Summary of Contents for Dover Anthony Complete 101 Series

Page 1 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B –– Copyright © 2022 Anthony, Inc. An Anthony Company All rights reserved. Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without permission of Anthony, Inc. All product and company names are trademarks or registered ®...
Page 2 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Anthony Locations Anthony is a manufacturer and solutions provider of glass doors, lighting systems, and display equipment for use in commercial refrigeration systems. For more information on Anthony, please visit www.anthonyintl.com. North America Locations Sylmar, CA Madison, GA...
Page 3: Applicable Walk -I N Models
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Applicable Walk-In Models 101 Series 101N, 101T, 101B Applicable Pass-Thru Models 103 Series 103N, 103T, 103B Copyright © 2022 Anthony, Inc. Anthony Company All rights reserved. Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without permission of Anthony, Inc.
Page 4: Table Of Contents
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Table of Contents ................................. 2 PPLICABLE ODELS ................................2 PPLICABLE ODELS INTRODUCTION ................................... 7 ................................. 7 ROPER USE OF NTHONY RODUCTS ................................... 7 UALIFIED ERSONNEL SECTION 1 - SAFETY ..................................8 ....................................
Page 5 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B SECTION 4 – DOOR INSTALLATION ............................. 31 ....................................31 ANDLING .................................... 31 NSTALLATION Figure 4.1: Seating Door onto Torque Master ........................32 Figure 4.2: Dielectric Grease in SOCKET (hinge pin plug) receptacle .................. 33 Figure 4.3: Engage Hinge Pin to Frame ..........................
Page 6 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B SECTION 15 – REMOVING & REPLACING THE HINGE PIN ......................61 SECTION 16 - TORQUE MASTER REPLACEMENT .......................... 64 Figure 16.1: Torque Master Replacement .......................... 64 SECTION 17 – PASS-THRU FRAME AND DOOR INSTALLATION ..................... 66 ....................................
Page 7 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B APPENDIX B – DOOR REVERSAL ..............................97 Frame ....................................97 Door 98 APPENDIX C – ANTI-FOG MAINTENANCE ..........................100 Care and Cleaning ................................100 APPENDIX D – POM LOCK INSTALLATION ..........................100 Figure D.1: Pom Lock Specifications ..........................
Page 8: Introduction
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Introduction This manual provides information required to perform installation, repairs, and required maintenance to the Anthony Frames and Doors. This manual is intended as a written guide for personnel who are properly trained and qualified to safely use a variety of different equipment and tools required during the installation, repairs, and performing maintenance of the Anthony Frames and Doors.
Page 9: Section 1 - Safety
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 1 - Safety Safety Messages This manual includes general, task-specific, and important Safety Messages. Each Safety Message includes several elements, Signal Words, Safety Alert Symbols, Safety Colors, and Safety Message. The following is an example of a safety message with all elements included. These Safety Messages are defined by the level of severity and are found throughout the manual indicating measures that must be taken while performing the specific task at hand.
Page 10: Safety Alerts Symbols
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Safety Alerts Symbols Your safety and the safety of others are very important. The following Safety Alert Symbols will be used in conjunction with the Safety Messages to warn of potential risks when installing or maintaining your Anthony Door. These Safety Alert Symbols communicate hazardous information quickly and reinforce the Safety Message without the use of words and across language barriers.
Page 11: Safety Equipment - Personal Protective Equipment
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B • Always keep the work area clean. • Pay attention to the risks presented by obstacles or other people in the work area. • Avoid all electrical dangers. • Pay attention to the risks of electric shock or arc flash hazards. •...
Page 12: Equipment List & Tools
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Equipment List & Tools The following is a list of all the different equipment, tools, materials, and other things you will need when installing the Anthony 101N Frame and doors. Equipment: Frame/Door Installation: Tools:...
Page 13: Section 2 - Standard Walk-In Line-Up Frame Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 2 – Standard Walk-In Line-Up Frame Installation Tools Required Refer to “Equipment List & Tools” in Section 1 for a complete list of all equipment, tools, materials, and other things needed for installation. If the Frames are not installed upon arrival, they should be protected from the environmental conditions, and ensure storage of the product indoors at a normal room temperature of 75°F or less, do not store outside, weather can damage the frame and cause issues such as plastic deformation.
Page 14: Frame Handling During Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Frame Handling during Installation During installation take special care not to push on or use mullions to lift the frame. Applying force to mullions may cause damage and affect the frame's optimal performance. If needed, we recommend using either a Sliding or Speed Clamp to align and squeeze the Frame into the net opening (see Figure 2.2).
Page 15 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Keep doors and frames clean for product efficiency. This can also help reduce energy consumption and potential health hazards. Whenever binding gasket or plastic parts only use food-grade silicone. Always use the correct tool for the job to be performed. This ensures proper installation and minimizes safety risks. If there is any doubt about the work to be performed, consult with a certified technician or Anthony/Anthony representative.
Page 16: Net Opening & Frame Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Net Opening & Frame installation Read the instructions in this Section completely before installing the frame. Before installing the frame, confirm that the size of the net opening accommodates the finished frame, net opening should be larger by 1/8” than the frame size, there should be a gap of 1/8" on top, 1/8"...
Page 17 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 2.4: Frame Alignment, Squareness, and Plumb WARNING Warning: Use only food-grade silicone sealant (add caulking for larger gaps) to seal the gap between the frame and the surrounding wall, inside the case, cooler or freezer. Not following these procedures can void Anthony’s Service &...
Page 18: Shimming The Frame
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Shimming the Frame Shimming is only to be used when necessary and will primarily be done at the header (top) of the frame and opening. If the gap between the frame and net opening is greater than 1/8”, proceed to shim the gap for a proper fit.
Page 19: Properly Sealing The Frame
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Properly Sealing the Frame The electrical connection at the Junction Box where the wires enter the frame, and where the wires enter the raceway in the frame must be sealed with NSF Approved Food Grade Silicone Sealant (RTV-108) at the time of installation. Ensure to seal the gap between the frame and the surrounding wall, inside the case, cooler or freezer.
Page 20: Continuous Lineup Frame Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Continuous Lineup Frame Installation Use the following instructions for walk-in line-ups when more than one frame section(s) is required (applies to 101N, 101B & 101T walk-in configurations with more than one frame). These instructions will guide you on how to install multiple frames using the provided T-Trim(s) which seals the gap between any two (2) frames.
Page 21: Three (3) Or More Frame Sections Line-Up
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 2.6: T-Trim installation Three (3) or more Frame Sections Line-up The following instructions are for installations that required three (3) or more frame sections: To begin, set the first frame (ensure that the first frame has a full flange on the right side and continuous flange on the left side) against the far-right side of the net opening/case opening and install according to instructions previously noted in this section ensuring to square, plumb, secure, and seal the first frame (shim if needed).
Page 22 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 2.6: Continuous frame sections layout Once the first frame, T-Trim, and second frame are in place, insert binding bolts (sex bolts) through the right side of the first frame, and into the left side of the second frame. Tighten until frames are pulled together. Refer to Figure 2.7. Figure 2.7: T-Trim installation Once the two frame sections and T-Trim are together and secured, ensure to square, plumb, secure, and seal the second frame (shim if needed).
Page 23 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 2.8: Last Frame installation After installing the second to last frame Insert a T-Trims on both ends of the second to the last frame and install according to instructions in Step 3. This will ensure the sealing of all installed frames. Refer to Figure 2.9 Figure 2.9: Second to Last Frame installation Once all frames and T-Trims have been installed, seal the entire line-up from inside of the case, caulking all four sides of the frame, in between the frame and net opening, and in any gaps left on the back end of the frames caused using the T-Trim(s)
Page 24: Frame Electrical Wiring Connections
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Frame Electrical Wiring Connections The electrical connection at the Junction Box where the wires enter the frame, and where the wires enter the raceway in the frame must be sealed with silicone caulking at the time of installation. WARNING Stop: Wiring for lights should have a separate circuit from the door/frame heater wiring circuit.
Page 25 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 2.11: Wiring Labels The seven individual wires extending from the flexible conduit atop the frame, provide electrical power to various frame and door functions for the wiring diagram label, affixed to the frame header. Using wire connectors, these wires should be grouped by the Hotwires (Circuit wires), the Neutral wires, and the ground wire for connection to either the facility or the case power.
Page 26: Section 3 - Door Unpacking Instructions
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 3 – Door Unpacking Instructions There are several precautions that you must be aware of when staging and unpacking the doors from the crate. The following section will address these precautions. As always, please read this manual in its entirety.
Page 27: Opening Shipping Crate
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 3.1. Shipping Crate containing Anthony Doors Opening Shipping Crate Anthony takes great care to ensure that your doors arrive undamaged and in acceptable condition shape. Please use and follow these steps to ensure the proper removal of your doors from the shipping crate.
Page 28 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 3.2. Unscrewing the top portion of the Shipping Crate After removing all screws securing the top wooden slats to the crate, remove the wooden slats (see Figure 3.3. next page). 27 | P a g e w w w .
Page 29 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 3.3. Removing the top portion of the Shipping Crate WARNING Warning: If you only have one or two people to remove doors from the crate, please see Step # 4; if 3 or more people are available proceed to Step # 5. After removing the top wooden slats from the crate, use the same wooden slats or another piece of wood to place under the crate to offset the weight as shown in Figure 3.4.
Page 30 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 3.5. Removing Front side of Shipping Crate WARNING Warning: When removing the front side of the crate ensure that you are opening side the that is labeled “Open This Side”. Do not remove any additional crate panels, the doors have specifically been packed to be removed from the side indicated on the crate.
Page 31: Removing Doors From Shipping Crate
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Removing Doors from Shipping Crate PROTECTIVE GEAR NOTICE Protective Eyewear– Potential risk of eye injuries, protective eyewear required when performing this, and any other associated tasks. Protective Gloves– Potential risk of injury to your hands, protective gloves required when performing this, and any other associated tasks.
Page 32: Section 4 - Door Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 4 – Door Installation This section provides the information needed to safely perform the proper installation of Anthony doors onto the frame. Door Handling Once staging is complete and you have removed the first door and made all the Pre-Installation enhancements it is time to begin installing the Anthony Doors one at a time.
Page 33 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 4.1: Seating Door onto Torque Master Now we will proceed to engage and lock the hinge pin into place and prepare the SOCKET (hinge pin plug) receptacle by using Dielectric grease on the socket of the frame before inserting the door hinge pin.
Page 34 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Ensure to apply 3 grams of a high viscosity dielectric grease to the Hinge Pin receptacle in most applications. For installations where doors are in Harsh and/or Extreme ambient conditions with excessive moisture, it is recommended to fill the holes in the Hinge Pin receptacle socket as shown below in Figure 4.2.
Page 35 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Engage door with hinge pin inserted into SOCKET (hinge pin plug) receptacle at top of the frame. Push the door into the frame until the hinge pin snaps in place. See Figure 4.3. Figure 4.3: Engage Hinge Pin to Frame WARNING Never use anything like a hammer, rubber mallet, or another tool to strike the Hinge pin...
Page 36 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B WARNING WARNING: DO NOT use power tools to install and secure the hold-open screw. Now you will need to set the door tension swing and correct the door alignment by adjusting the Torque Master™ Refer to “Torque Master™...
Page 37: Torque Master™ And Sag Adjustment
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Torque Master™ and Sag Adjustment The TorqueMaster regulates the door alignment and the door closing tension. For the door to operate properly it must be square in the frame and the pivot centerline must be perpendicular to the level. If the frame was correctly installed, the top and bottom gaps between the door and frame will be even from the pivot side to the handle side of the door.
Page 38: Torque Adjustment
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Torque Adjustment: Use a flathead screwdriver to adjust the torque rod tension, by turning the outside screw on the TorqueMaster. WARNING Warning: Exercise caution when handling the door and DO NOT use power tools when adjusting the Torque Master™.
Page 39: After Installation Gasket Check
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B After Installation Gasket Check After installation is completed, ensure that all door gaskets are securely installed for optimal sealing performance. When handing the door during installation gaskets can be pulled out of place. Use your hands and fingers to check the entire perimeter of the door and the gasket.
Page 40: Section 5 - Required Functionality For Complete Install
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 5 - Required Functionality for Complete Install The following items must be functional for the installation to be completed and closed out: Door Frame Assembly Door/frame assembly should be in proper alignment and level/plumb. Gasket The gasket must be properly sealed and touch the contact plate around the entire door assembly.
Page 41: Section 6 - Cooler/Freezer* Store Condition Requirements
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 6 - Cooler/Freezer* Store Condition Requirements The installation of Anthony doors in various applications requires specific store conditions to achieve optimal performance. Please note that ambient conditions in your store may vary throughout the day. Anthony/ Anthony Doors are built to ANSI/ASHRAE Standard 72-2014 Test Standard.
Page 42 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 6.1 Product Stocking – Shelves required to be fully stocked Ensure to stock on shelves to prevent direct air flow from evaporator to the door Figure 6.2 Evaporator Air Deflector - Contact evaporator manufacturer for recommended air deflector. 41 | P a g e w w w .
Page 43: Section 7 - Routine Preventative Maintenance
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 7 - Routine Preventative Maintenance The following provides information needed to safely perform regular periodical preventive maintenance. Regular preventative inspections will maximize the longevity of your Anthony products. These simple tasks will go a long way in ensuring optimal performance. Depending on maintenance being performed you may need to shut down the door or kill all power to the doors.
Page 44: Recommended Maintenance Inspection And Cleaning Intervals
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Recommended Maintenance Inspection and Cleaning Intervals Action Store Conditions Description Normal Conditions Once each quarter (every 3 months) Preventative Inspection Harsh Conditions Once a month (every 30 days) Cleaning All Conditions Once a month (every 30 days) Note: These are recommendations based on historical data of other Anthony door products and can vary depending on location, store conditions, store traffic, and other unknown variables.
Page 45: Gaskets
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B • Gaskets – When inspecting gaskets ensure that they are sealing properly along the entire perimeter of the door. Also, ensure that the gasket is properly inserted into the door plastic grove. Inspect and ensure gaskets are free of cracks, tears, deformities, and hardening.
Page 46: Section 8 - Troubleshooting
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 8 - Troubleshooting Table 8.1: Installation Troubleshooting PROBLEM / ISSUE PROBABLE CAUSES / FIXES FINAL REMEDY Fan to Door Proximity too small Condensation on Door Glass, Install air deflector Evaporator fans blowing cold air directly onto glass/frames Door Rail, or Frame Shelves not fully stocked...
Page 47 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Table 8.2: General Troubleshooting PROBLEM / ISSUE PROBABLE CAUSES / FIXES FINAL REMEDY Check power supply Check humidity controller No Power Check Hinge Pin connections Check glass wire connections Glass condensation Check Hinge Pin wiring Check main voltage Low voltage...
Page 48: Section 9 - Frame Replacement Parts
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 9 – Frame Replacement Parts The following section list Frame Replacement parts for both Normal Temperature and Low-Temperature Frames. Figure 9.1 Frame Assembly for 101 Series Normal Temperature for Replacement Parts (See Table 9.1 for Part Numbers) NOTICE Note: Parts depicted in Red can be replaced, parts in Black are not replaceable...
Page 49 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Table 9.1 Frame Assembly for 101 Series Normal Temperature for Replacement Parts List ITEM NO. PART NUMBER DESCRIPTION 02-10568-000X ASSEMBLY, TORQUE MASTER 02-24974-0XXXX ASSEMBLY, CONT PLATE, NO LCK, NO DVR, NO DR HT 75, 101N NT HA 02-24974-1XXXX ASSEMBLY, CONT PLATE, NO LCK, DVR, NO DR HT 75, 101N NT HA 11-10602-0001...
Page 50 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 9.2 Frame Assembly for101 Series Low Temperature for Replacement Parts (See Table 9.2 for part numbers) NOTICE Note: Parts depicted in Red can be replaced, parts in Black are not replaceable 49 | P a g e w w w .
Page 51 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Table 9.2 Frame Assembly for 101 Series Low Temperature for Replacement Parts List ITEM NO. PART NUMBER DESCRIPTION 02-10568-0001 ASSEMBLY, TORQUE MASTER 02-24974-XXXX ASSEMBLY, CONT PLATE, NO LCK, NO DRIVER, 75, 401N LT 02-24974-XXXX ASSEMBLY, CONT PLATE, DRIVER, DR HEAT, 75, 101N LT HA 11-10602-X00X...
Page 52: Section 10 - Door Replacement Parts
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 10 – Door Replacement Parts The following section list Frame Replacement parts for both Normal Temperature and Low-Temperature Door. Figure 10.1 Door Assembly for 101 Series Door, for Replacement Parts (See Table 10.1 for part numbers) NOTICE Note: Parts depicted in Red can be replaced, parts in Black are not replaceable.
Page 53 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B 02-10308-000X ASSEMBLY, TORQUE ROD 02-14649-0000 ASSEMBLY, HOLD OPEN FORK, 101N 15-14707-0001 HOLD OPEN FORK, CLOSED END 20-15707-0002 CAP, VINYL, HOLD OPEN, RED 40-25258-3502 SCREW, 8-32 X 3/16, PTH, SS, NYL PCH 40-14616-0001 STANDOFF, PIVOT, HOLD OPEN 40-15096-0001...
Page 54: Section 12 - Optimax 7 Led Lighting Fixture Replacement
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 12 – Optimax 7 LED Lighting Fixture Replacement All work performed must be done by a qualified personal only. All local and national electrical codes must be followed when replacing fixtures of the lighting system.
Page 55: Replacement Instructions
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Replacement Instructions The following instruction set will guide you on how to properly replace an Optimax 7 LED fixture. These instructions can be used for both Center and End Fixtures. WARNING Warning –Make sure to turn off the Light switch on the Frame Mullion (rightmost) before starting the replacement process.
Page 56 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Using a Philips head screwdriver, remove the mounting screws from the top and bottom of the existing light. WARNING Warning: Do NOT use a power drill to remove or install the screws that secure the fixture onto the frame, doing so can damage the frame and strip the threaded hole.
Page 57: End Jambs
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B End Jambs For end jambs, it may be necessary to remove zipper strips and additionally remove the contact plate of the Frame Sill see images and note below. NOTICE Note: For End Jambs, you may need to remove the contact plate of the Frame sill (bottom) to be able to remove the End Jamb contact plate.
Page 58: Section 13 - Removing & Replacing The Torque Rod
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 13 – Removing & Replacing the Torque Rod Please read the instructions in their entirety. It should answer most of your installation questions. For personal and system safety, and optimum product performance, make sure you thoroughly understand the contents before installing, using, or maintaining this product.
Page 59 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 13.2 Removing torque rod from the door. WARNING Warning: DO NOT use a steel-headed hammer. Use caution when striking any tool with another tool. DO NOT use excessive force when striking the screwdriver and potentially damaging the door. Continue to carefully tap the torque rod, if necessary, until the torque rod and rod end disengages.
Page 60: Section 14 - Removing & Replacing The Hold-Open Assembly
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 14 – Removing & Replacing the Hold-Open Assembly Please read the instructions in their entirety. It should answer most of your installation questions. For personal and system safety, and optimum product performance, make sure you thoroughly understand the contents before installing, using, or maintaining this product.
Page 61: Replacing The Hold-Open Assembly
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Replacing the Hold-Open Assembly Insert the pivot standoff into the door. Add Loctite #271 to threads. Torque to 100 in/lb. Place the pivot hole of the new hold open over the pivot standoff that is closest to the hinge pin. Retain with a new truss head screw and torque to 16 in/lb.
Page 62: Section 15 - Removing & Replacing The Hinge Pin
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 15 – Removing & Replacing the Hinge Pin The following instructions will guide you on how to remove and replace the Hinge Pin assembly from your door. PROTECTIVE GEAR NOTICE Protective Eyewear–...
Page 63 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Connect the hinge pin wires to the terminated door wires. Insert the remainder of the hinge pin into the frame mounting hole until the hinge pin is fully seated. Harness wires together using a tie-wrap and insert the harness into the door rail and install the access cover. Ensure to apply high viscosity dielectric grease to the Hinge Pin receptacle.
Page 64 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B WARNING Warning: Ensure to apply a minimum of 3 grams of dielectric grease (Anthony P/N: 98-25497-0001) to fill the holes in the socket as shown in Figure 4.2 in “Section 4 – Door Installation”. 63 | P a g e w w w .
Page 65: Section 16 - Torque Master Replacement
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 16 - Torque Master Replacement The following instructions will guide you on how to remove and replace Torque Master from the frame. PROTECTIVE GEAR NOTICE Protective Eyewear– Potential risk of eye injuries, protective eyewear required when performing this, and any other associated tasks.
Page 66 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Re-install door per instructions in Section 4 -Door Installation. WARNING Warning: Ensure to apply a minimum of 3 grams of dielectric grease (Anthony P/N: 98-25497-0001) to fill the holes in the socket as shown in Figure 4.2 in “Section 4 – Door Installation”. 65 | P a g e w w w .
Page 67: Section 17 - Pass-Thru Frame And Door Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 17 – Pass-Thru Frame and Door Installation Tools Required The following is a list of all the different equipment, tools, materials, and other things you will need when installing the Anthony 103 Pass- Thru Frame and Doors.
Page 68: Net Opening
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Net Opening Read the instructions in this Section completely before installing the frame. Before installing the frame, confirm that the size of the net opening accommodates the finished frame, the net opening should be larger by 1/8” than the frame size, and there should be a gap of 1/8" on top, and 1/8"...
Page 69: Frame Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Frame Installation The following instructions will ensure proper frame installation: When installing the frame, DO NOT install the Frame directly on Sheetrock, the frame is designed to be installed on Cooler/Freezer Boxes only Ensure that the Sealing Frame Flap is fully engaged to the Sill, Header, and Jack Studs creating a seal without any gaps (see Figure 17.1)
Page 70 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 17.1: Frame Alignment, Squareness, and Plumb WARNING Warning: Use only food-grade silicone sealant (add caulking for larger gaps) to seal the gap between the frame and the surrounding wall, inside the case, cooler or freezer. Not following these procedures can void Anthony’s Service &...
Page 71: Shimming The Frame
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Shimming the Frame Shimming is only to be used when necessary and will primarily be done at the header (top) of the frame and opening. If the gap between the frame and net opening is greater than 1/16”, proceed to shim the gap for a proper fit.
Page 72 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B 71 | P a g e w w w . a n t h o n y i n t l . c o m...
Page 73: Sealing The Frame
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Sealing the Frame The electrical connection at the Junction Box where the wires enter the frame, and where the wires enter the raceway in the frame must be sealed with NSF Approved Food Grade Silicone Sealant (RTV-108) at the time of installation. Ensure to seal the gap between the frame and the surrounding wall, inside the case, cooler or freezer.
Page 74 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Insert a mounting screw into a mounting hole in each corner of the frame and tighten each screw until it is approximately a quarter inch from flush. Check the frame is aligned properly or square. Refer to Figure 17.1 Frame Installation Reference. When the threshold is desired, drill and lag on pre-drilled mounting holes only.
Page 75: For Cut Threshold
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B For Cut Threshold Verify the cut threshold is square and plumb to the rest of the frame before drilling through pre-drilled mounting holes. Refer to Figure 17.5 Without Threshold. Figure 17.5: Frame Without Threshold 74 | P a g e w w w .
Page 76: Frame Electrical Wiring Connections
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Frame Electrical Wiring Connections The electrical connection at the Junction Box where the wires enter the frame, and where the wires enter the raceway in the frame must be sealed with silicone caulking at the time of installation. WARNING Stop: Wiring for lights should have a separate circuit from the frame heater wiring circuit.
Page 77 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B The seven individual wires extending from the flexible conduit atop the frame, provide electrical power to various frame and door functions for the wiring diagram label, affixed to the frame header. Using wire connectors, these wires should be grouped by the Hotwires (Circuit wires), the Neutral wires, and the ground wire for connection to either the facility or the case power.
Page 78 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 17.8: Wiring Diagram NOTICE Note – Wiring for lights should have a separate circuit from the door/frame heater wiring circuit. 77 | P a g e w w w . a n t h o n y i n t l . c o m...
Page 79: Section 18 - Pass-Thru Door Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 18 – Pass-Thru Door Installation Following the instructions will guide you on how to Install the Pass-Thru Door Assembly on Pass-Thru Frame. PROTECTIVE GEAR NOTICE Protective Eyewear– Potential risk of eye injuries, protective eyewear required when performing this, and any other associated tasks.
Page 80 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 18.2: Dielectric Grease in SOCKET (hinge pin plug) receptacle Engage door with hinge pin inserted into SOCKET (hinge pin plug) receptacle at top of the frame. Push the door into the frame until the hinge pin snaps in place.
Page 81 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 18.4: Tighten Hold-Open Screw NOTICE Note – DO NOT use power tools to install the hold-open screw. Exercise caution when handling the door. DO NOT over-tighten the hold-open bolt. Verify hold-open does not bind while sliding along the hold-open bolt.
Page 82: To Remove The Door Assembly
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B To Remove the Door Assembly Release tension on TorqueMaster™ with a flat-head screwdriver. Turn the TorqueMaster™ front-facing screw clockwise, until the door does not automatically close from an open position. Figure 18.5: Release TorqueMaster Tension Open door to access the hold open device, then loosen and remove the hold open using a Phillips #2 screwdriver.
Page 83 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Remove the hinge pin plug from the frame by inserting the top half of needle-nose pliers into the spring clip grip hole and the bottom half beneath the hinge pin shroud. Figure 18.7: Disengage Hinge Pin Compress pliers to clamp down on the hinge pin spring clip, then simultaneously pull the hinge pin away from the frame and pull the door top out.
Page 84: Pass-Thru Heavy Duty Hinge Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Pass-Thru Heavy Duty Hinge Installation Following the instructions will guide you on how to Install the Pass-Thru Door Assembly with Heavy Duty Hinging on Pass-Thru Frame. When installing Heavy Duty Pass-Thru doors, make sure the hinges are in their proper locations. You should see three (3) self-closing hinges on the door.
Page 85: Confirmation Of Parts
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B NOTICE Note – there are both right-hand and left-hand hinges. Confirmation of Parts All remaining parts required to install the door(s) are shipped along with the frame assembly. Quantities of parts will differ, depending on the number of doors installed.
Page 86: Door Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Door Installation Two people are required when installing a heavy-duty hinge door. For support and balance, it is easier to use some 2 x 4’s to position the door onto the frame during installation as shown in Figure 18.12.
Page 87 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure 18.14: Shimming Hinges Repeat this process to ensure all three (3) hinges are aligned and the door closes smoothly on its own. 86 | P a g e w w w . a n t h o n y i n t l . c o m...
Page 88: Hold Open
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Hold Open Once all hinges are installed, use the following instructions to install the hold open. Position the hold open onto the pivot and screw on tightly. Once the hold open is in place, ensure everything closes and opens with ease. If not, ensure all hinges are correctly placed and screws are fully tight.
Page 89: Section 19 - Pass-Thru Frame Replacement Parts
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 19 – Pass-Thru Frame Replacement Parts The following section list Pass-Thru Frame Replacement parts. Figure 19.1 Frame Assembly for 101 Series NT Pass-Thru; Replacement Parts (See Table 19.1 for part numbers) NOTICE Note: Parts depicted in Red can be replaced, parts in Black are not replaceable.
Page 90 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Table 19.1 Frame Assembly for 101 Series NT Pass-Thru Door Replacement Parts List ITEM NO. PART NUMBER DESCRIPTION 02-10568-000X ASSEMBLY, TORQUE MASTER, #1 BLK 02-24652-0000 ASSEMBLY, ENCLOSURE, DRIVER, REMOTE 02-25060-0001 ASSEMBLY, FR, CONDUIT FLEX, 90°EXT 15-12520-F091 PLATE, CONTACT, LH, 103N...
Page 91: Section 20 - Pass-Thru Door Replacement Parts
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Section 20 – Pass-Thru Door Replacement Parts The following section list Pass-Thru Frame Replacement parts. Figure 20.1 Door Assembly for 101 Series NT Pass-Thru; Replacement Parts (See Table 20.1 for part numbers) NOTICE Note: Parts depicted in Red can be replaced, parts in Black are not replaceable 90 | P a g e...
Page 92 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Table 20.1 Door Assembly for 101 Series NT Pass-Thru Door Replacement Parts List ITEM NO. PART NUMBER DESCRIPTION 02-10308-0002 ASSY, TORQ ROD 02-14649-0000 ASSY, HOLD OPEN FORK. 101N ASSY, GASKET & MAGNET, ACII, SANTROPRENE, PASS-THRU 60-24663-XXXX ASSY, GASKET &...
Page 93: Appendix A - Gasket Replacement Guidelines
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix A - Gasket Replacement Guidelines Please read the guidelines in their entirety. It should answer most of your installation questions. For personal and system safety, and optimum product performance, make sure you thoroughly understand the contents before installing, using, or maintaining this product. Preliminary Considerations for Servicing Gaskets Tools Required Rubber or plastic mallet...
Page 94: Gasket Removal
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Gasket Removal PROTECTIVE GEAR NOTICE Protective Eyewear– Potential risk of eye injuries, protective eyewear required when performing this, and any other associated tasks. Protective Gloves– Potential risk of injury to your hands, protective gloves required when performing this, and any other associated tasks.
Page 95: Gasket Installation
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Continue to pull the gasket from the Plastic rails gently around the entire perimeter. WARNING Warning – Warning: The gasket is composed of soft materials with welded miter joints. Use extra care when manually extracting the gasket from the rail grooves to prevent damaging it as well as the plastic rail.
Page 96 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Continue to insert the gasket arrow into the groove around the perimeter of the door surface by pressing the gasket firmly against the plastic cover, sliding from side to side, and applying full pressure against the gasket, forcing the gasket arrow into the groove in the plastic.
Page 97 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B When you get near the bottom of the door, carefully align the two bottom corners of the gasket onto the bottom corners of the plastic cover, with the gasket arrow facing the door rail and cover. Continue to insert the gasket arrow into the groove around the remaining perimeter of the door surface by pressing the gasket firmly against the plastic cover, sliding from side to side, and applying full pressure against the gasket, forcing the gasket arrow into the groove in the plastic.
Page 98: Appendix B - Door Reversal
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix B – Door Reversal Please read the guidelines in their entirety. It should answer most of your installation questions. For personal and system safety, and optimum product performance, make sure you thoroughly understand the contents before installing, using, or maintaining this product. Some doors are reversible.
Page 99: Door
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Pry off (underneath) the plug cap from the mounting hole, on the opposite side of the doorframe with a flat-head screwdriver. Set TorqueMaster onto the opened mounting hole. Align the flanged corners of the mounting tabs with the SAG ADJUSTMENT screw facing the inside of the frame.
Page 100 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Disconnect the Hot, Neutral, and Ground wires of the hinge pin. Loosen and remove the hinge pin assembly from the top door rail. Using a plastic mallet and a flat-head screwdriver, remove the torque rod from the bottom of the door assembly. Reinstall the hinge pin and the torque rod on the opposite ends of the door assembly.
Page 101: Appendix C - Anti-Fog Maintenance
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix C – Anti-Fog Maintenance The PET Film on your Anthony product is a scratch-resistant, permanent coating that prevents fogging and icing of cold surfaces. On transparent substrates, it provides a clear view (i.e., through a refrigerator door when opened). Described herein are the cleaning instructions should only be performed only by personnel that is qualified and/or fully understand the specific tasks in accordance with this documentation, in particular its warning notices, safety instructions, and the non-use of harmful chemicals which will hinder the effectiveness or damage the PET Film.
Page 102: Standard Pom Lock
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B There are two (2) different part numbers for the POM lock when ordered. Which Part you will need is determined by the type of frame that is present. If the frame has GIBS (see Figure D.1 and D.2), use Part Number: 02-11585-0003; this will include POM Lock and Key only. PROTECTIVE GEAR NOTICE Protective Eyewear–...
Page 103 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure D.2: Plug Removal The POM Lock inserts into the hinge pin access plate. Figure D.3: Hinge Pin Access Plate (lock retainer) Insert the key into the POM Lock square keyhole, then turn the key counterclockwise to lock. Remove the key.
Page 104 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure D.4: Front View POM Lock The POM Lock is always installed in the frame, over the top of the handle rail side of the door. To retrofit the POM Lock on existing doors in the field, contact Anthony Customer Service or the local Sales Representative in your area for information and instruction sheets.
Page 105: Appendix E - Pom Lock Retrofitting
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix E – POM Lock Retrofitting The POM lock is the only lock currently available for all Anthony Door Models. The POM Lock offers a quick and easy locking mechanism to help keep your doors locked when needed.
Page 106 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure E.2: Template Offset location Place the template provided on the frame with the right edge of the template on the mark created in Step 1. 105 | P a g e w w w .
Page 107 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure E.3: Template Placement on Frame Side view Mark the frame through the five holes on the template with a pencil. Remove the template and center punch the marks on the frame.
Page 108 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Remove the key. To remove the POM Lock, insert the key into the square lock hole and turn the key clockwise. Figure E.4: Front View POM Lock 107 | P a g e w w w .
Page 109: Appendix G - Cylinder Lock Replacement
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix G – Cylinder Lock Replacement The following section is only for Anthony Door Models with cylinder locks installed. The cylinder lock offers a quick and easy locking mechanism to help keep your Doors locked when needed. The following instructions will guide you on how to replace an existing cylinder lock.
Page 110 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure G.2: Cylinder lock exploded view Remove gasket from door rail containing the lock (leaving the gasket on the remaining door rail assembly for easy reassembly). Remove plastic cover from the door rail containing the lock assembly to expose access to the lock mount. Insert a large Phillips-head screwdriver into the lock access at the back of the door rail.
Page 111 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B If necessary, replace the strike. Refer to Figure G.4. Remove the lock assembly, out from the lock housing and through the front of the door rail. Refer to Figure G.4. Replace lock assembly into housing inside rail.
Page 112 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Figure G.6: Cylinder lock assembly replacement Figure G.7: Secure Lock Test lock and confirm that it works properly. Replace the plastic cover and gasket. Re-install door per instructions in Section 4 – Door Installation. 111 | P a g e w w w .
Page 113: Appendix H - Slimline Door Handle Replacement
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix H – Slimline Door Handle Replacement The following section is only for the Slimline Handle on 101 Series Door this applies to door models 101N, 103N, and 103T. If your door is configured with a full-length door handle the handle cannot be replaced. The following instructions will guide you on how to replace an existing Slimline handle.
Page 114 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B To remove the two (2) handle screws, insert a 5/32-inch hex ball-driver t-handle or 5/32-inch Allen Wrench and turn counterclockwise to loosen the screws, ensure to hold the handle while loosening both screws to keep the handle from falling and to ease the removal of the handle, as shown in Figure H.1.
Page 115: Appendix I - Pass-Thru Door Bottom Wiper Adjustment & Replacement
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix I – Pass-Thru Door Bottom Wiper Adjustment & Replacement The following section pertains only to Pass-Thru Doors with bottom wiper seal. The Bottom Wiper can be adjusted and/or replaced as needed.
Page 116 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B remove the old bottom wiper, as shown in Figure I.1. Position and align the new bottom wiper with all holes, insert all screws, and tighten enough to and adjust as needed once you have adjusted into place, proceed to tighten all the screws to secure the wiper in place, ensure that the wiper blade creates a good seal between floor and door eliminating unwanted airflow, as shown in Figure I.1.
Page 117: Appendix J - Removing & Replacing Door Rail Plastic Cover
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix J – Removing & Replacing Door Rail Plastic Cover The following section guides you on how to replace a damaged door rail plastic cover located on the back side of your door, behind the gasket, and attached to the door rail.
Page 118 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Continue to pry the plastic cover from the door rail until the entire end of the plastic rail is disengaged, as shown in Figure J.2. Figure J.2 – Prying Plastic Cover Pull the plastic cover up and out of the door rail grooves until the entire plastic cover is removed from the door rail, as shown in Figure J.3.
Page 119: Installing New Plastic Cover
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Installing New Plastic Cover To install the new replacement plastic covers, begin by aligning the replacement plastic cover evenly onto the door rail, as shown in Figure J.4. Insert the outer edge of the plastic cover into the outside groove of one of the door rails, as shown in Figure J.4. Figure J.4 –...
Page 120 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Repeat this procedure, aligning each mitered corner, with the remaining plastic covers until all four plastic covers are properly installed onto door rails. Confirm that each plastic cover is fully installed, and the mitered corners properly aligned. Once you complete installing/replacing door rail plastic proceed to re-install gaskets as instructed in “Appendix A –...
Page 121: Appendix K - Anthony Energy Controller
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Appendix K – Anthony Energy Controller The main purpose of the Anthony’s Energy Controller to maintain the Frames and Doors from condensation. The Energy Controller manages the Anti-sweat heat on the Frame based on the Frame temperature sensor reading. Anti-condensate heat is activated when the Frame temperature sensor temperature reads equal to or less than (Dew point Temperature + 10ºF).
Page 122: Programming, Settings, And Parameters
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Programming, Settings, and Parameters Sensor Button Use the Sensor button to set dewpoint offsets to the unit in addition to the 24-hour gasket seat mode. There are 3 additional modes that the button will go through when it is held (see modes below).
Page 123: 24-Hour Heat Mode
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B 24-Hour Heat Mode This mode is used to turn 24-hour constant heat on Frame/Door System, this mode will keep the heat on for a continuous 24-hour period and then revert to the previous setting. When the unit is in a 24-hour heat mode, the LED will blink slowly with an interval of 1 second to indicate that the heater is on for the remainder of the 24-hour heat mode.
Page 124: Troubleshooting
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Troubleshooting • When the unit is operating normally, the LED of the sensor will display the status of the heater. • When the heater is off, the LED will blink very dimly to show that the unit is operating, but the heater is off. •...
Page 125 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Notes ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________ 124 | P a g e w w w .
Page 126 Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Notes ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________________________ ______________________________________________________________________ 125 | P a g e w w w .
Page 127: Revision History
Complete 101 Series Installation Manual 99-25517-I001 July 2022 Rev. B Revision History ORIGINATOR DESCRIPTION OF CHANGE DATE A. Martinez Initial Release 5/19/2022 A. Martinez/ S. Putti Added Appendix K: Anthony Energy Controller 126 | P a g e w w w . a n t h o n y i n t l . c o m...
