Summary of Contents for Furniture of America CM-BK939TQ
- Page 5 Align the top of (#10) to (#12) and the bottom to (#9), insert a bolt (#D) into each end and secure using the Allen wrench. Align (#12) to (#1) and (#2), then insert 2 bolts (#A) into each side and secure using the Allen wrench. Align (#9) to (#1) and (#2), then insert a bolt (#F) into each end and secure using the Allen wrench.
- Page 6 Align the slats according to the image on the left, and insert a bolt (#B) into each pre-drilled hole. Secure using the Allen wrench (#H). Align each end of the support bar (#11) to (#9), then insert a bolt (#D) into each end and secure using the Allen wrench (#H).
- Page 7 Align the slat support legs (#14) to the holes along the center of the bottom bed, then insert the bolts (#C) from the top and secure using the Allen wrench (#H). Make sure all parts are firmly secured. ASSEMBLY IS COMPLETED...
