- Page 1 VL45/60 ProS If you have any questions or concerns, please email us at official@icecofreezer.com...
-
Page 3: Table Of Contents
Catalogue - - - - - - - - - Tips For Opening The Door - - - - - - - - - - - - - - - - - - - - - - Supply Details - - - - - - - - - - - - - - - - - - - - - - - - - - - Operation - - - - - - - - - - Cleaning And Maintenance... -
Page 4: Tips For Opening The Door
Tips For Opening The Door 1. To open the lid left, 2. Push the latch inwards keep fingers together and lift up the lid. and grip the right latch. 3. To open the lid right, 4. Grip the latch on both repeat the above steps. -
Page 5: Supply Details
Supply Details Refrigerator x1 Wire Basket x1 110V AC Wall 12/24V DC Cigarette Outlet Cable X1 Lighter Plug Cable x1 Extra Content Drain Plug Screws Corner Guards Handle Screwdriver... -
Page 6: Operation
3 Operation TEMPERATURE Battery Protection Settings Power ON/OFF Button Compressor Speed (Eco/Max Mode) Temp DOWN Button Temp UP Button... - Page 7 3.1 MAX & ECO Mode With the unit turned on(Press & Hold B/Power Button), you can press the MODE Button C to toggle between MAX or ECO mode for the fridge. TEMPERATURE...
- Page 8 3.2 Switch Between °C and °F With the unit turned on(Press & Hold B/Power Button), press and hold Button C and Button D for 3 seconds to toggle between the temperature values of Celsius & Fahrenheit. TEMPERATURE...
- Page 9 3.3 Setting Temperature With the unit turned on, the fridge's CURRENT interior temperature reading will appear on the display, as a solid non-flashing number. To change the fridge's set temperature: Press Temperature UP Button E to adjust the Temperature UP. Press Temperature DOWN Button D to adjust the Temperature DOWN.
- Page 10 3.5 Triple Battery Protection Operation With the unit turned on, Press Battery Protection Button A to adjust the fridge's low battery protection level pre-sets. TEMPERATURE NOTE: Details of Battery Protection Mode could be found in Page 16.
- Page 11 3.6 USB Connector TIPS: USB connector only takes effect when charging in DC power cord.
-
Page 12: Cleaning And Maintenance
Cleaning And Maintenance 4.1 Cleaning Always disconnect the power source before cleaning the fridge. You can clean the interior and exterior of the fridge by using warm water, mixed with a gentle non-abrasive detergent. You may use a soft sponge, or micro fiber cloth. - Page 13 4.2 DO NOT Use pointed objects to scrape, or defrost ice. Use abrasive detergents to clean. Use heavy duty sponges (due to scratching). Clean the fridge with running water or pressure washer. Clean the fridge without power input covers secured.
-
Page 14: Error Codes & Solutions
Error Codes & Solutions Description Code The DC voltage is below the protection settings and the battery protection mode is activated. The cooling fan is over-loaded with more than 1A of current. Motor start error The motor of compressor is blocked or the pressure difference in the refrigeration system is too high. - Page 15 Solutions 1.If error codes appear on the display If error codes appear when the fridge is powered by 12v source, please confirm whether the current voltage is stable. Because the voltage of the car battery is unstable during driving, it will activate the battery protection function and error codes will display.
-
Page 16: Warranty & Return Policy
Warranty & Return Policy 30-day money back guaranty upon receiving goods. 5-year warranty on the compressor. 1-year warranty for other parts or accessories. For returns or exchanges, please call us, or fill out the following return and exchange registration form in the package as a proof of return. -
Page 17: Troubleshooting (Q & A)
Troubleshooting (Q & A) 1. Heat & Water Resistance Heat resistance ICECO refrigerators are engineered to operate at an ambient temperature of up to 55 °C (131 °F). Weather Proof ICECO refrigerators can operate under light rain conditions. We DO NOT recommend exposing the fridge to moderate or heavy rain. - Page 18 2. Why did it change back to the original temperature after setting the temperature? The Solid/Non-Flashing number on the display is the CURRENT interior temperature. The Flashing number is your SET temperature after adjustment. The compressor will shut off when the SET temperature is reached.
- Page 19 4. What is the function of triple battery protection? How do they work? The triple battery protection is designed to prevent over-discharge and battery depletion. When the measured DC voltage is below the set value, the compressor will shut off to prevent battery depletion. Battery Cut-out Cut-in...
- Page 20 5. What is the electrical power in max/ fast cooling mode? Electrical Electrical Model Model Power Power GO12 JP42 VL35 GO20 Series JP Series VL Series VL45 VL60 ProS ProS VL75 VL90 ProD ProD TIPS: This data is only suitable for laboratory testing, and the actual power is subject to actual conditions.
- Page 21 Due to cold air naturally falling, different temperatures may exist in different locations in the refrigerator (the temperature of the bottom will be the lowest). The panel only shows the center temperature of the refrigerator. 7. What kind of cable do I need to use in the car and at home? Both the AC and DC cables are included with your fridge.
-
Page 22: Safety Instructions
Safety Instruction SAFETY INSTRUCTIONS Please read the user manual and safety instructions carefully before using the appliance. By ignoring the safety instructions, the manufacturer cannot be held responsible for the damage. The use of accessories that are not recommended by manufacturer can cause injuries and will invalidate any warranty that you may have. - Page 23 ！ Do not use the refrigerator in uncovered, outdoor areas exposed to the elements. ！ Do not use this appliance near direct heat sources, for example, a cooker, radiator or exposing it to direct sunlight. Do not place ice or liquids which are not ！...
- Page 24 WARNING! ！ Keep ventilation openings clear of obstruction. 3 inches recommended. ！ Do not use mechanical devices or other means to accelerate the defrosting process, unless recommended by the manufacturer. ！ Do not damage the refrigerant circuit. ！ Do not use electrical appliances inside the food storage compartments of the appliance, unless they are the type recommended by the manufacturer.
- Page 25 ！ Do not touch the compressor or the con-denser. They are hot. ！ When positioning the appliance, ensure the supply cord is not trapped, caught or damaged. ！ Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. Further information is provided on the technical data label inside the product.
- Page 26 3. This appliance is intended to be used in household and similar applications such as staff kitchen areas in shops, offices and other working environments; farm houses and by clients in hotels, motels and other residential type environments; bed and breakfast type environments; catering and similar non-retail applications.
- Page 28 Cooler Than A Cooler...
