M9203-AGx-2(Z) Series On/Off and Floating Point Control Electric Spring Return Actuator
(Part 2 of 2 )
Audible Noise Power On
Rating (Running)
-AGx-2 Models
Power On
(Running)
-AGx-2Z Models
Power On
(Holding)
Power Off
(Spring
Returning)
Electrical -AGA-2(Z) Models
Connections
Auxiliary Switch
(-xxB Models)
Conduit Connections
Mechanical Round Shafts
Connections
Square Shafts
Enclosure Rating
Ambient Standard
Conditions Operating
Storage
Dimensions
Compliance United States
Canada
Europe
Australia and
New Zealand
Shipping Weight
M9203-AGx-2(Z) Series On/Off and Floating Point Electric Spring Return Actuators Installation Guide
<28 dBA at 27 lb·in. (3 N·m) Load, at a Distance of 39-13/32 in. (1 m)
<37 dBA at 27 lb·in. (3 N·m) Load, at a Distance of 39-13/32 in. (1 m)
<20 dBA at a Distance of 39-13/32 in. (1 m)
<56 dBA at 27 lb·in. (3 N·m) Load, at a Distance of 39-13/32 in. (1 m)
120 in. (3.05 m) UL 444 Type CMP Plenum Rated Cable with 19 AWG
(0.75 mm²) Conductors and 0.25 in. (6 mm) Ferrule Ends
48 in. (1.2 m) UL 758 Type AWM Halogen Free Cable with 18 AWG (0.85 mm²)
Conductors and 0.25 in. (6 mm) Ferrule Ends
Integral 1/2 in. (13 mm) Threaded Conduit Connector(s)
Range of Sizes: 1/4 to 1/2 in. (6 to 12 mm)
Range of Sizes: 1/4 to 5/16 in. (6 to 8 mm)
NEMA 2 (IP54) for all Mounting Orientations
-22 to 140°F (-30 to 60°C); 90% RH Maximum, Noncondensing
-40 to 185°F (-40 to 85°C); 95% RH Maximum, Noncondensing
6.38 x 3.23 x 2.26 in. (162 x 82 x 57.5 mm)
UL Listed, CCN XAPX, File E27734; to UL 60730-1A: 2003-08, Ed. 3.1,
Automatic Electrical Controls for Household and Similar Use;
and UL 60730-2-14: 2002-02, Ed. 1, Part 2, Particular Requirements for Electric
Actuators. (Models: All)
Plenum Rated (UL 2043). Suitable for use in other environmental air space
(plenums) in accordance with Section 300.22 (C) of the National Electric Code
UL Listed, CCN XAPX7, File E27734; to UL 60730-1:02-CAN/CSA: July 2002,
3rd Ed., Automatic Electrical Controls for Household and Similar Use;
and CSA C22.2 No. 24-93 Temperature Indicating and Regulating Equipment
(Models: All)
CE Mark – Johnson Controls, Inc. declares that this product is in compliance with
the essential requirements and other relevant provisions of the EMC Directive
and Low Voltage Directive.
RCM Mark, Australia/NZ Emissions Compliant (Models: All)
-AGA Models: 2.0 lb (0.9 kg)
-AGB Models: 2.4 lb (1.1 kg)
