Extension Belt, adjustable
Assembly Instruction
Prod. No 3136226, 3136227, 3136228, 3136229
Contains:
1 x
Before the Extension belt is used for the first time it has to be adjusted to an appropriate length. How to adjust
the strap is described below. See the instruction guide for Multirall
use the Extension belt.
1.
1. Strap cover
2. Safety pin
3. Strap joint
2. Loosen the strap and remove the safety
pin.
7SE160242 Rev.3
ENGLISH 2021
2.
3.
overhead lift for more information on how to
TM
1. Slide the strap cover away from the strap
joint.
3. Adjust the strap to the desired length.
NOTE! Excessive strap must not be cut
off, due to the risk of the strap gliding
out.
