VERSION
# 20-06- 18
1 / 8
MODEL #
CM7058CK/EK/Q
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Table of Contents
Related Manuals for Furniture of America Winsor CM7058CK
Summary of Contents for Furniture of America Winsor CM7058CK
- Page 1 MODEL # CM7058CK/EK/Q Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 8...
- Page 5 CM7058CK/EK/Q #1 1pc #2 1pc #3 2pcs #4 1Set Headboard Footboard Bed Rail Bed Slat (13pcs) #5 1pc #6 4pcs Center Rail Support 30x30x350mm #A 14pcs Screw M8 x 30mm 5 / 8...
- Page 6 CM7058CK/EK/Q is packed in 3 cases Carton Disignation Part Hardware Headboard CM7058CK/EK/Q-HB Footboard CM7058CK/EK/Q-FB #A 14pcs Side Rail Bed Slat CM7058CK/EK/Q-R Center Rail Support Leg 6 / 8...
- Page 7 ASSEMBLY INSTRUCTIONS Hook each end of the bed rails (#3) to the slots along the headboard panel (#1) and the footboard panel (#2). Part #1 x1pc Part #2 x1pc Part #3 x2pcs Insert the threaded ends of the supports (#6) into the holes along the center rail (#5).
- Page 8 ASSEMBLY INSTRUCTIONS Place the center rail (#5) onto the slot along the center of the headboard and footboard, then insert a screw (#A) into Hardware #A x2pcs each end. Secure using a screwdriver. Place the bed slats (#4) onto the bed rails (#3), Hardware #A x12pcs then insert a screw (#A)
