1 / 9
MODEL #
CM7058D-M
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7058D-M
Summary of Contents for Furniture of America CM7058D-M
- Page 1 MODEL # CM7058D-M Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 DRESSER & MIR R OR CM7058D-M #1 1pc #2 1pc #3 2pcs Dresser Mirror Mirror Support #A 6pcs #B 6pcs #C 6pcs #D 1pc Allen Wrench M4 Flat Washer Ø1/4" Bolt Ø1/4 x 1-3/8" Lock Washer Ø1/4" #E 1Set Anti Tip Kit...
- Page 6 CM7058D-M is packed in 2 cases Carton Disignation Part Hardware Dresser #E 1 Set CM7058D Back Rail #A 6pcs #B 6pcs CM7058M Mirror #C 6pcs #D 1pc 62mm 325mm 850mm 130mm 232mm 850mm 82mm 19mm 6 / 8...
- Page 7 ASSEMBLY INSTRUCTIONS Part #1 x1pc Adjust the leveler according to the ground level. 1. Prepare 6 bolt assemblies by first inserting Part #2 x1pc a lock washer (#B) onto the bolt (#A) then a flat washer (#C) onto that same bolt Part #3 x2pcs (#A).
- Page 8 ASSEMBLY INSTRUCTIONS Hardware #E x 1 Set WALL 8 / 8...
- Page 9 9 / 9...
