BV700 Series
Actuated Ball Valve SAE
Instruction Manual
Failure to follow these instructions or to properly install and maintain this equipment could result in gas
leakage, fire or explosion causing property damage and personal injury or death.
Oasis products must be installed, operated and maintained by trained and competent personnel in
accordance with all applicable local codes, rules and regulations in addition to the Oasis Instructions.
Oasis Engineering Ltd. will not be held liable in such circumstances where installation, operation and
maintenance procedures were performed by incompetent personnel resulting in improper assembly, unsafe
operation, equipment damage or personal injury.
Oasis Engineering Ltd
129 Birch Avenue, Tauranga, New Zealand.
T: +64 7 928 3808 F: +64 7 928 3809
E: info@oasisNGV.com
W: www.OasisNGV.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Oasis BV700 Series
Summary of Contents for Oasis BV700 Series
- Page 1 Oasis products must be installed, operated and maintained by trained and competent personnel in accordance with all applicable local codes, rules and regulations in addition to the Oasis Instructions. Oasis Engineering Ltd. will not be held liable in such circumstances where installation, operation and maintenance procedures were performed by incompetent personnel resulting in improper assembly, unsafe operation, equipment damage or personal injury.
-
Page 2: Tools Required
High pressure gas and gas equipment can cause serious harm to both infrastructure and personnel if safety precautions are not followed. Oasis recommends considering the use of the following PPE when working with high pressure along with any other site specific health and safety requirements:... -
Page 3: Installation Instructions
3. Use pliers and crush the lock tab onto 4. Insert the ball valve into the actuator the nut. mount so that the stop pin goes in first. BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice. - Page 4 BV708 = 4Nm 8. Tighten on the actuator ensuring the drive 7. Install the drive dog over the stem. dog is correctly located. BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 5 6. Assembly is complete. bottom out on the port face and the O-ring should neatly fill the void creating the seal. Faces touch O-ring BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 6 Installation Instructions Oasis recommends that for valves bigger than 3/4” the actuator bracket is mounted separately using the mounting holes in the supplied actuator bracket. BV702/703/704 Actuator Bracket Design BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 7 Installation Instructions BV706/708 Actuator Bracket Design Mounting holes For mounting holes pattern please refer to Actuated Ball Valves Specification sheet. BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 8 Recommended Spanners for End Caps: BV702 = 25mm BV703 = 28mm BV704 = 34mm BV706 = 50mm BV708 = 60mm BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 9 (BV708 - 916 Nitrile 90, ^ For low pressure service kits, the seats will be supplied with an O-ring installed 920 Nitrile 90 for Matched Bore Valves) The Complete Oasis Seal Kit must be used Tools Required Small flat screw driver...
- Page 10 6. Remove nut and tab. Open and close valve to ensure all trapped gas is released 9.Discard seat. 8. Remove end cap. 7. Discard gland. BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 11 11. Remove stem first. Do not scratch body 12. Remove and discard stem. 12. Remove and discard 2nd seat. Do not scratch body BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 12 14. Remove cap O-ring and discard. 14. Remove cap O-rings and discard. 15. Clean body and end cap, visually check parts for damage. BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 13 2. Insert stem assembly first. install. Take care not to pinch O-ring when installing low pressure seat Click 3. Insert stem assembly. 3. Insert first seat. Click BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 14 Take care not to pinch O-ring when in cap. Take care not to pinch O-ring when in- installing low pressure seat stalling low pressure seat. BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
- Page 15 10. Using pliers bend the lock tab upwards structions from step 4 on page 3 for so that it is tight against the nut . re-installation of product. BV700-INS-04 3618 © Oasis Engineering Limited We reserve the right to modify product specifications without prior notice.
