- Page 1 VL45/60 ProS V1.5 Please email us at: official@icecofreezer.com...
-
Page 2: Table Of Contents
Catalogue - - - - - - - - - Tips For Opening The Door - - - - - - - - - - - - - - - - - - - - - - Supply Details - - - - - - - - - - - - - - - - - - - - - - - - - - - Operation - - - - - - - - - - Cleaning And Maintenance... -
Page 3: Tips For Opening The Door
Tips For Opening The Door 1. To open the lid from the 2. Push the latch inwards right side, keep fingers and lift up the lid. together and grip the right latch. 3. To open the lid from the 4. Grip the latch on both left side, repeat the sides and push them above steps. -
Page 4: Supply Details
Supply Details Refrigerator x1 Wire Basket x1 5.9 Feet 110V AC Wall 11.5 Feet 12/24V Outlet Cable X1 DC Cigarette Lighter Plug Cable x1 Extra Supplies Drain Plug Screws Corner Guards Handle Allen Wrench... - Page 5 MODEL VL45 ProS VL60 ProS 28.1x15.9x18.1 inch 30.2 x18.5x18.1 inch Dimensions HxWxD 712.6x406.1x461 mm 767.6x470.1x461 mm 52.0 lbs 55.8 lbs Weight 23.6 kg 25.3 kg 47.5 quarts 63.4 quarts Storage Volume 45 liters 60 liters Voltage DC 12/24V & AC 110-120V...
-
Page 6: Operation
3 Operation TEMPERATURE Battery Protection Settings Power ON/OFF Button Compressor Speed (MAX/ECO Mode) Temp DOWN Button Temp UP Button... - Page 7 3.1 MAX & ECO Mode TEMPERATURE After the fridge turned on(Press & Hold B/Power Button), you can press the MODE Button C to switch between MAX or ECO mode for the fridge. 3.2 Switch Between °C and °F TEMPERATURE After the fridge turned on(Press & Hold B/Power Button), press and hold Button C and Button D for 3 seconds to switch between the temperature values of Celsius &...
- Page 8 3.3 Setting Temperature TEMPERATURE After the fridge turned on, the fridge's CURRENT interior temperature reading will appear on the display, as a solid non-flashing number. To change the fridge's set temperature: Press Temperature Up (Button E) to increase the temperature. Press Temperature Down (Button D) to decrease the temperature.
- Page 9 3.4 Triple Battery Protection Operation TEMPERATURE After the fridge turned on, press Battery Protection Button A to adjust the fridge's low battery protection level pre-sets. NOTICE: Details of Battery Protection Mode could be found in Page 15. 3.5 USB Connector NOTICE: USB connector only takes effect when charging in DC power cord.
-
Page 10: Cleaning And Maintenance
Cleaning And Maintenance 4.1 Cleaning Always unplug the fridge before cleaning the fridge. You can clean the interior and exterior of the fridge by using warm water, mixed with a gentle non-abrasive detergent. You may use a soft sponge, or micro fiber cloth. - Page 11 4.2 Danger Behavior Use pointed objects to scrape, or defrost ice. Use abrasive detergents to clean. Use heavy duty sponges (due to scratching). Clean the fridge with running water or pressure washer. Clean the fridge without power input covers secured.
-
Page 12: Error Codes & Solutions
Error Codes & Solutions Description Code The DC voltage is below the protection settings and the battery protection mode is activated. The cooling fan is over-loaded with more than 1A of current. Motor start error The motor of compressor is blocked or the pressure difference in the refrigeration system is too high. - Page 13 Solutions If this error code appears when the fridge is operating on 12V DC, please try to lower the battery protection setting and see if the error is resolved. The battery protection mode may be triggered prematurely on certain vehicles due to small wiring imperfections, contributing to a measured DC voltage drop at compressor start-up.
-
Page 14: Warranty & Return Policy
Warranty & Return Policy 30 days refund guarantee upon receiving. 5 years warranty on the compressor. 1 year warranty for other parts or accessories. For returns or exchanges, please call us, or fill out the following return and exchange registration form in the package as a proof of return. -
Page 15: Troubleshooting (Q & A)
Troubleshooting (Q & A) 1. Heat resistance & water resistance Heat resistance ICECO refrigerators are engineered to operate at an ambient temperature of up to 55 °C(131 °F). Weather Proof ICECO refrigerators can operate under light rain conditions. Please keep the vents above clear of water, and please add some clearances to the bottom of the fridge if the ground is wet. - Page 16 2. Why did it change back to the original temperature after setting the temperature? The Solid/Non-Flashing number on the display is the CURRENT interior temperature. The Flashing number is your SET temperature after adjustment. The compressor will shut off when the SET temperature is reached. 3.
- Page 17 10.9 volts. 5. What is the power draw in max/ fast cooling mode? Electrical Electrical Model Model Power Power GO12 JP42 VL35 GO20 Series JP Series VL Series VL45 ProS VL60 ProS VL75 ProD VL90 ProD...
- Page 18 This data is only suitable for laboratory testing, and the actual power is subject to actual conditions. 6. Why is there a temperature difference (between the actual temperature of the refrigerator and the set temperature)? Because of the sinking nature of cold air, the different temperatures may exist in different locations in the refrigerator (the temperature of the bottom will be the lowest).
-
Page 19: Safety Instructions
Safety Instruction SAFETY INSTRUCTIONS Please read the user manual and safety instructions carefully before using the appliance. By ignoring the safety instructions, the manufacturer cannot be held responsible for the damage. The use of accessories that are not recommended by manufacturer can cause injuries and will invalidate any warranty that you may have. - Page 20 ！ Do not leave the refrigerator unattended in uncovered, outdoor areas exposed to the elements. ！ Do not use this appliance near direct heatsources, such as an open flame or radiator. ！ Do not place open containers of liquid inside the fridge. ！...
- Page 21 WARNING! ！ Please keep the fridge in a well ventilated area. ！ Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. ！ Do not use electrical devices inside the food storage compartments of the appliance, unless approved/recommended by the manufacturer.
- Page 22 ！ Do not touch the compressor or the condenser when the fridge is operating. They may be very hot. ！ When setting up the appliance, ensure the supply cord is not trapped or damaged. Further information is provided on the technical data label inside the product.
- Page 23 3. This appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments; bed and breakfast type environments; catering and similar non-retail applications.
- Page 24 Cooler Than A Cooler...
