SOUTHERN ENTERPRISES INC.
RELAX...If you can follow a few easy, step-by-step directions
in order .YOU CAN ASSEMBLE THIS ITEM.
PLEASE FIND HARDWARE IN RED POLYBAG BEFORE DISCARDING PACKING MATERIAL.
(1) WOOD DOWELS
(2) METAL KNOBS
(3) LONG FLAT HEAD WOOD SCREWS
(4) SHORT FLA T HEAD WOOD SCREWS
(5) LONG PAN HEAD WOOD SCREWS
(6) SHORT PAN HEAD WOOD SCREWS
(7) MAGNET
(A) LEFT UPPER SIDE PANEL
(B) RIGHT UPPER SIDE PANEL
WHITE
NATURAL STYLE NO:
NASSAU SPACESAVER
HARDWARE LIST
40PCS
(8) SHELF SUPPORTS
4PCS
(9) T-BOLTS
6PCS
(10) LOCK WASHERS
8PCS
(11) LONG MACHINE SCREWS
16PCS
(12) PLASTIC COVERS
20PCS
(13) SHORT MACHINE SCREWS
1PC
(14) PLASTIC ANCHORS
PARTS LIST
1PCS
(L) BACK PANEL
1PCS
(M) LEFT SIDE DOOR
BE7181
STYLE NO:
BE7581
8PCS
12PCS
12PCS
12PCS
8PCS
4PCS
2PCS
1PC
1PC
