Summary of Contents for Frico Soloclim SCV21DCIN
- Page 1 Original instructions Soloclim vertical ..9 ..16 ..24 ..32 ..40 ..48 ..56 ..64 ..72 ..80 ..88...
- Page 2 Soloclim vertical The introduction pages consist mainly of pictures. For translation of the English texts used, see the respective language pages. Introduktionssidorna består huvudsakligen av bilder. För översättning av de engelska texter som används, se respektive språksidor. Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de engelske tekstene, se de respektive språksidene Les pages de présentation contiennent principalement des images.
- Page 3 Soloclim vertical Fig.1 Components 1. Touch screen control panel 6. External air outlet 10. Data label 2. Air outlet deflector 7. External air intake 11. Terminal block 3. Front panel 8. Condensate drain tube 12. Air filter 4. Intake grille 9.
- Page 4 Soloclim vertical Fig.3 Minimum distances Fig.4 Drilling template 2000 Outlet Inlet 2000 A. Holes for M8 plugs B. Ø162 mm hole for outlet air duct C. Ø162 mm hole for inlet air duct D. Ø18 mm condensate drain back E. Ø18 mm condensate drain base F.
- Page 5 Soloclim vertical Fig.5 Air ducts Plastic sheets for air ducts Fig.6 Wall grilles A. Chain B. Flange C. Spring D. Outside air grill...
- Page 6 Soloclim vertical Fig.7 Mounting the unit 1. Wall bracket 2. Interlocking points 3. Anchor brackets Fig.8 Drainage 1. Drainage tube 0,6 m (Ø18 mm outside, Ø13 mm inside) 2. Safety drain Fig.8b 300 mm...
- Page 7 Soloclim vertical Fig.9 Opening the unit / Access to the terminal block N PE Wiring diagram GR Grey BR Brown double sided tape YG Yellow-Green BL Blue CP Presence contact N Neutral Phase IG System main switch PE Earth connection Accessories Art.
-
Page 8: Technical Specifications
Soloclim vertical Technical specifications Art. no Type Cooling Heat Voltage Refrigerant WxHxD Weight* output* output* [kW] [kW] [mm] [kg] 999925 SCV21DCI 2,04 2,10 2,72 3,10 230V~ R410a 500x1398x185 999926 SCV23DCI 2,35 2,36 2,75 3,15 230V~ R410a 500x1398x185 ) According to standard EN 14511 ) Weight without refrigerant SCV21DCIN SCV23DCIN... -
Page 9: General Instructions
• After transport or if the unit has been tilted (e.g. during the safety manual "Repair and maintenance - cleaning), leave it for an hour before connecting it to units with R290/R32/R410a" at www.frico.net. the mains supply. • Always keep the unit in an upright position. -
Page 10: Identification Of The Unit
IN: air inlet wall grille manual "Repair and maintenance - units with R290/ OUT: air outlet wall grille R32/R410a" at www.frico.net. 1. Check the template to identify the outlet duct. 2. Fold the outlet wall grille. Identification of the unit 3. -
Page 11: Electrical Installation
Soloclim vertical 6. Fasten the unit to the upper part of the bracket. separation of at least 3 mm, should only be wired by a competent electrician and in accordance with the latest 7. Verify that the bracket fits securely into the interlocking edition of IEE wiring regulations. -
Page 12: Control Panel
Soloclim vertical Control Soloclim is controlled by the touch-screen control panel on the front of the unit or by the supplied remote control. Control panel Remote control Setpoint Heating mode Comfort mode Night Increase / up Decrease / down Air deflector On / off Setting power Timer... - Page 13 Soloclim vertical Dehumidification mode Setting power In this mode, the unit dehumidifies the room. The unit has five power settings - Minimum, Selecting this mode is useful during mid-seasons, Medium, Maximum, Dual Power and Automatic - i.e. on rainy days when the temperature is selected by pressing this key sequentially.
-
Page 14: Troubleshooting
Check that the system main switch has not been tripped (if it The unit does not work. has, reset it). If the problem repeats immediately, contact Frico Technical support and do not try to make the unit work. The remote control does not work. - Page 15 In the event of an alarm, check that the tube is not bent or obstructed, thus preventing the water from flowing out. If the fault cannot be rectified, please contact Frico Technical support specifying the error code to simplify intervention.
- Page 16 Main offi ce Frico AB Tel: +46 31 336 86 00 Industrivägen 41 SE-433 61 Sävedalen mailbox@frico.se Sweden www.frico.net For latest updated information and information about your local contact: www.frico.net...
