- Page 1 Front Cover independant Care Horizontal ES independant Care Horizontal MD independant Care Horizontal LG English Mounting Instructions 0051 90-582-72-10 Revision 01 Date of Release: 2021-04 www.klsmartin.com...
- Page 2 Symbol Explanation The following symbols are either part of this instruction for use and / or of the product labeling. Safety alert symbol CAUTION Indicates a situation which, if not avoided, could result in minor or moderate injury. WARNING Indicates a situation which, if not avoided, could result in death or serious injury.
- Page 3 Neutral Line F1, F2, F3, … Fuse identification as per electrical diagram (where applicable) SOCKET 1, SOCKET 2, … Socket identification as per electrical diagram (where applicable) xxxVA (lighting) Power consumption of each light Correct configuration Click Apply screw lock to the screw Tighten screw/nut with specified torque Press on to fix Pull off with suction cup...
-
Page 4: Table Of Contents
independant Care Horizontal Mounting Instructions Table of Contents General Information ............................ 5 1.1 Manufacturer ............................. 5 1.2 Hotline ..............................5 1.3 Obligation to Report Incidents ......................5 1.4 Terms & Acronyms ..........................6 1.5 Symbols Used in this Document ......................6 General Safety Warnings .......................... -
Page 5: General Information
independant Care Horizontal Mounting Instructions 1 General Information Manufacturer We thank you for buying one of our products. This product bears the CE mark. This means that it meets the basic requirements on the safety and the performance of medical devices set forth by the respective applicable European regulations. We are the manufacturer of this product: LM Medical Division s.r.l. -
Page 6: Terms & Acronyms
independant Care Horizontal Mounting Instructions Terms & Acronyms Designation Description Acrylonitrile butadiene styrene copolymer (synthetic plastic) Electromagnetic Compatibility IDP/UDA Medical Supply Unit Medical Device Symbols Used in this Document Words marked with ® are trademarks owned by the respective proprietors. Throughout this document, important information (such as general or safety-related notices) is marked with the following symbols and signal words: Life hazard or serious injury! -
Page 7: General Safety Warnings
independant Care Horizontal Mounting Instructions 2 General Safety Warnings Danger to life from explosion! • Do not use the service head in areas where flammable, combustible or explosive gas mixtures may form. Danger to life from fire! Escaping oxygen is a powerful oxidant and thereby greatly intensifies the combustion process: Open fire, glowing items, or open light are not allowed when working with oxygen! •... - Page 8 independant Care Horizontal Mounting Instructions Danger of injury from electric shock! When connecting the IDP Care to the power supply, it is mandatory to observe the data indicated on the label, such as voltage (V) and frequency (Hz). • Establish the power connection according to the circuit diagram supplied by the manufacturer. Danger of injury due to use of unsuitable spare parts! •...
- Page 9 independant Care Horizontal Mounting Instructions Danger of injury from falling parts! During all assembly/disassembly work, no persons may be under the components of the service head. Danger of injury due to improperly performed repairs! Operators/users must not replace any parts of the service head by themselves. This is reserved exclusively for qualified staff approved by the manufacturer.
-
Page 10: Safety Instructions For The Installer
independant Care Horizontal Mounting Instructions 3 Safety Instructions for the Installer • Read the following installation instructions carefully. • Comply with all safety instructions and installation requirements. The load-bearing capacity and the condition of the ceiling must be determined. Assembly, installation and servicing of the service head may be carried out only by LM Medical Division or Gebrüder Martin, or by trained and authorized service personnel of these companies. -
Page 11: Mounting
independant Care Horizontal Mounting Instructions 4 Mounting The horizontal console is delivered complete and tested, and is ready for mounting. The mounting process is described using the IDP Care Horizontal ES as an example. It also applies to the other versions of the IDP Care Horizontal. Surface Mounting 1 Gas connections 2 Aluminum cover... - Page 12 independant Care Horizontal Mounting Instructions After opening the cover, the fastening holes of the console are accessible: The following illustrations show the standard fastening hole positions for different console lengths. • Fix the console at the recommended standard height of 1,700 mm above the finished floor (1). •...
- Page 13 independant Care Horizontal Mounting Instructions For console width up to 2,000 mm For console width >2,000 mm...
- Page 14 independant Care Horizontal Mounting Instructions • Fasten the horizontal console directly to the wall using suitable dowels, see section 3.1 “Fastening Elements”, page 10: 1 Dowel 2 Washer 3 Screw • Place the aluminum cover back on the horizontal console using slight pressure.
-
Page 15: Wall Mounting
independant Care Horizontal Mounting Instructions Wall Mounting • For mounting, pull the aluminum cover off the console using a suction cup. • Observe the information in the following drawings for wall mounting. 2 Washer 4 Recommended reinforcement of the inner wall for plasterboard wall mounting 1 Screw... -
Page 16: Establishing The Gas Connection
independant Care Horizontal Mounting Instructions Establishing the Gas Connection The soldering of the gas lines, as well as the inspection for tightness, pressure, flow, contamination of the respective gases is the responsibility of the supplier of the on-site gas supply system. These guidelines correspond to the typical standards in force in Italy. -
Page 17: Electrical Connections
independant Care Horizontal Mounting Instructions Electrical Connections Danger of injury from electric shock! • Disconnect the system from the power supply before starting any electrical work: – Turn off the power supply on all phases on site and secure it against reactivation. 1 Through opening for power cable 4 Terminals for electrical components 2 Ground connection... -
Page 18: Weight Table
independant Care Horizontal Mounting Instructions 5 Weight Table The weight is crucial for the selection of the right dowel. The company commissioned with mounting is also responsible for selection the dowels. All weights may vary depending on the gas and electric configuration. Weight Weight Weight... -
Page 19: Transport, Maintenance And Cleaning
independant Care Horizontal Mounting Instructions 6 Transport, Maintenance and Cleaning Transport, storage, preservation and disposal Ambient conditions for storage and transportation • Temperature: -10°C to +40°C (14–104°F) • Humidity: 30–75% • Atmospheric pressure: 700–1,060 hPa Do not stack more than 5 devices on top of each other and do not store them in a vertical position. In case of irreparable breakage or end of life equipment’s, dispose the device follow the current regulations. -
Page 20: Installing Accessories
independant Care Horizontal Mounting Instructions 7 Installing Accessories The label (2) indicates the maximum total load for the standard rail (1). - Page 21 independant Care Horizontal Mounting Instructions 1 Adjustable...
- Page 22 independant Care Horizontal Mounting Instructions 1 Adjustable...
- Page 23 independant Care Horizontal Mounting Instructions...
- Page 24 independant Care Horizontal Mounting Instructions...
-
Page 25: Faq & Troubleshooting
independant Care Horizontal Mounting Instructions 8 FAQ & Troubleshooting Question Answer Wall fixing bracket and screws – galvanized steel Which are the materials independant Care is made of? Frame, lids – epoxy painted aluminum Front panel – acrylic or polycarbonate (upon request) Installation of the independant Care is not particularly difficult if performed by qualified personnel in accordance with these Is independant Care easy to install? -
Page 26: Electromagnetic Interference Tables
independant Care Horizontal Mounting Instructions 9 Electromagnetic Interference Tables Table 201 Emission test Compliance Electromagnetic environment The devices of the independant Flex series use HF energy only for the internal RF emissions Group 1 mechanism. Therefore, their HF emissions are very low and not likely to cause interference in nearby electronic equipment. - Page 27 independant Care Horizontal Mounting Instructions Table 203 Evidence of Test level Level of Electromagnetic environment immunity IEC 60601 compliance (distance of transmitter equipment) = 17 ⋅ Conducted radio 3 Vrms 3 Vrms where P means the maximum output power rating in Watt of the frequency transmitter and d is the separation distance in meters = 35...
-
Page 28: Instruction And Commissioning Protocol For Medical Devices
Gebrüder Martin GmbH & Co. KG KLS Martin Platz 1 D-78532 Tuttlingen/Germany Instruction and commissioning protocol for medical devices According to the 93/42/CEE Product type: Serial n Device location: Manufacturer: Installation date: Important information! The following commissioning protocol is valid only if it is supplied with the installation and operating manuals, both of which are to be used as additional documents for commissioning. - Page 29 Gebrüder Martin GmbH & Co. KG KLS Martin Platz 1 D-78532 Tuttlingen/Germany Training on structurally identical devices has been carried out. The operation of the system has been explained, and it has been pointed out that the Instructions for Use must be observed.
-
Page 30: Technical Specification
independant Care Horizontal Mounting Instructions 10 Technical Specification The independant models include power distribution, diagnostic alarms, signals, nurse call system and medical gas distribution in a single device; thanks to a range of accessories, it can also support other medical devices. All consoles are made of extruded aluminum profile of a suitable thickness, either anodized or coated with epoxy powder in RAL color selected according to the customer’s requirements. - Page 31 independant Care Horizontal Mounting Instructions Regulation The equipment should be considered class IIb Registered office of the manufacturer and Via Brigate Alpine n° 9 San Pancrazio – 25036 Palazzolo Sull’Oglio (BS) – Italy production site Arrangement In compliance with provisions No. 151/05 laid down by Legislative Decree...
-
Page 32: Technical Data
independant Care Horizontal Mounting Instructions 11 Technical Data 11.1 Dowel Screw diameter 9.5–25 mm – dowel penetration depth 44 mm – dowel length 29 mm – dowel length without drill tip Screw length 28 mm – min. bolt penetration E/min 50 mm –... - Page 33 independant Care Horizontal Mounting Instructions...
- Page 34 independant Care Horizontal Mounting Instructions...
- Page 35 independant Care Horizontal Mounting Instructions...
- Page 36 independant Care Horizontal Mounting Instructions...
- Page 37 independant Care Horizontal Mounting Instructions...
- Page 38 independant Care Horizontal Mounting Instructions...
- Page 39 independant Care Horizontal Mounting Instructions...
- Page 40 A company of the KLS Martin Group Via Brigate Alpine, 9 · 25036 Palazzolo sull’Oglio · Brescia · Italy KLS Martin Platz 1 · 78532 Tuttlingen · Germany Phone + 39 030 7453357 Phone +49 7461 706-0 · Fax +49 7461 706-193 info@klsmartin.com ·...
