Table of Contents Getting to Know Your System Kit ������������������������������������������������������������������������������������������������������������������������������������������������3 Understanding Your Tablet Icons ������������������������������������������������������������������������������������������������������������������������������������������������4 Sensor Setup �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������5 Your Study Night ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 The Morning After Your Study ������������������������������������������������������������������������������������������������������������������������������������������������������8 Intended Use and Cautions ������������������������������������������������������������������������������������������������������������������������������������������������������������9 Intended Use ���� �����������������������������������������������������������������������������������������������������������������������������������������������������������������������9 Product Overview �������������������������������������������������������������������������������������������������������������������������������������������������������������������9 Contraindications �������������������������������������������������������������������������������������������������������������������������������������������������������������������9 Notes �������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������9 Cautions ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������...
Getting to Know Your System Kit Your Tablet Your Recorder Important Features Tablet Power Button Recorder Pair Button Recorder Pause Button Your Sensors Effort Belt Nasal Cannula Pulse Oximeter * If Provided. Only used when a Sleep Theragnostic is ordered. Important: Charge your Tablet and Recorder when you arrive home and after each study night Before and after use, inspect the trays for damage to the...
These Icons will appear at the top of your Tablet’s screen At a glance you will see the status of your • MATRx plus system� The color of the icon will change from white • to green when each component is properly connected and ready for use�...
Sensor Setup Note: Use this page as a guide when viewing your Tablet’s how-to videos on Sensor setup. 1. Connect Recorder and Tablet *If prompted by Tablet 2. Confirm Range of Motion Warning: If the range of motion values are not the same, stop the test and contact your Healthcare Provider.
Page 6
Nasal Cannula Pulse Oximeter Note: Remove nail polish or false nail from your finger. Note: Connect if provided.
Your Study Night Prep Check Plug In For Sleep Sensors working Tablet plugged in Ready Start Sleep for Sleep Note: Sleep in your normal body position. 7 Hours Sweet dreams! Good morning! Good night! If you feel the If you need If your hear Helpful MP move...
The Morning After Your Study If More Nights Are Needed Plug-in your Recorder and Tablet If Provided, rinse Trays under cold water. Caution: Do not wet any other parts of the system. Store your System Kit out-of-reach of children and pets until your next study night.
Intended Use and Cautions Intended Use The MATRx plus is indicated for use by a lay person in a home and hospital environment under the direction of a Healthcare Professional (HCP)� MATRx plus records the following data: patient respiratory nasal airflow, snoring, blood oxygen saturation, pulse, respiratory effort and body position during sleep�...
Cautions Only use with Zephyr approved parts and accessories� Do not blow into the Nasal Cannula connection to avoid causing damage� Avoid electrostatic discharge� The relative humidity should be at least 5%� Avoid impeded blood flow (e�g� blood pressure cuff ) as this may affect pulse and saturation measurements�...
• Dry mouth • Use of the MATRx plus may cause disruption in sleep from the use of the sensors and Mandibular Positioner� Stop use of the device during a Sleep Theragnostic if you experience any of the following: •...
Page 12
Avoid the use of drugs and alcohol prior to your night study� Choking hazard: Keep the system out of reach of children and pets� Discontinue the study if any parts of the MATRx plus Recorder, Tablet, sensors, Titration Trays and/or retention material show damage�...
Frequently Asked Questions What should I do if I have to get up during the study? Do not remove any sensors • Pause the study by using the button on the Recorder or Tablet • • When you are ready to go back to sleep, press the same button on the Recorder or the Resume button on the Tablet What should I do if I can’t sleep? Pause and resume the study by using the button on the Recorder�...
System Troubleshooting Patient Tablet Error Messages ERROR TITLE ERROR MESSAGE CAUSE / ACTIONS Incorrect date of birth Check the entered birth data and Re-enter your date of birth • Incorrect Date of Birth try again� If error continues, contact your •...
Page 15
ERROR TITLE ERROR MESSAGE CAUSE / ACTIONS Tablet is not plugged into power, power adapter is not connected properly or electrical outlet is not functioning� Confirm power adapter is correctly • plugged into the Tablet and an Tablet Not Plugged in Confirm the Tablet is plugged in�...
Page 16
ERROR TITLE ERROR MESSAGE CAUSE / ACTIONS The MP motor has stalled� This may be caused by pushing Press Continue and this will pause tray • against the trays while they movement for 30 minutes and allow are moving in your mouth� To you to fall asleep MP Error correct this error, press Continue...
Zephyr Sleep Technologies #102, 701 64th Ave� S�E� Calgary, Alberta, Canada T2H 2C3 Toll Free: 1�877�341�8814 Technical Support: 1�877�227�9832 Email: info@zephyrsleep�com www.zephyrsleep.com Trademarks and Patents MATRx plus™ is a trademark of Zephyr Sleep Technologies Inc� other trademarks property their respective holders� This device is covered under one or more patents as set forth at www�zephyrsleep�com/patents...
Manufacturer Declaration for Emissions Essential Performance The prevention of excessive mandibular motion is considered Essential Performance of the MATRx plus device� Excessive mandibular motion is mitigated by design� EMC Standards and Testing TABLE 1: EMC TEST LIMITS Phenomenon Basic EMC Standard...
Page 19
TABLE 1: EMC TEST LIMITS Frequency Range Dwell Time (s) Test Level (V/m) Modulation Frequency 1720 1845 1970 2450 5240 5500 5785...
The radiated energy from the MATRx plus conforms to the FCC limit of the SAR (Specific Absorption Rate) requirement set forth in 47 CFR Part 2 section 1093� The radiated energy from the Zephyr Wireless MATRx plus antennas conforms to the IC limit of the RF exposure requirement regarding IC RSS-102, Issue 2 clause 4�2�...
