Oasis BV700 Series Instruction Manual
Actuated ball valve npt
Hide thumbs
Also See for BV700 Series:
- Instruction manual (15 pages) ,
- Instruction manual (11 pages) ,
- Instruction manual (11 pages)
Advertisement
Quick Links
BV700 Series
Actuated Ball Valve NPT
Instruction Manual
Failure to follow these instructions or to properly install and maintain this equipment could result in gas leak-
age, fire or explosion causing property damage and personal injury or death.
Oasis products must be installed, operated and maintained by trained and competent personnel in
accordance with all applicable local codes, rules and regulations in addition to the Oasis Instructions.
Oasis Engineering Ltd. will not be held liable in such circumstances where installation, operation and
maintenance procedures were performed by incompetent personnel resulting in improper assembly, unsafe
operation, equipment damage or personal injury.
Oasis recommends that all service technicians should watch the Product Servicing Video before attempting to
service this part.
Oasis Engineering Ltd
129 Birch Avenue, Tauranga, New Zealand.
T: +64 7 928 3808
E: info@oasisNGV.com
W: www.OasisNGV.com
Servicing Video
Instruction Manual
Advertisement
Related Manuals for Oasis BV700 Series
Summary of Contents for Oasis BV700 Series
- Page 1 Oasis products must be installed, operated and maintained by trained and competent personnel in accordance with all applicable local codes, rules and regulations in addition to the Oasis Instructions. Oasis Engineering Ltd. will not be held liable in such circumstances where installation, operation and maintenance procedures were performed by incompetent personnel resulting in improper assembly, unsafe operation, equipment damage or personal injury.
-
Page 2: Tools Required
High pressure gas and gas equipment can cause serious harm to both infrastructure and personnel if safety precautions are not followed. Oasis recommends considering the use of the following PPE when working with high pressure along with any other site specific health and safety requirements:... -
Page 3: Installation
4. Insert the ball valve into the actuator the nut. mount so that the stop pin goes in first. BV700-INS-03 2822 © Oasis Engineering Limited BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. - Page 4 BV708 = 4Nm 8. Tighten on the actuator ensuring the drive 7. Install the drive dog over the stem. dog is correctly located. BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 5 BV700-INS-03 2822 © Oasis Engineering Limited BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. We reserve the right to modify product specifications without prior notice.
- Page 6 Installation Instructions Oasis recommends that for valves bigger than 3/4” the actuator bracket is mounted separately using the mounting holes in the supplied actuator bracket. BV702/703/704 Actuator Bracket Design BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
-
Page 7: Mounting Holes
Mounting holes For mounting holes pattern please refer to Actuated Ball Valves Specification sheet. BV700-INS-03 2822 © Oasis Engineering Limited BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. We reserve the right to modify product specifications without prior notice. -
Page 8: Operation
Recommended Spanners for End Caps: BV702 = 25mm BV703 = 28mm BV704 = 34mm BV706 = 50mm BV708 = 60mm BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. - Page 9 **It is normal for the service kit to include a ball with a small hole in the bottom ^For low pressure service kits, the seats will be supplied with an O-ring installed The Complete Oasis Seal Kit must be used Tools Required...
- Page 10 6. Remove nut and tab. Open and close valve to ensure all trapped gas is released 9.Discard seat. 8. Remove end cap. 7. Discard gland. BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 11 12. Remove and discard 2nd seat Do not scratch body BV700-INS-03 2822 © Oasis Engineering Limited BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. We reserve the right to modify product specifications without prior notice.
- Page 12 13. Remove cap O-ring and discard. 13. Remove cap O-rings and discard. 14. Clean body and end cap, visually check parts for damage BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 13 3. Insert stem assembly. 3. Insert first seat. Click BV700-INS-03 2822 © Oasis Engineering Limited BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. We reserve the right to modify product specifications without prior notice.
- Page 14 Take care not to pinch O-ring when in- stall in cap. Take care not to pinch O-ring stalling low pressure seat when installing low pressure seat. BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 15 4 on page 3 for so that it is tight against the nut . re-installation of product. BV700-INS-03 2822 © Oasis Engineering Limited BV700-INS-03 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
