Westomatic Primo Mini Manual

Service menu
Hide thumbs Also See for Primo Mini:

Advertisement

Quick Links

Download this manual
SERVICE MENU

Advertisement

loading
Need help?

Need help?

Do you have a question about the Primo Mini and is the answer not in the manual?

Questions and answers

Related Manuals for Westomatic Primo Mini

Summary of Contents for Westomatic Primo Mini

  • Page 1 SERVICE MENU...
  • Page 2 SERVICE MENU The service menu allows engineers to access drink and machine settings. 01. INGREDIENTS 02. RECIPES 03. SETTINGS 04. COUNTERS 05. SERVICE NOTIFICATIONS 06. HARDWARE 07. ERROR MESSAGES 08. SOFTWARE 09. CHANGE PIN CODES 10. RINSE & CLEAN MESSAGES...
  • Page 3 1.INGREDIENTS You can customise your machine to suit your requirements using the service menu. Selection 1 is for canister content and calibration. 01. CANISTER CONTENT 02.INGREDIENT CALIBRATION 03. CANISTER EMPTY SIGNALLING...
  • Page 4 3 options to choose 02. INGREDIENT from: CALIBRATION Canister Content, Calibration must be Ingredient calibration, done to ensure correct almost empty? product dispense. 01. CANISTER CONTENT Select ingredient, the Each instant product estimated weight is has its own specific shown. weight.
  • Page 5 Hold the cup under the 03. ALMOST EMPTY canister chute and SIGNALLING press ACTIVATE. Collect Activate the canister the ingredient, and empty - ON/OFF repeat 2 more times. When switched ON, an Weigh the ingredients extra button is shown and divide by 3. at the top of the screen.
  • Page 6 Fill the canisters up completely. Select the canister you filled up by pressing the picture. Swipe to reach all canisters. Press confirm refill button to SAVE the canister refill. Relevant recipes are enabled again.
  • Page 7 2.RECIPES This section allows you to set up drink recipes. 01. POSITION SCREEN - used to assign recipes to the desired screen position. 02. QUICK RECIPE PRO - fine tune your drink, cup volume, taste strength etc 03. RECIPE OPTIONS - additional settings, like prices, multi-cup, recipe name etc 04.
  • Page 8 01. POSITION SCREEN. The recipe is then This allows you to assign assigned to the selected a recipe to a screen screen position 8. position. Select a screen - swipe To remove a recipe - to screen 1, 2 or 3. select the recipe you Select an empty want to remove.
  • Page 9 Select the drink you MIXER SPEED want to fine tune. Speed 1 = start speed 02. QUICK RECIPE PRO Speed 2 = end speed Speed Ratio = ratio speed 1&2 Set +/- here: TEST your recipe COFFEE (gr) SAVE your settings TOPPING (gr) CUP VOLUME (ml) TEST the drink...
  • Page 10 RECIPE ACTIVE - sliding Activate the Cup Size ON/OFF function to use different RECIPE DISABLED - cup/jug sizes recipe button does not work, and recipe button is dimmed dark. CUP VOLUME & PRICE 2 Cup sizes - Number of cup sizes per normal/large recipe (3 max) 3 Cup sizes -...
  • Page 11 Allergens Info. Jug dispensing options: Per recipe user can be PIN code 11111 warned about Lactose/ Jug volume/coffee Soy/Gluten/Wheat. Info strength adjustment slide displayed after recipe screen. Leak out time - the time Select the ingredients that the product you want to display. continues to run out of SAVE the settings the mixer.
  • Page 12 POSITION LOGO ON CUP 05. ALLERGENS INFO Horizontal / vertical Slide to switch on, position adjustment SAVE changes SAVE settings 05. ALLERGENS INFO ALTERNATIVE RECIPE The start screen shows NAME. you in orange text the Select left side to show ingredients you selected.
  • Page 13 REFERRAL RECIPES ALTERNATIVE RECIPE Select the recipe COFFEE NAME: Selecting milk/sugar CAPPUCCINO SPECIAL strength option the recipe Extra Long automatically changes into COFFEE MILK/SUGAR LOAD DEFAULTS LOAD DEFAULT VALUES Select this if you want to Select this item to reset load factory recipe.
  • Page 14 COFFEE DELAY TIME - 04. RECIPE SETTINGS time before ingredient All the parameters for starts. "building" the perfect STEPS - pause in drink. All parameters ingredient dispense based on 100ml drink UNIT 1/2/3 SUGAR DELAY TIME - Dosing Valve before ingredient Delay time - water dispense starts supply towards...
  • Page 15 Speed 1 - start speed Speed 2 - end speed Speed Ratio - ratio speed 1 & 2 Test your drink SAVE settings OTHER VALUES: Hot water / cold water delay times. INGREDIENT RANGE Adjust percentage volumes of drinks in each drink.
  • Page 16 3.SETTINGS You can adjust the settings to suit your requirements using the SETTINGS menu. 01. LANGUAGE 02. TEMPERATURE 03. DISPLAY 04. FAN 05. PAYMENT & TELEMETRY 06. OPERATOR SETTINGS 07. DEMO MODE 08. DRIP TRAY SIGNAL 09. GENERAL RECIPE OPTIONS 10.
  • Page 17 01. LANGUAGE Stand-by Temp - factory Select the language and setting is OFF. Boiler press SAVE. temp during stand-by. Extended Heating time - factory setting 5 sec. 02. TEMPERATURE 03. DISPLAY Temp boiler - Set boiler Show clock - ON/OFF temp 85°C Daylight Saving - ON/OFF Dispense release - Set...
  • Page 18 04. FAN General Settings: Speed during rest - 61% Payment System (off / 40-100%) connected - ON/OFF Speed recipe External Release - preparation - 76% ON/OFF (40-100%) Running time after Payment Status: preparation - 60sec (0- Free/paid 300sec) Decimal position - 2 Cashless payment timeout - 20sec Max Coin - £3...
  • Page 19 Currency Symbol - 09. GENERAL RECIPE ON/OFF OPTIONS - ON/OFF Position Symbol before/after amount SAVE settings External Release - Addition Sugar / Milk ON/OFF Add in the sliders for On - informs of an the options of milk or sugar. external release signal Press START Release Time - 20secs...
  • Page 20 4.COUNTERS You can receive audit information for Cleaning/Rinsing/ Operating and Recipe dispenses. 01. RINSE HISTORY 02. CLEANING HISTORY 03. RECIPE COUNTERS 04. OPERATING HOURS 05. RESET HISTORY...
  • Page 21 01. Rinse History 04. Operating Hours Time and date of For the motors in the last rinse actions. machine. 02. Cleaning History 05. Reset History Time and date of Resetting the Rinse last cleaning and Cleaning History. actions. 03.Recipe Counters Total Recipe Counters (cups) - Free/Price LowHigh / Token / Test...
  • Page 22 5.SERVICE NOTIFICATIONS You can set your water filter alerts in this section. It warns you when the water filter has reached its capacity. This can be either Litres or Months. The factory setting for Litres is 2400 (0-10000), or months is 12 (0-18). It's important to reset the counter after the filter has been replaced.
  • Page 23 6.HARDWARE You can select the components you want to check in this section. 01. INPUTS - read status of sensor 02. OUTPUTS (motors) - activate a motor 03. OUTPUTS (valves) - activate a valve 04. OUTPUTS (others) - activate another component 05.
  • Page 24 01. Inputs (sensors) 04. Outputs - others Temp = live boiler temp Select the output, hold means the ACTIVATE, component sensors are active. starts, release the ACTIVATE and the component will stop. 02. Outputs - motors Select the motor to test, hold ACTIVATE, the nominal current is shown, release ACTIVATE...
  • Page 25 7.ERROR MESSAGES You can review error messages and clear the notifications in this section. 01. READ 02. REMOVE...
  • Page 26 01. READ This shows you the last 30 error messages / time / date. 02. REMOVE Confirm with yes to remove the error log.
  • Page 27 08.SOFTWARE You can use this menu to LOAD or SAVE machine settings.
  • Page 28 SD Card is accessed via 02 Recipe Settings - can the front of the be copied from another machine - gold contacts machine - includes cup facing outwards. volume, dispensed ingredients, canister contents 01.Load Data / 03 Language - here Software you are able to load Must have an SD Card...
  • Page 29 05 Load other Variant - 02. Save Data assign ingredients to Allows you to save data other canisters to the SD card on personal settings and audit logs 06 Load Default Values 01 Personal Settings- Reset factory and default save to copy to another settings - all personal machine eg.
  • Page 30 03 Counters - contains 06 Rinse Cleaning - when all recipe counters and how often the rinse and clean cycles were run 04 Error messages - 07 Save All - saves all contains all error the options in one messages file for a full machine audit.
  • Page 31 09.CHANGE PIN CODES You can use this menu to change the pin codes. OPERATOR MENU FREE VEND RELEASE SERVICE MENU...
  • Page 32 OPERATOR MENU: SERVICE MENU: Default code = 11111 Default code = 22222 FREE VEND: Default code = 12345 RELEASE: Default code = 44321 This releases the touch screen.
  • Page 33 10.RINSE & CLEANING MESSAGES You can use this menu to inform the user when the machine mixers need a simple rinse or a thorough clean. OPERATOR MENU FREE VEND RELEASE SERVICE MENU...
  • Page 34 RINSING: Cleaning Obligated - Cups - default setting is ON/OFF - when switched 0 (0-1000) on the machine will not Days - default setting is 1 work until the clean (0-31days) program has completed. Rinsing Obligated - Rinse Machine - this gives ON/OFF - when switched instructions for a short on the machine will not...
  • Page 35 CONTACT + 4 4 ( 0 ) 1 6 2 6 3 2 3 1 0 0 W e s t o m a t i c V e n d i n g S e r v i c e s L t d , s a l e s @ w e s t o m a t i c .

This manual is also suitable for:

Primo midi
