UM2148
3.2

Selecting reference voltage

The reference voltage for the current limiter circuitry of the STSPIN250 can be selected
through dedicated resistors shown below.
Signal
REF
REF

Table 4: Reference voltage selection

R17 R20
200 kΩ Not mounted
Not mounted 200 kΩ
These signals must be used by all expansion boards stacked on the
X-NUCLEO-IHM13A1.
DocID030083 Rev 1
Hardware description and configuration
Connector Remarks
Default
NUCLEO-F401RE or
CN8 pin1
NUCLEO-F334R8 or
NUCLEO-L053R8
CN5 pin1 NUCLEO-F030R8
9/14
