CM7057T
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 5
Rev.14-04-22
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7057T
Summary of Contents for Furniture of America CM7057T
- Page 1 Assembly Instructions CM7057T ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Headboard Bolt M8x1” #B x 8 pcs #2 x 2 pcs Bolt M8x3”...
- Page 4 Align the feet (#4) onto the pre-drilled holes on the bottom corners of the headboard (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#D) onto the bolt (#B) and then the flat washer (#C) onto the SAME bolt (#B), in that order.
- Page 5 Prepare a complete bed slat by connecting two end caps (#E) onto the ends of the bed slat (#5). Align the end caps (#E) with the pre-drilled holes on each side of the side rails (#2) and snap both ends to lock in place. III.
