- Page 1 Operation manual Split system air conditioners Operation manual FTXF25D5V1B6 English Split system air conditioners FTXF35D5V1B6...
-
Page 2: Table Of Contents
OFF/ON timer operation ..........Latest revisions of the supplied documentation may be available on 6 Energy saving and optimum operation the regional Daikin website or via your installer. 7 Maintenance and service The original documentation is written in English. All other languages Overview: Maintenance and service ......... -
Page 3: Instructions For Safe Operation
2 User safety instructions concerning use of the appliance in a Instructions for safe operation safe way and understand the hazards WARNING: MILDLY FLAMMABLE involved. MATERIAL Children SHALL NOT play with the The refrigerant inside this unit is mildly appliance. flammable. -
Page 4: About The System
3 About the system WARNING CAUTION Do NOT place a flammable spray After a long use, check the unit stand bottle near the air conditioner and do and fitting for damage. If damaged, the NOT use sprays near the unit. Doing unit may fall and result in injury. -
Page 5: About The User Interface
3 About the system 3.2.1 Components: User interface ON/OFF Air inlet Air outlet Flap (horizontal blade) Louvers (vertical blades) Front panel Model name plate Room temperature sensor Signal receiver Operation indicator (green) Timer lamp (orange) Indoor unit ON/OFF switch Air filter Signal transmitter LCD display ON/OFF button... -
Page 6: To Operate The User Interface
4 Before operation Icon Description Before operation The indoor unit receives a signal from the user interface To mount the user interface holder Current temperature setting Airflow rate = Automatic Airflow rate = Indoor unit quiet Airflow rate = High Airflow rate = Medium high Airflow rate = Medium Airflow rate = Medium low... -
Page 7: When To Use Which Feature
5 Operation 5.3.1 To start/stop operation mode and to set Operation mode Operation range the temperature Drying ▪ Outdoor temperature: –10~46°C DB ▪ Indoor temperature: 18~32°C DB : Unit is operating. ▪ Indoor humidity: ≤80% : Operation mode = Automatic A safety device might stop the operation of the system if the unit runs outside its operation range. -
Page 8: Airflow Direction
5 Operation To adjust the airflow rate INFORMATION When the unit is installed in a corner of a room, the 1 Press to change the airflow setting as follows: direction of the louvers should be facing away from the wall. Efficiency will drop if a wall blocks the air. 5.3.4 Comfort airflow operation 5.3.3... -
Page 9: Econo Operation
6 Energy saving and optimum operation Note: Powerful operation can be set only when the unit is running. If INFORMATION Each time is pressed, the time setting advances by you press or if you change operation mode, operation will 1 hour. The timer can be set between 1 to 9 hours. be cancelled;... -
Page 10: Maintenance And Service
Formula to calculate the quantity in CO equivalent Use Daikin service parts only. tonnes: GWP value of the refrigerant × total refrigerant We recommend performing maintenance at least once a charge [in kg] / 1000 year. However, applicable legislation might require shorter Please contact your installer for more information. -
Page 11: To Clean The Indoor Unit And User Interface
8 Troubleshooting To clean the indoor unit and user interface NOTICE ▪ Do NOT use gasoline, benzene, thinner, polishing powder or liquid insecticide. Possible consequence: Discoloration and deformation. ▪ Do NOT use water or air of 40°C or higher. Possible consequence: Discoloration and deformation. -
Page 12: Symptoms That Are Not System Malfunctions
8 Troubleshooting 8.1.7 Symptom: White mist comes out of a unit Malfunction Measure (Indoor unit) If a safety device such as a fuse, a Turn OFF the main power breaker or an earth leakage breaker switch. ▪ When humidity is high during cooling operation (in oily and dusty frequently actuates or the ON/OFF places). -
Page 13: Disposal
9 Disposal Indoor unit Error code Description Indoor unit PCB abnormality Freeze-up protection or high-pressure control Fan motor (DC motor) abnormality Indoor heat exchanger thermistor abnormality Room temperature thermistor abnormality Outdoor unit Error code Description 4-way valve abnormality Outdoor unit PCB abnormality Overload activation (compressor overload) Compressor lock DC fan lock... - Page 16 DAIKIN ISITMA VE SOĞUTMA SİSTEMLERİ SAN.TİC. A.Ş. Head Office: Gülsuyu Mahallesi, Fevzi Çakmak Caddesi, Burçak Sokak No:20 34848 Maltepe - İstanbul / TÜRKİYE Factory: Kargalıhanbaba OSB Mahallesi, Organize Sanayi 1 Sokak No:28 54300 Hendek - Sakarya / TÜRKİYE 3P520336-16T 2021.10...
