Level 2 cache. This card has 512 MB of onboard memory (on the motherboard) and two •...

  • Page 28: Technical Specifications

    System Processing Engine Card Technical Specifications Table 2-1 Table 2-1 Technical Specifications for the SPE Card Type Description Processor Intel Pentium III 700 MHz CPU Memory 1.5-GB SDRAM maximum Storage 20.4-GB or 40-GB hard disk drive Operating system Microsoft Windows 2000 Server Database software Microsoft SQL Server 7.0 Dimensions and weight...

  • Page 29: System Switch Processor Card

    VCCI V-3/97.04, Class B System Switch Processor Card The system switch processor (SSP) card is an IOS-based Ethernet switch that passes data between all system cards to any Catalyst switches connected to the Cisco ICS 7750. The SSP supports eight 10/100 Mbps Ethernet connections, which are bidirectional, full-duplex, and can autosense speed and autonegotiate transmission mode.
  • Page 30 System Switch Processor Card Figure 2-3 Status LED Alarm LED Hot-swap button Port 1x activity LED Ethernet port 1x Ethernet port 2x Port 2x activity LED Two of the SSP Ethernet ports are external 10/100 Ethernet RJ-45 ports on the front panel, used for switching functionality between the Cisco ICS 7750 and any connected Catalyst 3500 Series XL or other Catalyst switches.

  • Page 31: Feature Summary

    Flash memory—The SSP stores configuration information in Flash memory and NVRAM. • Supports IEEE 802.1p class of service (CoS) with two queues on each port to prioritize voice and data traffic. • Supports quality of service (QoS). 78-10360-02 System Switch Processor Card Cisco ICS 7750 System Description...
  • Page 32 High performance—The SSP is compatible with the Catalyst 2900 Series XL • Cisco switch to provide the following features: 10.8-Gbps switching fabric. – Cisco Group Management Protocol (CGMP) enables a switch to – selectively forward routed IP multicast traffic to targeted multimedia end stations only. •...

  • Page 33: Technical Specifications

    Password-protected in-band and out-of-band management. Multilevel security on console access to prevent unauthorized users from altering the switch configuration. lists the technical specifications for the SSP card. 12.0(5.2)XU for system software release 2.1.0 12.0(5)WC2b for system software release 2.2.0 12.0(5)WC5 for system software release 2.3.0...

  • Page 34: System Alarm Processor Card

    System Alarm Processor Card Table 2-2 Technical Specifications for the SSP Card (continued) Type Description Nonoperating (storage) Temperature shock: –4 to 149ºF (–20 to 65ºC) at 41ºF (5ºC) per minute environment Temperature range: –4 to 149ºF (–20 to 65ºC) Altitude: up to 15,000 ft (4570 m) Relative humidity: 5 to 95% Safety AS/NZS 3260, TS001...
  • Page 35 Chapter 2 Processor Cards Feature Summary System Alarm Processor Card Figure 2-4 SAP Card Status Alarm Power 1 LEDs Power 2 Temperature Hot-swap button COM ports Console port C O N S O Cisco ICS 7750 System Description 2-13 78-10360-02...

  • Page 36: Feature Summary

    System Alarm Processor Card Feature Summary Key features and benefits of the SAP include the following two COM ports and one console port: • The COM 1 port is a 115-kbps port that supports a 9-pin RS-232 cable. Use this port for monitoring an uninterruptible power supply (UPS). •...
  • Page 37 Chapter 2 Processor Cards Feature Summary Table 2-3 Technical Specifications for the SAP Card (continued) Type Description Nonoperating (storage) Temperature shock: –4 to 149ºF (–20 to 65ºC) at 41ºF (5ºC) per minute environment Temperature range: –4 to 149ºF (–20 to 65ºC) Altitude: up to 15,000 ft (4570 m) Relative humidity: 5 to 95% Emissions and immunity...

  • Page 38: Multiservice Route Processor Card

    Chapter 2 Processor Cards Feature Summary Multiservice Route Processor Card Multiservice Route Processor Card The multiservice route processor (MRP) card is a voice- and data-capable router that supports both digital and analog voice trunks and WAN routing interfaces. Using the MRP you can link remote Ethernet LANs to the Public Switched Telephone Network (PSTN) and existing private branch exchanges (PBXs), as well as most common analog devices such as fax machines and teleconferencing stations.
  • Page 39 Chapter 2 Processor Cards Feature Summary Multiservice Route Processor Card Figure 2-5 MRP Card Status Alarm LEDs Slot 0 Hot-swap button Slot 1 LED Cisco ICS 7750 System Description 2-17 78-10360-02...

  • Page 40: Feature Summary

    Multiservice Route Processor Card Feature Summary Key features and benefits of the MRP include the following: Digital signal processor (DSP) support—Supports up to ten DSPs; each DSP • can handle multiple voice channels, depending on the codec complexity. Interface cards support—The MRP architecture incorporates VIC, WIC, and •...

  • Page 41: Technical Specifications

    Chapter 2 Processor Cards Feature Summary Voice compression—Up to six voice calls can occupy a single 64-KB data • channel simultaneously, without compromising data performance. Cisco IOS voice-compression technology integrates data and voice traffic to enable use of existing data networks. •...

  • Page 42: Feature Summary

    Multiservice Route Processor Card Table 2-4 Technical Specifications for the MRP200 and MRP300 Cards (continued) Type Description Expansion slots Two packet voice/data module (PVDM) expansion slots, supporting 4-, 8-, 12-, 16-, and 20-channel PVDMs Note One VPN module socket, supporting DES and 3DES encryption for full-duplex T1 serial connection (4-Mbps for 1514-byte packets) Cisco IOS requirement •...

  • Page 43: Technical Specifications

    Chapter 2 Processor Cards Feature Summary Table 2-4 Technical Specifications for the MRP200 and MRP300 Cards (continued) Type Description Operating environment Temperature range: 32 to 104ºF (0 to 40ºC) Altitude: 10,000 ft (3000 m) Relative humidity: 10 to 85% Shock: 54 in./s (1.37 m/s) Vibration: 0.35 Grms from 3 to 500 Hz Nonoperating (storage) Temperature shock: –4 to 149ºF (–20 to 65ºC) at 41ºF (5ºC) per minute...

  • Page 44: Analog Station Interface Cards

    Analog Station Interface Cards Analog Station Interface Cards Analog station interface (ASI) cards enable you to connect to analog telephones, fax machines, and teleconferencing stations. Two ASI cards are available: ASI81—Contains an 8-port Foreign Exchange Station (FXS) module and any •...
  • Page 45 Chapter 2 Processor Cards Feature Summary Analog Station Interface Cards Figure 2-6 ASI81 Card Status Alarm LEDs Slot 0 Hot-swap button Slot 1 LED Cisco ICS 7750 System Description 2-23 78-10360-02...

  • Page 46: Analog Station Interface Cards

    Chapter 2 Processor Cards Feature Summary Analog Station Interface Cards Figure 2-7 ASI160 Card Status LEDs Alarm Hot-swap button Cisco ICS 7750 System Description 2-24 78-10360-02...

  • Page 47: Feature Summary

    Chapter 2 Processor Cards Feature Summary Feature Summary Key features and benefits of the ASI81, MRP3-8FXS, ASI160, and MRP3-16FXS cards include the following: • High-density analog port support—Enables you to continue to support analog telephones as you migrate to IP Phones. •...

  • Page 48: Technical Specifications

    Analog Station Interface Cards External data security—IPSec tunneling with DES and 3DES encryption • provide standards-based data privacy, integrity, and authenticity as data travels through a public network. Remote access security—For remote access VPNs, L2F and L2TP combine • with IPSec encryption to provide a secure multiprotocol solution (for IP, IPX, and AppleTalk traffic).

  • Page 49: Feature Summary

    Chapter 2 Processor Cards Feature Summary Table 2-5 Technical Specifications for the ASI and MRP3 Cards (continued) Type Description Optional Flash SIMM 80-pin SIMM module for adding up to 64 MB of Flash memory, using a module (MRP3-8FXS single 16-, 32-, or 64-MB Flash SIMM and MRP3-16FXS only) Optional cards ASI81 and MRP3-8FXS: One modular VIC/WIC/VWIC slot...
  • Page 50 Analog Station Interface Cards Table 2-5 Technical Specifications for the ASI and MRP3 Cards (continued) Type Description Safety C-UL per CSA C22.2 1950 TUV Bauart per EN 60950 UL recognized per UL 1950 3rd edition Emissions standards BSMI CNS13438, Class B CAN/CSA-C22.2 No.

  • Page 51: Voice And Wan Interface Cards

    Chapter 2 Processor Cards Feature Summary Voice and WAN Interface Cards MRP200 and MRP300 cards have two slots while ASI81 and MRP3-8FXS cards have one slot that accept existing VICs, WICs, and VWICs that are used in Cisco 1700, 2600, and 3600 series routers. This interface card support helps you build upon existing Cisco networks while maintaining interoperability and consistent end-to-end service between locations.

  • Page 52: Vics

    Voice and WAN Interface Cards Table 2-6 WIC, VIC, and VWIC Cards for MRP , ASI81, and MRP3-8FXS Cards (continued) Module Description VWIC-2MFT-T1 Two-port T1/fractional T1 multiflex trunk with CSU/DSU VWIC-2MFT-E1 Two-port E1/fractional E1 multiflex trunk with CSU/DSU 1. DID = Direct Inward Dialing 2.

  • Page 53: Vic-2Bri-Nt/Te

    Chapter 2 Processor Cards Feature Summary Figure 2-8 2DID Technical Specifications Table 2-7 Table 2-7 Technical Specifications for VIC-2DID Card Type Interface type Signaling formats Physical connector Number of connectors/ports Cisco IOS requirement Spare VIC-2BRI-NT/TE The VIC-2BRI-NT/TE card is an ISDN BRI interface network and terminal sides card with two ports (see PBXs and key systems.

  • Page 54: Vic-2Fxs

    Voice and WAN Interface Cards Figure 2-9 2B-NT/TE Technical Specifications Table 2-8 Table 2-8 Technical Specifications for VIC-2BRI-NT/TE Card Type Interface type Interface ISDN Digital Access Physical connector Number of connectors/ports Cisco IOS requirement Compliance ITU Compliance Safety conformance Spare VIC-2FXS The VIC-2FXS card is an FXS interface card with two ports (see Figure 2-10).
  • Page 55 Chapter 2 Processor Cards Feature Summary Figure 2-10 2-Port VIC with FXS, FXO, or E&M Interfaces (Typical) Technical Specifications Table 2-9 Table 2-9 Technical Specifications for VIC-2FXS Card Type Interface type Address signaling formats Signaling formats Ringing tone Ringing voltage Ringing frequencies Physical connector Number of connectors/ports...

  • Page 56: Vic-4Fxs/Did

    Voice and WAN Interface Cards VIC-4FXS/DID The VIC-4FXS/DID card supports up to four FXS ports or DID analog trunks. Each port on the VIC-4FXS/DID can be configured to be used in FXS or DID mode. Figure 2-11 VIC-4FXS/DID Card 4FXS/DID Technical Specifications Table 2-10 Table 2-10 Technical Specifications for VIC-4FXS/DID Card...

  • Page 57: Vic-2Fxo-M1, Vic-2Fxo-M2, And Vic-Fxo-M3

    Chapter 2 Processor Cards Feature Summary Table 2-10 Technical Specifications for VIC-4FXS/DID Card (continued) Type DID homologation Spare VIC-2FXO-M1, VIC-2FXO-M2, and VIC-FXO-M3 The VIC-2FXO card is a two-port FXO interface card with battery reversal detection and caller ID support and is available for the following locations: VIC-2FXO-M1—North America •...

  • Page 58: Vic-2E/M

    Voice and WAN Interface Cards Table 2-11 Technical Specifications for VIC-2FXO Cards (continued) Type Cisco IOS requirement Compliance Safety conformance Spare VIC-2E/M The VIC-2E/M card is a two-port E&M analog interface card (see Figure 2-10). Use the VIC-2E/M card to connect to PBX or key system trunk lines. Technical Specifications Table 2-12 Table 2-12 Technical Specifications for VIC-2E/M Card...

  • Page 59: Wics

    Chapter 2 Processor Cards Feature Summary Table 2-12 Technical Specifications for VIC-2E/M Card (continued) Type Cisco IOS requirement Compliance Safety conformance Spare WICs This section describes the WICS that are available for use in the MRP card, the ASI81 card, and the MRP3-8FXS card: WIC-1T and WIC-2T •...
  • Page 60 Voice and WAN Interface Cards Figure 2-12 One-Port Serial WAN Interface Card, WIC-1T Figure 2-13 Two-Port Serial WAN Interface Card, WIC-2T Technical Specifications Table 2-13 Table 2-13 Technical Specifications for WIC-1T and WIC-2T Cards Type Interface type Serial network support Physical connector Cisco ICS 7750 System Description 2-38...

  • Page 61: Wic-2A/S

    Chapter 2 Processor Cards Feature Summary Table 2-13 Technical Specifications for WIC-1T and WIC-2T Cards (continued) Type Number of connectors/ports Cisco IOS requirement Compliance Safety conformance Spare WIC-2A/S The WIC-2A/S card is a two-port serial, low-speed (up to 128 kbps), asynchronous and synchronous interface card.

  • Page 62: Wic-1B-S/T

    Voice and WAN Interface Cards WIC-1B-S/T The WIC-1B-S/T card is a one-port ISDN BRI interface card (S/T interface). See Figure 2-14. Figure 2-14 1-Port ISDN BRI WAN Interface Card (S/T Interface), WIC-1B-S/T Technical Specifications Table 2-15 Table 2-15 Technical Specifications for WIC-1B-S/T Card Type Interface type Interface...

  • Page 63: Wic-1B-U

    Chapter 2 Processor Cards Feature Summary WIC-1B-U The WIC-1B-U card is a one-port ISDN BRI interface card with integrated NT1 (U interface). (Externally, the WIC-1B-U is identical to the WIC-1T card; see Figure 2-12.) Technical Specifications Table 2-16 Table 2-16 Technical Specifications for WIC-1B-U Card Type Interface type Interface...
  • Page 64 Voice and WAN Interface Cards Figure 2-15 One-Port 56-kbps CSU/DSU Card, WIC-1DSU-56K4 Technical Specifications Table 2-17 Table 2-17 Technical Specifications for WIC-1DSU-56K4 Card Type Interface type Cisco IOS requirement Serial network support Physical connector Number of connectors/ports Compliance Safety conformance Spare Cisco ICS 7750 System Description 2-42...

  • Page 65: Wic-1Dsu-T1

    Chapter 2 Processor Cards Feature Summary WIC-1DSU-T1 The WIC-1DSU-T1 card is a single-port, T1/fractional T1 CSU/DSU interface card. Use the WIC-1DSU-T1 card for a cost effective router-CSU/DSU combination with the following features: T1 or fractional T1 network interface • • N x 64-kbps or N x 56-kbps non-channelized data rates (N = 1 to 24) Full management features: •...

  • Page 66: Vwics

    Voice and WAN Interface Cards VWICs This section describes the VWICS that are available for use in the MRP card and the ASI81 card: • VWIC-1MFT-T1 and VWIC-2MFT-T1 VWIC-1MFT-E1 and VWIC-2MFT-E1 • VWIC-1MFT-T1 and VWIC-2MFT-T1 The VWIC-1MFT-T1 card is a one-port, RJ-48 multiflex trunk T1 interface card that supports 24 channels (see two-port, RJ-48 multiflex trunk T1 interface card that supports 48 channels (see Figure...
  • Page 67 Chapter 2 Processor Cards Feature Summary Figure 2-16 1-Port T1 Multiflex Trunk Interface Card, VWIC-1MFT-T1 VWIC 1MFT-T1 Figure 2-17 2-Port T1 Multiflex Trunk Interface Card, VWIC-2MFT-T1 VWIC 2MFT-T1 Technical Specifications Table 2-19 VWIC-2MFT-T1 cards. Table 2-19 Technical Specifications for VWIC-1MFT-T1 and VWIC-2MFT-T1 Cards Type Interface type Transmit bit rate...

  • Page 68: Vwic-1Mft-E1 And Vwic-2Mft-E1

    Voice and WAN Interface Cards Table 2-19 Technical Specifications for VWIC-1MFT-T1 and VWIC-2MFT-T1 Cards (continued) Type Output level (LBO) Input level DTE interface (WIC mode) DTE interface (VIC mode) DCE interface Physical connector Number of connectors/ports Cisco IOS requirement Compliance Safety conformance Spare 1.
  • Page 69 Chapter 2 Processor Cards Feature Summary Table 2-20 Technical Specifications for VWIC-1MFT-E1 and VWIC-2MFT-E1 Cards Type Interface type Transmit bit rate Receive bit rate Data rate Clocking E1 national bits Encoding DTE interface (WIC mode) DTE interface (VIC mode) DCE interface Physical connector Number of connectors/ports Cisco IOS requirement...
  • Page 70 Chapter 2 Processor Cards Feature Summary Voice and WAN Interface Cards Cisco ICS 7750 System Description 2-48 78-10360-02...

  • Page 71: Chapter 3 Summary Of Power And Cooling System Features

    Summary of Power and Cooling System Features The Cisco ICS 7750 power and cooling system includes the following components: • Cisco ICS 7750 Chassis, Backplane, and Fan Tray, page 3-1 • Power Supply Module, page 3-4 • Power Protection Component, page 3-7 Cisco ICS 7750 Chassis, Backplane, and Fan Tray The Cisco ICS 7750 chassis is compact and designed for installation in a standard 19-inch rack or on a desktop.

  • Page 72: C H A P T E R 3 Summary Of Power And Cooling System Features

    The chassis, backplane, and fan tray have the following key features: • Two fixed, single-wide slots for the system alarm processor (SAP) card and the system switch processor (SSP) card. Six interchangeable slots for system processing engine (SPE), multiservice •...

  • Page 73: Technical Specifications

    Chapter 3 Summary of Power and Cooling System Features All cards are hot-swappable. • Hot-swappable fan tray, accessible from the front of the chassis. • Fans are monitored and controlled through the SAP card. • • Grounding lug for grounding the chassis to the wall outlet, optionally including the uninterruptible power supply (UPS).

  • Page 74: Power Supply Module

    Power Supply Module Table 3-1 Chassis Technical Specifications (continued) Type Description Shock Operating: up to 27 in. per second (0.69 m per second) Nonoperating: up to 35 G Vibration 0.35 Grms from 3 to 500 Hz Safety UL 1950, Third Edition CAN/CSA 22.2 No.
  • Page 75 Chapter 3 Summary of Power and Cooling System Features Power Supply Module Figure 3-2 Power Supply Module On/off switch IN P U T 1 0 0 -2 4 0 V 4 7 -6 3 H z AC power A C O K...

  • Page 76: Key Features

    Power Supply Module Key Features The power supply module has the following key features: Automatic remote enable/disable signal: Ensures that the power supply • remains off until fully seated and turns the power supply off during removal. Operates as a single or redundant module. •...

  • Page 77: Power Protection Component

    Chapter 3 Summary of Power and Cooling System Features Table 3-2 Technical Specifications for Power Supply Module (continued) Type Description Altitude Operating: Up to 10,000 ft (3,000 m) Nonoperating: Up to 15,000 ft (4,570 m) Vibration Operating: 0.41 Grms from 3 to 500 Hz with spectral break points of 0.0005 G2/Hz at 10 Hz and 200 Hz and 5 dB/octave roll-off at each end, 2 hours per axis Nonoperating: 1.12 Grms from 3 to 500 Hz with spectral break points of...
  • Page 78 RPS 300 automatically supplies power to the switch. The RPS 300 can power only one switch at a time. For complete redundancy, you should connect each switch in the Cisco ICS 7750 to a separate RPS 300.

  • Page 79: Cisco Rps 300

    AC input connector DC output connectors Feature Summary The RPS 300 has the following key features: Redundant support for the Catalyst 3524-PWR-XL switch • • Provides a redundant power connection for up to six switches, powering one switch at a time •...

  • Page 80: Technical Specifications

    Power Protection Component Table 3-3 Technical Specifications for RPS 300 (continued) Type Description Temperature Operating: 32 to 113ºF (0 to 45ºC) Nonoperating: –4 to 149ºF (–20 to 65ºC) Relative humidity Operating: 10 to 85% (noncondensing) Nonoperating: 5 to 95% (noncondensing) Altitude Operating: Up to 10,000 ft (3,000 m) Nonoperating: Up to 15,000 ft (4,570 m)
  • Page 81 Summary of System Software Features The chapter describes the required system software that runs on Cisco ICS 7750 cards and includes these sections: • ICSConfig Program, page 4-3 • Cisco ICS System Manager, page 4-5 • Fault Management Module, page 4-8 Cisco IOS, page 4-9 •...

  • Page 82: Summary Of System Software Features

    Table 4-1 Summary of System Software Applications Software Platform ICSConfig System processing Program engine (SPE) card (running System Manager) ICS System SPE card (runs on one Manager SPE per chassis) Fault SPE cards Management Module Cisco IOS Multiservice routing processor (MRP), analog station interface (ASI), and MRP300 cards...

  • Page 83: Chapter 4 Summary Of System Software Feature

    Chapter 4 Summary of System Software Features Table 4-1 Summary of System Software Applications (continued) Software Platform System switch processor (SSP) card Cisco SPE cards CallManager ICSConfig Program The ICSConfig program is a component that is installed on the SPE running System Manager.
  • Page 84 ICSConfig Program Security settings for the following: • IOS-based cards – SNMP – – The SPE The system – • Preferences for managing system event notifications Figure 4-1 Cisco ICS 7750 with the network. Figure 4-1 Cisco ICS 7750 System Description Chapter 4 shows the type of information that ICSConfig collects to integrate the ICS 7700 System Configuration for the Cisco ICS 7750 System...

  • Page 85: Cisco Ics System Manager

    Chapter 4 Summary of System Software Features Cisco ICS System Manager Cisco ICS System Manager provides a suite of tools to manage an integrated data and voice network. From a centralized, web-based user interface, the network administrator can use these tools for the following tasks: Preventive fault management •...
  • Page 86 Cisco ICS System Manager By using a browser on any PC connected to the LAN, the administrator can access the System Manager Configuration page, as shown in manage the following system components: SSP—For switched fast Ethernet settings to access other system components •...

  • Page 87: Key Features

    Chapter 4 Summary of System Software Features Key Features ICS System Manager has the following key features: Configuration—A single web interface allows network administrators to • configure many system components, such as the SSP. (To configure IP phones and voice gateways, use Cisco CallManager.). •...

  • Page 88: Fault Management Module

    Fault Management Module Technical Specifications Table 4-2 Table 4-2 Technical Specifications for ICS System Manager Type Description Hardware Runs on one SPE310 Database software Microsoft SQL 7.0 Client PC hardware Minimum requirements: 233-MHz CPU 64 MB of RAM CD-ROM drive VGA monitor with 640 x 480 pixel display and 256 colors Client operating system Windows 98 Windows NT 4.0...

  • Page 89: Cisco Ios

    Chapter 4 Summary of System Software Features Enables ICS System Manager to monitor the SPE and system alarm processor • (SAP) cards and the chassis Determines the current status of the SPE on which it is running • The SAP card is responsible for reporting environmental and physical problems to the FMM.
  • Page 90 Cisco IOS Table 4-3 Feature Sets Supported by the Cisco ICS 7750 on MRP and ASI Cards Image Name Cisco 7700 IOS IP, Voice, Plus IP/Voice Plus Cisco 7700 IOS IP, IPX, AT, IBM, Voice, Plus Table 4-4 ASI cards (as of IOS Release 12.2(4)YH). conventions: Yes—The feature is supported in the software image.
  • Page 91 Chapter 4 Summary of System Software Features Table 4-4 Feature List, by Feature Set, for MRP and ASI Cards (continued) Feature Sets Voice Features Plus IP Routing Protocols Open Shortest Path First (OSPF) Flooding Reduction Multimedia and Quality of Service Express Real-time Transport Protocol(RTP) Transmission Control...
  • Page 92 Cisco IOS Table 4-4 Feature List, by Feature Set, for MRP and ASI Cards (continued) Feature Sets Voice Features Plus Switching Web Cache Communications Protocol (WCCP) Version 2 WAN Optimization Class-Based Weighted Fair Queuing Low Latency Queuing WAN Services 1- and 2-Port T1 Multiflex Voice WAN Interface Cards (VWICs)

  • Page 93: Cisco Callmanager

    Quality of service (QoS) based on IEEE 802.1p CoS values Remote Monitoring (RMON) support through the CLI or SNMP • • Spanning-Tree Protocol (STP) UplinkFast • Switch Network View stack management Terminal Access Control Access Server+ (TACACS+) • • UniDirectional Link Detection (UDLD) for detecting unidirectional links •...
  • Page 94 Cisco CallManager The Cisco ICS 7750 supports “native” Cisco CallManager functionality by using the feature set that is available on other Cisco CallManager platforms. You can install Cisco CallManager on any SPE, including the SPE running System Manager. Cisco CallManager can function as either a publisher or a subscriber on any SPE.

  • Page 95: Key Features

    Chapter 4 Summary of System Software Features Key Features Cisco CallManager is the call-processing component of the Cisco IP Telephony Solution for the Enterprise part of Cisco AVVID (Architecture for Voice, Video and Integrated Data). The Cisco IP Telephony Applications Server provides a high-availability server platform for Cisco CallManager call processing, services, and applications.
  • Page 96 Cisco CallManager Table 4-5 Key Features of Cisco CallManager (continued) Feature System administration System administration tools Cisco CallManager Serviceability Cisco ICS 7750 System Description 4-16 Chapter 4 Description Use a web-based interface to the configuration database that permits remote device and system configuration. Provides access to HTML-based online help for users and administrators.

  • Page 97: System Capabilities

    Chapter 4 Summary of System Software Features System Capabilities The following is a summary of Cisco CallManager system capabilities: Call routing using Alternate Automatic Routing (AAR), Automated Route • Selection (ARS), and automated bandwidth selection Attenuation/gain adjustment per device, comfort noise generation, silence •...

  • Page 98: Specifications

    Cisco CallManager – – Specifications Table 4-6 Table 4-6 Specifications for Cisco CallManager on the Cisco ICS 7750 Type Description Hardware platform Runs on the SPE310 System software Requires Cisco ICS 7750 system software release 2.1.0 or later Applications software Cisco CallManager Release 3.1(2c) or later Client PC hardware Minimum requirements:...

  • Page 99: Internal Software Applications

    Summary of Software Applications Features The chapter describes the optional software applications that run internally on Cisco ICS 7750 cards or externally on servers or other devices: • Internal Software Applications, page 5-1 • External Software Applications, page 5-22 Internal Software Applications The following software can run on the system processing engine (SPE) 310 and interoperate with the Cisco ICS 7750: •...

  • Page 100: C H A P T E R 5 Summary Of Software Applications Features

    Internal Software Applications Cisco CallManger Extended Services Cisco CallManager Extended Services comes bundled with Cisco CallManager, Release 3.1 or higher. By using Customer Response Application (CRA) technology, Cisco CallManger Extended Services runs preconfigured application scripts to provide these two application solutions: •...

  • Page 101: Cisco Callmanager Auto Attendant

    Chapter 5 Summary of Software Applications Features Logout Service The user logs out by pressing the Services button and selecting Logout. After the user logs out, Cisco CallManager sends the original user profile to the phone and restarts the phone. Figure 5-1 Cisco IP Telephony...
  • Page 102 Internal Software Applications The Cisco CallManager AA provides the following functionality: Answers a call • Plays a user-configurable Welcome prompt • • Plays a Main Menu prompt that asks the user to perform one of three actions: Press “0” for the operator –...

  • Page 103: Key Features

    Chapter 5 Summary of Software Applications Features Key Features Cisco CallManager Extended Services solution applications have the key features described in Table 5-1 Components of Cisco CallManager Extended Services Application Key Function Cisco Provides temporary CallManager configuration of a Cisco IP Extension phone with a user profile Mobility...

  • Page 104: Specifications

    Internal Software Applications Specifications Table 5-2 Table 5-2 Specifications for Cisco CallManager Extended Services Type Description Software Package Included with Cisco CallManager 3.1 and higher. Install by using the Cisco CallManager Extended Services CD. Software Platform Cisco Customer Response Applications (CRA) Engine and preconfigured scripts.

  • Page 105: Cisco Unity Voice Messaging

    Chapter 5 Summary of Software Applications Features Table 5-3 Components of Cisco Unity Voice Messaging Application Key Function Intelligent Voice Receives and stores voice Mail messages ActiveAssistant Browser-based administration interface for users Automated Electronic receptionist for Attendant answering and directing incoming calls Visual Messaging Web-based interface for...
  • Page 106 Internal Software Applications Table 5-3 Components of Cisco Unity Voice Messaging (continued) Application Key Function Digital Connects multiple Cisco Unity Networking servers Cisco Unity Connects Cisco Unity servers Bridge with analog OctelNet servers Unity System Web-based system Administrator administration interface System Capabilities Cisco Unity Voice Messaging includes the following system capabilities: Integrates into Microsoft BackOffice, where Microsoft Exchange 2000 holds...

  • Page 107: Key Features

    Chapter 5 Summary of Software Applications Features Offers class of service (CoS) designations to the system administrator for • setting up groups of users with common characteristics instead of programming all of the settings for each individual user Supports Simple Mail Transfer Protocol/Multipurpose Internet Mail •...

  • Page 108: Configuration Options For Cisco Unity Voice Messaging

    Internal Software Applications Table 5-4 Features of Cisco Unity Voice Messaging (continued) Feature Call forward to a personal greeting Multilingual support Configuration Options for Cisco Unity Voice Messaging Cisco Unity Voice Messaging on the Cisco ICS 7750 can be configured in a standalone or networked environment.
  • Page 109 Chapter 5 Summary of Software Applications Features Networked to AMIS-compliant voice-mail systems—By using the Digital • Networking licensed feature, the Cisco Unity Voice Messaging system can connect to other AMIS-compliant voice-mail systems. These connections are made through the Public Switched Telephone Network (PSTN) by using multiservice route processors (MRPs) in the Cisco ICS 7750 that support the following: –...
  • Page 110 IN USE CONSOLE Summary of Software Applications Features CISCO ICS 7700 SERIES INTEGRATED COMMUNICATIONS SYSTEM POWER SUPPLY 2 AC OK OVERTEMP DC OK SPE running System Manager and Cisco CallManager (slot 6) System switch processor (SSP) System alarm processor (SAP) 78-10360-02...

  • Page 111: Specifications

    Chapter 5 Summary of Software Applications Features MS Exchange 2000 • Microsoft Data Engine (MSDE) • Microsoft SQL Enterprise Manager • Specifications Table 5-5 Cisco ICS 7750. Table 5-5 Specifications for Cisco Unity on the Cisco ICS 7750 Type Description Platform The SPE310 for applications with Windows 2000 Server and ICS System Manager Core Software.

  • Page 112: Cisco Customer Response Applications

    Internal Software Applications Qualified Combinations of Product Releases Cisco Unity Voice Messaging and the Cisco Unity–CM TSP have been qualified for the product combinations identified in Table 5-6 Qualified Combinations of Product Releases Cisco Unity Voice Cisco Unity–CM TSP Messaging Release Release 3.0(1) 3.0(2)

  • Page 113: Components

    Chapter 5 Summary of Software Applications Features Table 5-7 Key Features of the Cisco CR Platform Feature Description Open architecture design Allows integration with a variety of technologies and products to provide agent-assisted service (IP ICD) and self-service (IP IVR) to customers. Stores application scripts in an industry-standard LDAP directory.

  • Page 114: Components

    Internal Software Applications Figure 5-3 Cisco IP Telephony Solution Components PSTN Administration Java-compliant browser Enterprise database Figure 5-3 components: Gateway—Connects the enterprise IP telephony network to the PSTN and to • other private telephone systems, such as a PBX. In the Cisco ICS 7750, the MRP provides the gateway function.
  • Page 115 Chapter 5 Summary of Software Applications Features CRA server—Contains the CRA Engine that runs CRA application scripts. • CRA application scripts use a series of steps that are implemented as Java Beans packaged in *.jar files. In the Cisco ICS 7750, the CRA server runs on an SPE.
  • Page 116 Internal Software Applications Table 5-8 Components of Cisco Customer Response Applications (continued) Component Key Function Cisco CRA Editor For building and debugging application scripts that automate customer interactions Repository For storing voice application scripts Cisco ICS 7750 System Description 5-18 Chapter 5 Summary of Software Applications Features Description...

  • Page 117: Cisco Ip Interactive Voice Response Product

    Chapter 5 Summary of Software Applications Features Table 5-8 Components of Cisco Customer Response Applications (continued) Component Key Function CRA Real-Time Generates reports of Reporting system statistics CRA Software For creating or modify Developer’s Kit (SDK) CRA Editor steps for customized applications CRA Application...

  • Page 118: Cisco Ip Integrated Contact Distribution Product

    Internal Software Applications Supports ODBC access to databases for retrieving or entering data such as • access to checking account information Extracts and parses web-based content, and presents the data to customers • who are using a telephone, thereby delivering web-maintained information to a voice media user Supports up to 48 ports in a dedicated SPE310 configuration and up to 10 •...

  • Page 119: Specifications

    Chapter 5 Summary of Software Applications Features A call in queue hears messages with progress announcements or • advertisements. Queue scripts are built by using the CRA Editor. These application scripts • determine the queuing messages and handle the in-queue call. Sample scripts are available, and customized scripts can be built.

  • Page 120: External Software Applications

    External Software Applications Table 5-9 Specifications for IP ICD and IP IVR (continued) Type Description Database Microsoft SQL server, Oracle, Sybase, or IBM DB2 databases. Browser Microsoft Internet Explorer 5.5. Capacity When installed on the same SPE that Cisco CallManager is installed on—up •...

  • Page 121: Key Features

    Chapter 5 Summary of Software Applications Features VPN support—Combining Cisco IOS Firewall with Cisco IOS encryption • and QoS VPN features enables secure, low-cost transmissions over public networks. Scalability—Cisco IOS Firewall scales to meet any network’s bandwidth and • performance requirements. Easier management—Using Cisco ConfigMaker software, network •...

  • Page 122: Key Features

    External Software Applications Table 5-10 Key Features of Cisco IOS Firewall (continued) Feature VPNs, IPSec encryption, and QoS support Real-time alerts Audit trail Event logging Firewall management Integration with Cisco IOS software Basic and advanced traffic filtering Standard and extended access control lists (ACLs) let you apply Policy-based multi-interface support Redundancy/failover...

  • Page 123: Ciscoworks2000

    Chapter 5 Summary of Software Applications Features Table 5-10 Key Features of Cisco IOS Firewall (continued) Feature Time-based access lists Peer router authentication Improved attack detection and defense for e-mail servers CiscoWorks2000 The CiscoWorks2000 solutions assist in managing the enterprise network. These solutions address three areas in the network: WAN, LAN, and service level management.

  • Page 124: Ciscoworks2000

    Campus Manager Content Flow Monitor TrafficDirector Cisco ICS 7750 System Description 5-26 Chapter 5 Key Function Layer 2/Layer 3 switch topology representation with a device locator VLAN and ATM configuration tools Connectivity analysis between two devices in the network Extensive user tracking tool...
  • Page 125 Provides accurate Cisco inventory baseline information, including memory, slots, software versions, and boot ROMs, to make decisions about the network Can send router and switch device software updates to selected devices on a schedule; reduces time and errors involved in network updates...

  • Page 126: Routed Wan Management Solution

    External Software Applications Routed WAN Management Solution Routed WAN Management Solution provides wide-area network monitoring, troubleshooting, traffic management, access control, and applications to administer the routed infrastructure of multiservice and VPN routing platforms built with Cisco products. Routed WAN Management Solution. Table 5-12 Applications Included in CiscoWorks2000 Routed WAN Management Solution Application Access Control List (ACL)

  • Page 127: Routed Wan Management Solution

    Provides accurate Cisco inventory baseline information, including memory, slots, software versions, and boot ROMs, to make decisions about the network Can send router and switch device software updates to selected devices on a schedule; reduces time and errors involved in network updates...

  • Page 128: Service Management Solution

    Displays a console representation of Cisco router and switch devices (color-coded to indicate operational status) with access to configuration and monitoring tools Allows service-level data to be...
  • Page 129 Features of Cisco IP Phones Cisco IP Phones are full-featured devices that provide voice communication over an IP network. These Cisco IP Phones function like traditional analog telephones, so that you can place and receive calls and perform functions, such as call forwarding, redialing, speed dialing, transferring calls, placing conference calls, and accessing voice mail.

  • Page 130: Cisco Ip Phone 7960 And Cisco Ip Phone 7940

    Cisco IP Phone 7960 and Cisco IP Phone 7940 Cisco IP Phone 7960 and Cisco IP Phone 7940 The Cisco IP Phone 7960 is a full-featured, multiline phone used primarily by managers and executives. The Cisco 7960 has six programmable buttons for lines or for speed dialing, and it has four interactive soft keys.

  • Page 131: Key Features

    Dynamic Host Control Protocol (DHCP), Trivial File Transfer Protocol (TFTP), Cisco CallManager, and backup Cisco CallManagers. 78-10360-02 One connector connects the phone to the Catalyst switch, using a straight-through cable; the phone can receive inline power from the Catalyst switch over this connection.

  • Page 132: Technical Specifications

    Cisco IP Phone 7960 and Cisco IP Phone 7940 Services—For accessing any web-based information using Extensible • Markup Language (XML). Help—Online help provides information about all of the capabilities of the • phone. • Comfort noise generation and voice activity detection (VAD) programming system-wide.

  • Page 133: Cisco Ip Phone 7910 And 7910+Sw

    The Cisco IP Phone 7910+SW includes a Cisco two-port switch for connecting the phone to a PC or other Ethernet device. 78-10360-02 Cisco IP Phone 7910 and 7910+SW...
  • Page 134 Cisco IP Phone 7910 and 7910+SW The LCD display shows the time and date, the phone number, the calling party name and number, and the line or call status. The phone operates with IP telephony systems based on Cisco CallManager technology. Figure 6-2 Figure 6-2 Handset with indicator light...

  • Page 135: Key Features

    Chapter 6 Features of Cisco IP Phones Key Features The Cisco IP Phone 7910 and the Cisco IP Phone 7910+SW include the following key features: • One line with four dedicated feature buttons (line, hold, transfer, and settings). • The Cisco 7910 has one standard 10BASE-T RJ-45 connection. •...

  • Page 136: Technical Specifications

    Cisco IP Phone 7910 and 7910+SW Table 6-2 Technical Specifications for the Cisco IP Phone 7910 and Cisco IP Phone 7910+SW (continued) Type Description Relative humidity Operating: 10 to 95% (noncondensing) Power 100 to 240 VAC, 50 to 60 Hz, 0.5A (when using the AC adapter) 48 VDC, 0.2A (when using the in-line power over the network cable) Cables Two pair of Category 3 for 10-Mbps cables...

  • Page 137: Cisco Ip Phone Expansion Module 7914

    Chapter 6 Features of Cisco IP Phones Cisco IP Phone Expansion Module 7914 The Cisco IP Phone Expansion Module 7914 attaches to the Cisco IP Phone 7960 and adds 14 buttons and an LCD display to aid administrative assistants and others who must monitor and manage calls.

  • Page 138: Cisco Ip Phone Expansion Module 7914

    Cisco IP Phone Expansion Module 7914 Line buttons that are assigned with directory numbers can be illuminated to show the line status information identified in Table 6-3 Button Light Off/dark Green, steady Red, steady Amber, flashing Green, flashing Red, flashing Each button that is not used as a directory number or line key can be programmed as a speed-dial key by using the Cisco IP Phone User Options web page.

  • Page 139: Technical Specifications

    Chapter 6 Features of Cisco IP Phones Technical Specifications Table 6-4 Module 7914. Table 6-4 Technical Specifications for Cisco IP Phone Expansion Module 7914 Type Description Dimensions Height: 8 in. (20.3 cm) Width: 4.75 in. (12.1 cm) Depth: 2 in. (5.1 cm) Weight 0.82 lb (.36 kg) Temperature...

  • Page 140: Cisco Ip Conference Station 7935

    Cisco IP Conference Station 7935 Table 6-4 Technical Specifications for Cisco IP Phone Expansion Module 7914 (continued) Type Description Standards IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 100BASE-X ports IEEE 802.1D Spanning-Tree Protocol IEEE 802.1p CoS prioritization IEEE 802.1Q VLAN IEEE 802.3z 1000BASE-X specification 1000BASE-X (GBIC) 1000BASE-SX...

  • Page 141: Cisco Ip Conference Station 7935

    Chapter 6 Features of Cisco IP Phones Figure 6-4 LEDs—Indicate call status. LCD screen—Displays instructions and information. Scroll buttons—For navigating through the menu options. Select button—For choosing a menu option. Soft keys—Functions change with the call state. Volume buttons—For increasing and decreasing caller and speaker volume.

  • Page 142: Key Features

    Supports G.711 and G.729a audio compression. Has comfort noise generation and voice activity detection. • Uses Cisco Discovery Protocol to Cisco Catalyst switch port providing • protocol for E911 services, phone tracking, and asset/theft management. Has an RJ-45 port that provides 10/100BASE-TX Ethernet LAN connection •...

  • Page 143: Technical Specifications

    Chapter 6 Features of Cisco IP Phones Technical Specifications The recommended environments for operating the Cisco IP Conference Station are closed offices and conference rooms up to 20 by 30 feet in dimension without major glass or ceramic surfaces, and with normal background air-conditioning noise.

  • Page 144: Cisco Ip Softphone

    Cisco IP SoftPhone Table 6-5 Technical Specifications for Cisco IP Conference Station 7935 (continued) Type Description Emissions FCC Part 15 (CFR 47) Class B CES-003 Class B EN 55022 Class B CISPR22 Class B VCCI Class B AS/NZS 3548 Class B EN55024 Telecom IC CS-03...

  • Page 145: Cisco Ip Softphone

    Chapter 6 Features of Cisco IP Phones Figure 6-5 Icon bar Lines 78-10360-02 Cisco IP SoftPhone Cisco ICS 7750 System Description Cisco IP SoftPhone Call blocks Context-sensitive button bar 6-17...

  • Page 146: Key Features

    Cisco IP SoftPhone Key Features Cisco IP SoftPhone includes the following key features: Cisco IP SoftPhone can be used as a standalone phone—Place and receive all • calls through a computer rather than an IP phone; the PC must have a full-duplex sound card with appropriate drivers installed, and it must also have a computer headset or computer handset.

  • Page 147: System Requirements

    Chapter 6 Features of Cisco IP Phones Voice mail integration—Integrates with a voice-mail system to transfer calls • or place calls directly into a voice mailbox. CallManager services—Uses the services of CallManager to route calls • through an IP telephony network. System Requirements Table 6-6 SoftPhone on a PC.

  • Page 148: Cisco Callmanager Attendant Console

    Cisco CallManager Attendant Console Cisco CallManager Attendant Console Cisco CallManager Attendant Console is designed to automate the user and administrative operations of a manual attendant console. The Cisco CallManager Attendant Console uses a graphical user interface and a Cisco IP phone to perform attendant console functions such as call handling and line-state monitoring.

  • Page 149: Cisco Callmanager Attendant Console

    Chapter 6 Features of Cisco IP Phones Figure 6-6 Cisco CallManager Attendant Console window Menu bar Directory pane Call Control toolbar Speed Dial pane Speed Dial Group tab 78-10360-02 The Cisco CallManager Attendant Console Interface 10 Call Details area 11 Call Control pane 12 Line Status area Cisco ICS 7750 System Description Cisco CallManager Attendant Console...

  • Page 150: Key Features

    Cisco CallManager Attendant Console Key Features Cisco CallManager Attendant Console includes the following key features: Loop keys— Provides for simultaneous management of all lines available on • the associated IP phone. Line status—Displays icons to show these line states: • –...

  • Page 151: Technical Specifications

    Chapter 6 Features of Cisco IP Phones Technical Specifications Table 6-7 Attendant Console. Table 6-7 System Capabilities of the Cisco CallManager Attendant Console System Capabilities Description Capacities 32 hunt groups (pilot numbers) per Cisco CallManager cluster. 16 hunt group members per hunt group. As many call loops per CallManager Attendant Console as configured on the controlled IP phone device.
  • Page 152 Chapter 6 Features of Cisco IP Phones Cisco CallManager Attendant Console Cisco ICS 7750 System Description 6-24 78-10360-02...

  • Page 153: Chapter 7 Features Of Lan-Based Switching Technologies

    • Catalyst 6000 Switches, page 7-7 • The Catalyst 3524-PWR XL switch and Catalyst 4000 switches allow LANs to fully integrate voice, video, and data applications. Catalyst 6000 switches are primarily for enterprise and service provider environments. Catalyst 3524-PWR XL Switch The Catalyst 3524-PWR XL switch was developed for use with the Cisco ICS 7750 to allow full integration of voice, video, and data applications.

  • Page 154: Key Features

    AC power Redundant connector power system connector Key Features The Catalyst 3524-PWR XL switch has the following key features: 24 autosensing 10/100 Ethernet ports: full-duplex operation delivering up to • 200 Mbps. Two fixed GBIC-based Gigabit Ethernet ports: full-duplex operation •...
  • Page 155 400 Mbps to Gbps of aggregated bandwidth between switches, to routers, and to individual servers. • Cisco Inter Switch Link (ISL) and IEEE 802.1Q trunking support on all ports: supports automatic segmentation of phone and data endpoints into separate logical networks.

  • Page 156: Technical Specifications

    Autodetection and control of inline phone power on a per-port basis on all 10/100 ports. Support for fan-fault and over-temperature detection through Cluster Management Suite (CMS). lists the technical specifications for the Catalyst 3524-PWR XL switch. Features of LAN-Based Switching Technologies 78-10360-02...

  • Page 157: Technical Specifications

    Chapter 7 Features of LAN-Based Switching Technologies Table 7-1 Technical Specifications for Catalyst 3524-PWR XL Switch (continued) Type Description Safety UL 1950, Third Edition CAN/CSA 22.2 No. 950-95, Third Edition NOM-019-SCFI AS/NZS 3260 and TS001-1997 IEC 60950 with all country deviations...

  • Page 158: Catalyst 4000 Switches

    Quality of service (QoS), multiple queues with weighted round robin (WRR) scheduling. Comprehensive management tools based on standard CiscoWorks2000 applications. Hardware-based access control list (ACL) support on dual Gigabit Ethernet uplinks. Inter-switch link (ISL) and 802.1Q trunking on dual Gigabit Ethernet uplinks. Features of LAN-Based Switching Technologies 78-10360-02...

  • Page 159: Catalyst 6000 Switches

    Chapter 7 Features of LAN-Based Switching Technologies Catalyst 6000 Switches Catalyst 6000 series switches offer integrated solutions for enterprise and service provider environments that include the following key features: Scalable, intelligent multilayer switching for enterprise and Internet service • provider (ISP) infrastructures—hardware-based acceleration for Layer 2, 3, and 4 switching and services.
  • Page 160 Chapter 7 Features of LAN-Based Switching Technologies Catalyst 6000 Switches Cisco ICS 7750 System Description 78-10360-02...

  • Page 161: Chapter 8 Features Of Other Compatible Cisco Devices

    Features of Other Compatible Cisco Devices The ICS 7750 environment supports several other Cisco devices, which let you add features to your system: • Cisco 1750 Modular Access Router, page 8-1 • Cisco 2600 Series Routers, page 8-2 • Cisco Voice Gateway 200, page 8-3 DT-24+ and DE-30+ Digital Gateway Modules, page 8-5 •...

  • Page 162: Cisco 2600 Series Routers

    Cisco 2600 Series Routers The Cisco 1750 router has the following key features: Flexibility—full Cisco IOS support, multiprotocol routing (IP, Internetwork • Packet Exchange [IPX], AppleTalk, IBM/SNA) and bridging Modular architecture—accepts WAN and voice interface cards, autosensing • 10/100 Fast Ethernet, expansion slot for adding a VPN module Security—Firewall feature set;...

  • Page 163: Cisco 2600 Series Routers

    Chapter 8 Features of Other Compatible Cisco Devices Key Benefits The Cisco 2600 series enables businesses to extend a cost-effective, seamless network infrastructure to the branch office with the following benefits: • Investment protection—Because the 2600 series supports field-upgradable modular components, customers can easily change network interfaces without upgrading the entire branch office network solution.

  • Page 164: Features

    Cisco Voice Gateway 200 The Cisco VG200 chassis can hold a network module (NM) that provides processing and digital signal processor (DSP) resources, and voice interface cards (VICs), which provide the physical voice interfaces. A typical configuration includes an NM-2V network module and two VICs. These VICs can be any combination of Foreign Exchange Station (FXS), Foreign Exchange Office (FXO), ear and mouth (E&M), or Basic Rate Interface (BRI) (both user and network sides), for a total of four ports.

  • Page 165: Features

    Chapter 8 Features of Other Compatible Cisco Devices DT-24+ and DE-30+ Digital Gateway Modules The DT-24+ and DE-30+ digital gateways are modules that are used with Cisco CallManager to connect Cisco IP phones to the Internet. The DT-24+ or DE-30+ module is installed in a 32-bit Personal Computer Interface (PCI) slot in a PC desktop or server chassis.

  • Page 166: Features

    DT-24+ and DE-30+ Digital Gateway Modules encoding (A-law or mu-law), dual tone multifrequency (DTMF) detection, generation, and signaling, and line echo cancellation. Thirty simultaneous channels of G.723.1 encoding/decoding are also supported. Features DT-24+ and DT-30+ digital gateways include the following features: •...

  • Page 167: I N D E X

    CallManager description 4-3, 4-13 to 4-14 features 4-15 specifications 4-18 system capabilities 4-17 to 4-18 CallManager AutoAttendant description features CallManager Extended Services description specifications Catalyst 3524-PWR XL switch Catalyst 4000 switch Catalyst 6000 switch Cisco ICS 7750 System Description IN-1...
  • Page 168 Index chassis features illustration technical specifications 3-3 to 3-4 Cisco 1750 Modular Access Router Cisco 2600 series routers Cisco CallManager See CallManager Cisco CallManager Attendant Console See Attendant Console Cisco CRA components 5-15 to 5-19 description 5-14 features 5-14 to 5-15 Cisco IP Conference Station 7935 See IP Conference Station Cisco IP Integrated Contact Distribution...

  • Page 169: Dt-24+ Digital Gateways

    directory DC Directory 5-18 LDAP 5-18 documentation, ICS 7750 DT-24+ digital gateway module DT-30+ digital gateway module Extension Mobility architecture illustration description features fan tray Fault Management Module 4-2, 4-8 to 4-9 FCC registration number firewall See IOS Firewall Flash memory, MRP300 card 5-20 ICS 7750 documentation 78-10360-02...
  • Page 170 Index IP Phone 7910+SW description features technical specifications 6-7 to 6-8 IP Phone 7940 description features 6-3 to 6-4 technical specifications 6-4 to 6-5 IP Phone 7960 description features 6-3 to 6-4 illustration technical specifications 6-4 to 6-5 IP Phone Expansion Module description features 6-9 to 6-10...
  • Page 171 obsolete SPE200 card organization, document power supply, uninterruptible power supply module description features illustration technical specifications 3-6 to 3-7 publications See documentation replacing SPE200 routers Cisco 1750 Cisco 2600 series RPS 300 features illustration technical specifications 3-9 to 3-10 78-10360-02 SAP card description features...
  • Page 172 Index system processing engine cards See SPE200 cards, SPE310 card system switch processor card See SSP card uninterruptible power supply See UPS 3-7 to 3-8 VG200 VIC-2BRI-NT/TE description 2-31 technical specifications 2-32 VIC-2DID description 2-30 technical specifications 2-31 VIC-2E/M description...
  • Page 173 WIC-1B-S/T description 2-40 technical specifications 2-40 WIC-1B-U description 2-41 technical specifications 2-41 WIC-1DSU-56K4 description 2-41 technical specifications 2-42 WIC-1DSU-T1 description 2-43 technical specifications 2-43 WIC-1T description 2-37 technical specifications 2-38 WIC-2A/S description 2-39 technical specifications 2-39 WIC-2T description 2-37 technical specifications 2-38 WICs 2-37 to 2-43...
  • Page 174 Index Cisco ICS 7750 System Description IN-8 78-10360-02...

Table of Contents
