  • Page 1 Z3-DM8168-MOD-35 Module Z3-DM8168-APP-41 PCIe Carrier Manufacturing Test Procedure VERSION 2.1.1 November 25, 2012 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 2 No part of this document may be copied or reproduced in any form or by any means without prior written consent of Z3 Technology, LLC. Z3 Technology, LLC assumes no responsibility for any errors that may appear in this document. This document contains confidential proprietary information that is not to be disclosed to any unauthorized person without prior written consent of Z3 Technology, LLC.
  • Page 3 Minor revision to Figure 1 and section 5, 6, and 7. 2.1.1 11/25/2012 Minor page and TOC update. Updated address on page 22. 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...

  • Page 4: Table Of Contents

    Functional test coverage ........................13 Procedure .............................. 13 Pass/Fail Criteria ............................14 Reloading the Flash ..........................14 10 Log of Successful Flash Programming ....................15 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...

  • Page 5: Purpose

    2 General Description The Z3-DM8168-MOD-35 is a compact OEM module, supporting H.264 codec at up to two channels of 1080p at 60 fps (frames per second) encode and stream, decode from stream or store in applications. The Z3-DM8168-MOD-35 features a unique expansion interface comprised of five high density connectors providing access to the greatest majority of interface signals available from the DM8168 processor.

  • Page 6: Testing Modules And Application Boards

    3 Testing modules and application boards Since the DM8168-MOD-35 module has no I/O ports, it is necessary to use a carrier board of some sort to be able to connect power and signal to the various inputs and outputs. The Z3-DM8168-APP-41 application board was selected to be the carrier.

  • Page 7: Overview Of The Process

    ” from the server and write to Flash. u-boot.bin.img d. Get the file “ ” from the server and write to Flash. uImage 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...

  • Page 8: Test And Programming Setup

    1080p60, so the extra-thin cables will NOT work. Ensure that the cable is capable of 1080p60 by testing it from the media player to the TV monitor, with the media player configured for 1080p60 output. 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...

  • Page 9: Bootp Server Setup

    7. Configure the terminal with 115200 bps, 8 data bits, 1 stop bit, no parity and no flow control. Since the functional test takes advantage of ANSI escape codes, using the Teraterm terminal program is highly recommended. 8. Apply power to the DM8168-APP-41. 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...

  • Page 10: Target Configuration

    If the test is successful, the result is a module with a programmed Flash chip. The following functions are also tested and verified working by this procedure: All power supplies • Power switch • CPU core • 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...

  • Page 11: Pass/Fail Criteria

    Once that line is printed, the tweezers can be removed. The pins 11 and 13 of J20 are Figure 2 shown in below. 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 12 Ethernet PHY: GENERIC (x001cc914) @ 0x01 DaVinci EMAC Press SPACE to abort autoboot in 0 seconds Booting from NAND and ubifs... Set powerlevel to 5 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...

  • Page 13: Functional Test Coverage

    DDR3 memory, Flash, clock oscillators, PLL, fan and stress the power supplies. Procedure Prepare the test setup as described in section 5 above. If the Z3-DM8168-MOD-35 does not have the proper software loaded in the flash, then execute the steps described in section 6 above. Then follow the procedure below: 1) Insert a jumper block at J20 connecting pins 11 and 13, or hold a pair of tweezers connecting the pins and turn power on.

  • Page 14: Pass/Fail Criteria

    ***” message is displayed and the monitor “**** TEST PASS TV shows video from both inputs. The LED D6 on the DM8168-MOD-35 will turn on GREEN when the test succeeds, and will turn RED or not turn on at all if any test fails.

  • Page 15: Log Of Successful Flash Programming

    ARM clk: 987MHz DDR clk: 675MHz I2C: ready DRAM: 1 GiB NAND: 256 MiB *** Warning - bad CRC or NAND, using default environment 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 16 Erasing at 0x260000 -- 100% complete. Writing to Nand... done Using DaVinci EMAC device TFTP from server 192.168.0.6; our IP address is 192.168.81.68 Filename '/z3/z3-netra/init/images/u-boot-env.scr'. 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 17 NAND write: device 0 offset 0x0, size 0x80000 524288 bytes written: OK SW ECC selected Using DaVinci EMAC device TFTP from server 192.168.0.6; our IP address is 192.168.81.68 Filename '/z3/z3-netra/init/images/uImage'. 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 18 TFTP from server 192.168.0.6; our IP address is 192.168.81.68 Filename '/z3/z3-netra/init/images/ubifs-image'. Load address: 0x82000000 Loading: ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 19 ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 20 22282240 bytes written: OK Saving Environment to NAND... Erasing Nand... Warning: Erase size 0x00002000 smaller than one erase block 0x00020000 Erasing 0x00020000 instead 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 21 Erasing at 0x260000 -- 100% complete. Writing to Nand... done ************************************* ******** NAND update SUCCESS ******** ************************************* Z3-DM8168-MOD# 100 N 8 ST, STE 250 ♦ Lincoln, NE 68508-1369 U.S.A. Z3 Technology, LLC ♦ ♦ +1.402.323.0702...
  • Page 22 Z3 Technology is a leading provider of OEM ready low power multimedia modules and systems for a variety of video-centric end applications. Learn more at www.z3technology.com Z3 Technology, LLC • 100 N. 8 St. STE 250 • Lincoln, NE 68508 • USA Phone: +1.402.323.0702 •...
