Passive Gas Tube
(for organic solvents)
Thank you for purchasing this product.
This operation manual describes
important precautions for preventing
accidents as well as procedures for
handling the product.
To ensure safety, read this operation
manual thoroughly before use and
use the product correctly.
After reading this operation manual,
keep it handy for future reference.
2005-2016 SIBATA SCIENTIFIC TECHNOLOGY LTD.
CODE 080150-066
Advertisement
Table of Contents
Related Manuals for Sibata 080150-066
Summary of Contents for Sibata 080150-066
- Page 1 To ensure safety, read this operation manual thoroughly before use and use the product correctly. After reading this operation manual, keep it handy for future reference. 2005-2016 SIBATA SCIENTIFIC TECHNOLOGY LTD.
-
Page 2: Table Of Contents
Table of Contents Page Page The Sampling Rate Before Use of This Product Sampling Rate About This Operation Manual Calculation Procedure Included Items Required Tools and Materials Safety Precautions Sampling Procedure About This Product Sampling Rate Calculation Names of Parts Main Specifications Instructions for Use Options... -
Page 3: Before Use
Passive gas tubes ······························· Set of 12 (individually packaged in aluminum bags) O peration manual (this manual) ·············· 1 copy Note: If any of the items are damaged or missing, contact your Sibata representative or the vendor where you purchased the product. -
Page 4: Safety Precautions
Safety Precautions (Be Sure to Read This) The precautionary information in this operation manual is provided to ensure the safe use of the product and to prevent property damage and injury to you and other people. It is all important for ensuring safety, so be sure to read it thoroughly before using the product and observe it during use. - Page 5 Precautionary Information WARNING Do not modify the Analysis should only product or use it for be performed by a purposes other than person with technical Mandatory Prohibited chemical analysis. expertise about chemical analysis. Doing so may result in an Not doing so could result in accident.
-
Page 6: About This Product
About This Product The passive gas tube (for organic solvents) simply extracts organic solvents in the air, and is an Omni-directional sampler that can measure the density of each substance in the environment. This sampler samples organic solvent gas in the air, by making the gas touched to a granular activated carbon provided in the tube through a pore of PTFE. -
Page 7: Instructions For Use
Instructions for Use When handling the passive gas tube, be careful not to touch the PTFE tube. Sampling (adsorption in the passive gas tube) (1) Cut open the aluminum bag with scissors or something similar (Markings on the aluminum bag indicate where to cut.). The bag contains the passive gas tubes individually packaged in aluminum. -
Page 8: Analysis Procedure
Analysis Procedure Extraction and analysis requires technical expertise regarding chemical analysis. Inexperienced operators should always perform extraction and analysis work under the supervision of an experienced operator or outsource the process to an analysis and measurement service provider qualified to do so. In addition, precautionary measures, such as wearing protective gear or preventing fires, are required for handling the hazardous or highly volatile substances described... -
Page 9: Analyzing Samples
Analyzing Samples This product is designed for use with hazardous and highly volatile substances. Implement appropriate precautionary measures. In a clean location, remove the passive gas tube used for sampling from its aluminum bag. Picking up an aluminum ring of a passive gas tube lightly by pliers, make them transformed and pull out a PTFE cap. -
Page 10: The Sampling Rate Of This Product
The Sampling Rate of This Product (as a Reference) (Room Temperature) Sampling Rate Classification Organic Solvent (μg/(ppm min)) Aliphatic Hydrocarbon n-Hexane 0.179 Alcohols Isopropyl alcohol 0.066 n-Butanol 0.056 2-Butanol 0.088 Isobutyl alcohol 0.088 Isopentyl alcohol 0.096 Ketones Acetone 0.097 Methyl ethyl ketone 0.094 Methyl isobutyl ketone 0.184... - Page 11 (Room Temperature) Sampling Rate Classification Organic Solvent (μg/(ppm min)) Aromatic carbonization water Benzene 0.178 element class Toluene 0.180 Xylene 0.186 Ethylbenzene 0.130 Styrene (Relative Humidity 0.105 20 to 50%) Cyclo hydrocarbon Cyclohexane 0.091 Others Tetrahydrofuran 0.154 N · N- Dimethylformamide 0.096 Note: Those material sampling rates, which aren’t indicated on this table, are calculated by the “Sampling Rate Calculation Procedure”...
-
Page 12: Sampling Rate Calculation Procedure
Sampling Rate Calculation Procedure Extraction and analysis requires technical expertise regarding chemical analysis. Inexperienced operators should always perform extraction and analysis work under the supervision of an experienced operator or outsource the process to an analysis and measurement service provider qualified to do so. -
Page 13: Main Specifications
Weight About 2 g Tubes Included Set of 12 (individually packaged in aluminum bags) Product Code 080150-066 Note: This product was jointly developed with Kanagawa-ken Preventive. Note: A special organic solvents passive holder is sold separately. (Product Code: 080150-0671) Options... -
Page 14: Product Shelf Life
Inquiries If you have any questions about this product, or if there is any other way in which we can be of assistance, contact your Sibata representative or the vendor where you purchased the product. Please also visit our website to contact us for inquiries. - Page 16 2016.10.28H(06)
