Zephyr ZGS-11000-2 v2 Operation And Maintenance Manual page 2

Manual RHGSE Operation and Maintenance Manual
DEFINITIONS OF WARNINGS, CAUTIONS and NOTES contained in this manual
Shall be used when there is danger of injury or death to personnel.
Shall be used to highlight essential procedures or statements which may facilitate performance
Table 1 - Warning and Caution Symbols used through the manual.
Warning
Warning Hot Surface Burn Hazard
Warning Moving Parts
Must Wear Eye Protection
Switch Off Before Operating
Before operation of the Ground Support Equipment, thoroughly review the entire manual in order to prevent
During regular cable maintenance using the RHGSE with a cable load up to a 600 lbs. (272.15kg) load is
possible. However the RHGSE should not be used repeatedly at 600 lbs. (272.15kg) without relieving the twist
from the cable by extended the cable in flight, because it can add a twist the cable. The maximum sustained
load should not be above 300 lbs. (136.08kg) for repetitive evolutions.
During cable pre-conditioning the RHGSE should be used with loads up to no more than 300 lbs. (136.08kg).
Then the cable should be extended in flight and retracted with 200 lbs. (90.71kg) maximum, to allow the cable to
relieve the twist imparted during the process of acclimating the cable to the Hoist Brake Drum.
This manual contains proprietary information and is not to be copied or disclosed without written permission from Zephyr International LLC
Shall be used when there is danger of damage to equipment
of a procedure or operation.
Limitations, Warnings and Cautions
damage to the cable, hoist, helicopter or operator.
LIMITATION CAUTION DURING REGULAR OPERATIONS
LIMITATION CAUTION DURING CABLE PRECONDITIONING
Copyright 2002-2015
WARNING
CAUTION
NOTE
Warning Electrical Hazard
Warning Lifting Hazard
Warning Strong Magnetic Field
Must Wear Hand Protection
WARNING
ZOM-11000-2 v2 Rev G
.
Page 2 of 38
