iVAM1-12G
1RU Multi-Channel Audio Video 12G Monitor

User Guide

Part Number 821835, Revision C

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iVAM1-12G and is the answer not in the manual?

Questions and answers

Summary of Contents for Wohler iVAM1-12G

  • Page 1: User Guide

    1RU Multi-Channel Audio Video 12G Monitor User Guide Part Number 821835, Revision C...
  • Page 2 In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.
  • Page 3: Table Of Contents

    Loudness Settings ................25 Source Select ..................27 Presets ..................... 29 All Presets ..................29 Preset Favorites ................. 31 Unit Settings ..................32 Speaker Options................. 33 Meter Scales..................34 Unit Configuration ................36 Phase Configuration................37 HDMI Settings ................... 38 Page 3 iVAM1-12G...
  • Page 4 System Update .................. 43 Factory Reset ..................44 System Information ................45 CHAPTER 3: Technical Info ............... 46 CHAPTER 4: The iVAM1-12G Web GUI..........51 Web Browser / Control Device................ 51 First Time IP Assignments ................51 Peer-to-Peer Connection..............51 Network Connection................
  • Page 5 Updating an iVAM1-12G Remotely ..............91 Updating Multiple Units Remotely ..............93 APPENDIX B: Dante Network Setup ............. 96 Introduction ....................96 What is in the iVAM1-12G for Dante..............96 Dante Device Setup ................... 98 Dante Clock Selection ................... 99 Channel Names....................
  • Page 6 Introduction ....................115 API: Presets ....................115 Page 6 iVAM1-12G...
  • Page 7: Chapter 1: Installation

    Either 8 or 16 channel meters can be displayed. The iVAM1-12G includes two 12G SDI inputs and it can monitor both video and audio from them. Standard features include Loudness measurement, phase status and HDR detection.
  • Page 8: Safety Symbols

    The ambient temperature inside the mounting enclosure should not exceed 40° Celsius (104° Fahrenheit). Adjacent devices can be rack mounted (or stacked) in proximity to the unit if this temperature is not exceeded. Otherwise, allow a 1RU (1.75”/44.45mm) space above and below the unit for air circulation. Page 8 iVAM1-12G...
  • Page 9: Sympathetic Vibration

    Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at their own expense. Page 9 iVAM1-12G...
  • Page 10: Ices-003

    ICES-003 This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. Page 10 iVAM1-12G...
  • Page 11: Chapter 2: Local Operation

    CHAPTER 2: Local Operation Operation The iVAM1-12G can be operated easily and simply from controls on its front panel, as described in this chapter. It may be accessed remotely in two ways, via the Wohler Web GUI for administrative purposes or by third party equipment via Application Programming Interface (API) commands.
  • Page 12 Output Routing option is installed, speaker audio may optionally be set to not mute, using the Wohler Web GUI. Refer to the Output Options section of Chapter 4. If the speaker audio is set to mute with headphone insertion, and a headphone is...
  • Page 13: Rear Panel

    Cage Cage Power Connection: The iVAM1-12G receives power from an AC inlet, which is a standard IEC receptacle for 100 to 240 VAC ±10%, 50/60 Hz power connection. Four regional AC power cords, supplied according to shipping region, are available.
  • Page 14 The Wohler Web GUI is described in Chapter 4 of this manual. Third party equipment, connecting to the iVAM1-12G via a LAN plugged into this port and using an API commands, can view and change product options, as well. This API is described in Appendix E of this manual.
  • Page 15 Wohler Technologies Technical Service. e. SMTPE 2110 or 2022-6 Receiver: This uses Multi-Mode 850 NM, LC fiber connectors. It allows the iVAM1-12G to monitor SDI audio transmitted in real time over Ethernet. You must use the MN-Set configuration software to set up this option. It is available from Wohler Technologies Technical Service.
  • Page 16 Volume and Balance controls. The Analog Outputs are standard on the iVAM1-12G. Refer to Figure 2-5 for the pinout of this connector. Figure 2-5: Analog XLR-M Output Connections 12. Option Card Slot: This metal plate can be removed to reveal a location in which future optional modules can be installed.
  • Page 17: Sfp-2022-6 / Sfp-2110 Address Setup

    192.168.39.215 iVAM1-12 with SFP-2022-6 / SFP-2110 The optional SFP-2022-6 or SFP-2110 module furnished by Wohler Technologies is manufactured by Embrionix and comes from the factory with a default IP address. To integrate it into your digital network, you need to set its address to the source to be monitored.
  • Page 18: Channel Meters And Touch Operations

    It is available from Wohler Technologies Technical Service. The procedure to accomplish this is described in the SFP-2022-6 / SFP-2110 Setup Guide (part number 821822), which is available at https://wohler.com/downloads/ Channel Meters and Touch Operations The audio mixer terminology of “solo” is used in this manual when referring to muting all but a specific audio channel or pair.
  • Page 19 Mute / Un-Mute Selection: A violet box surrounds any channel pair that is muted. Typically, when the iVAM1-12G is first powered, all of the channel pairs are muted. Touching a muted channel pair un-mutes it and removes the violet box. Muting and un-muting by touching is an alternate action function.
  • Page 20: Video Screen

    Set which Phase Indicators appear using the Phase Config Menu or with the System Preferences: Phase Indicator Configuration tab in the Wohler Web GUI. Video Screen Information about the signal can be superimposed over the upper part of the video image.
  • Page 21: Dolby Zoom Screen

    A wide range of Metadata is available, which can help you diagnose possible problems. It will vary according to the type of Dolby signal. For example, for checking Guard Band, the iVAM1-12G will display the Line Position of each Dolby E bitstream in the Dolby signal.
  • Page 22: Menu / Option Touchscreen

    HDMI Settings HDMI Settings Screen Analog Config Analog Config. Screen Network Settings System Options Screen Network Settings System Reboot System Reboot Screen System Update System Update Factory Reset Screen System Details Factory Reset Screen System Details Screen Page 22 iVAM1-12G...
  • Page 23: Main Menu

    As shown in Figure 2-14, the Source knob is positioned to the lower left of the Loudness Meter Screen. If the Source Knob Select setting in the Unit Config menu is set to Cluster Select, then rotating the Source knob will adjust the Page 23 iVAM1-12G...
  • Page 24 (shown as LRA -0.1 above). 2. The Average Loudness is the average of all calculated loudness measurements made over the Program period (shown as PROG - 20.5 above). Page 24 iVAM1-12G...
  • Page 25: Loudness Settings

    Continuous Monitoring Modes, and also to set the Alarm mode. It also provides a summary of various Loudness settings, as set in the Configuration | System Preference | Loudness Configuration tab of the Web GUI. Refer to Figure 2-15. Page 25 iVAM1-12G...
  • Page 26 4. Window: This may be set to Momentary, Short, or one of 22 values, ranging from one second to two hours. Note: Further and more detailed descriptions of all of the above Loudness terms Page 26 iVAM1-12G...
  • Page 27: Source Select

    This screen also shows sources which are unlicensed and therefore nonfunctional. These sources are shown in a gray color. To license these sources so that they may be used, contact Wohler Technologies. Figure 2-16 shows the Source Select Menu.
  • Page 28 AoIP CH 1-16 AoIP CH 17-32 AoIP CH 33-48 AoIP CH 49-64 Valid license is required This selection requires a license from Wohler to enable. Please call at +1-510-870-0810 or email at support@wohler.com. Thank you! Back Touch Back to return to the Source Select menu or touch Menu to return to the Main Menu.
  • Page 29: Presets

    Figure 2-18: All Presets Screen - Group Selection The Presets are normally arranged into Groups. Use this screen to select which Preset-containing Group to examine. After selecting one of the Groups, the Preset Selection screen shown in Figure 2-19 is shown. Page 29 iVAM1-12G...
  • Page 30 To return to the All Presets Group Selection screen instead, touch the Groups button. To return to the Menu without making a selection, touch the Menu button. Figure 2-20: All Presets Screen - No Presets To return to the Menu from this screen, touch the Menu button. Page 30 iVAM1-12G...
  • Page 31: Preset Favorites

    Preset to select it. To exit this screen without making a selection, touch Menu. If no Favorite Presets have been designated, this screen will appear as shown in Figure 2-22. Figure 2-22: Preset Favorites Screen - No Favorites Page 31 iVAM1-12G...
  • Page 32: Unit Settings

    Touching the Unit Settings selection on the Main Menu screen proceeds to the Unit Settings Menu, which contains additional menu selections. The Unit Settings Menu is shown in Figure 2-23. This is an intermediary menu which leads to other menus and screens. Figure 2-23: Unit Settings Menu Page 32 iVAM1-12G...
  • Page 33: Speaker Options

    Touching the Speaker Options selection on the Unit Settings Menu screen proceeds to the Speaker Options screen. The controls on this screen affect various characteristics of the monitored audio as heard on the iVAM1-12G. This screen is shown in Figure 2-24.
  • Page 34: Meter Scales

    Touch the left or right arrows to select the scale. A representation of the chosen scale will be shown at the right. The possible scales that can be selected are shown in Figure 2-26. Figure 2-26: Meter Scale Selection Page 34 iVAM1-12G...
  • Page 35 10 ms to reach -2 dB of IEC Type II -24 dB 2.8 sec. settled reading None Bar or Floating Segment Not Displayed When you have made your choices, touch Save to retain them. Touch Back or Meters to exit this screen. Page 35 iVAM1-12G...
  • Page 36: Unit Configuration

    3. AES termination: AES signals should have one and only one termination. This termination should physically be at the last destination of an AES coax cable. If the iVAM1-12G is the last connection in a series of AES connections, then its terminations should be turned on. A symptom of too many terminations (or no termination) is that no signal appears to be present on the AES input.
  • Page 37: Phase Configuration

    Unit Settings menu. 3. Save & Exit: When you have finished making the changes you want on this screen, touch the Save & Exit button to save the changes and return to the Unit Settings menu. Page 37 iVAM1-12G...
  • Page 38: Hdmi Settings

    (EDID) to disclose their capabilities to the video source. The iVAM1-12G can use this information to ensure its compatibility with the HDMI Monitor. If you decide that you do not want the iVAM1-12G to receive this information, set this switch to Off. By default this switch is set to On.
  • Page 39: Analog Configuration

    Analog Config screen. Contained in this menu is an Analog Reference as illustrated in Figure 2-30. The parameters set on this screen pertain to the Analog Input and Analog Output DB25 and XLR connectors on the rear panel of the iVAM1-12G. Figure 2-30: Analog Configuration Screen Analog Config...
  • Page 40: System Options Menu

    (fixed) or a dynamic (DHCP) network address. Figure 2-32: Network Settings Screen 1. To change the IP Address, Net Mask, Gateway, or DNS, tap the item you would like to change. A keypad will appear, as shown in Figure 2-33. Page 40 iVAM1-12G...
  • Page 41 (fixed) network address, touch the DHCP button again. The colors of the buttons will return to the ones depicted in Figure 2-32. Figure 2-34: Network Settings: DHCP 1. To complete the network addressing scheme change, touch the Save button. This will save the changes you selected. Page 41 iVAM1-12G...
  • Page 42: System Reboot

    Figure 2-35: System Reboot If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.
  • Page 43: System Update

    Touching the System Update selection in the System Options Menu displays System Update screen as shown in Figure 2-36, showing the current software version of the product. To update the system software locally from the iVAM1-12G front panel, follow the procedure in the Local Update from the Front Panel section of Appendix A.
  • Page 44: Factory Reset

    Mac address 28.) If you have any doubt as to whether you should press Yes, press Back or No instead, and contact Wohler Technical Service for advice. Pressing Back or No will return you to the System Options menu.
  • Page 45: System Information

    System Details screen as shown in Figure 2-38. This screen lets you view the product Serial Number, Software Version, and various other information. Figure 2-38: System Details Screen The information shown on this screen is read only and cannot be changed. Touch Back to return to the System Options Menu. Page 45 iVAM1-12G...
  • Page 46: Chapter 3: Technical Info

    CHAPTER 3: Technical Info Table 3–1: iVAM1-12G Specifications Specification Values/Domains Power Requirements 100 VAC to 240 VAC ± 10%, 50/60Hz Power Consumption 65 Watts Dimensions 1.75” x 19” x 5.5” (45mm x 483mm x (H x W x D) 140mm), standard 19” rack mounting Shipping/Net Weight 8 lbs.
  • Page 47 Power Output 5 Watts RMS, 12 Watts peak (each side) Acoustic Frequency 150 Hz to 16 kHz (± 5 dB) Response Headphone Out - Stereo 40 Hz to 20 kHz (± 1 dB) Headphone Load 8Ω to 150Ω Page 47 iVAM1-12G...
  • Page 48 Table 3–2: iVAM1-12G I/O Options Option Part # Description MADI optical fiber transceiver. Multi-Mode, LC SFP-Madi-MM- 829081 (fiber) connectors. SFP module with software Fiber activation key. MADI optical fiber transceiver. Single-Mode, SFP-Madi-SM- 829082 LC (fiber) connectors. SFP module with Fiber software activation key.
  • Page 49 **MN-Set is configuration software that is necessary so that you can set up this module. It is available at no cost either from its manufacturer, Embrionix, or by contacting Wohler Technologies Technical Service. Table 3–3: iVAM1-12G Option Cards Option Part # Description Enables decoding and monitoring of Dolby®...
  • Page 50 Figure 3–1: iVAM1-12G Block Diagram 12G-SDI Input 1 HDMI Output Video from SDI 1, 2, or SFP 12G-SDI Input 2 Video SDI-1 LKFS-M : -20.5 12G/2160p/60Hz 12G-SDI Output Selector Audio & Video from SDI 1, 2, or SFP Monitoring Processor...
  • Page 51: Chapter 4: The Ivam1-12G Web Gui

    The self-contained iVAM1-12G Web GUI allows you to customize the configuration of the iVAM1-12G to suit your needs. If the default configuration suits your needs and you prefer to use it that way, then you do not need to use the iVAM1-12G Web GUI.
  • Page 52: Network Connection

    GUI. Network Connection When connected to a network, the iVAM1-12G address will need to be changed to another address in order to be compatible with the address assignments for that particular network. Immediately after the host setup is complete, change the iVAM1-12G’s address.
  • Page 53: Network Setup

    Network Setup Make network IP Address changes for the local iVAM1-12G Management (MGMT) Port here. Figure 4–2: Set IP Addresses iVAM1-12G The procedure for changing the IP Address information is as follows: 1. Use DHCP? Check this box if your network has a DHCP server and you want to use dynamic addressing.
  • Page 54: Dashboard

    Throughout the Web GUI, pages are a click or two away using the list of selections on the left side. The Dashboard page shows all of the available Preset configurations at a glance. The iVAM1-12G allows you to assign Presets to particular groups. In Figure 4-3, two groups, Operator-1 and Operator-2 are shown.
  • Page 55 Figure 4-4, to the right of the associated Recall button. After clicking the Preset Edit button, the screen shown in Figure 4-5 will appear. Clicking a Group Edit button will cause the screen in Figure 4-6 to appear. Page 55 iVAM1-12G...
  • Page 56 1. Delete: Remove the Preset from the system. Do Not delete the currently active Preset. 2. Rename: Rename the Preset, but keep all of its other characteristics. 3. Make Favorite: Make this Preset a favorite. This can be done for frequently used Presets. Page 56 iVAM1-12G...
  • Page 57 Figure 4–6: Dashboard Group Edit The Edit options for a Group are as follows: 1. Delete: Delete the Group and all of the Presets it contains. 2. Rename: Rename the Group, but keep all of its other characteristics. Page 57 iVAM1-12G...
  • Page 58: Audio Meters

    Audio Meters Click on Audio Meters to remotely display the audio meters of the iVAM1-12G. This display is shown in Figure 4-7. Also displayed is the name of the source that the meters are displaying. In Figure 4-7, this is SDI/BNC-1.
  • Page 59: System Preferences

    Reference. This tab is shown in Figure 4-8. This System Audio Clock Reference setting can be overridden by the optional System Clock Reference setting in the Preset Management menu when the Preset is chosen. Figure 4–8: System Audio Clock Reference Tab Page 59 iVAM1-12G...
  • Page 60: Loudness Configuration Tab

    Loudness is to be calculated on the Loudness Meter. This tab is shown in Figure 4-9. Figure 4–9: Loudness Configuration Tab iVAM1-12G The following settings can be made on this tab: 1. Loudness Standard: This is the loudness standard by which the loudness calculation is made.
  • Page 61: Phase Indicator Configuration Tab

    Select All and Reset All buttons are also provided. Figure 4–10: Phase Indicator Configuration Tab iVAM1-12G When you have finished making the settings click Apply to save them or click Cancel to discard them.
  • Page 62: Preset Management

    Selection Selection Preset Input Routing iVAM1-12G 1. Preset Configuration: You may create a new Preset, adjust an existing Preset, or create a new Preset from an existing Preset: To create a new Preset, enter the name for the new Preset in the •...
  • Page 63 Cluster anything you want by simply changing the words within the Cluster Name field. When finished, click Update. To undo your change, click Reset. To undo all of the Cluster changes for the 16 channels, click Reset All. Page 63 iVAM1-12G...
  • Page 64 Phase Indicator Settings and then simply click each switch to the desired on or off position. Select All and Reset All buttons are also provided. Figure 4–12: Global Phase Indicator Enable / Disable Global Phase Indicators iVAM1-12G Page 64 iVAM1-12G...
  • Page 65 Preset or as a default for the whole system. Refer to the Global Output Routing section in this chapter to learn the function of each of the checkboxes and of the matrix in this tab. Page 65 iVAM1-12G...
  • Page 66 Save button to save the Preset, click the Save & Apply button to save the Preset and make it the current Preset, or click the Reset button to discard the changes just made. These selections are shown in Figure 4-14. Page 66 iVAM1-12G...
  • Page 67: Dolby Presets

    1 - 16 to meters 1 - 16, simply click the Autofill button. Note that by default, channels 15 and 16 are a downmix of the decoded Dolby channels. When you have finished making all of the settings for this Dolby Preset, click Save & Apply. Page 67 iVAM1-12G...
  • Page 68: Output Routing

    Six or eight channels could be directed to the AES outputs, which could feed an external surround sound system. Contact Wohler Sales to purchase the license for the OPT-OUTPUT- ROUTING feature.
  • Page 69: Destination Outputs

    The source inputs which may be routed are described in this section. 1. Cluster Information: Cluster information show type of cluster and cluster name. 2. Speaker Assignment: Speaker assignment can be used to configure to which speakers the audio is routed to. The possible options are: Left Right Page 69 iVAM1-12G...
  • Page 70: Output Options

    What signal outputs can be controlled using the Output Routing feature? All the outputs on the iVAM1-12G can be controlled using the Output Routing feature. This includes – Internal Speakers, Analog XLR outputs, all 4 pairs of AES outputs on HD-15, AoIP Pair 9 and Pair 10 and all 4 pairs of HDMI outputs.
  • Page 71: How Do The Outputs Behave If I Do Not Purchase Opt-Output-Routing License

    Using Global Output Routing (optional licensing upgrade), you may route any signals to the XLR & AES outputs. You may route signals to the XLR outputs using the Analog/XLR checkboxes and route signals to the AES outputs by using the AES/Pair 1 to Pair 4 checkboxes. Page 71 iVAM1-12G...
  • Page 72: How Do I Have A Downmixed Pre-Fade Output On Aes Pair-1 Combined With A Post-Fade Output On The Analog Xlrs

    The setting shown above determines that outputs will follow the Audio Meter screen solos & mutes for the XLR outputs because the checkbox is checked. It is not checked for the AES outputs, so they will not be affected by the solo & mute Page 72 iVAM1-12G...
  • Page 73: How Do I Route Only Specific Monitored Channels To The Analog Xlr Outputs

    The Global Output Routing feature allows channels to be routed or combined and routed to various destinations. For example, channels 1 to 8 can be routed to AES outputs, while channels 9 to 16 can be routed to Analog XLR outputs: Page 73 iVAM1-12G...
  • Page 74: How Do I Keep The Internal Speakers Muted And Have Audio Only On The Analog Xlr Outputs

    What are AoIP-Pair 9 and AoIP Pair 10? AoIP-Pair 9: Selected inputs will be mixed to AoIP transmit channels 17 and 18. Note that configuration for channels 1 - 16 is not supported. Use a Dante Controller Page 74 iVAM1-12G...
  • Page 75 In the Output Routing setting, for the Analog XLR outputs, keep the Volume Control checkbox unchecked and the Solo/Mute checkbox checked. This ensures that the Volume Control is not applied to the outputs, while the Solos/Mutes are. Page 75 iVAM1-12G...
  • Page 76: Preset Replication

    To start Preset Replication, click on the Preset Replication tab on the master unit. This will start the unit discovery process and will list all the iVAM1-12G units that you currently have on your network. The discovery process will continue for a period of 2 minutes.
  • Page 77 The progress of the Preset replication for each unit, as the Presets are being copied, will be displayed in the Process column. When all of the Presets have been copied to each of the selected units, you may leave this screen. Page 77 iVAM1-12G...
  • Page 78: Import/Export Presets

    The iVAM1-12G will create Preset Tags for the each set of Presets. Refer to Figure 4-19. You may also change these Preset Tags, using the Preset Change Field. They allow you to quickly resolve questions about which Presets on various units are the most up to date.
  • Page 79: Import Configuration

    If there were any errors, repeat these steps to try again. Figure 4–20: Database Export Import Configuration Use the following steps to copy the Preset configuration into the iVAM1-12G: 1. Click the Choose File button as shown in Figure 4-20 and select the Preset Tag you would like to import.
  • Page 80 Figure 4–21: Database Import Page 80 iVAM1-12G...
  • Page 81: System

    These tabs are explained in the following three sections. System Information This tab displays a variety of information about the iVAM1-12G. It is shown in Figure 4-22. This information could be useful to view if you are contacting Wohler Technical Service.
  • Page 82: Sfp Information

    This tab displays a variety of information about the module inserted into the SFP slot on the rear panel of the iVAM1-12G. It is shown in Figure 4-23. This information could be useful to view if you need to ascertain what module, if any, is installed, or if you are contacting Wohler Technical Service.
  • Page 83: Licenses

    This tab displays the license number for each of the modules or features in the iVAM1-12G. It is shown in Figure 4-24. You will use this tab to enter any new license numbers that you purchase. Contact Wohler Sales to obtain new license numbers.
  • Page 84: Factory Reset

    If you have any doubt as to whether you should perform a Factory Reset, do not click the Initiate Factory Reset button. Contact Wohler Technical Service for advice. Factory Reset will also reset your IP address to the default one. After a Note: Factory Reset, the IP Settings will need to be updated.
  • Page 85: Reboot System

    The Reboot System function should be used with a bit of caution. It puts the iVAM1-12G out of service for several minutes while it is rebooting, and this may unexpectedly interfere with the use of the product by the remote operator.
  • Page 86: Appendix A: Software Upgrades

    Introduction This chapter describes how to download a software update file to your computer, transfer it to a USB flash drive and install the updated into an iVAM1-12G. Download the Software The iVAM1-12G software update can be found at http://www.wohler.com, under Product Downloads on the Products >...
  • Page 87: Local Update From The Front Panel

    USB flash drive. 2. Insert the USB flash drive with iVAM1-12G update package(s) into the front panel USB jack. 3. From the Menu screen, touch System Options. The screen shown in Figure A-1 will appear.
  • Page 88 The upgrade will take 5 minutes or more, after which the iVAM1-12G will restart. After the system has completed its restart cycle and is once again operational, you may then remove the flash drive.
  • Page 89: Updating Via The Web Gui Using A Flash Drive

    USB flash drive. 2. Connect to the iVAM1-12G with the Wohler Web GUI. Navigate to the System | System Update menu, as shown in Figure A-5. If the iVAM1-12G...
  • Page 90 Figure A-8 – Software Upgrade in Progress 7. At this point, wait for the update to complete. It may take several minutes, Page 90 iVAM1-12G...
  • Page 91: Updating An Ivam1-12G Remotely

    Use the following steps to update the iVAM1-12G software: 1. The Software Update files you downloaded earlier must be in the same computer that is running the Web GUI. Connect to the iVAM1-12G with the Wohler Web GUI. Navigate to the System | System Update menu. Click within the large blue dotted line rectangle at the right of the screen.
  • Page 92 3. At this point, wait for the update to complete. It may take several minutes, until the it is critical not to disturb the iVAM1-12G or the Web GUI update process is complete. When it is complete, the iVAM1-12G will restart.
  • Page 93: Updating Multiple Units Remotely

    Use the following steps to update one or more iVAM1-12G units remotely by transferring the software from a previously updated iVAM1-12G: 1. If any of the iVAM1-12G units that you intend to update remotely may be in use, contact the people using them and let them know what you will be doing.
  • Page 94 Figure A-13 – List of Found iVAM1-12G Units 4. Then click Update Selected Devices. The window shown in Figure A-14 will appear. Figure A-14 – Apply System Package 5. Click Apply System Update. The screen shown in Figure A-15 will appear.
  • Page 95 6. At this point, wait for each update to complete. It may take several minutes, it is critical not to disturb any of the iVAM1-12G units or the Web until the update process is complete. When it is complete, each iVAM1- 12G will restart.
  • Page 96: Appendix B: Dante Network Setup

    On iVAM1-12G, the AoIP source can be selected through the Source Select option. The iVAM1-12G is set up at the Wohler factory to be used as a slave rather than a master within the Dante network. Other devices or software, such as a Dante Controller, are expected to be responsible for most device configurations and all audio routing.
  • Page 97 Card ID will be shown in red, e.g. Wohler-xxxxxx where xxxxxx is the last 6 hex digits of the card MAC address as shown in B-1. This usually indicates that the IP address of the card is not in the same subnet as the Dante Controller host.
  • Page 98: Dante Tm Device Setup

    Dante Device Setup The iVAM1-12G’s default Dante Device Name is “Wohler- …” followed by the last 6 digits of the Dante port MAC address, as shown in Figure B-2. This name can be changed by the Dante Controller to appear that way on the network, but that will not change the iVAM1-12G’s unit name appearing on GUI pages and iVAM1-12G...
  • Page 99: Dante Clock Selection

    Dante Clock Selection While the Brooklyn’s internal clock is highly accurate, the iVAM1-12G does not have provisions for external sync clocks, such as those that are GPS or media reference (video genlock or audio word clock) based. So it is generally not the best candidate to be the PTP Master Clock (commonly called the “grandfather clock”) for the...
  • Page 100: Aes67

    AES67 The iVAM1-12G Brooklyn II can be configured for AES67 operation. AES67 operation with Dante is limited to eight or less receive and transmit channels at 48 kHz sample rates. 24 bit linear (L24) encoding and 1 msec packet time are fixed default transmit parameters.
  • Page 101 Figure B–6: Device View - Network Config Page 101 iVAM1-12G...
  • Page 102: Device Lock

    Device Lock command at this time. Dante Firmware Upgrades Wohler iVAM1-12G monitors ship with current Brooklyn II firmware as of the option installation date. The version information is found in the Dante Controller Device View-Status page. iAM software/firmware is tested with the latest Dante code release.
  • Page 103: Additional Information

    8171152, European Patent 2255541, Chinese Patent ZL200780026677.0 and other patents pending or issued, see or such other www.audinate.com/patents legend as Audinate may stipulate from time to time to the Manufactured Product and any packaging and marketing materials therefor. Page 103 iVAM1-12G...
  • Page 104: Appendix D: Ravenna (Zman) Setup

    Merging ZMAN Card is virtually plug and play. The iAM rear panel AoIP jack supports 1Gb/s and 100Mb/s Ethernet devices in Ravenna Audio over IP network configurations. iVAM1-12G channel source selections are made by choosing Input Type ‘AoIP’ in Configuration-Configure Presets page regardless of which AoIP option is installed.
  • Page 105: Configuring The Aoip Merging Option Card

    The iVAM1-12G can be configured using its Front Panel controls or its web interface through its Management port. Details specific to the iVAM1-12G can be found in Chapters 2 and 4 of this manual.
  • Page 106: Getting Started | General Settings

    6. Network Interface: Note the address of the card and its type (Zeroconf, DHCP, Static). (If necessary, the address can be changed to another type such as a Static address which must include a Network Mask and Gateway.) Page 106 iVAM1-12G...
  • Page 107: Getting Started | Ptp

    Announce: This is PTP Profile related - PTP announcement interval (1 - 2 - 4 - 8 -16 seconds) i. Sync: This is PTP Profile related (0.0625 - 0.125 - 0.25 - 0.5 seconds) 3. Status: Page 107 iVAM1-12G...
  • Page 108: Getting Started | Session Sources

    7. TTL: Time to Live (also called Hop Limit) - This value should not be modified. 8. Payload type: RTP Payload type - This value should not be modified. Page 108 iVAM1-12G...
  • Page 109: Getting Started | Session Sinks

    3. Label: This is the Sink name. 4. Source: This is a drop down menu to select a source (both sap and bonjour advertised sources are automatically listed). 5. Manual: This allows manual entry of an SDP. Page 109 iVAM1-12G...
  • Page 110: Getting Started | Session Info

    (usually the same as the source name) 4. Clock Domain: This is the PTP clock type and domain 5. Payload: Selections are Payload / Codec / Sampling Rate / Number of Channels 6. SDP: This displays detailed SDP information on the current stream. Page 110 iVAM1-12G...
  • Page 111: Getting Started | Ins/Outs

    Getting Started | I/O Router This page allows remapping of incoming channels to different internal channel assignments. For example, Stream channel 1 can be remapped to Merging card Channel 0, and so on. Figure D-6: Getting Started | I/O Router Page 111 iVAM1-12G...
  • Page 112: Operation

    IAM interface for display on meters and speakers, etc. The iVAM1-12G must be set to receive AOIP from the Source Select Front Panel menu or a browser iVAM1-12G GUI.
  • Page 113 For example, for monitoring 2 SDI sources (four 8 channel Flows), assign two flows to 1-8 and 9-16 and the next SDI signal to 17-24 and 25- 32. Touch the iVAM1-12G AOIP selection menu to select the proper range to monitor, up to 57-64.
  • Page 114: Zman Session Sources

    Figure D-8: Session Sources Tab ZMAN Updating The Zman card is pre-initialized with the correct Wohler firmware load. In case of future upgrades, use the following steps: 1. In Aneman, right click the ZMAN entry on the bottom Devices section, and select Maintenance Mode.
  • Page 115: Appendix E: Api Documentation

    Follow the instructions in the First Time IP Assignments section of Chapter 4 to achieve the required network connection. API: Presets 1. GET Active Preset Method: GET /api/cf/presets/current Example Response: "serial_number": "", "model": "iVAM1-12G", "version": 1.3, "name": "iVAM1-12G", "result": { "group": { "Id": 1, "Name": ""...
  • Page 116 "NumberOfMeters": 2, "FirstMeter": 3, "Name": "Stereo 2.0 #2", "Type": "Stereo", "MuteOnPresetRecall": true "NumberOfMeters": 2, "FirstMeter": 5, "Name": "Stereo 2.0 #3", "Type": "Stereo", "MuteOnPresetRecall": true "NumberOfMeters": 2, "FirstMeter": 7, "Name": "Stereo 2.0 #4", "Type": "Stereo", "MuteOnPresetRecall": true "NumberOfMeters": 2, Page 116 iVAM1-12G...
  • Page 117 "Cage": 1, "Channel": 8, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Right" "2": { "Source": { "Slot": 1, "Cage": 1, "Channel": 2, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, Page 117 iVAM1-12G...
  • Page 118 "Source": { "Slot": 1, "Cage": 1, "Channel": 11, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Left" "15": { "Source": { "Slot": 1, "Cage": 1, "Channel": 15, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, Page 118 iVAM1-12G...
  • Page 119 "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Right" "6": { "Source": { "Slot": 1, "Cage": 1, "Channel": 6, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Right" "7": { "Source": { Page 119 iVAM1-12G...
  • Page 120 "Cage": 1, "Channel": 1, "ConnectorType": "BNC", "InputNo": 1, "InputIndex": 0, "Type": "SDI" "VolumeDb": 0, "DelayMs": 0, "Speaker": "Left" "SystemClockSource": { "Slot": 0, "Cage": 0, "ConnectorType": "None", "InputNo": 0, "Type": "None", "Pair": "Favorite": 0, "PresetId": 1, "GroupName": "G1" Page 120 iVAM1-12G...
  • Page 121 "Name": "SDI", "Id": "Id": "Name": "AES", "Presets": [ "Favorite": 0, "Name": "dfsdf", "Id": "Id": 4. GET to recall the preset Method: GET api/op/presets/<int:presetID>/activate Example Response: "error": null, "params": { "PresetId": "result": { "PresetId": 1, "GroupId": 1, "PresetName": "SDI", Page 121 iVAM1-12G...
  • Page 122 Method: POST api/op/preset/<int:presetID>/delete Example Response: "error": null, "params": { "PresetId": "result": { "PresetId": 7. POST to rename group Method: POST /api/op/group/<int:groupID>/newGrpNameSdi/rename Example Response: "error": null, "params": { "GroupId": 1, "GroupName": "newGrpNameSdi" "result": { "GroupId": 1, "GroupName": "newGrpNameSdi" Page 122 iVAM1-12G...
  • Page 123 Example Response: "error": null, "params": { "PresetId": 4, "Favorite": "result": { "PresetId": 4, "Favorite": 10. Source Select Method: POST /api/op/sourceselect Body content for SDI/SMPTE-2022-6/ SMPTE-2110 "SourceType": “<String: SDI Input Source>” Note: Allowed SDI input sources are: "Bnc-1.Sdi", "Bnc-2.Sdi", Page 123 iVAM1-12G...
  • Page 124 "SourceType": "Analog.DB25" Body content for Aes "SourceType": "Aes" 5. Body content for Aoip "SourceType": "Aoip", "ChannelGroup": <Int: 1-16> Note: ChannelGroup 1 => Channels 1-16 and ChannelGroup 2 => Channels 17-32 and so on 6. Body content for TOSLINK Page 124 iVAM1-12G...
  • Page 125 "SourceType": "Toslink" Example Response: "unit_name": "iVam", "model": "iVam", "api_version": 1, "message": "Input Source Toslink has been applied successfully", "serial_number": "162978", "status": Page 125 iVAM1-12G...
