- Page 1 DRAWER WARMER HDW & HDW-B Series Installation & Operating Manual I&W #07.05.014.00...
-
Page 2: Table Of Contents
Voltage ______________________________________ Date of Purchase _______________________________ INTRODUCTION Hatco Drawer Warmers are designed to keep all foods at optimum serving temperatures without affecting quality. HDW models include an attached cord and plug set while the HDW-B models have a flexible conduit for built-in installation. -
Page 3: Important Safety Instructions
4. On free-standing units, plug unit into an electrical outlet of the correct voltage, size and plug configu- ALL MODELS The Hatco Drawer Warmers are built of rugged stainless steel with durable nylon rollers, 12 gauge stainless steel slides and heavy-duty hardware. Each drawer features... -
Page 4: Specifications
SPECIFICATIONS ELECTRICAL RATING CHART - HDW MODELS Model Voltage HDW-1 HDW-2 HDW-3 HDW-4 ELECTRICAL RATING CHART - HDW Model Voltage HDW-1N HDW-2N HDW-3N The electrical information in the shaded areas pertains to Export models only. Printed March 1999 Watts Amps... -
Page 5: Electrical Rating Chart - Hdw-B
ELECTRICAL RATING CHART - HDW Model Voltage HDW-1B HDW-2B HDW-3B ELECTRICAL RATING CHART - HDW Model Voltage HDW-1BN HDW-2BN HDW-3BN The electrical information in the shaded areas pertains to Export models only. Printed March 1999 Watts Amps 1350 11.3 1350 1350 1350 1350... -
Page 6: Dimensions - Hdw & Hdw-N
SPECIFICATIONS DIMENSIONS - HDW & HDW Model (A) Depth (B) Width HDW-1 22-5/8" 29-1/4" (58 cm) (74 cm) HDW-2 22-5/8" 29-1/4" (58 cm) (74 cm) HDW-3 22-5/8" 29-1/4" (58 cm) (74 cm) HDW-4 22-5/8" 29-1/4" (58 cm) (74 cm) HDW-1N 27"... -
Page 7: Plug Configurations
PLUG CONFIGURATIONS Free-standing units are supplied from the factory with an electrical cord and plug installed. Plugs are supplied according to the applications as shown in Figure 5. Built-in units are supplied with a flexible conduit and applicable wiring. CAUTION On free-standing units, plug unit into an electrical outlet of the correct voltage, size and plug configura- tion. -
Page 8: Location
28-1/8" 19-5/8" (71 cm) (50 cm) a lock strip (not supplied by Hatco) must be perma- nently fastened to the lower front inside lip of the cabinet opening. See Figure 7. 5. Partially insert the Drawer Warmer into the opening, making sure the flexible conduit is fed into the wire connection area first. -
Page 9: Operation
FOOD HOLDING CAPACITY A standard drawer has the following capacity: Dinner Rolls: Ribs: Potatoes: FOOD HOLDING GUIDE TYPE OF HEAT Moist Moist Moist Moist OPERATION HATCO DRAWER WARMER RECOMMENDED SETTINGS Recommended Type Vent Storage Control Product Temp. Heat Setting Rolls, Hard 160-185... -
Page 10: Maintenance
LOCKING CASTERS - 2" (6 cm) Diameter These locking casters are available for the freestanding HDW-1, HDW-2 and HDW-3 models. The casters add 4-1/4" (10 cm) to the height of the Drawer Warmer. LOCKING CASTERS - 3" (8 cm) Diameter These locking casters are available for the freestanding HDW-1, HDW-2 and HDW-3 models. -
Page 11: Hatco Limited Warranty
Hatco-authorized service agency for replace- ment or repair. Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. -
Page 12: Authorized Parts Distributors
HATCO AUTHORIZED PARTS DISTRIBUTORS ALABAMA Jones McLeod Appl. Svc. Birmingham 205-251-0159 ARIZONA Auth. Comm. Food Equip. Phoenix 602-234-2443 Byassee Equipment Co. Phoenix 602-252-0402 CALIFORNIA Industrial Electric Huntington Beach 714-379-7100 Chapman Appl. Service San Diego 619-298-7106 P & D Appliance S. San Francisco...
