Installation & Service
MULTI-SHELF FROZEN FOOD MERCHANDISER
Low Temperature Self Serve Display Cases
This manual has been designed to be used in conjunction with the General
Save the Instructions in Both Manuals for Future Reference!!
This merchandiser conforms to the American National Standard Institute & NSF International Health and Sanitation standard ANSI/NSF 7 - 2003.
PRINTED IN Specifications subject to REPLACES
IN U.S.A.
change without notice.
Manual
N6F/N6FL
(UL/NSF) Installation & Service Manual.
1/06
EDITION
Hillphoenix, Inc. * Conyers, GA 30013
ISSUE
PART
12/21
DATE
NO.
D
9037160
REV.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TYLER Hillphoenix N6F and is the answer not in the manual?

Questions and answers

Related Manuals for Dover TYLER Hillphoenix N6F

Summary of Contents for Dover TYLER Hillphoenix N6F

  • Page 1 Installation & Service Manual N6F/N6FL MULTI-SHELF FROZEN FOOD MERCHANDISER Low Temperature Self Serve Display Cases This manual has been designed to be used in conjunction with the General (UL/NSF) Installation & Service Manual. Save the Instructions in Both Manuals for Future Reference!! This merchandiser conforms to the American National Standard Institute &...

  • Page 2: Table Of Contents

    N6F/N6FL CONTENTS Page Specifications N6F/N6FL Specification Sheets ......4 Pre-installation Responsibilities ..(See General-UL/NSF I&S Manual) Installation Procedures Carpentry Procedures .
  • Page 3 Installation & Service Manual N6F/N6FL Page General Information NSF Product Thermometer ....... 18 Night Curtains and Strip Doors .
  • Page 4 N6F/N6FL SPECIFICATIONS N6F/N6FL Multi-Shelf Frozen Food Merchandiser Specification Sheets December, 2021 Page 4...
  • Page 5 Installation & Service Manual N6F/N6FL March, 2008 Page 5...

  • Page 6: Installation Procedures

    N6F/N6FL INSTALLATION PROCEDURES Electrical Procedures Electrical Considerations Carpentry Procedures CAUTION Case Pull-Up Locations Make sure all electrical connections at components and terminal blocks are tight. This will prevent burning of electrical terminals and/or premature component failure. NOTE • Lower raceway cover will be shipped loose.

  • Page 7: Defrost Information

    Installation & Service Manual N6F/N6FL Defrost Information given rack should defrost at one time because the defrosting cases become a See “General-UL/NSF I&S Manual” for condenser during the defrost period and the operational descriptions for each type of other refrigerated cases must provide enough defrost control.

  • Page 8: Wiring Diagrams

    N6F/N6FL In addition the primary air band fans on the When there is more than one case, the control N6F are cycled off during the defrost cycle wiring must be modified as shown below. This with a limit “klixon type” thermostat that is puts the fourth pole on the special contactor mounted to a coil return bend on the right in a series circuit to the reset solenoid.

  • Page 9: N6F Domestic & Export (50 Hz) Case Circuits

    N6F Domestic & Export (50 Hz) Case Circuits (Electric Defrost) March, 2008 Page 9...
  • Page 10 Page 10 March, 2008...
  • Page 11 N6F Domestic & Export (50 Hz) Case Circuits (Gas Defrost) March, 2008 Page 11...
  • Page 12 Page 12 March, 2008...

  • Page 13: N6Fl Domestic & Export (50 Hz) Case Circuits

    N6FL Domestic & Export (50 Hz) Case Circuits (Electric Defrost) March, 2008 Page 13...
  • Page 14 Page 14 March, 2008...
  • Page 15 N6FL Domestic & Export (50 Hz) Case Circuits (Gas Defrost) March, 2008 Page 15...
  • Page 16 Page 16 March, 2008...

  • Page 17: Cleaning And Sanitation

    Installation & Service Manual N6F/N6FL CLEANING AND SANITATION Discharge Air Honeycomb 1. Outer honeycomb (ambient/secondary), Component Removal and remove screws and rear retainer plate. Installa-tion Instructions for Inner honeycomb (primary), loosen screws and slide rear retainer plate back Cleaning until honeycomb grid sections can be NOTE removed.

  • Page 18: General Information

    N6F/N6FL GENERAL INFORMATION Night Curtains and Strip “Doors” Night curtains and strip “doors” are available NSF Product Thermometer from several souces. They promote energy Installation savings by partially closing off the front of the case. TYLER does not promote these 1.

  • Page 19: Service Instructions

    Installation & Service Manual N6F/N6FL SERVICE INSTRUCTIONS See “General-UL/NSF I&S Manual” for T-8 lamp, canopy ballast, fan blade and motor, and color band and bumper replacement instructions. Ballast and Lighting Locations Shelf Loading Observe all the LOAD LINE stickers when stocking the shelves with product.

  • Page 20: Fan Locations

    N6F/N6FL Fan Locations N6F/N6FL case air velocities should be as follows: Ambient Air - 360 fpm Secondary Air - 400 fpm Primary Air - 600 fpm Cleaning Honeycomb The inner honeycomb (primary) should not require cleaning. The outer honeycomb (ambient/secondary) will require cleaning. How often will depend on the amount of dust and lint in the store air.

  • Page 21: Anti-Sweat Heater Replacement

    Installation & Service Manual N6F/N6FL 1. Remove bottom trays (1) from case (2). 1. Remove the screws (1) and front molding (2) and inner honeycomb (3) from the 2. Disconnect defective defrost heater (3) interior top of the case. and remove from the defrost heater support (4) and case (2).

  • Page 22: Parts Information

    N6F/N6FL PARTS INFORMATION Cladding and Trim Parts List Item Description 6’ 8’ 12’ Screw (per cover) 5183536 (3) 5183536 (3) 5183536 (3) Pull-Up Angle Cover 5611559 (2) 5611559 (2) 5611559 (2) Screw 5183536 (8) 5183536 (8) 5183536 (8) Canopy Hood Joint Trim, Ptd. 9029422 9029422 9029422...
  • Page 23 Installation & Service Manual N6F/N6FL Item Description 6’ 8’ 12’ Top Shelf Duct Joint 5629694 5629694 5629694 Screw 5205439 (4) 5205439 (4) 5205439 (4) January, 2005 Page 23...

  • Page 24: Operational Parts List

    N6F/N6FL Operational Parts List Case Usage Domestic Export Electrical Circuit 115 Volt 60 Hertz 220 Volt 50 Hertz Case Size 6’ 8’ 12’ 8’ 12’ Fan Motors (ambient) 5125532 5125532 5125532 5202538 5202538 5 Watt 5 Watt 5 Watt 5 Watt 5 Watt (secondary) 5125532...
  • Page 25 Installation & Service Manual N6F/N6FL Case Usage Domestic Export Case Size 6’ 8’ 12’ 8’ 12’ Opt. ECM Fan Blades (cont.) (sec.)(7.75” 13° 5B) 9042245 ---- ---- ---- ---- (sec.)(7.75” 15° 5B) ---- 9301932 9301932 ---- ---- (prim.)(8.75” 22° 5B) 9040683 9040683 ----...
