BV700 Series
Ball Valve with Vent NPT
Instruction Manual
Failure to follow these instructions or to properly install and maintain this equipment could result in gas leak-
age, fire or explosion causing property damage and personal injury or death.
Oasis products must be installed, operated and maintained by trained and competent personnel in
accordance with all applicable local codes, rules and regulations in addition to the Oasis Instructions.
Oasis Engineering Ltd. will not be held liable in such circumstances where installation, operation and
maintenance procedures were performed by incompetent personnel resulting in improper assembly, unsafe
operation, equipment damage or personal injury.
Oasis recommends that all service technicians should watch the Product Servicing Video before attempting to
service this part.
Oasis Engineering Ltd
129 Birch Avenue, Tauranga, New Zealand.
T: +64 7 928 3808
E: info@oasisNGV.com
W: www.OasisNGV.com
Servicing Video
Instruction Manual
Advertisement
Related Manuals for Oasis BV700 Series
Summary of Contents for Oasis BV700 Series
- Page 1 Oasis products must be installed, operated and maintained by trained and competent personnel in accordance with all applicable local codes, rules and regulations in addition to the Oasis Instructions. Oasis Engineering Ltd. will not be held liable in such circumstances where installation, operation and maintenance procedures were performed by incompetent personnel resulting in improper assembly, unsafe operation, equipment damage or personal injury.
-
Page 2: Tools Required
High pressure gas and gas equipment can cause serious harm to both infrastructure and personnel if safety precautions are not followed. Oasis recommends considering the use of the following PPE when working with high pressure along with any other site specific health and safety requirements:... -
Page 3: Installation Instructions
BV700-INS-06 2822 © Oasis Engineering Limited BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. We reserve the right to modify product specifications without prior notice. - Page 4 Actuate valve 4 times before use to ensure initial sealing. 3. Open vent and vent gas. 4. Close vent when all gas is vented. Vents BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 5 **It is normal for the service kit to include a ball with a small hole in the bottom. ^ For low pressure service kits, seats will be supplied with an O-ring installed. The Complete Oasis Seal Kit must be used Tools Required...
- Page 6 With the valve removed open and close valve to ensure all trapped gas is released 4. Discard gland. 3. Remove handle. BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 7 8. Remove and discard stem. 7. Remove and discard ball. BV700-INS-06 2822 © Oasis Engineering Limited BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. We reserve the right to modify product specifications without prior notice.
- Page 8 Do not scratch body with pick tool 10. Remove Cap O-ring/backup and discard. 11. Clean body and end cap. Visually check parts for damage. BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 9 3. Insert the stem assembly. 4. Insert the ball. Click BV700-INS-06 2822 © Oasis Engineering Limited BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. We reserve the right to modify product specifications without prior notice.
- Page 10 Recommended End Cap Torque: BV706 = 120 Nm BV708 = 120 Nm 7. Install gland. 8. Install handle, spring washer and nut. BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 11 BV708 = 6 Nm 10. Re-install as per the instruction on page 3, leak test on first re-use. BV700-INS-06 2822 © Oasis Engineering Limited BV700-INS-06 2822 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
