Iceco VL75 ProD Manual

Hide thumbs Also See for VL75 ProD:
Table of Contents

Advertisement

Quick Links

Download this manual
VL75/90 ProD
V7.0
SECOP Compressor
Local Technical
5-Year Warranty
Support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VL75 ProD and is the answer not in the manual?

Questions and answers

Related Manuals for Iceco VL75 ProD

Summary of Contents for Iceco VL75 ProD

  • Page 1 VL75/90 ProD V7.0 SECOP Compressor Local Technical 5-Year Warranty Support...

  • Page 2: Table Of Contents

    Catalogue Multi-Directional Lid Opening ..Supply Details ........Operation ................ON/OFF Button ........MAX & ECO Mode ......Switch Between °C to °F ......Setting Temperature ..... Triple Battery Protection Operation ........USB Connector Error Code And Solutions ....Cleaning And Maintenance ..
  • Page 3 What is the speci cation of the fuse of the ........refrigerator? Warranty & Return Policy ....Safety Instructions ......Accessories (Purchase Separately) ........Fridge Accessories ......Power Support Series ....ICECO Portable Fridge Catalog...

  • Page 4: Multi-Directional Lid Opening

    Multi-Directional Lid Opening Our lid can be opened from either side or fully removed for maximum convenience. Right-Side Opening Left-Side Opening Push the right latch inward Repeat the same steps and lift the lid. on the left side. Full Removal Press both latches inward to completely remove the lid.

  • Page 5: Supply Details

    Supply Details VL75 ProD VL75 ProD Basket x 3 Refrigerator x 1 DC Cigarette AC Wall Outlet Cable x 1 Lighter Plug Cable x 1 *Note: The AC cable is usually used for power bank, vehicles, onboard ships with AC sockets.
  • Page 6 VL90 ProD VL90 ProD Basket x 3 Refrigerator x 1 DC Cigarette AC Wall Outlet Cable x 1 Lighter Plug Cable x 1 *Note: The AC cable is usually used for power bank, vehicles, onboard ships with AC sockets. Extra Supplies Drain Plug Screws Corner Guards...
  • Page 7 0°F to 50°F (-18°C to +10°C) Range *Note: Unit can be used with 100-125V~, when connected to an AC cable. If unit is used with 200-240V~, please contact ICECO service team to get another AC cable. The AC cable is usually...

  • Page 8: Operation

    Operation LEFT RIGHT NOTICE: Two display screens correspond to the left and right zone respectively.
  • Page 9 Battery Protection Setting (DC only) Power (Press & Hold to turn on/o ) Compressor Speed (MAX/ECO Mode) Temp. Setting UP (Right Zone) Temp. Setting DOWN (Right Zone) Temp. Setting UP (Left Zone) Temp. Setting DOWN (Left Zone)

  • Page 10: On/Off Button

    3.1 ON/OFF Button When power-on, short press the " " button, the system enters the standby mode; In the standby mode, short press the " " button, the system enters the power-on mode. 3.2 MAX & ECO Mode After the fridge turned on (Press & Hold the " "...

  • Page 11: Setting Temperature

    3.4 Setting Temperature After the fridge turned on, the fridge's CURRENT interior temperature reading will appear on the display, as a solid/non- ashing number. To change the fridge's set temperature: Press Temperature Up ( " " Button) to increase the temperature of the right / left zone;...

  • Page 12: Usb Connector

    3.6 USB Connector DC power cable NOTICE: USB power port only takes e ect when charging in DC power cord.

  • Page 13: Error Code And Solutions

    Error Code And Solutions Error Code And Solutions Description Code The DC Voltage is below the protection settings and the battery protection mode is activated. The cooling fan is over-loaded with more than 1A of current. Repeated switching of the machine or a faulty input voltage causes this motor start error.
  • Page 14 Error Code The DC Voltage is below the protection settings and the battery protection mode is activated. Solutions 1. In case of using in the car, turn the car ignition on and start the refrigerator again; 2. In the case of using the AC cable to connect the electricity at AC socket, you can adjust the battery protection to medium or low mode.
  • Page 15 Error Code Repeated switching of the machine or a faulty input voltage causes this motor start error. The pressure di erence in the refrigeration system is too high. Solutions 1. Make sure to turn o the machine and wait for 5 minutes before turning it on again.
  • Page 16 Error Code Minimum motor speed error, the compressor is over-loaded, and the motor cannot maintain its minimum speed of 1850 rpms. Solutions 1. Make sure to turn o the machine and wait for 5 minutes before turning it on again. If the compressor starts and then stops a few seconds later, it is an E1 fault, and you need to refer to the above E1 troubleshooting method for troubleshooting;...
  • Page 17 Error Code Compressor control module temperature too high or too low protection. (ambient temperature is too high or too low, or the system load is too high, causing the internal temperature of the module/ECU > 212°F or< 14°F) Solutions 1. The compressor will break down at ambient temperatures above 55°C.
  • Page 18 E6/LL Error Code The temperature sensing head is loose or damaged. Solutions 1. Check the temperature sensing head to see if the connection is tight. If it is loose, reconnect it and install it in place. 2. If the sensor head is damaged, replacing the sensor head can solve the problem.

  • Page 19: Cleaning And Maintenance

    Cleaning And Maintenance 5.1 Cleaning Always unplug the fridge before cleaning the fridge. You can clean the interior and exterior of the fridge by using warm water, mixed with a gentle non-abrasive detergent. You may use a soft sponge, or micro ber cloth. When not in use, it’s better to leave the lids open to reduce odors.

  • Page 20: Troubleshooting (Q & A)

    Troubleshooting (Q & A) 6.1 Heat Resistance & Water Resistance Heat Resistance ICECO refrigerators are engineered to operate at an ambient temperature of up to 55°C (131°F). Water Resistance ICECO refrigerators can operate under light rain conditions. Please keep the vents above clear of water, and please add some clearances to the bottom of the fridge if the ground is wet.

  • Page 21: Why Did It Change Back To The Original Temperature After Setting The Temperature

    6.3 Why did it change back to the original temperature after setting the temperature? The Solid/Non-Flashing number on the display is the CURRENT interior temperature. The Flashing number is your SET temperature after adjustment. The compressor will shut o when the SET temperature is reached.

  • Page 22: What Is The Function Of Triple Battery Protection? How Do They Work

    6.6 What is the function of triple battery protection? How do they work? The triple battery protection is designed to prevent over-discharge and battery depletion. When the measured DC voltage is below the set value, the compressor is shut o to prevent battery depletion. VOLTAGE PROTECTION POSITION HIGH...

  • Page 23: What Is The 24 Hours Power Consumption

    JP50 VL45 ProS 0.482 KW·H 0.510 KW·H VL45 VL60 ProS 0.348 KW·H 0.548 KW·H VL60 VL75 ProD 0.416 KW·H 0.636 KW·H VL65 VL90 ProD 0.545 KW·H 0.658 KW·H VL74 0.562 KW·H This data is only suitable for laboratory testing, and the actual power consumption is subject to actual conditions.

  • Page 24: Warranty & Return Policy

    Please call us: +1 (888) 606 1046 (Mon-Fri 9:00am-6:00pm PT) Please email us: cial@icecofreezer.com (for Amazon/Walmart orders) support@icecofreezer.com for website orders support@iceco-us.com for other orders *Please let us know your order number rst for a quick solution.
  • Page 25 If the product is received damaged or defective during transportation, you will need to contact our customer service within 2 business days. Make sure to provide relevant photos or videos, your order ID number, and your name. A customer service agent will help assist into solving the issue at a timely manner (Return, Exchange, or Discount Compensation).

  • Page 26: Safety Instructions

    Safety Instruction Please read the user manual and safety instructions carefully before using the appliance. By ignoring the safety instructions, the manufacturer cannot be held responsible for the damage. The use of accessories that are not recommended by manufacturer can cause injuries and will invalidate any warranty that you may have.
  • Page 27 Please don't put hot/warm food into the fridge directly without letting it cooling o . Place/arrange the content of your fridge securely when using the refrigerator inside a moving vehicle. To maximize energy savings, please make sure the lid is closed and secure, and only open the fridge when you need to.
  • Page 28 WARNING! Please keep the fridge in a well ventilated area. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not use electrical devices inside the food storage compartments of the appliance, unless approved/recommended by the manufacturer.
  • Page 29 Further information is provided on the technical data label inside the product. 1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 30 DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: *Take o the doors. *Leave the shelves in place so that children may not easily climb inside.
  • Page 31 FCC warning: Any Changes or modi cations not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 32: Accessories (Purchase Separately)

    Accessories (Purchase Separately) 9.1 Fridge Accessories Insulated Cover Slide Mount Tie Down Kit VL75/90 ProD VL75 ProD VL75/90 ProD 9.2 Power Support Series PB250 PB1000 250Wh 1057Wh Battery Solar Panel Magnetic Battery...

  • Page 33: Iceco Portable Fridge Catalog

    9.3 ICECO Portable Fridge Catalog Dual Zone Capacity 21 quarts Cooling Range 0°F to 50°F Consumption 0.433 (KW.H/24H) Product Weight 27.5 lbs GO20 Product dimension 22.4 x 12.6 x 12.4 White/Gray (L*W*H) inches /Other limited colors Single Zone Capacity 31/40/50 quarts Cooling Range -4°F to 68°F...
  • Page 34 Single Zone Capacity 47/78 quarts Cooling Range 0°F to 50°F Consumption 0.4348/0.416 (KW.H/24H) Product Weight 50.6/62.5 lbs Product dimension 27.4 x 15.8 x 19.2/ VL45/74 (L*W*H) 32.3 x 19.4 x 19.6 Green/Other limited colors inches Single Zone Dual Zone Capacity 63/68 quarts Cooling Range 0°F to 50°F...
  • Page 35 Dual Zone Capacity 79/95 quarts Cooling Range 0°F to 50°F Consumption 0.636/0.658 (KW.H/24H) Product Weight 69.6/75.1 lbs VL75/90 Product dimension 36.5 x 18.5 x 18.1/ ProD (L*W*H) 38.3 x 20.7 x 18.1 Black/Other limited colors inches Single Zone/Dual Zone Capacity 21/37 quarts Cooling Range -4°F to 68°F...
  • Page 36 Cooler Than A Cooler +1 (888) 606 1046 (Mon-Fri 9:00am-6:00pm PT) cial@icecofreezer.com (for Amazon/Walmart orders) support@icecofreezer.com (for website orders) support@iceco-us.com (for other orders)
