USB-5201 User's Guide

USB specifications

Parameter
USB device type
Device compatibility
USB cable type
USB cable length

Environmental

Parameter
Operating temperature range
Storage temperature range
Humidity

Mechanical

Parameter
Dimensions (L × W × H)
User connection length

Screw terminal connector

Parameter
Connector type
Wire gauge range
Table 13. USB specifications
Specification
USB 2.0 (full-speed)
USB 1.1, USB 2.0
Self-powered, 500 mA consumption max
A-B cable, UL type AWM 2725 or equivalent. (min 24 AWG VBUS/GND,
min 28 AWG D+/D–)
3 meters (9.84 ft) max
Table 14. Environmental specifications
Specification
0 °C to 70 °C
–40 °C to 85 °C
0% to 90% non-condensing
Table 15. Mechanical specifications
Specification
128.52 x 88.39 × 35.56 mm (5.06 × 3.48 × 1.43 ft)
3 m (9.84 ft) max
Table 16. Screw terminal connector specifications
Specification
Screw terminal
16 AWG to 30 AWG
24
Specifications
