Page 2: Before You Begin
BEFORE YOU BEGIN What is included 1 × H-S6 snow machine 1 × power cord 1 × fluid hose 1 × 20L tank 1 × 10M directional hose 1 × waterproof cover 1 × wireless remote 1 × user manual... - Page 3 The information and specifications contained in this User Manual are subject to change without notice. DJPOWER assumes no responsibility or liability for any errors or omissions and reserves the right to revise or to create this manual at any time. Copyright © 2022 DJPOWER.
- Page 4 2.1.1 Description H-S6 is a convenient ultra-quiet snow machine launched by DJPOWER, which can pack accessories, pipelines, and consumables into the flight case. This machine improves the disadvantages of the traditional snow machine hanging high. It has a 10M hose (can be extended to 20 meters), which can be extended to higher point or used at a distance, equipped with a 20L tank capacity.
- Page 5 A 10M hose (can be extended to 20 meters) can be extended to higher point or used at a distance • 20L big capacity tank, avoid adding consumables frequently. • With high-power fan, adjustable snow output, to meet any large realistic snow • Use only DJPOWER high-quality PRO-X.2 snow liquid. 2.1.3 Product Overview...
-
Page 6: Technical Specifications
2.1.4 Production Dimensions TECHNICAL SPECIFICATIONS Voltage AC 220-240 V, 50/60 Hz Breaker Type Overload Protector AC power Breaker data 10A/250V Total Power 850W Tank capacity Capacity 20 L √ Adjustable Output Output Fluid Consumption Rate Appr. 2.5min/L Lie flat √ Keep upright √... -
Page 7: Installation Setting
INSTALLATION SETTING 4.1.1 AC Power supply H-S6 has a fixed voltage power supply, which can be used according to the specific model AC 220 V-240 V, 50/60 Hz. To determine the power requirements of the machine (circuit breaker, power outlet and wiring), please refer to the values listed on the machine panel label, or refer to the machine specification data. - Page 8 • When choosing the installation location of the nozzle, please take the convenience of replacing the nozzle and regular maintenance into consideration 4.1.4 Adjustable Mounting Bracket Adjust mounting bracket by loosening screws, set the nozzle to desired angle and tighten the screw to finish adjustment.
- Page 9 WORKING WITH THE H-S6 5.1.1 Preparations Before operating the machine, prepare according to the following steps: Step 1: After checking that the machine and accessories are not damaged, place the machine on a flat surface with at least 50 cm of space around the machine.
- Page 10 Press FUNCTION button, there are 11 pages as below: LCD display Description Value Range Ready To Fog It shows that the machine is ready to TOPCAT H-S6 work Interval Set 5～200s Snow output interval setting (the range is from 5 to 200 seconds) Duration Set Snow output duration setting (the 5～200s...
- Page 11 able to be controlled. If you need to control, you need to rematch The function switch will continue to Last timer work regularly after power off and ON/OFF ON/OFF restart, ON means open, OFF means close Press ▲&▼ to choose the language. Language After setting, press ENTER button to English...
- Page 12 After the wireless receiver has been tested, it will be fixed on the panel of the H-S6, please do not try to pull it out.
-
Page 13: Technical Information
6-250 Snow Output 1-100% TECHNICAL INFORMATION 6.1.1 Maintenance H-S6 needs regular cleaning and maintenance to achieve the best results. Some cleaning and maintenance steps are essential. Here are the recommended cleaning steps: • Unplug the product from power. • Empty snow fluid from the machine. - Page 14 If the cleaning mode is not turned off manually, the machine will automatically turn off the cleaning function after the machine cleaning time reaches 1 minute. • Test-run your H-S6 on a monthly basis to achieve the best performance. 6.1.2 Storage...
