BEA CGS-KF112 Manual

Please keep for further use
Designed for colour printing
Other use of the device is outside the permitted purpose and can not be
guaranteed by the manufacturer. The manufacturer cannot be held responsible
for incorrect installations or inappropriate adjustments of the sensor.
DESCRIPTION
1
2
1. Radar antenna
2. M12, male, connector (4 pins)
TECHNICAL SPECIFICATIONS
Technology
Transmitter frequency *
Transmitter radiated power
Transmitter power density
Detection mode
Supply voltage **
Max. power consumption
Output **
Max. switching current
Output voltage
Voltage drop (Vdrop)
Temperature range
Dimensions
Cable length
Material
Protection degree
Accessaries
* Other values are permitted for compliance with country-specific regulations.
** External electrical sources must be within specified voltages, max 15W and ensure double insulation from primary
voltages.
CGS-KF112
ACTIVATION SENSOR FOR ESCALATORS
3. LED: - flashes after power-on
4. Mounting slot
FMCW Technology
24.00 GHz ~ 24.25 GHz
<20dBm EIRP
< 10 W/m²
Motion
12 V ~ 24 V DC +30% / -10%
< 1.5W
PNP
100mA
Vin-Vdrop
< 2V @ 100mA
-20°C ~ + 55°C
48mm (L) x 43 mm (H) x 24 mm (W)
50cm
ABS + PC
IP67
5m/7m cable with M12 connector (Female)
Remote control
Specifications are subject to changes without prior notice. Measured in specific conditions.
- lights up when the sensor detects motion
3
4
