DRAWER WARMER
This manual contains important safety information
concerning the maintenance, use and operation of
this product. Failure to follow the instructions
contained in this manual may result in serious injury.
If you're unable to understand the contents of this
manual, please bring it to the attention of your
supervisor. Do not operate this equipment unless
you have read and understood the contents of
this manual.
HDW-1R2 Series
Installation &
Operating Manual
I & W #07.05.123.00
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso
y operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted
no puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este equipo
al menos que haya leído y comprendido el contenido
de este manual.
