- Page 1 Frame and Door Installation Manual Pass Thru Series Rev. C - 2022 99-18745-I001...
- Page 2 Frame and Door Installation Manual 103 Series Applicable Models Pass-Thru Series 103B, 103N, 403B, 403N, 403I, 403W, 213Z,23ZN, ELC3,EL13,103T Copyright © 2021 by ALL rights reserved. Information in this document is subject to change without notice. Companies, names and data used in examples herein are fictitious unless otherwise noted.
-
Page 3: Table Of Contents
Frame and Door Installation Manual 103 Series TABLE OF CONTENTS 1. PRELIMINARY CONSIDERATIONS FOR DOOR AND FRAME SERVICING PROCEDURES ......4 1.1. Safety................................4 1.2. Tools ................................4 1.3. Tips ................................4 2. NET OPENING AND FRAME INSTALLATION…………….................5 2.1. Net Opening and Frame Installation ……………………………………………………………………………..5 2.2. -
Page 4: Preliminary Considerations For Door And Frame Servicing Procedures
Frame and Door Installation Manual 103 Series PRELIMINARY CONSIDERATIONS FOR DOOR AND FRAME SERVICING PROCEDURES 1.1. Safety Proper safety equipment includes: NOTE: Turn off all electrical power prior to beginning work on the door or on any electrical equipment. Use extra caution when working with or around the door glass package. -
Page 5: Net Opening And Frame Installation
Frame and Door Installation Manual 103 Series 2. FRAME INSTALLATION AND SERVICE MAINTENANCE 2.1 Net Opening and Frame Installation Read instructions completely before installing the frame. Before installing the frame, confirm that the size of the net opening accommodates the finish frame, net opening should be 1/8” larger than the frame size, this is 1/16”... - Page 6 Frame and Door Installation Manual 103 Series ``If everything is aligned, squared, plumb and gaps do not exceed 1/16” skip the shimming process and proceed to sealing the Frame refer to “Sealing the Frame” below for instructions. The following instructions will ensure properly shim frame when necessary: 1.
- Page 7 Frame and Door Installation Manual 103 Series To Install a Pass Thru Frame with Threshold NOTES: 1. If a Roll-A-Way cart is included in the order, it must be behind the door before installing the frame. 2. Standard Roll-A-Way Application-Roll-A-Way is a permanent fixture of case. 3.
-
Page 8: Sealing The Frame
Frame and Door Installation Manual 103 Series Sealing the Frame 2.4. The electrical connection at the Junction Box where the wires enter the frame, and where the wires enter the raceway in the frame must be sealed with NSF Approved Food Grade Silicone Sealant (RTV-108) at the time of installation. -
Page 9: Frame Electrical Wiring Connections
Frame and Door Installation Manual 103 Series 2.5. Frame Electrical Wiring Connections Wire Diagram Connection Label Wiring Diagram The seven individual wires extending from the flexible conduit atop the frame, provide electrical power to various frame and door functions for the wiring diagram label, affixed to the frame header. -
Page 10: Door Installation
Frame and Door Installation Manual 103 Series WIRING DIAGRAM DOOR INSTALLATION 3.1. To Install the Door Assembly 1. Hold the door on each side, with the handle facing forward. Lift door, align torque rod to insert into TorqueMaster™ socket at base of frame. Insert Torque Rod 2. -
Page 11: To Remove The Door Assembly
Frame and Door Installation Manual 103 Series 3. Insert the hold-open bolt through the elongated hold-open slot. 4. Insert the hold open through stand-off and secure it with a Phillips screw (provided) using a #2 Philips screwdriver. Keep the screwdriver perpendicular to the screw head. - Page 12 Frame and Door Installation Manual 103 Series 3. Retract the door to a near-closed position. 4. Remove hinge pin plug from frame by inserting top-half of needle-nose pliers into the spring clip grip hole and the bottom half beneath the hinge pin shroud. Disengage Hinge Pin 5.
-
Page 13: To Reverse The Door Swing
Frame and Door Installation Manual 103 Series 3.3. To Reverse the Door Swing Some doors are reversible. Remove the door from the frame first and then perform the following steps. 3.3.1. Frame 1. To remove Torquemaster, insert flat-head screwdriver into top center cutout in Torquemaster, and turn mounting screw counter-clockwise for less than ½... -
Page 14: Door
Frame and Door Installation Manual 103 Series 5. Relocate and install the hold-open stand-offs and spacer into the opposite hold-open mount of the same doorframe. 3.3.2. Door Insert Stand-Off 1. Access the hinge pin wire connections in the rail on the hinge side of the door assembly. -
Page 15: Torquemaster™ And Sag Adjustment
Frame and Door Installation Manual 103 Series 7. Check and confirm torque rod and hinge pin are correctly installed. 8. Reinstall the door into the frame per the door installation procedures. TORQUEMASTER™ AND SAG ADJUSTMENT The TorqueMaster™ regulates the door alignment and the door closing tension. Remove Torque Rod 1. -
Page 16: Section 5 - Cooler/Freezer* Store Condition Requirements
Frame and Door Installation Manual 103 Series Section 5 - Cooler/Freezer* Store Condition Requirements The installation of Anthony doors in various applications require specific store conditions to achieve optimal performance. Please note that ambient conditions in your store may vary throughout the day. Anthony/ Anthony Doors are built to ANSI/ASHRAE Standard 72-2014 Test Standard. -
Page 17: Appendix A - Preventative Maintenance Guidelines
Frame and Door Installation Manual 103 Series APPENDIX A - PREVENTATIVE MAINTENANCE GUIDELINES Introduction This guideline provides information required to perform recommended and required preventative maintenance to the Anthony doors and frame. Routine Preventative Maintenance The following provides information needed to safely perform regular periodical preventive maintenance. Regular preventative inspections will maximize the longevity of your Anthony products. - Page 18 Frame and Door Installation Manual 103 Series Recommendations Here is an outline of standard recommend Preventative Inspection criteria: Freezer/Cooler Temp & Defrost Settings • – Regularly inspect and ensure that ambient conditions are correct* Ensure HVAC vents do not blow directly on doors Avoid direct evaporator air impingement on the cooler/freezer door.
- Page 19 Frame and Door Installation Manual 103 Series Gaskets • – When inspecting gaskets ensure that they are sealing properly along the entire perimeter of the door. Also, ensure that the gasket is properly inserted into the door plastic grove. Inspect and ensure gaskets are free of cracks, tears, deformities, and hardening.
- Page 20 Frame and Door Installation Manual 103 Series Troubleshooting PROBLEM / ISSUE PROBABLE CAUSES / FIXES FINAL REMEDY Fan to Door Proximity too small Condensation on Door Glass, Install air deflector Door Rail, or Frame Evaporator fans blowing cold air directly onto glass/frames Shelves not fully stocked Stock merchandise Door/gasket seal malfunction...
-
Page 21: Revision History Page
Frame and Door Installation Manual 103 Series PROBLEM / ISSUE PROBABLE CAUSES / FIXES FINAL REMEDY Check power supply Check humidity controller No Power Check Hinge Pin connections Check glass wire connections Glass condensation Check Hinge Pin wiring Check main voltage Low voltage Check humidity controller Check power supply...
