Technical Specifications

M9203-AGx-2(Z) Series On/Off and Floating Point Control Electric Spring Return Actuator
(Part 1 of 2 )
Power -AGx-2 Models
Requirements
-AGx-2Z Models
Input Signal -AGx-2(Z) Models
Control Input -AGx-2(Z) Models
Impedance
Auxiliary Switch -xxB Models
Rating
Spring Return
Rated Torque Power On
(Running)
Power Off
(Spring
Returning)
Rotation Range
Rotation Time Power On
for 90 Degrees of (Running)
Travel -AGx-2 Models
Power On
(Running)
-AGx-2Z Models
Power Off
(Spring
Returning)
Life Cycles
AC 24 V (AC 19.2 V to 28.8 V) at 50/60 Hz: Class 2 (North America) or Safety
Extra-Low Voltage (SELV) (Europe), 4.7 VA Running, 2.7 VA Holding Position
DC 24 V (DC 21.6 V to 28.8 V): Class 2 (North America) or SELV (Europe), 1.8 W
Running, 1 W Holding Position
Minimum Transformer Size: 6 VA per Actuator
AC 24 V (AC 19.2 V to 28.8 V) at 50/60 Hz: Class 2 (North America) or Safety
Extra-Low Voltage (SELV) (Europe), 5.1 VA Running, 2.8 VA Holding Position
DC 24 V (DC 19.2 V to 28.8 V): Class 2 (North America) or SELV (Europe), 1.9 W
Running, 1.1 W Holding Position
Minimum Transformer Size: 6 VA per Actuator
AC 19.2 to 28.8 V at 50/60 Hz or DC 24 V +20%/-10%
Class 2 (North America) or SELV (Europe)
Minimum Pulse Width: 500 msec
4,700 ohm
One Single-Pole, Double-Throw (SPDT), Double-Insulated Switch with Silver
Contacts:
AC 24 V, 50 VA Pilot Duty
AC 120 V, 5.8 A Resistive, 1/4 hp, 275 VA Pilot Duty
AC 240 V, 5.0 A Resistive, 1/4 hp, 275 VA Pilot Duty
Direction Is Selectable with Mounting Position of Actuator:
Actuator Face Labeled A Is Away from Damper or Valve: CCW Spring Return
Actuator Face Labeled B Is Away from Damper or Valve: CW Spring Return
27 lb·in. (3 N·m) All Operating Temperatures
27 lb·in. (3 N·m) All Operating Temperatures
Maximum Full Stroke: 95°
Adjustable Stop: 35 to 95° Maximum Position
150 Seconds Constant for 0 to 27 lb·in. (3 N·m) Load, at All Operating Conditions
90 Seconds Constant for 0 to 27 lb·in. (3 N·m) Load, at All Operating Conditions
12 to 17 Seconds for 0 to 27 lb·in. (3 N·m) Load, at Room Temperature
16 Seconds Nominal at Full Rated Load
22 Seconds Maximum with 27 lb·in. (3 N·m) Load at -22°F (-30°C)
60,000 Full Stroke Cycles with 27 lb·in. (3 N·m) Load
1,500,000 Repositions with 27 lb·in. (3 N·m) Load
