directions for use

Stûv 22

TO GIVE TO THE USER

[en]

05/2018

SN 2270: 174675 -...

SN 2290: 175816 -...

SN 22110: 189136 -...

Table of Contents

Need help?

Do you have a question about the 22/70 SF and is the answer not in the manual?

Questions and answers

Summary of Contents for Stuv 22/70 SF

Page 1 directions for use | gebrauchsanweisung | návod k použití | mode d'emploi | gebruiksaanwijzing | istruzioni per l’uso | instrucciones de uso | instruções de utilização | directions for use | gebrauchsanweisung | návod k použití | mode d'emploi | gebruiksaanwijzing | istruzioni per l’uso | instrucciones de uso | instruções de utilização | directions for use | gebrauchsanweisung | návod k použití...
Page 2: Table Of Contents
You have chosen a Stûv stove; problems, please contact your thank you. distributor. It has been designed to give you maximum comfort, performance and safety. The greatest care has been taken during the manufacturing process. If you still have any Contents INSTALLATION REPORT GENERAL INFORMATION...
Page 3 Contents Release the window position In case of problems... Table of annual maintenance THE EXTENSION OF THE STÛV GUARANTEE : A SIMPLE PROCEDURE FOR MORE PEACE OF MIND. SPF CERTIFICATES FOR BELGIUM PERFORMANCE DECLARATION (EU305/2011) PRODUCT DATASHEET (EU 2015/1186) CONTACTS Stûv 22 - directions for use [en] - 0118...
Page 4: Installation Report
INSTALLATION REPORT Name of Stûv reseller: Device reference number: Serial number: Fitting date: Flue convection Inside the building standing against an external wall Intake orifice (Ø or cm²): in the middle of the building Outlet orifice (Ø or cm²): Outside the building Type of flue: External air intake Flue...
Page 5: General Information
EN 13229 : 2001 / A2 : 2004 EN 13229 : 2001 / A2 : 2004 EN 13229 : 2001 / A2 : 2004 Wood insert Stûv 22/70 SF Wood insert Stûv 22/90 SF Wood insert Stûv 22/110 SF Minimum insulation thickness with...
Page 6: Recommandations
Standards, certification and technical characteristics (continuation) Standards, certification and technical characteristics (continuation) Other technical characteristics 22/70 SF 22/90 SF 22/110 SF Minimum draught needed to obtain the 12 Pa 12 Pa 12 Pa rated calorific output Weight-flow ratio of smokes...
Page 7: Overview
Overview Supplied as standard with the stove [1] Stove [2] Combustion chamber trim (choose from light or dark) Finish [3] Door frame (Provided with the chosen cladding) [Through these different configurations, Stûv offers various trims and finishing modes. Please refer to the various manuals to find out the installation instructions.] Optional...
Page 8: Dimensions Of The Appliance Without Door And Without Finish
Dimensions of the appliance without door and without finish Stûv 22/70 355 260 103 110 212 505 117 1014 111 610 640 220 600 470 Stûv 22/90 455 250 205 103 110 212 505 135 137 540 570 220 600 670 Stûv 22/110 555 250 305 103 110 212 505 135...
Page 9 Dimensions (continued) Dimensions of the air box in the Ø100mm and Ø160mm “nozzle” configuration Ø100mm 25 mm Ø100mm 10 mm Stûv 22/70 520 355 198 Stûv 22/90 520 455 198 Stûv 22/110 520 555 198 * distance between the centre of the air inlet nozzle and the centre of the smoke outlet. Dimensions of the air box in the Ø160mm “bend”...
Page 10: How Does Your Stûv 22 Work
How does your Stûv 22 work ? It heats ! Exactly what’s required where it’s required ! When the stove is working (i.e. when the lighting stage is finished) the The air required for combustion bed of embers will glow and the is strictly reduced to the amount logs will produce large flames.
Page 11: Fuel
Fuel Which wood should you choose ? for having a barbecue and a fire at a lower rate. Different kinds of wood have different heat capacities and do not burn in the Hornbeam [photo 3], same way. cherry wood [photo 4], fruit trees Generally you should opt for hard Excellent fuels but scarce.
Page 12: Fuel (Continued)
Fuel (continued) Drying Wood drying Moisture tester Whatever the wood chosen it should Big logs should be split for the wood This little accessory, available from be really dry. Damp wood heats a to dry better. Wood should be covered your Stûv dealer, accurately tests the great deal less and a great part of the or sheltered from the rain, but well...
Page 13: Use
Recommandations Important ! Should a fire in the flue get out of control This stove should have been installed in accordance with good practice Do not open the stove's door during guidelines and local and national the initial period. regulations. A qualified professional Close the air valve completely using Stûv 22 should have ensured that the...
Page 14: Initial Cautions
Recommandations (continued) When the appliance is not used ... Warning! – Close the damper fully. Neither the Stûv 22 nor its frames or front panels are intended for cooking. – If your device is fitted with an Ensure that nothing is laid on the opening/closing valve for the surfaces of the appliance.
Page 15: Basic Usage
Basic usage Handling of the glass door for loading Use the cold grip to raise or lower the glass door [photos 1 & 2]. Using the damper to change the way the fire burns Hold the control key firmly, perpendicular to the stove, and move it sideways, horizontally Slide the damper control left to close, thus reducing how much combustion...
Page 16: Lighting The Fire
Lighting the fire Before lighting Lighting the fire After a period of inactivity, check Open the air damper fully [diagram 3] that there are no obstructions in the Light the fire by putting an eco- system, its ducts or the air inlets and friendly firelighter in with some outlets or any mechanical blockages.
Page 17 Use of the fan (optional) When to use the fan? Using the remote control. When the stove is hot enough, press –Short press on "A": Increases the fan the key of your choice. Any key allows speed position by 1. you to reactivate the system when it is –Short press on "B": Decreases the in standby mode...
Page 18: Maintaining The Fire
Maintaining the fire Two factors determine the rate of the After reloading, it is advisable to open fire : the quantity of the wood burned the valve for a few minutes using the and the quantity of the combustion cold grip. air.
Page 19: Operating As An Open Fire
Operating as an open fire Please remember Air inlet The stove burns most efficiently when it is closed (further explanations on If your stove’s air box is connected to page 10). the outside with a Ø160mm flexible tube, you will be able to enjoy the Caution benefits of a make-up air inlet so that your stove won’t use up all the air in...
Page 20: Installing And Using The Barbecue Kit
Installing and using the barbecue kit With the Stûv BBQ kit, you can cook food thanks to radiated heat by putting it in front of the flames rather than on top. There is no need to wait until there are just embers, just push the embers and burning logs to the back of the stove.
Page 21 Installing and using the barbecue kit (continued) Stûv 22 - directions for use [en] - 0118...
Page 22: Maintenance
MAINTENANCE Regular maintenance Be careful ! Removal of ashes Wait until the stove has cooled Leave a bed of ashes at the bottom down completely before carrying out of the stove as this encourages maintenance. combustion and still contains some fuel.
Page 23: Annual Maintenance
Annual maintenance Be careful ! − Clean the fan Wait until the stove has cooled down completely before carrying out maintenance. Do not forget, once a year, to : – sweep your chimney, – Check the seal – Clean below the castings Chimney sweeping Do the sweeping at least once a year in accordance with local and national...
Page 24: Chimney Sweeping
Chimney sweeping Stûv 22 - directions for use [en] - 0118...
Page 25: Chimney Sweeping
Chimney sweeping Warning! When removing the valve [figure 12], take care not to lose the spring Refit all components in reverse order. Do not forget to reposition crosspiece in its initial notches. Checking the seal Open the door and check that the white silicon seal is still in good condition.
Page 26: Cleaning Under The Stove Sole Plates
Cleaning under the stove sole plates If you have a fan fitted, please continue maintenance by following the instructions in the next section. Once the work is carried out, reassemble the sole plate parts in reverse order of disassembly. Stûv 22 - directions for use [en] - 0118...
Page 27: Cleaning The Fan
Cleaning the fan Resetting the glass door guides If your stove’s glass door no longer goes up completely, you can reset the alignment of the guides by vigorously opening the glass upwards several times. If this does not suffice, proceed as follows: >...
Page 28: Release The Window Position
The model and the serial number of your stove are indicated on an information plate attached to the body of the stove [photo 1]. 22110 SF Stûv S.A. B-5170 Bois-de-Villers www.stuv.com 160595 Stûv 22 - directions for use [en] - 0118...
Page 29: Table Of Annual Maintenance
Table of annual maintenance Date Engineer Notes Stûv 22 - directions for use [en] - 0118...
Page 30: The Extension Of The Stûv Guarantee : A Simple Procedure For More Peace Of Mind
The statutory warranty and should occur, we undertake to 2. Complete the online form extended warranty do not cover: resolve it. on http://tech.stuv.com/en/ wood/warranty/the-stuv- If you complete the guarantee – the components subject to wear commercial-warranty.html form within 30 days, Stûv will offer and tear (e.g.
Page 31 Complete your guarantee form directly online at www.stuv.com ! Your responsibility As a user, you also have an important role to play in ensuring you get the best out of your Stûv. We strongly recommend : – making sure that it is installed...
Page 32: Spf Certificates For Belgium
SPF CERTIFICATES FOR BELGIUM Kingdom of Belgium Federal Public Service of Health, Food Chain Safety and the Environment, Directorate-General for the Environment RD 12 October 2010 regulating the minimum efficiency requirements and emission levels of pollutants heaters powered by solid fuel Manufacturer: Name of manufacturer Stûv SA Address of manufacturer Rue Jules Borbouse 4...
Page 33 SPF CERTIFICATES FOR BELGIUM Kingdom of Belgium Federal Public Service of Health, Food Chain Safety and the Environment, Directorate-General for the Environment RD 12 October 2010 regulating the minimum efficiency requirements and emission levels of pollutants heaters powered by solid fuel Manufacturer: Name of manufacturer Stûv SA Address of manufacturer Rue Jules Borbouse 4...
Page 34 SPF CERTIFICATES FOR BELGIUM Kingdom of Belgium Federal Public Service of Health, Food Chain Safety and the Environment, Directorate-General for the Environment RD 12 October 2010 regulating the minimum efficiency requirements and emission levels of pollutants heaters powered by solid fuel Manufacturer: Name of manufacturer Stûv SA Address of manufacturer Rue Jules Borbouse 4...
Page 35: Performance Declaration (Eu305/2011)
Recommended fuel: wooden logs only Manufactured by: Stûv s.a Rue Jules Borbouse, 4 B-5170 Bois-de-Villers Tél: +32(0)81.43.47.96 - Fax: +32(0)81.43.48.74 info@stûv.com www.stuv.com Approved certifying body: This device complies with CE regulations 0608 - SGS Nederland bv Leemansweg 51 NL-6827 BX Amhem...
Page 36 Recommended fuel: wooden logs only Manufactured by: Stûv s.a Rue Jules Borbouse, 4 B-5170 Bois-de-Villers Tél: +32(0)81.43.47.96 - Fax: +32(0)81.43.48.74 info@stûv.com www.stuv.com Approved certifying body: This device complies with CE regulations 0608 - SGS Nederland bv Leemansweg 51 NL-6827 BX Amhem...
Page 37 Recommended fuel: wooden logs only Manufactured by: Stûv s.a Rue Jules Borbouse, 4 B-5170 Bois-de-Villers Tél: +32(0)81.43.47.96 - Fax: +32(0)81.43.48.74 info@stûv.com www.stuv.com Approved certifying body: This device complies with CE regulations 0608 - SGS Nederland bv Leemansweg 51 NL-6827 BX Amhem...
Page 38: Product Datasheet (Eu 2015/1186)
Stûv s.a Rue Jules Borbouse, 4 Rue Jules Borbouse, 4 Rue Jules Borbouse, 4 B-5170 Bois-de-Villers B-5170 Bois-de-Villers B-5170 Bois-de-Villers info@stuv.com - www.stuv.com info@stuv.com - www.stuv.com info@stuv.com - www.stuv.com Riferimento del modello: Riferimento del modello: Riferimento del modello: Stûv 22-90 Stûv 22-110...
Page 39: Contacts
Jules Borbouse 4 01680 Vantaa T 51 33 10 93 B-5170 Bois-de-Villers (Belgium) T 400 872 858 Importer for Estonia info@stuv.com – www.stuv.com www.takkamaailma.com Tulering Kaminasalong Oü Importer for Sweden Sopruse 145 – 13417 Tallinn Eldoform Sverige AB T +372 56 249 004 - www.tulering.ee Slipgatan 2 –...
Page 40 This document is available in several languages : However, we do not accept responsibility for any errors that may have been made. Contact your distributor or visit www.stuv.com Editor: Gérard Pitance - rue Jules Borbouse 4 - 5170 Bois-de-Villers - Belgium...
