Summary of Contents for Daikin FTXF20W1VMA
- Page 1 OPERATION MANUAL DAIKIN ROOM AIR CONDITIONER MODELS FTXF20W1VMA FTXF25W1VMA FTXF35W1VMA FTXF46W1VMA FTXF50W1VMA...
- Page 2 Features Enhanced comfort, energy savings and rapid cooling COMFORT AIRFLOW The airflow direction is upward while in COOL and DRY operation, and downward while HEAT operation. This function prevents cold air or warm air from blowing directly on your body. Page 12 ECONO This function enables efficient operation by limiting the maximum...
-
Page 3: Table Of Contents
Contents Read Before Operation Safety Precautions .......... Names of Parts ..........Preparation Before Operation ......Basic Operation AUTO · COOL · DRY · HEAT · FAN ONLY Operation ....Adjusting the Airflow Rate ....Adjusting the Airflow Direction ... Useful Functions COMFORT AIRFLOW Operation .. -
Page 4: Read Before Operation
Read Before Operation Safety Precautions Read the precautions in this manual carefully This appliance is filled with R32. before operating the unit. • Keep this manual where the user can easily find it. • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. - Page 5 Read Before Operation • Do not sit on the outdoor unit, put things on the unit, or pull the unit. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage. •...
-
Page 6: Names Of Parts
Read Before Operation Names of Parts Indoor Unit Air inlet Front panel Air outlet Flap (horizontal blade) Model name Indoor temperature Page 11 sensor • Detects the air temperature Louvres (vertical blades) around the unit. • The louvres are inside of the air outlet. - Page 7 Read Before Operation „ Open the front panel Air filter Outdoor Unit „ RXF20/25/35 Outdoor temperature Air inlet sensor (back) (back and side) Refrigerant pipes and inter-unit wire Earth terminal (inside) Air outlet Drain hose „ RXF46/50 Outdoor temperature Air inlet sensor (back) (back and side) Refrigerant pipes and...
- Page 8 Read Before Operation Names of Parts Remote Controller Display (LCD) Signal transmitter • Displays the current settings. (In this illustration, each section is shown with its displays on for the purpose of explanation.) AUTO buttons • Automatically selects an appropriate •...
-
Page 9: Preparation Before Operation
Read Before Operation Preparation Before Operation CAUTION Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the alkaline solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. -
Page 10: Basic Operation
Basic Operation AUTO · COOL · DRY · HEAT · FAN ONLY Operation The air conditioner operates with the operation mode of your choice. „ To start operation Press button of your desired operation mode. AUTO operation Press . “ ”... -
Page 11: Adjusting The Airflow Rate
Basic Operation Adjusting the Airflow Rate You can adjust the airflow rate to increase your comfort. „ To adjust the airflow rate setting Press • Each pressing of changes the airflow rate setting in sequence. AUTO Indoor unit quiet Airflow rate 1-5 (Low to High) •... -
Page 12: Adjusting The Airflow Direction
Basic Operation Adjusting the Airflow Direction You can adjust the airflow direction to increase your comfort. ATTENTION • Always use a remote controller to adjust the angle of the flap. - If you attempt to move the flap forcibly by hand when it is swinging, the mechanism may be damaged. •... -
Page 13: Useful Functions
Useful Functions COMFORT AIRFLOW Operation The air direction and flow rate are adjusted so that the air will not blow directly at people in the room. „ To start Press • “ ” appears on the LCD. COOL operation DRY operation HEAT operation Flap direction Goes up... -
Page 14: Powerful Operation
Useful Functions POWERFUL Operation POWERFUL operation quickly maximises the cooling (heating) effect in any operation mode. In this mode, the air conditioner operates at maximum capacity. „ To start Press during operation. • “ ” appears on the LCD. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. -
Page 15: Econo Operation
Useful Functions ECONO Operation ECONO operation enables efficient operation by limiting the maximum power consumption. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit. „ To start Press •... -
Page 16: Outdoor Unit Quiet Operation
Useful Functions OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. „ To start Press • “ ”... -
Page 17: Timer Operation
TIMER Operation ON/OFF TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off in the morning or at night. You can also use the ON TIMER and OFF TIMER together. [ON TIMER operation] „ To set Press “ ... - Page 18 TIMER Operation ON/OFF TIMER Operation [OFF TIMER operation] „ To set Press “ ” appears on the LCD. • Each pressing of changes the time setting by 1 hour. The time can be set between 1 and 12 hours. • The TIMER lamp lights orange. Display „...
-
Page 19: Care
Care Care and Cleaning CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fins of the indoor unit. If you touch those parts, this may cause an injury. „... - Page 20 Care Care and Cleaning CAUTION • Do not touch the aluminium fins by bare hand at the time of dismounting or mounting the filter. „ Air filter Open the front panel. Wash the air filters with water or clean them with •...
- Page 21 Care „ Filter (small) * For the applicable filter type, please refer to Page 18 Attaching Clean or replace. [Cleaning] Open the front panel and pull out the air filters. Deodorizing filter (enzyme blue) : Blue / Page 19 Titanium apatite deodorizing filter : Insert the filter.
- Page 22 Care Care and Cleaning „ Prior to a long period of non-use Operate the FAN ONLY mode for several hours on a fine day to dry out the inside. • Press After operation stops, turn off the circuit breaker for the room air conditioner.
- Page 23 When the Need Arises Indoor unit The flap does not start swinging immediately. • The air conditioner is adjusting the position of the flap. The flap will start moving soon. The air conditioner stops generating airflow during HEAT operation. Different sounds are heard. •...
- Page 24 When the Need Arises Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, consult your dealer. Not a problem Check This case is not a problem. Please check again before requesting repairs.
- Page 25 When the Need Arises Mist comes out Case Description / what to check • This happens when the air in the room is cooled into mist by the cold airflow during COOL Mist comes out of the indoor unit. or other operation. Remote controller Case Description / what to check...
- Page 26 When the Need Arises Troubleshooting „ Call your dealer immediately WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. • Continued operation in an abnormal condition may result in problems, electric shock or fire. •...
- Page 27 When the Need Arises „ Fault diagnosis by remote controller • In case the air conditioner is malfunctioning, you can check the error code via the remote controller before consulting with service personnel and informing them of the malfunction code. When is held down for about 5 seconds, “ ...
- Page 28 MEMO...
- Page 29 MEMO...
- Page 30 MEMO...
- Page 31 MEMO...
- Page 32 Quick Reference The two-dimensional bar code is a manufacturing code. 3P683779-7 M22N007 (2201) HT...
- Page 33 OPERATION MANUAL DAIKIN ROOM AIR CONDITIONER MODELS FTXF60W1VMA FTXF71W1VMA...
- Page 34 Features Enhanced comfort, energy savings and rapid cooling COMFORT AIRFLOW The airflow direction is upward while in COOL and DRY operation, and downward while HEAT operation. This function prevents cold air or warm air from blowing directly on your body. Page 12 ECONO This function enables efficient operation by limiting the maximum...
-
Page 35: When The Need Arises Faq
Contents Read Before Operation Safety Precautions .......... Names of Parts ..........Preparation Before Operation ......Basic Operation AUTO · COOL · DRY · HEAT · FAN ONLY Operation ....Adjusting the Airflow Rate ....Adjusting the Airflow Direction ... Useful Functions COMFORT AIRFLOW Operation .. -
Page 36: Read Before Operation
Read Before Operation Safety Precautions Read the precautions in this manual carefully This appliance is filled with R32. before operating the unit. • Keep this manual where the user can easily find it. • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. - Page 37 Read Before Operation • Do not sit on the outdoor unit, put things on the unit, or pull the unit. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage. •...
-
Page 38: Names Of Parts
Read Before Operation Names of Parts Indoor Unit Air inlet Front panel Air outlet Model name Flaps (horizontal blades) Indoor temperature Page 11 sensor • Detects the air temperature around the unit. Louvres (vertical blades) • The louvres are inside of the air outlet. - Page 39 Read Before Operation „ Open the front panel Air filter Outdoor Unit „ RXF60 Outdoor temperature Air inlet sensor (back) (back and side) Refrigerant pipes and inter-unit wire Earth terminal (inside) Air outlet Drain hose „ RXF71 Outdoor temperature Air inlet sensor (back) (back and side) Refrigerant pipes and...
- Page 40 Read Before Operation Names of Parts Remote Controller Display (LCD) Signal transmitter • Displays the current settings. (In this illustration, each section is shown with its displays on for the purpose of explanation.) AUTO buttons • Automatically selects an appropriate •...
-
Page 41: Preparation Before Operation
Read Before Operation Preparation Before Operation CAUTION Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the alkaline solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. -
Page 42: Basic Operation
Basic Operation AUTO · COOL · DRY · HEAT · FAN ONLY Operation The air conditioner operates with the operation mode of your choice. „ To start operation Press button of your desired operation mode. AUTO operation Press . “ ”... -
Page 43: Adjusting The Airflow Rate
Basic Operation Adjusting the Airflow Rate You can adjust the airflow rate to increase your comfort. „ To adjust the airflow rate setting Press • Each pressing of changes the airflow rate setting in sequence. AUTO Indoor unit quiet Airflow rate 1-5 (Low to High) •... -
Page 44: Adjusting The Airflow Direction
Basic Operation Adjusting the Airflow Direction You can adjust the airflow direction to increase your comfort. ATTENTION • Always use a remote controller to adjust the angle of the flaps. - If you attempt to move the flaps forcibly by hand when they are swinging, the mechanism may be damaged. •... -
Page 45: Useful Functions
Useful Functions COMFORT AIRFLOW Operation The air direction and flow rate are adjusted so that the air will not blow directly at people in the room. „ To start Press • “ ” appears on the LCD. COOL operation DRY operation HEAT operation Flaps direction Goes up... -
Page 46: Powerful Operation
Useful Functions POWERFUL Operation POWERFUL operation quickly maximises the cooling (heating) effect in any operation mode. In this mode, the air conditioner operates at maximum capacity. „ To start Press during operation. • “ ” appears on the LCD. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. -
Page 47: Econo Operation
Useful Functions ECONO Operation ECONO operation enables efficient operation by limiting the maximum power consumption. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit. „ To start Press •... -
Page 48: Outdoor Unit Quiet Operation
Useful Functions OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. „ To start Press • “ ”... -
Page 49: Timer Operation
TIMER Operation ON/OFF TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off in the morning or at night. You can also use the ON TIMER and OFF TIMER together. [ON TIMER operation] „ To set Press “ ... - Page 50 TIMER Operation ON/OFF TIMER Operation [OFF TIMER operation] „ To set Press “ ” appears on the LCD. • Each pressing of changes the time setting by 1 hour. The time can be set between 1 and 12 hours. • The TIMER lamp lights orange. Display „...
-
Page 51: Care
Care Care and Cleaning CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fins of the indoor unit. If you touch those parts, this may cause an injury. „... - Page 52 Care Care and Cleaning CAUTION • Do not touch the aluminium fins by bare hand at the time of dismounting or mounting the filter. „ Air filter Open the front panel. Wash the air filters with water or clean them with •...
- Page 53 Care „ Filter (small) * For the applicable filter type, please refer to Page 18 Attaching Clean or replace. [Cleaning] Open the front panel and Deodorizing filter (enzyme blue) : Blue / pull out the air filters. Page 19 Titanium apatite deodorizing filter : Blue-Black Insert the filter.
- Page 54 Care Care and Cleaning „ Prior to a long period of non-use Operate the FAN ONLY mode for several hours on a fine day to dry out the inside. • Press After operation stops, turn off the circuit breaker for the room air conditioner.
- Page 55 When the Need Arises Indoor unit The flaps do not start swinging immediately. • The air conditioner is adjusting the position of the flaps. The flaps will start moving soon. The air conditioner stops generating airflow during HEAT operation. Different sounds are heard. •...
-
Page 56: Troubleshooting
When the Need Arises Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, consult your dealer. Not a problem Check This case is not a problem. Please check again before requesting repairs. - Page 57 When the Need Arises Mist comes out Case Description / what to check • This happens when the air in the room is cooled into mist by the cold airflow during COOL Mist comes out of the indoor unit. or other operation. Remote controller Case Description / what to check...
- Page 58 When the Need Arises Troubleshooting „ Call your dealer immediately WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. • Continued operation in an abnormal condition may result in problems, electric shock or fire. •...
- Page 59 When the Need Arises „ Fault diagnosis by remote controller • In case the air conditioner is malfunctioning, you can check the error code via the remote controller before consulting with service personnel and informing them of the malfunction code. When is held down for about 5 seconds, “ ...
- Page 60 MEMO...
- Page 61 MEMO...
- Page 62 MEMO...
- Page 63 MEMO...
- Page 64 Quick Reference The two-dimensional bar code is a manufacturing code. 3P683779-8 M22N008 (2201) HT...
- Page 65 OPERATION MANUAL DAIKIN ROOM AIR CONDITIONER MODELS FTKF20TVMA FTKF25TVMA FTKF35TVMA FTKF46TVMA FTKF50TVMA...
- Page 66 Features Enhanced comfort, energy savings and rapid cooling COMFORT AIRFLOW The airfl ow direction is upward while in COOL and DRY operation. This function prevents cold air from blowing directly on your body. Page 12 ECONO This function enables effi cient operation by limiting the maximum power consumption. It is useful when using the air conditioner and other electrical devices simultaneously on a shared electrical circuit. Page 14 POWERFUL POWERFUL operation quickly maximises the cooling effect in any operation mode. Page 13 OUTDOOR UNIT QUIET OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit. This function is useful when you need to consider the noise for your neighbourhood. Page 15...
- Page 67 Contents Read Before Operation Safety Precautions .......... Names of Parts ..........Preparation Before Operation ......Basic Operation COOL · DRY · FAN ONLY Operation ..........Adjusting the Airflow Rate ....Adjusting the Airflow Direction ... Useful Functions COMFORT AIRFLOW Operation ..POWERFUL Operation ...... ECONO Operation ......OUTDOOR UNIT QUIET Operation ........... TIMER Operation ON/OFF TIMER Operation ....Care Care and Cleaning .
-
Page 68: Read Before Operation
Read Before Operation Safety Precautions Read the precautions in this manual carefully This appliance is filled with R32. before operating the unit. • Keep this manual where the user can easily find it. • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. WARNING Failure to follow these instructions properly may result in personal injury or loss of life. Failure to observe these instructions properly may result in property damage or personal injury, CAUTION which may be serious depending on the circumstances. Be sure to follow the Be sure to establish an earth Never attempt. instructions. connection. • After reading, keep this manual in a convenient place so that you can refer to it whenever necessary. If the equipment is transferred to a new user, be sure also to hand over the manual. WARNING • Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. • The appliance must be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). - Page 69 Read Before Operation • Do not sit on the outdoor unit, put things on the unit, or pull the unit. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage. • Do not place objects that are susceptible to moisture directly beneath the indoor or outdoor units. Under certain conditions, condensation on the main unit or refrigerant pipes, air filter dirt or drain blockage may cause dripping, resulting in fouling or failure of the object concerned. • After prolonged use, check the unit stand and its mounts for damage. If they are left in a damaged condition, the unit may fall and cause injury. • To avoid injury, do not touch the air inlet or aluminium fins of the indoor or outdoor units. • The appliance is not intended for use by unattended young children or infirm persons. Impairment of bodily functions and harm to health may result. • Children should be supervised to ensure that they do not play with the unit or its remote controller. Accidental operation by a child may result in impairment of bodily functions and harm health. • Avoid impacts to the indoor and outdoor units, or otherwise product damage may result. • Do not place flammable items, such as spray cans, within 1m of the air outlet. The spray cans may explode as a result of hot air from the indoor or outdoor units. • Be careful not to let pets urinate on the air conditioner. Urination on the air conditioner may result in electric shock or fire. • Do not wash the air conditioner with water, as this may result in electric shock or fire. • Do not place water containers (vases, etc.) above the unit, as this may result in electric shock or fire hazards if they should topple over. • Do not insert the batteries in the wrong polarity (+/-) orientation as this may result in short circuiting, fire, or battery leakage. • Do not sit or hang on the panel. The panel may fall, and injury or product malfunctioning may result. • Do not sway the panel. The panel may hit people or objects, and injury or property damage may result. • Do not let children play around the panel. Injury or property damage may result. • Do not pull the wires. The wires may be broken and the panel may fall, and injury or property damage may result.
-
Page 70: Names Of Parts
Read Before Operation Names of Parts Indoor Unit Air inlet Front panel Air outlet Flap (horizontal blade) Model name Indoor temperature Page 11 sensor • Detects the air temperature Louvres (vertical blades) around the unit. • The louvres are inside of the air outlet. Page 11 Display Signal receiver • Receives signals from the remote OPERATION lamp (green) controller. - Page 71 Read Before Operation „ Open the front panel Air filter Outdoor Unit „ RKF20/25/35 Air inlet Outdoor temperature (back and side) sensor (back) Refrigerant pipes and inter-unit wire Air outlet Earth terminal (inside) Drain hose „ RKF46/50 Air inlet Outdoor temperature (back and side) sensor (back) Refrigerant pipes and...
- Page 72 Read Before Operation Names of Parts Remote Controller Signal transmitter Display (LCD) • Displays the current settings. (In this illustration, each section is shown with its displays on for the purpose of explanation.) • To use the remote controller, aim the transmitter at the indoor unit. If there is anything blocking the signals between the unit and the remote controller, such Direct operation buttons as a curtain, the unit may not operate. • Starts the COOL, DRY, or FAN ONLY • The maximum transmission distance operation. Page 9 is about 7m. TEMPERATURE OFF button adjustment button • Stops the operation. Page 9 • Changes the temperature setting.
-
Page 73: Preparation Before Operation
Read Before Operation Preparation Before Operation CAUTION Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the alkaline solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. • Keep batteries out of reach of children. In the event that batteries are swallowed, seek the immediate attention of a medical professional. • Do not expose batteries to heat or fire. Do not disassemble or modify batteries. The insulation or gas release vent inside the battery may be damaged, resulting in battery leakage, rupturing, or heating. -
Page 74: Basic Operation
Basic Operation COOL · DRY · FAN ONLY Operation The air conditioner operates with the operation mode of your choice. „ To start operation Press button of your desired operation mode. COOL operation Press . “ ” appears on the LCD. DRY operation Press . “ ” appears on the LCD. FAN ONLY operation Press . -
Page 75: Adjusting The Airflow Rate
Basic Operation Adjusting the Airfl ow Rate You can adjust the airfl ow rate to increase your comfort. „ To adjust the airfl ow rate setting Press • Each pressing of changes the airfl ow rate setting in sequence. AUTO Indoor unit quiet Airflow rate 1-5 (Low to High) • When the airfl ow is set to “ ”, quiet operation starts and noise from the indoor unit will become quieter. • In the quiet operation mode, the airfl ow rate is set to a weak level. • In DRY operation, the airfl ow rate setting cannot be changed. -
Page 76: Adjusting The Airflow Direction
Basic Operation Adjusting the Airfl ow Direction You can adjust the airfl ow direction to increase your comfort. CAUTION • Always use a remote controller to adjust the angle of the fl ap. - If you attempt to move the fl ap forcibly by hand when it is swinging, the mechanism may be damaged. • Be careful when adjusting the louvres. - Inside the air outlet, a fan is rotating at a high speed. Auto swing For up and down airfl ow direction 1. Press • “ ” appears on the LCD • The fl ap (horizontal blade) will begin to swing. 2. If you want to stop the movement of the fl ap, press again when the fl ap reaches the desired position. -
Page 77: Useful Functions
Useful Functions COMFORT AIRFLOW Operation The air direction and fl ow rate are adjusted so that the air will not blow directly at people in the room. „ To start Press • “ ” appears on the LCD. COOL operation DRY operation Flap direction Goes up Airfl ow rate The airfl ow rate can be set to any level AUTO • Not available in FAN ONLY mode. „ To cancel Press again. • “ ” disappears from the LCD. • The fl ap will return to the memory position from before COMFORT AIRFLOW operation. NOTE Note on COMFORT AIRFLOW operation • If the up and down airfl ow direction is selected, COMFORT AIRFLOW operation will be cancelled. -
Page 78: Powerful Operation
Useful Functions POWERFUL Operation POWERFUL operation quickly maximises the cooling effect in any operation mode. In this mode, the air conditioner operates at maximum capacity. „ To start Press • “ ” appears on the LCD. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. „ To cancel Press again. • “ ” disappears from the LCD. NOTE Notes on POWERFUL operation • Pressing causes the settings to be cancelled, and “ ” disappears from the LCD. • POWERFUL operation will not increase the capacity of the air conditioner if the air conditioner is already in operation with its maximum capacity demonstrated. − In COOL operation To maximise the cooling effect, the capacity of outdoor unit increases and the airfl ow rate becomes fi xed at the maximum setting. The temperature and airfl ow settings cannot be changed in COOL operation. -
Page 79: Econo Operation
Useful Functions ECONO Operation ECONO operation enables effi cient operation by limiting the maximum power consumption. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit. „ To start Press • “ ” appears on the LCD. • Not available in FAN ONLY mode. „ To cancel Press again. • “ ” disappears from the LCD. NOTE Notes on ECONO operation • This operation is performed with lower power and therefore may not provide a suffi cient cooling effect. • Pressing causes the settings to be cancelled, and “ ” disappears from the LCD. • If the power consumption level is already low, switching to ECONO operation will not reduce the power consumption. Some useful functions can be used together. COMFORT AIRFLOW + ECONO Available OUTDOOR UNIT QUIET + ECONO... -
Page 80: Outdoor Unit Quiet
Useful Functions OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. „ To start Press • “ ” appears on the LCD. „ To cancel Press again. • “ ” disappears from the LCD. NOTE Notes on OUTDOOR UNIT QUIET operation • POWERFUL operation and OUTDOOR UNIT QUIET operation cannot be used at the same time. Priority is given to the function of whichever button is pressed last. • Even the operation is stopped by using the remote controller or the indoor unit ON/OFF switch when using OUTDOOR UNIT QUIET operation, “ ” will remain on the remote controller display. • OUTDOOR UNIT QUIET operation will drop neither the frequency nor fan speed if they have been already dropped low enough. Possible combinations of OUTDOOR UNIT QUIET operation and basic operations Operation mode OUTDOOR UNIT QUIET COOL... -
Page 81: Timer Operation
TIMER Operation ON/OFF TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off in the morning or at night. You can also use the ON TIMER and OFF TIMER together. [ON TIMER operation] „ To set Press “ ” appears on the LCD. • Each pressing of changes the time setting by 1 hour. The time can be set between 1 and 12 hours. • The TIMER lamp lights orange. Display „ To cancel Press • “ ” disappears from the LCD. • The TIMER lamp goes off. NOTE In the following cases, set the timer again. • After the circuit breaker has turned off. • After a power failure. - Page 82 TIMER Operation ON/OFF TIMER Operation [OFF TIMER operation] „ To set Press “ ” appears on the LCD. • Each pressing of changes the time setting by 1 hour. The time can be set between 1 and 12 hours. • The TIMER lamp lights orange. Display „ To cancel Press • “ ” disappears from the LCD. • The TIMER lamp goes off. [ON/OFF TIMER combination] „ To combine • A sample setting for combining the 2 timers is shown below. • “ ” and “ ” are appears on the LCD. [Example] When setting while the unit is operating • Stops the unit 1 hour later and starts it 7 hours after that.
-
Page 83: Care And Cleaning
Care Care and Cleaning CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fi ns of the indoor unit. If you touch those parts, this may cause an injury. „ Quick reference Cleaning parts Front panel • Wipe it with a soft damp cloth. • Only neutral detergent may be used. If dirty Air fi lter • Vacuum dust or wash the fi lter. Once every 2 weeks Titanium apatite deodorizing fi lter (sold separately) and dust collection fi lter (PM2.5) (sold separately) Page 19 Titanium apatite deodorizing fi lters and dust collection fi lters are sold separately... - Page 84 Care Care and Cleaning CAUTION • Do not touch the aluminium fi ns by bare hand at the time of dismounting or mounting the fi lter. „ Air fi lter Open the front panel. Wash the air fi lters with water or clean them with • Hold the front panel by the sides and open it. vacuum cleaner. • It is recommended to clean the air fi lters every 2 weeks. Pull out the air fi lters. • Push the fi lter tab at the centre of each air fi lter a little upwards, then pull it down.
- Page 85 Care „ Titanium apatite deodorizing filter (sold separately) / dust collection filter (PM2.5) (sold separately) Attaching [Cleaning for titanium apatite deodorizing filter (Blue-Black)] Open the front panel and 3-1 Vacuum dust, and soak in lukewarm pull out the air filters. water or water for about 10 to Page 19 15 minutes if very dirty.
- Page 86 Care Care and Cleaning „ Prior to a long period of non-use Operate the FAN ONLY mode for several hours on a fine day to dry out the inside. • Press After operation stops, turn off the circuit breaker for the room air conditioner.
-
Page 87: When The Need Arises
When the Need Arises Indoor unit The flap does not start swinging immediately. • T he air conditioner is adjusting the position of the flap. The flap will start moving soon. Operation does not start soon. Different sounds are heard. „ A sound like flowing water „ When any direct operation button was pressed soon after operation was stopped. -
Page 88: Troubleshooting
When the Need Arises Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, consult your dealer. Not a problem Check This case is not a problem. Please check again before requesting repairs. The air conditioner does not operate Case Description / what to check • Has the circuit breaker been tripped or the fuse blown? OPERATION lamp is off. • Is there a power failure? • Are batteries set in the remote controller? • Turn off the power with the circuit breaker and restart operation with the remote controller. OPERATION lamp is blinking. If the OPERATION lamp is still blinking, check the error code and consult your dealer. - Page 89 When the Need Arises Mist comes out Case Description / what to check • This happens when the air in the room is cooled into mist by the cold airfl ow during COOL Mist comes out of the indoor unit. or other operation. Remote controller Case Description / what to check • The batteries may be exhausted. Replace both batteries with new dry batteries AAA.LR03 (alkaline). The unit does not receive signals Page 8 For details, refer to “Preparation Before Operation”.
- Page 90 When the Need Arises Troubleshooting „ Call your dealer immediately WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. • Continued operation in an abnormal condition may result in problems, electric shock or fire. • Consult the dealer where you bought the air conditioner. Do not attempt to repair or modify the air conditioner by yourself. • Incorrect work may result in electric shock or fire.
- Page 91 When the Need Arises „ Fault diagnosis by remote controller • In case the air conditioner is malfunctioning, you can check the error code via the remote controller before consulting with service personnel and informing them of the malfunction code. When is held down for about 5 seconds, “ ” blinks in the temperature display section. Press repeatedly until a long beep is produced. • The code indication changes as shown below, and notifi es you with a long beep. CODE MEANING NORMAL...
- Page 92 Quick Reference The two-dimensional bar code is a manufacturing code. 3P372379-16N M18N117 (1906) HT...
- Page 93 OPERATION MANUAL DAIKIN ROOM AIR CONDITIONER MODELS FTKF60TVMA FTKF71TVMA...
- Page 94 Features Enhanced comfort, energy savings and rapid cooling COMFORT AIRFLOW The airfl ow direction is upward while in COOL and DRY operation. This function prevents cold air from blowing directly on your body. Page 12 ECONO This function enables effi cient operation by limiting the maximum power consumption. It is useful when using the air conditioner and other electrical devices simultaneously on a shared electrical circuit. Page 14 POWERFUL POWERFUL operation quickly maximises the cooling effect in any operation mode. Page 13 OUTDOOR UNIT QUIET OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit. This function is useful when you need to consider the noise for your neighbourhood. Page 15...
- Page 95 Contents Read Before Operation Safety Precautions .......... Names of Parts ..........Preparation Before Operation ......Basic Operation COOL · DRY · FAN ONLY Operation ..........Adjusting the Airflow Rate ....Adjusting the Airflow Direction ... Useful Functions COMFORT AIRFLOW Operation ..POWERFUL Operation ...... ECONO Operation ......OUTDOOR UNIT QUIET Operation ........... TIMER Operation ON/OFF TIMER Operation ....Care Care and Cleaning .
-
Page 96: Read Before Operation
Read Before Operation Safety Precautions Read the precautions in this manual carefully This appliance is filled with R32. before operating the unit. • Keep this manual where the user can easily find it. • The precautions described herein are classified as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. WARNING Failure to follow these instructions properly may result in personal injury or loss of life. Failure to observe these instructions properly may result in property damage or personal injury, CAUTION which may be serious depending on the circumstances. Be sure to follow the Be sure to establish an earth Never attempt. instructions. connection. • After reading, keep this manual in a convenient place so that you can refer to it whenever necessary. If the equipment is transferred to a new user, be sure also to hand over the manual. WARNING • Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. • The appliance must be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). - Page 97 Read Before Operation • Do not sit on the outdoor unit, put things on the unit, or pull the unit. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage. • Do not place objects that are susceptible to moisture directly beneath the indoor or outdoor units. Under certain conditions, condensation on the main unit or refrigerant pipes, air filter dirt or drain blockage may cause dripping, resulting in fouling or failure of the object concerned. • After prolonged use, check the unit stand and its mounts for damage. If they are left in a damaged condition, the unit may fall and cause injury. • To avoid injury, do not touch the air inlet or aluminium fins of the indoor or outdoor units. • The appliance is not intended for use by unattended young children or infirm persons. Impairment of bodily functions and harm to health may result. • Children should be supervised to ensure that they do not play with the unit or its remote controller. Accidental operation by a child may result in impairment of bodily functions and harm health. • Avoid impacts to the indoor and outdoor units, or otherwise product damage may result. • Do not place flammable items, such as spray cans, within 1m of the air outlet. The spray cans may explode as a result of hot air from the indoor or outdoor units. • Be careful not to let pets urinate on the air conditioner. Urination on the air conditioner may result in electric shock or fire. • Do not wash the air conditioner with water, as this may result in electric shock or fire. • Do not place water containers (vases, etc.) above the unit, as this may result in electric shock or fire hazards if they should topple over. • Do not insert the batteries in the wrong polarity (+/-) orientation as this may result in short circuiting, fire, or battery leakage. • Do not sit or hang on the panel. The panel may fall, and injury or product malfunctioning may result. • Do not sway the panel. The panel may hit people or objects, and injury or property damage may result. • Do not let children play around the panel. Injury or property damage may result. • Do not pull the wires. The wires may be broken and the panel may fall, and injury or property damage may result.
-
Page 98: Names Of Parts
Read Before Operation Names of Parts Indoor Unit Air inlet Front panel Air outlet Model name Flaps (horizontal blades) Indoor temperature Page 11 sensor • Detects the air temperature around the unit. Louvres (vertical blades) • The louvres are inside of the air outlet. Page 11 Display Signal receiver • Receives signals from the remote OPERATION lamp (green) controller. - Page 99 Read Before Operation „ Open the front panel Air fi lter Outdoor Unit Outdoor temperature Air inlet sensor (back) (back and side) Refrigerant pipes and inter-unit wire Earth terminal (inside) Air outlet Drain hose...
- Page 100 Read Before Operation Names of Parts Remote Controller Signal transmitter Display (LCD) • Displays the current settings. (In this illustration, each section is shown with its displays on for the purpose of explanation.) • To use the remote controller, aim the transmitter at the indoor unit. If there is anything blocking the signals between the unit and the remote controller, such Direct operation buttons as a curtain, the unit may not operate. • Starts the COOL, DRY, or FAN ONLY • The maximum transmission distance operation. Page 9 is about 7m. TEMPERATURE OFF button adjustment button • Stops the operation. Page 9 • Changes the temperature setting.
-
Page 101: Preparation Before Operation
Read Before Operation Preparation Before Operation CAUTION Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the alkaline solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. • Keep batteries out of reach of children. In the event that batteries are swallowed, seek the immediate attention of a medical professional. • Do not expose batteries to heat or fire. Do not disassemble or modify batteries. The insulation or gas release vent inside the battery may be damaged, resulting in battery leakage, rupturing, or heating. -
Page 102: Basic Operation
Basic Operation COOL · DRY · FAN ONLY Operation The air conditioner operates with the operation mode of your choice. „ To start operation Press button of your desired operation mode. COOL operation Press . “ ” appears on the LCD. DRY operation Press . “ ” appears on the LCD. FAN ONLY operation Press . -
Page 103: Adjusting The Airflow Rate
Basic Operation Adjusting the Airfl ow Rate You can adjust the airfl ow rate to increase your comfort. „ To adjust the airfl ow rate setting Press • Each pressing of changes the airfl ow rate setting in sequence. AUTO Indoor unit quiet Airflow rate 1-5 (Low to High) • When the airfl ow is set to “ ”, quiet operation starts and noise from the indoor unit will become quieter. • In the quiet operation mode, the airfl ow rate is set to a weak level. • In DRY operation, the airfl ow rate setting cannot be changed. -
Page 104: Adjusting The Airflow Direction
Basic Operation Adjusting the Airfl ow Direction You can adjust the airfl ow direction to increase your comfort. CAUTION • Always use a remote controller to adjust the angle of the fl aps. - If you attempt to move the fl aps forcibly by hand when they are swinging, the mechanism may be damaged. • Be careful when adjusting the louvres. - Inside the air outlet, a fan is rotating at a high speed. Auto swing For up and down airfl ow direction 1. Press • “ ” appears on the LCD. • The fl aps (horizontal blade) will begin to swing. 2. If you want to stop the movement of the fl aps, press again when the fl aps reach the desired position. -
Page 105: Useful Functions
Useful Functions COMFORT AIRFLOW Operation The air direction and fl ow rate are adjusted so that the air will not blow directly at people in the room. „ To start Press • “ ” appears on the LCD. COOL operation DRY operation Flaps direction Goes up Airfl ow rate The airfl ow rate can be set to any level AUTO • Not available in FAN ONLY mode. „ To cancel Press again. • “ ” disappears from the LCD. • The fl aps will return to the memory position from before COMFORT AIRFLOW operation. NOTE Note on COMFORT AIRFLOW operation • If the up and down airfl ow direction is selected, COMFORT AIRFLOW operation will be cancelled. -
Page 106: Powerful Operation
Useful Functions POWERFUL Operation POWERFUL operation quickly maximises the cooling effect in any operation mode. In this mode, the air conditioner operates at maximum capacity. „ To start Press • “ ” appears on the LCD. • POWERFUL operation ends in 20 minutes. Then the system automatically operates again with the previous settings which were used before POWERFUL operation. „ To cancel Press again. • “ ” disappears from the LCD. NOTE Notes on POWERFUL operation • Pressing causes the settings to be cancelled, and “ ” disappears from the LCD. • POWERFUL operation will not increase the capacity of the air conditioner if the air conditioner is already in operation with its maximum capacity demonstrated. − In COOL operation To maximise the cooling effect, the capacity of outdoor unit increases and the airfl ow rate becomes fi xed at the maximum setting. The temperature and airfl ow settings cannot be changed in COOL operation. -
Page 107: Econo Operation
Useful Functions ECONO Operation ECONO operation enables effi cient operation by limiting the maximum power consumption. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit. „ To start Press • “ ” appears on the LCD. • Not available in FAN ONLY mode. „ To cancel Press again. • “ ” disappears from the LCD. NOTE Notes on ECONO operation • This operation is performed with lower power and therefore may not provide a suffi cient cooling effect. • Pressing causes the settings to be cancelled, and “ ” disappears from the LCD. • If the power consumption level is already low, switching to ECONO operation will not reduce the power consumption. Some useful functions can be used together. COMFORT AIRFLOW + ECONO Available OUTDOOR UNIT QUIET + ECONO... -
Page 108: Outdoor Unit Quiet
Useful Functions OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed on the outdoor unit. This function is convenient during night. „ To start Press • “ ” appears on the LCD. „ To cancel Press again. • “ ” disappears from the LCD. NOTE Notes on OUTDOOR UNIT QUIET operation • POWERFUL operation and OUTDOOR UNIT QUIET operation cannot be used at the same time. Priority is given to the function of whichever button is pressed last. • Even the operation is stopped by using the remote controller or the indoor unit ON/OFF switch when using OUTDOOR UNIT QUIET operation, “ ” will remain on the remote controller display. • OUTDOOR UNIT QUIET operation will drop neither the frequency nor fan speed if they have been already dropped low enough. Possible combinations of OUTDOOR UNIT QUIET operation and basic operations Operation mode OUTDOOR UNIT QUIET COOL... -
Page 109: Timer Operation
TIMER Operation ON/OFF TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off in the morning or at night. You can also use the ON TIMER and OFF TIMER together. [ON TIMER operation] „ To set Press “ ” appears on the LCD. • Each pressing of changes the time setting by 1 hour. The time can be set between 1 and 12 hours. • The TIMER lamp lights orange. Display „ To cancel Press • “ ” disappears from the LCD. • The TIMER lamp goes off. NOTE In the following cases, set the timer again. • After the circuit breaker has turned off. • After a power failure. - Page 110 TIMER Operation ON/OFF TIMER Operation [OFF TIMER operation] „ To set Press “ ” appears on the LCD. • Each pressing of changes the time setting by 1 hour. The time can be set between 1 and 12 hours. • The TIMER lamp lights orange. Display „ To cancel Press • “ ” disappears from the LCD. • The TIMER lamp goes off. [ON/OFF TIMER combination] „ To combine • A sample setting for combining the 2 timers is shown below. • “ ” and “ ” are appears on the LCD. [Example] When setting while the unit is operating • Stops the unit 1 hour later and starts it 7 hours after that.
-
Page 111: Care And Cleaning
Care Care and Cleaning CAUTION • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fi ns of the indoor unit. If you touch those parts, this may cause an injury. „ Quick reference Cleaning parts Front panel • Wipe it with a soft damp cloth. • Only neutral detergent may be used. If dirty Air fi lter • Vacuum dust or wash the fi lter. Once every 2 weeks Titanium apatite deodorizing fi lter (sold separately) and dust collection fi lter (PM2.5) (sold separately) Page 19 Titanium apatite deodorizing fi lters and dust collection fi lters are sold separately... - Page 112 Care Care and Cleaning CAUTION • Do not touch the aluminium fi ns by bare hand at the time of dismounting or mounting the fi lter. „ Air fi lter Open the front panel. Wash the air fi lters with water or clean them with • Hold the front panel by the sides and open it. vacuum cleaner. • It is recommended to clean the air fi lters every 2 weeks. Pull out the air fi lters. • Push the fi lter tab at the centre of each air fi lter a little upwards, then pull it down.
- Page 113 Care „ Titanium apatite deodorizing filter (sold separately) / dust collection filter (PM2.5) (sold separately) Attaching Clean or replace the titanium apatite deodorizing filters or Open the front panel and dust collection filters (PM2.5). pull out the air filters. Page 19 [Cleaning for titanium apatite deodorizing filter (Blue-Black)] Insert the titanium apatite...
- Page 114 Care Care and Cleaning „ Prior to a long period of non-use Operate the FAN ONLY mode for several hours on a fine day to dry out the inside. • Press After operation stops, turn off the circuit breaker for the room air conditioner.
-
Page 115: When The Need Arises
When the Need Arises Indoor unit The flaps do not start swinging immediately. • T he air conditioner is adjusting the position of the flaps. The flaps will start moving soon. Operation does not start soon. Different sounds are heard. „ When any direct operation button was pressed „ A sound like flowing water soon after operation was stopped. -
Page 116: Troubleshooting
When the Need Arises Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, consult your dealer. Not a problem Check This case is not a problem. Please check again before requesting repairs. The air conditioner does not operate Case Description / what to check • Has the circuit breaker been tripped or the fuse blown? OPERATION lamp is off. • Is there a power failure? • Are batteries set in the remote controller? • Turn off the power with the circuit breaker and restart operation with the remote controller. OPERATION lamp is blinking. If the OPERATION lamp is still blinking, check the error code and consult your dealer. - Page 117 When the Need Arises Mist comes out Case Description / what to check • This happens when the air in the room is cooled into mist by the cold airfl ow during COOL Mist comes out of the indoor unit. or other operation. Remote controller Case Description / what to check • The batteries may be exhausted. Replace both batteries with new dry batteries AAA.LR03 (alkaline). The unit does not receive signals Page 8 For details, refer to “Preparation Before Operation”.
- Page 118 When the Need Arises Troubleshooting „ Call your dealer immediately WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. • Continued operation in an abnormal condition may result in problems, electric shock or fire. • Consult the dealer where you bought the air conditioner. Do not attempt to repair or modify the air conditioner by yourself. • Incorrect work may result in electric shock or fire.
- Page 119 When the Need Arises „ Fault diagnosis by remote controller • In case the air conditioner is malfunctioning, you can check the error code via the remote controller before consulting with service personnel and informing them of the malfunction code. When is held down for about 5 seconds, “ ” blinks in the temperature display section. Press repeatedly until a long beep is produced. • The code indication changes as shown below, and notifi es you with a long beep. CODE MEANING NORMAL...
- Page 120 Quick Reference The two-dimensional bar code is a manufacturing code. 3P372379-17N M18N118 (1906) HT...
