Page 1 United States Stove Company Project # 22-753 Model: KP5522 Additional Models: KP5522-P, KP5522-L, KP5522-W, US5522, US5522-P, US5522-L, US5522-W, AP5622, AP5622-P, AP5622-L, AP5622-W VG5722, VG5722-P, VG5722-L, VG5722-W, SP1100, SP1100-W Type: Pellet-Fired Room Heater March 29, 2022 Revised Date: May 17, 2022...
Page 2 Project # 22-753 Model: KP5522 Revision History Date: March 29, 2022 – Original Issue Date: May 17, 2022 – The following changes were made per request from EPA: B415 Calculations page was included in Appendix A, see page 73 of Non-CBI report.
Page 3: Table Of Contents
Project # 22-753 Model: KP5522 Contents Affidavit ................................. 3 Introduction ..............................4 Notes ................................. 4 Pellet Heater Identification and Testing ......................5 Test Procedures and Equipment ........................6 Results ................................7 Summary Table ............................7 Test Run Narrative ............................ 8 Run 1 ..............................
Page 4: Affidavit
Affidavit PFS-TECO was contracted by United States Stove Company to provide testing services for the KP5522 Pellet-Fired Room Heater per EPA ALT-146, using ASTM E2779, Determining PM Emissions from Pellet Heaters. All testing and associated procedures were conducted at PFS-TECO’s Portland Laboratory on 2/18/2022. PFS-TECO’s Portland Laboratory is located at 11785 SE Highway 212 –...
Page 5: Introduction
Model: KP5522 Introduction United States Stove Company of South Pittsburg, TN, contracted with PFS-TECO to perform EPA certification testing on KP5522 Pellet-Fired Room Heater. All testing was performed at PFS-TECO’s Portland Laboratory. Testing was performed by Mr. Sebastian Button. Notes •...
Page 6: Pellet Heater Identification And Testing
Model: KP5522 Pellet Heater Identification and Testing • Appliance Tested: KP5522 • Serial Number: un-serialized prototype, PFS tracking #121 • Manufacturer: United States Stove Company • Catalyst: No • Heat exchange blower: Integral • Type: Pellet Stove • Style: Free Standing •...
Page 7: Test Procedures And Equipment
Project # 22-753 Model: KP5522 Test Procedures and Equipment All Sampling and analytical procedures were performed by Sebastian Button. procedures used are directly from ASTM E2779 and ASTM E2515. See the list below for equipment used. See Appendix C submitted with this report for calibration data.
Page 8: Results
Higher Heating Values efficiency of 76% and a CO emission rate of 0.15 g/min. The calculated first hour particulate emission rate was 2.8 g/hr. The United States Stove Company Model KP5522 Pellet-Fired Room Heater meets the 2020 PM emission standard of ≤ 2.0 g/hr per CFR 40 part 60, §60.532 (b).
Page 9: Test Run Narrative
Project # 22-753 Model: KP5522 Test Run Narrative Run 1 Run 1 was performed on 2/18/2022 as an attempted integrated test run per EPA ALT- 146/ ASTM E2779. The overall test duration was 360 minutes. The particulate emissions rate for the integrated test run was 1.5 g/hr. The run had an overall HHV efficiency of 76%.
Page 10: Appliance Description
Additional Models Discussion: This model is offered under a variety of different KP5522-P, KP5522-L, branding designations under the following model numbers: KP5522-W, US5522, US5522-P, US5522-L, US5522-W, AP5622, AP5622-P, AP5622-L, AP5622-W VG5722, VG5722-P, VG5722-L, VG5722-W, SP1100, and SP1100-W . The various models are identical in all aspects with the exception of the brand names.
Page 11 Project # 22-753 Model: KP5522 Appliance Front Appliance Left Page | 10...
Page 12 Project # 22-753 Model: KP5522 Appliance Right Appliance Rear Page | 11...
Page 13: Test Fuel Properties
Project # 22-753 Model: KP5522 Test Fuel Properties Test fuel used was Bear Mountain Wood Pellet Fuel, a PFI Certified Premium Pellet Brand. A sample of pellets was sent to Twin Ports Testing for analysis, see report below. Page | 12...
Page 14: Pellet Fuel Analysis
Project # 22-753 Model: KP5522 Pellet Fuel Analysis Page | 13...
Page 15: Sampling Location And Descriptions
Project # 22-753 Model: KP5522 Sampling Location and Descriptions Sample ports are located 16.5 feet downstream from any disturbances and 2 feet upstream from any disturbances. Flow rate traverse data was collected 8 feet downstream from any disturbances and 4 feet upstream from any disturbances. (See below).
Page 16: Sampling Methods
Project # 22-753 Model: KP5522 Sampling Methods ASTM E2515 was used in collecting particulate samples. The dilution tunnel is 12 inches in diameter. All sampling conditions per ASTM E2515 were followed. No alternate procedures were used. Analytical Methods Description All sample recovery and analysis procedures followed ASTM E2515 procedures. At the...
Page 17: Sealed Unit
Project # 22-753 Model: KP5522 Sealed Unit Page | 16...
Page 18: List Of Appendices
Project # 22-753 Model: KP5522 List of Appendices The following appendices have been submitted electronically in conjunction with this report: Appendix A – Test Run Data, Technician Notes, and Sample Analysis Appendix B – Labels and Manuals Appendix C –Equipment Calibration Records Appendix D –...
Page 19 Conditioning Data.xlsm Pre-Conditioning Data Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Date(s): 1/26/22 - 1/28/22 Technician: Notes: Indicate initial air setting and any changes in in setting during Catalyst Exit Elapsed Time Flue (°F) conditioning, as well as weight and average moisture content of all fuel (°F)
Page 20 Sebastian Button From: Sebastian Button Sent: Thursday, March 10, 2022 2:23 PM Sebastian Button Subject: Burn Instructions Sebastian Button Laboratory Supervisor - Portland Laboratory From: John Voorhees <john.voorhees@usstove.com> Sent: Monday, February 14, 2022 12:17 PM To: Sebastian Button <sebastian.button@pfsteco.com> Subject: RE: Pellet Stove Great news, yes, 5522.
Page 21 PELLET TEST DATA PACKET ASTM E2779/E2515 Run 1 Data Summary Client: USSC Model: KP5522 Job #: 22-753 Tracking #: Test Date: 2/18/2022 3/9/2022 Techician Signature Date PFS-TECO...
Page 22 Run 1.xlsm TEST RESULTS - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Burn Rate Summary High Burn Rate (dry kg/hr) 2.26 Medium Burn Rate (dry kg/hr) 1.58 Medium Burn Rate Target: <...
Page 23 Run 1.xlsm Overall Pellet Test Efficiency Results Manufacturer: USSC Model: KP5522 Date: 02/18/22 Run: 1 Control #: 22-753 Test Duration: 360 Output Category: Integrated Test Results in Accordance with CSA B415.1-09 HHV Basis LHV Basis Overall Efficiency 76.2% 84.2% Combustion Efficiency 99.5%...
Page 24 Run 1.xlsm Max Burn Rate Segment Efficiency Results Manufacturer: USSC Model: KP5522 Date: 02/18/22 Run: 1 Control #: 22-753 Test Duration: 60 Output Category: Maximum Test Results in Accordance with CSA B415.1-09 HHV Basis LHV Basis Overall Efficiency 77.2% 85.3% Combustion Efficiency 99.5%...
Page 25 Run 1.xlsm Medium Burn Rate Segment Efficiency Results Manufacturer: USSC Model: KP5522 Date: 02/18/22 Run: 1 Control #: 22-753 Test Duration: 120 Output Category: Medium Test Results in Accordance with CSA B415.1-09 HHV Basis LHV Basis Overall Efficiency 76.0% 83.9% Combustion Efficiency 99.5%...
Page 26 Run 1.xlsm Minimum Burn Rate Segment Efficiency Results Manufacturer: USSC Model: KP5522 Date: 02/18/22 Run: 1 Control #: 22-753 Test Duration: 180 Output Category: Minimum Test Results in Accordance with CSA B415.1-09 HHV Basis LHV Basis Overall Efficiency 75.5% 83.4% Combustion Efficiency 99.5%...
Page 27 Run 1.xlsm DILUTION TUNNEL & MISC. DATA - ASTM E2779 / E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Test Start Time: 9:35 Date: 2/18/2022 High Burn End Time (min): Medium Burn End Time (min):...
Page 28 Run 1.xlsm PELLET STOVE PREBURN DATA - ASTM E2779 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: Technician: Date: 2/18/2022 Recording Interval (min): Run Time (min): Average: 0.068 Flue Draft (in Elapsed Time Scale Weight Flue (°F) Ambient (°F)
Page 29 Run 1.xlsm PELLET STOVE PREBURN DATA - ASTM E2779 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: Technician: Date: 2/18/2022 39.7 -0.06 0.070 39.6 -0.11 0.070 39.6 -0.07 0.070 39.5 -0.08 0.070 39.4 -0.08 0.080 39.3 -0.1...
Page 30 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 31 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 32 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 33 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 34 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 35 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 36 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 37 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 38 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 39 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 40 Run 1.xlsm BOX A TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: 1 Technician: SJB Date: 2/18/2022 Particulate Sampling Data Fuel Weight (lb) Temperature Data (°F) Dilution Orifice...
Page 41 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 42 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 43 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 44 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 45 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 46 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 47 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 48 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 49 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 50 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 51 Run 1.xlsm BOX B TEST DATA - ASTM E2779 / ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: Run #: Technician: Date: 2/18/2022 Particulate Sampling Data Flue Gas Data Meter Gas Meter Orifice dH Flue Draft Elapsed...
Page 52 Run 1.xlsm LAB SAMPLE DATA - ASTM E2515 Client: USSC Job #: 22-753 Model: KP5522 Tracking #: 121 Run #: Technician: SJB Date: 2/18/2022 Sample ID Tare, mg Total, mg Final, mg Catch, mg 246.6 247.7 A - 1st Hour...
Page 53 ASTM E2779 Wood Heater Run Sheets Client: USSC Job Number: 22-753 Tracking #: 121 Model: 5522 Run Number: 1 Test Date: 2/18/2022 Pellet Heater Control Settings High Burn Rate Settings: Heat Setting: #5 (Max setting) – Air Damper Fully Open Medium Burn Rate Settings: Heat Setting: #3 (Min setting) –...
Page 57 Twin Ports Testing, Inc. 1301 North 3rd Street Superior, WI 54880 715-392-7114 800-373-2562 715-392-7163 www.twinportstesting.com Report No: USR:W222-0106-01 Analytical Test Report Issue No: Client: PFS-TECO Signed: 11785 SE Hwy 212 Ste 305 Clackamas, OR 97015 Attention: Sebastian Button Amber Anderson Chemist PO No: 3/9/2022...
Page 58 Project # 22-751 Model: Charnwood Skye E700 Tunnel Schematic Page | 16...
Page 59 Equations and Sample Calculations – ASTM E2779 & E2515 Client USSC Model: KP5522 Tracking #: Run: Equations used to calculate the parameters listed below are described in this appendix. Sample calculations are provided for each equation. The raw data and printout results from a sample run are also provided for comparison to the sample calculations.
Page 60 Run 1.xlsm – Weight of test fuel burned during test run, dry basis, kg ASTM E2779 equation (1) = (M )(100/(100 + FM)) Where, average fuel moisture of test fuel, % dry basis weight of test fuel in hopper at start of test run, wet basis, kg weight of test fuel in hopper at end of test run, wet basis, kg Sample Calculation: FM = 4.37 %...
Page 61 Run 1.xlsm – Weight of test fuel burned during test run segment i , dry basis, kg BSidb ASTM E2779 equation (2) = (MS )(100/(100 + FM)) BSidb Siwb ESiwb Where, weight of test fuel in hopper at start of test run segment i , wet basis, kg SSiwb weight of test fuel in hopper at end of test run segment i , wet basis, kg ESiwb...
Page 62 Run 1.xlsm BR – Average dry burn rate over full integrated test run, kg/hr ASTM E2779 equation (3) 60 M θ Where, = Total length of full integrated test run, min θ Sample Calculation: = 8.32 = 360 θ 60 x 8.32 1.39 kg/hr Page 4 of 14...
Page 63 Run 1.xlsm – Average dry burn rate over test run segment i , kg/hr ASTM E2779 equation (4) 60 M BSidb θ Where, Total length of test run segment i , min θ Sample Calculation (from medium burn rate segment): 3.15 BSidb θ...
Page 64 Run 1.xlsm – Average gas velocity in the dilution tunnel, ft/sec ASTM E2515 equations (9) Where: Adjustment factor for center of tunnel pitot tube strav , ASTM E2515 Equation (1) placement, Fp = scent Dilution tunnel velocity calculated after the multi-point pitot traverse at the center, ft/sec scent Dilution tunnel velocity calculated after the multi-point pitot traverse, ft/sec strav...
Page 65 Run 1.xlsm – Average gas flow rate in dilution tunnel, dscf/hr ASTM E2515 equation (3) Where: 3600 Conversion from seconds to hours (ASTM method uses 60 to convert in minutes) Water vapor in gas stream, proportion by volume; assume 2% Cross sectional area of dilution tunnel, ft Standard absolute temperature, 528 °R Absolute average gas static pressure in dilution tunnel, = P...
Page 66 Run 1.xlsm – Volume of Gas Sampled Corrected to Dry Standard Conditions, dscf m(std) ASTM E2515 equation (6) Where: 17.64 °R/in. Hg Volume of gas sample measured at the dry gas meter, dcf Dry gas meter calibration factor, dimensionless Barometric pressure at the testing site, in. Hg Average pressure differential across the orifice meter, in.
Page 67 Run 1.xlsm – Total Particulate Matter Collected, mg ASTM E2515 Equation (12) Where: mass of particulate matter from probe, mg mass of particulate matter from filters, mg mass of particulate matter from filter seals, mg Sample Calculation: Using equation for Train A (first hour): Using equation for Train A (remainder): Train A Aggregate = 4.0 mg...
Page 68 Run 1.xlsm - Concentration of particulate matter in tunnel gas, dry basis, corrected to standard conditions, g/dscf ASTM E2515 equation (13) Where: Constant, 0.001 g/mg Total mass of particulate matter collected in the sampling train, mg Volume of gas sampled corrected to dry standard conditions, dscf m(std) Sample calculation: For Train A:...
Page 69 Run 1.xlsm – Total Particulate Emissions, g ASTM E2515 equation (15)   −  Where: Concentration of particulate matter in tunnel gas, g/dscf Concentration particulate matter room air, g/dscf Average dilution tunnel gas flow rate, dscf/hr Total time of test run, minutes θ...
Page 70 Run 1.xlsm PR - Proportional Rate Variation ASTM E2515 equation (16) Where: θ = Total sampling time, min θ = Length of recording interval, min = Volume of gas sample measured by the dry gas meter during the “ith” time interval, dcf = Volume of gas sample as measured by dry gas meter, dcf = Average gas velocity in the dilution tunnel during the "ith"...
Page 71 Run 1.xlsm – Average particulate emissions for full integrated test run, g/hr ASTM E2779 equation (5) = 60 (E /θ) Where, = Total particulate emissions, grams θ = Total length of full integrated test run, min Sample Calculation: (Dual train average) = 8.99 g θ...
Page 72 Run 1.xlsm – Average particulate emission factor for full integrated test run, g/dry kg of fuel burned ASTM E2779 equation (6) Where, = Total particulate emissions, grams = Weight of test fuel burned during test run, dry basis, kg Sample Calculation: (Dual train average) = 8.99 g 8.32 kg...
Page 73 USSC Manufacturer: KP5522 Air Fuel Ratio (A/F) Model: Dry Molecular Weight (M 02/18/22 Overall Heating Efficiency: 76.24% 29.41 Date: Combustion Efficiency: 99.50% Dry Moles Exhaust Gas (N 843.31 Note: In the “Input data”, "Calc. % O ", "Fuel Properties", Run: and “Mass Balance”...
Page 74 6.75 0.03 7.72 134.1% 19.75 12.01 157.9 20.7 100.2% 78.1% 78.3% 14.8 6.75 22.30 6.54 21.45 6.71 0.03 7.41 143.9% 19.79 12.37 157.2 20.6 100.2% 77.8% 77.9% 15.4 6.71 22.82 6.50 21.96 6.67 0.03 6.90 161.9% 19.87 12.96 157.2 20.7 100.2% 77.0% 77.2%...
Page 75 4.71 0.03 4.61 290.9% 20.22 15.60 131.8 21.1 100.5% 74.9% 75.3% 24.6 4.71 45.74 4.60 44.69 4.69 0.03 5.10 254.0% 20.15 15.04 131.6 21.1 100.5% 76.2% 76.6% 22.3 4.69 46.01 4.58 44.95 4.66 0.03 4.03 347.2% 20.31 16.27 131.4 21.1 100.7% 73.0% 73.5%...
Page 76 2.89 0.03 2.95 509.0% 20.48 17.52 109.6 20.1 101.1% 71.6% 72.3% 38.3 2.89 66.74 2.84 65.90 2.87 0.03 4.87 270.5% 20.19 15.30 110.0 20.0 100.5% 78.3% 78.7% 23.3 2.87 67.00 2.82 66.16 2.84 0.02 3.79 376.2% 20.35 16.55 109.8 20.0 101.0% 75.3% 76.1%...
Page 77 1.71 0.03 2.57 597.0% 20.54 17.95 96.4 19.4 101.3% 72.0% 72.9% 43.9 1.71 80.37 1.68 79.81 1.68 0.02 4.43 307.5% 20.25 15.81 97.6 19.5 100.8% 78.9% 79.5% 25.6 1.68 80.63 1.66 80.08 1.68 0.03 4.69 284.7% 20.21 15.51 98.1 19.5 100.5% 79.4% 79.8%...
Page 78 0.53 0.03 4.63 289.0% 20.22 15.57 97.2 19.7 100.5% 79.4% 79.9% 24.5 0.53 93.94 0.52 93.76 0.50 0.03 2.73 557.4% 20.51 17.77 97.9 19.7 101.2% 72.7% 73.6% 41.4 0.50 94.20 0.50 94.03 0.49 0.03 4.42 307.9% 20.25 15.82 98.9 19.7 100.6% 78.7% 79.2%...
Page 79 Moisture Content M 4.19 Combustion Efficiency: 99.50% Moisture of Wood (wet basis): 4.19 Dry kg : 8.32 Initial Dry Weight Wt (kg): Total Input (kJ): 163,490 155,063 (Btu) 8.32 Total Output (kJ): 124,653 118,227 (Btu) Moisture Content Dry 4.37 Efficiency: 76.24% 44.3 Total CO (g):...
Page 80 3.88 8.59 2.77 19639.20 4.19 80.24 21.28 1.99 8.60 -0.02 0.20 38.94 60.58 0.15 -0.09 404.74 43.37 2.43 431.04 3.88 8.59 2.77 19639.20 4.19 80.19 21.27 1.91 8.25 -0.02 0.19 38.94 65.03 0.16 -0.09 421.54 43.38 2.43 430.32 3.88 8.59 2.77 19639.20 4.19...
Page 81 3.88 8.59 2.77 19639.20 4.19 79.76 21.16 1.19 5.16 -0.02 0.12 38.95 131.77 0.25 -0.20 673.78 43.60 2.43 404.93 3.88 8.59 2.77 19639.20 4.19 79.84 21.18 1.32 5.70 -0.02 0.13 38.95 114.97 0.23 -0.17 610.30 43.54 2.43 404.76 3.88 8.59 2.77 19639.20 4.19...
Page 82 3.88 8.59 2.77 19639.20 4.19 79.50 21.09 0.76 3.32 -0.03 0.08 38.97 231.46 0.40 -0.36 1050.56 43.91 2.43 382.76 3.88 8.59 2.77 19639.20 4.19 79.80 21.17 1.26 5.44 -0.02 0.12 38.95 122.47 0.24 -0.18 638.63 43.57 2.43 383.15 3.88 8.59 2.77 19639.20 4.19...
Page 83 3.88 8.59 2.77 19639.20 4.19 79.45 21.07 0.66 2.91 -0.03 0.07 38.97 271.90 0.45 -0.42 1203.40 44.04 2.43 369.59 3.88 8.59 2.77 19639.20 4.19 79.74 21.15 1.14 4.95 -0.03 0.11 39.06 139.33 0.18 -0.23 702.65 43.65 2.43 370.76 3.88 8.59 2.77 19639.20 4.19...
Page 84 3.88 8.59 2.77 19639.20 4.19 79.76 21.16 1.20 5.19 -0.02 0.12 38.95 130.89 0.25 -0.20 670.46 43.59 2.43 370.32 3.88 8.59 2.77 19639.20 4.19 79.47 21.08 0.70 3.08 -0.03 0.07 38.97 253.66 0.43 -0.39 1134.45 43.98 2.43 371.04 3.88 8.59 2.77 19639.20 4.19...
Page 85 SUMS AVERAGE 4005.63 3025.39 2944.64 2911.45 3832.22 3524.59 293.32 56334.12 136063.49 25017.08 679827.48 -67042.58 747685.87 41655.88 4486.26 37223.36 Energy Losses (kJ/kg of Dry Fuel) Heat Content Change - Ambient to Stack Temperature Room Total Flue Gas Constituent Temp Flue Gas Constituent Loss Total O Comb...
Page 86 5495.81 4122.68 4005.74 3962.02 5319.69 4792.46 293.82 214.01 249.75 43.43 1603.57 -76.91 2114.69 118.47 4267.01 199.55 5469.68 4103.81 3987.58 3944.03 5292.81 4770.80 293.71 212.99 266.85 45.26 1662.55 -83.26 2114.44 118.42 4337.25 156.84 5465.45 4100.54 3984.38 3940.87 5288.93 4766.96 293.82 212.84 300.06 48.61 1782.61...
Page 87 4393.17 3313.71 3224.18 3188.06 4212.62 3858.84 294.21 171.12 436.64 72.53 2148.05 -178.33 2085.05 116.20 4851.28 105.71 4386.29 3308.63 3219.28 3183.20 4205.76 3852.98 294.21 170.84 380.40 65.64 1942.72 -154.38 2082.24 116.19 4603.65 120.41 4379.41 3303.56 3214.37 3178.35 4198.91 3847.12 294.21 170.60 520.03 83.06 2449.56...
Page 88 3521.14 2669.26 2600.41 2570.59 3347.27 3113.32 293.26 137.21 617.83 113.21 2700.55 -320.18 2067.52 114.39 5430.54 132.08 3541.17 2684.28 2615.01 2585.03 3366.67 3130.78 293.15 137.93 328.74 68.57 1650.88 -164.91 2051.92 114.43 4187.56 92.61 3534.40 2679.24 2610.12 2580.19 3360.01 3124.94 293.15 138.12 457.27 58.90 2118.66...
Page 89 3016.03 2293.30 2235.84 2209.85 2851.88 2677.38 292.54 117.55 623.56 129.61 2659.33 -377.58 2054.39 113.33 5320.19 106.60 3058.79 2325.16 2266.75 2240.43 2893.74 2714.34 292.65 119.46 323.98 50.28 1574.24 -201.89 2037.65 113.42 4017.13 53.67 3078.94 2340.22 2281.37 2254.89 2913.37 2731.83 292.65 119.93 301.75 71.14 1495.18...
Page 90 3034.55 2306.87 2248.95 2222.83 2870.50 2693.04 292.82 118.20 301.95 71.93 1490.33 -176.81 2034.10 113.37 3953.07 79.63 3063.64 2328.62 2270.07 2243.72 2898.83 2718.30 292.82 119.39 590.68 122.17 2545.40 -351.63 2053.48 113.43 5192.93 92.98 3106.20 2360.42 2300.94 2274.26 2940.29 2755.22 292.82 121.00 329.26 75.46 1598.75...
Page 91 SUMS 54.8 -24.3 -796.79 38020.2 126399.0 -792.5 Chemical Sensible and Total Chem Grams Produced Loss 1 Latent Loss Output Loss 2 0.00 0.00 0.00 230.99 0.23 -0.08 174.10 0.28 -0.04 192.56 0.26 -0.06 142.82 0.19 -0.04 170.74 0.18 -0.07 171.53 0.17 -0.06 138.72...
Page 92 -1.57 201.12 0.20 -0.06 -1.38 158.21 0.16 -0.05 -1.38 134.96 0.14 -0.05 -1.20 146.87 0.15 -0.05 -1.64 170.41 0.18 -0.06 -0.43 172.09 0.23 -0.05 -1.23 178.86 0.17 -0.05 -1.36 165.78 0.17 -0.05 1.23 138.71 0.26 -0.02 0.52 140.56 0.22 -0.03 -0.70 153.30 0.21...
Page 93 -2.30 108.02 0.15 -0.07 -2.32 122.73 0.17 -0.07 -3.73 151.48 0.23 -0.11 -1.84 108.18 0.14 -0.06 -2.62 119.39 0.17 -0.08 -2.15 105.16 0.15 -0.07 -2.48 124.21 0.17 -0.08 -1.16 149.01 0.25 -0.07 -0.80 127.13 0.20 -0.05 -1.88 109.97 0.14 -0.06 -2.43 111.11 0.16...
Page 94 -5.03 137.11 0.27 -0.14 -2.13 94.74 0.15 -0.07 -2.93 75.69 0.09 -0.07 -1.59 66.95 0.11 -0.05 -4.29 101.25 0.13 -0.10 -5.05 114.72 0.15 -0.12 -2.02 65.36 0.07 -0.05 -1.00 29.18 0.03 -0.02 -3.56 79.49 0.10 -0.08 -3.50 78.56 0.10 -0.08 -0.44 72.15 0.19...
Page 95 -4.96 111.57 0.25 -0.14 -2.02 55.69 0.07 -0.05 -1.60 63.38 0.11 -0.05 -3.98 109.29 0.22 -0.11 -2.36 59.13 0.07 -0.06 -3.20 73.07 0.10 -0.07 -4.71 100.20 0.14 -0.11 -1.23 59.94 0.09 -0.04 -2.96 71.66 0.16 -0.08 -3.57 63.10 0.10 -0.08 -4.80 84.32 0.06...
Page 96 -2.11 81.74 0.14 -0.06 -4.11 97.09 0.21 -0.11 -1.27 47.01 0.08 -0.04 -2.97 64.92 0.09 -0.07 -5.65 114.93 0.16 -0.13 -3.30 81.39 0.10 -0.08 -1.75 59.13 0.11 -0.05 -4.60 92.41 0.13 -0.11 -4.40 84.52 0.12 -0.10 -0.28 76.46 0.19 -0.04 -0.64 103.34 0.43...
Page 97 According to the information provided, you seek an alternative test method for use when conducting testing on the United States Stove Company, Model KP5517 pellet heater. Currently, as required by section 60.534(a)(l)(i) of Subpart AAA, a manufacturer has the option to test their appliance in accordance with 40 CFR part 60, Appendix B, Method 28R for a crib fuel appliance or ASTM E2779-10 “Standard Test Method for Determining Particulate Matter Emissions from...
Page 98 the position(s) as needed to achieve a burn rate that is ≤ 50% of the maximum burn rate.” Table 1 of ASTM E2779-10 also notes that the Medium Burn Rate Category test must be ≤ 50% of the maximum burn rate. The memorandum states that this is incorrect as it assumes that zero is the other bound for determining half of the maximum burn rate, and that the correct approach in determining the Medium Burn Rate Category should be at a level below 50% of the span between the Maximum Burn Rate and the Low Burn Rate (a non-zero value).
Page 99 Group Leader Measurement Technology Group Angelina Brashear – EPA/OAQPS/AQAD Chuck French – EPA/OAQPS/SPPD Rafael Sanchez – EPA/OECA Robert Scinta – EPA/OECA Michael Toney – EPA/OAQPS/AQAD Nathan Topham – EPA/OAQPS/SPPD John Voorhees – United States Stove Company Chet Wayland – EPA/OAQPS/AQAD...
Page 100 02/02/2022 MEMORANDUM SUBJECT: Appropriate calculation of Medium Burn Rate Category in ASTM E-2779 Testing FROM: Steffan Johnson Digitally signed by STEFFAN Group Leader STEFFAN JOHNSON Date: 2022.02.02 Measurement Technology Group JOHNSON 08:28:07 -05'00' Air Quality Assessment Division Robert Scinta, P.E. Chief, Air Branch Monitoring, Assistance, and Media Programs Division Office of Compliance, Office of Enforcement and Compliance Assurance...
Page 101 The correct application of this requirement would be to determine the Medium Burn Rate Category at a level below 50% of the span between the Maximum Burn Rate and the Low Burn Rate (a non-zero value). Ergo, the correct calculation for finding that midpoint of 50% is defined For example, if the Maximum Burn rate of an appliance is 1.79 kg/hr and the minimum is 1.23 kg/hr, the method would currently place the 50% requirement at 0.895 kg/hr.
Page 105 State of California to cause cancer, birth defects, and/or other reproductive harm. For emissions standards. more information, go to www.P65warnings.ca.gov THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. © 2022 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380 Ph. 800-750-2723...
Page 106 This app is available only Text to 423-301-5624 or; on the App Store for iPhone and iPad. Email us at: Search US Stove. Save your receipt with customerservice@usstove.com your records for any claims. © 2022 United States Stove Company...
Page 107 Declaration of Completion: As the qualified person responsible for the work described above, I confirm that the appliance as associated work has been installed as per manufacturer’s instructions and following any applicable building and installation codes. Signed: ______________________________________ Print Name: __________________________________Date: ______________ Home Owner: RETAIN THIS INFORMATION FOR FUTURE REFERENCE © 2022 United States Stove Company...
Page 108 2. Unpack the top mount controls and ensure that the wiring harness shown is attached securely. 4. Secure the control panel to the top of the stove with two sheet metal screws. © 2022 United States Stove Company...
Page 109 AND CAN BE HAZARDOUS TO YOUR HEALTH IF with clearance requirements for a freestanding stove NOT PROPERLY VENTED. installation. Alcove Unit - supported by pedestal/legs and placed © 2022 United States Stove Company...
Page 110 For safety reasons, please adhere to the installation clearances and restrictions. Any reduction in clearance to combustibles may only be done by means approved by a regulatory authority. © 2022 United States Stove Company...
Page 111 The maximum recommend vertical venting height is 12- the floor of the home. feet for 3-inch type “PL” vent. Total length of horizontal © 2022 United States Stove Company...
Page 112 Vent surfaces can get hot enough E. Minimum 2-foot (0.61m) clearance above any grass, to cause burns if touched by children. Noncombustible plants, or other combustible materials. shielding or guards may be required. © 2022 United States Stove Company...
Page 113 4 inch “PL” pellet venting products. The use of other of vertical venting. An approved vertical vent cap is components other than stated herein could cause bodily recommended. harm, heater damage, and void your warranty. © 2022 United States Stove Company...
Page 114 If clearance through a combustible wall. Once outside the an offset is required, it is better to install 45-degree structure, a 3” (76 mm) clearance should be maintained elbows rather than 90-degree elbows. © 2022 United States Stove Company...
Page 115 Please conform to any local building codes or regulations having jurisdiction before you have a qualified installer proceed with this Support installation. Bracket 3” to 6” Pipe Adapter 3” PL Vent Clean Out Tee © 2022 United States Stove Company...
Page 116 The air to fuel ratio can be adjusted to allow almost any fuel quality to burn effectively by following the procedures detailed © 2022 United States Stove Company...
Page 117 When adjusting the Draft Fan setting, try only 1 setting above or below the heat setting. It is better to leave the stove in the automatic mode. © 2022 United States Stove Company...
Page 118 T’Stat requires more heat, the unit will begin to feed pellets at the preselected heat setting ranging from “1” to “5”. Use 18 gauge, 2 conductor wire © 2022 United States Stove Company...
Page 119 Your pellet stove is designed to burn premium hardwood WHILE THE STOVE IS PLUGGED IN. pellets that comply with the Pellet Fuels Institute (PFI) standard (minimum of 40 lbs density per cubic ft, 1/4” to © 2022 United States Stove Company...
Page 120 • WE RECOMMEND THAT YOU NOT LET THE the “Heat Level Advance” button. HOPPER DROP BELOW 1/4 FULL. If the fire doesn’t start in 12 minutes, press “On/Off”, wait a few minutes, clear the burn pot, and start the procedure again. © 2022 United States Stove Company...
Page 121 The stove will shut down and show “E2” on the two digit display. The stove has to fully shut down before restarting. © 2022 United States Stove Company...
Page 122 CO. the top as well as from the bottom. The creosote should be removed with a brush specifically designed for the © 2022 United States Stove Company...
Page 123 Gaskets Inspected 5. Re-install the retainer and eight nuts and rope gasket Glass Wiped Cleaned using high-temperature silicone to adhere the gasket Hopper (end of Empty & to the door. season) Vacuumed © 2022 United States Stove Company...
Page 124 ATTENTION: THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. IT IS AGAINST FEDERAL REGULATIONS TO OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. © 2022 United States Stove Company...
Page 125 FACTORY DEFAULTS To return the control to its original factory default settings, press and hold the AUX UP and AUX DOWN buttons together for three seconds. © 2022 United States Stove Company...
Page 126 Door Handle Kit 88118 Ignitor Flange Gasket IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING USSC PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM USSC. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2022 United States Stove Company...
Page 127 Part numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been gathered you can contact customer service by phone 1-800-750-2723 Ext 5051 or Email parts@usstove.com. Model Information Model Number Serial Number © 2022 United States Stove Company...
Page 128 Engineer Name: ____________________________________ Engineer Name: ____________________________________ License No.: ________________________________________ License No.: ________________________________________ Company: __________________________________________ Company: __________________________________________ Telephone No.: _____________________________________ Telephone No.: _____________________________________ Stove Inspected: Chimney Swept: Stove Inspected: Chimney Swept: Items Replaced: ____________________________________ Items Replaced: ____________________________________ © 2022 United States Stove Company...
Page 153 State of California to cause cancer, birth defects, and/or other reproductive harm. For emissions standards. more information, go to www.P65warnings.ca.gov THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. © 2022 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380 Ph. 800-750-2723...
Page 154 This app is available only Text to 423-301-5624 or; on the App Store for iPhone and iPad. Email us at: Search US Stove. Save your receipt with customerservice@usstove.com your records for any claims. © 2022 United States Stove Company...
Page 155 Declaration of Completion: As the qualified person responsible for the work described above, I confirm that the appliance as associated work has been installed as per manufacturer’s instructions and following any applicable building and installation codes. Signed: ______________________________________ Print Name: __________________________________Date: ______________ Home Owner: RETAIN THIS INFORMATION FOR FUTURE REFERENCE © 2022 United States Stove Company...
Page 156 CORD IN FOOT TRAFFIC AREAS OR PINCH THE CORD UNDER FURNITURE. US Stove highly recommends your stove be installed by a qualified NFI (US) or WETT (Canada) technician. To find the nearest qualified installer, go to: https://nficertified.org, https://www.wettinc.ca/ © 2022 United States Stove Company...
Page 157 330 mm PARALLEL Sidewall to top edge 8” 203 mm of unit H Backwall to flue 3” 76.2mm CORNER J Adjacent wall to unit 8” 203 mm ALCOVE K Alcove depth 36” 914 mm © 2022 United States Stove Company...
Page 158 The maximum recommend vertical venting height is 12- the floor of the home. feet for 3-inch type “PL” vent. Total length of horizontal © 2022 United States Stove Company...
Page 159 Vent surfaces can get hot enough E. Minimum 2-foot (0.61m) clearance above any grass, to cause burns if touched by children. Noncombustible plants, or other combustible materials. shielding or guards may be required. © 2022 United States Stove Company...
Page 160 4 inch “PL” pellet venting products. The use of other of vertical venting. An approved vertical vent cap is components other than stated herein could cause bodily recommended. harm, heater damage, and void your warranty. © 2022 United States Stove Company...
Page 161 If clearance through a combustible wall. Once outside the an offset is required, it is better to install 45-degree structure, a 3” (76 mm) clearance should be maintained elbows rather than 90-degree elbows. © 2022 United States Stove Company...
Page 162 Please conform to any local building codes or regulations having jurisdiction before Support you have a qualified installer proceed with this Bracket installation. 3” to 6” Pipe Adapter 3” PL Vent Clean Out Tee © 2022 United States Stove Company...
Page 163 The air to function. fuel ratio can be adjusted to allow almost any fuel quality B. Heat Range Arrow Buttons to burn effectively by following the procedures detailed © 2022 United States Stove Company...
Page 164 When adjusting the Draft Fan setting, try only 1 setting above or below the heat setting. It is better to leave the stove in the automatic mode. © 2022 United States Stove Company...
Page 165 T’Stat requires more heat, the unit will begin to feed pellets at the preselected heat setting ranging from “1” to “5”. Use 18 gauge, 2 conductor wire © 2022 United States Stove Company...
Page 166 Your pellet stove is designed to burn premium hardwood WHILE THE STOVE IS PLUGGED IN. pellets that comply with the Pellet Fuels Institute (PFI) standard (minimum of 40 lbs density per cubic ft, 1/4” to © 2022 United States Stove Company...
Page 167 • WE RECOMMEND THAT YOU NOT LET THE the “Heat Level Advance” button. HOPPER DROP BELOW 1/4 FULL. If the fire doesn’t start in 12 minutes, press “On/Off”, wait a few minutes, clear the burn pot, and start the procedure again. © 2022 United States Stove Company...
Page 168 The stove will shut down and show “E2” on the two digit display. The stove has to fully shut down before restarting. © 2022 United States Stove Company...
Page 169 CO. the top as well as from the bottom. The creosote should be removed with a brush specifically designed for the © 2022 United States Stove Company...
Page 170 5. Re-install the retainer and eight nuts and rope gasket Hopper (end of Empty & using high-temperature silicone to adhere the gasket season) Vacuumed to the door. 6. Never use substitute materials for the glass. © 2022 United States Stove Company...
Page 171 CO. the top as well as from the bottom. The creosote should be removed with a brush specifically designed for the © 2022 United States Stove Company...
Page 172 ATTENTION: THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. IT IS AGAINST FEDERAL REGULATIONS TO OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. © 2022 United States Stove Company...
Page 173 FACTORY DEFAULTS To return the control to its original factory default settings, press and hold the AUX UP and AUX DOWN buttons together for three seconds. © 2022 United States Stove Company...
Page 174 Door Handle Kit 88118 Ignitor Flange Gasket IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING USSC PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM USSC. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2022 United States Stove Company...
Page 175 Part numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been gathered you can contact customer service by phone 1-800-750-2723 Ext 5051 or Email parts@usstove.com. Model Information Model Number Serial Number © 2022 United States Stove Company...
Page 176 Engineer Name: ____________________________________ Engineer Name: ____________________________________ License No.: ________________________________________ License No.: ________________________________________ Company: __________________________________________ Company: __________________________________________ Telephone No.: _____________________________________ Telephone No.: _____________________________________ Stove Inspected: Chimney Swept: Stove Inspected: Chimney Swept: Items Replaced: ____________________________________ Items Replaced: ____________________________________ © 2022 United States Stove Company...
Page 201 State of California to cause emissions standards. cancer, birth defects, and/or other reproductive harm. For more information, go to www.P65warnings.ca.gov THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. © 2022 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380 Ph. 800-750-2723...
Page 202 1-800-750-2723 Ext 5050 or; available only on the App Store for Text to 423-301-5624 or; iPhone and iPad. Search US Stove. Email us at: Save your receipt with your records customerservice@usstove. for any claims. © 2022 United States Stove Company...
Page 203 Signed: ___________________________________ Print Name: ______________________________ Date: _____________ Home Owner: RETAIN THIS INFORMATION FOR FUTURE REFERENCE © 2022 United States Stove Company...
Page 204 US Stove highly recommends your stove be installed FOOT TRAFFIC AREAS OR PINCH THE CORD by a qualified NFI (US) or WETT (Canada) technician. UNDER FURNITURE. To find the nearest qualified installer, go to: https://nficertified.org, https://www.wettinc.ca/ © 2022 United States Stove Company...
Page 205 Sidewall to top edge 8” 203 mm Rear (interior of unit 2” 50 mm vertical) H Backwall to flue 3” 76.2mm CORNER J Adjacent wall to unit 8” 203 mm ALCOVE K Alcove depth 36” 914 mm © 2022 United States Stove Company...
Page 206 In addition to the previously detailed installation WILL NOT FUNCTION PROPERLY. requirements, mobile home installations must meet the following requirements: • This stove must be securely fastened to the floor of the mobile home using two 1/4” lag bolts that © 2022 United States Stove Company...
Page 207 The pellet vent pipe is designed to disassemble for cleaning and should be checked several times during the burning season. The pellet vent pipe is not furnished with the unit and must be purchased separately. © 2022 United States Stove Company...
Page 208 Outside Fresh Air is Mandatory when installing this pellet stove room heater in airtight homes and mobile homes. Be sure that the outside air vent has an approved © 2022 United States Stove Company...
Page 209 Canadian installations must conform to CAN/ elbows rather than 90-degree elbows. CSA-B365. To vent the unit through the wall, connect the pipe adapter to the exhaust motor adapter. If the exhaust adapter is at least 18” (457 © 2022 United States Stove Company...
Page 210 Please conform to any local building codes or regulations having jurisdiction before Support you have a qualified installer proceed with this Bracket installation. 3” to 6” Pipe Adapter 3” PL Vent Clean Out Tee © 2022 United States Stove Company...
Page 211 Matching stoves operating conditions until start-up is the amount of air required for proper combustion completed. to the fuel rate is the primary objective in effectively © 2022 United States Stove Company...
Page 212 When adjusting the Draft Fan setting, try only 1 setting above or below the heat setting. It is better to leave the stove in the © 2022 United States Stove Company...
Page 213 T’Stat requires more heat, the unit will begin to feed pellets at the preselected heat setting ranging from “1” to “5”. Use 18 gauge, 2 conductor wire © 2022 United States Stove Company...
Page 214 We cannot accept ATTENTION: responsibility for damage due to poor quality pellet. THIS APPLIANCE IS DESIGNED FOR THE USE OF PELLETIZED FUEL THAT MEET OR EXCEED THE STANDARD SET BY THE PELLET FUEL INSTITUTE (PFI). © 2022 United States Stove Company...
Page 215 Attempts to achieve heat output MAY ARISE FROM SPARKS OR FUMES rates that exceed heater design specifications can ENTERING THE ROOM. result in permanent damage to the heater. • THE DOOR MUST BE CLOSED AND SEALED DURING OPERATION. © 2022 United States Stove Company...
Page 216 The stove will shut down and show EXCEPT WHEN REFILLING. “E2” on the two digit display. The stove has to fully • DO NOT OVERFILL HOPPER. shut down before restarting. © 2022 United States Stove Company...
Page 217 (2 screws). The auger motor is located in the center rear of the unit. Note: When cleaning, take care not to damage the fan blades. © 2022 United States Stove Company...
Page 218 CO bottom. The creosote should be removed with a monitors in areas having the potential to generate brush specifically designed for the type of chimney in use. A qualified chimney sweep can perform this © 2022 United States Stove Company...
Page 219 Glass Wiped Cleaned 5. Re-install the retainer and eight nuts and rope Hopper (end of Empty & gasket using high-temperature silicone to season) Vacuumed adhere the gasket to the door. © 2022 United States Stove Company...
Page 220 ATTENTION: THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. IT IS AGAINST FEDERAL REGULATIONS TO OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. © 2022 United States Stove Company...
Page 221 FACTORY DEFAULTS To return the control to its original factory default settings, press and hold the AUX UP and AUX DOWN buttons together for three seconds. © 2022 United States Stove Company...
Page 222 Ignitor Flange Gasket 893241-US Door Handle Kit IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING USSC PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM USSC. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2022 United States Stove Company...
Page 223 Part numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been gathered you can contact customer service by phone 1-800-750-2723 Ext 5051 or Email parts@usstove.com. Model Information Model Number Serial Number © 2022 United States Stove Company...
Page 224 Engineer Name: _______________________________ Engineer Name: _______________________________ License No.: ____________________________________ License No.: ____________________________________ Company: _____________________________________ Company: _____________________________________ Telephone No.: _________________________________ Telephone No.: _________________________________ Stove Inspected: Chimney Swept: Stove Inspected: Chimney Swept: Items Replaced: _______________________________ Items Replaced: _______________________________ © 2022 United States Stove Company...
Page 249 State of California to cause cancer, birth defects, and/or other reproductive harm. For more emissions standards. information, go to www.P65warnings.ca.gov THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE. © 2022 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380 Ph. 800-750-2723...
Page 250 This app is available only Text to 423-301-5624 or; on the App Store for iPhone and iPad. Email us at: Search US Stove. Save your receipt with customerservice@usstove.com your records for any claims. © 2022 United States Stove Company...
Page 251 Declaration of Completion: As the qualified person responsible for the work described above, I confirm that the appliance as associated work has been installed as per manufacturer’s instructions and following any applicable building and installation codes. Signed: _______________________________________ Print Name: ___________________________________ Date: _______________ Home Owner: RETAIN THIS INFORMATION FOR FUTURE REFERENCE © 2022 United States Stove Company...
Page 252 DO NOT ROUTE THE CORD IN FOOT TRAFFIC AREAS OR PINCH THE CORD UNDER FURNITURE. US Stove highly recommends your stove be installed by a qualified NFI (US) or WETT (Canada) technician. To find the nearest qualified installer, go to: https://nficertified.org, https://www.wettinc.ca/ © 2022 United States Stove Company...
Page 253 For safety reasons, please adhere to the installation clearances and restrictions. Any reduction in clearance to combustibles may only be done by means approved by a regulatory authority. © 2022 United States Stove Company...
Page 254 3-inch type “PL” vent. Total length of horizontal vent must not exceed 4-feet. This could cause back pressure. • The heater must be electrically grounded to the steel © 2022 United States Stove Company...
Page 255 Vent surfaces can get hot enough to cause burns if E. Minimum 2-foot (0.61m) clearance above any grass, touched by children. Noncombustible shielding or guards plants, or other combustible materials. may be required. Minimum 3-foot (0.91m) clearance from an forced air © 2022 United States Stove Company...
Page 256 “PL” pellet venting products. The use of other components necessary install a 90° elbow and appropriate length other than stated herein could cause bodily harm, heater of vertical venting. An approved vertical vent cap is damage, and void your warranty. recommended. © 2022 United States Stove Company...
Page 257 45-degree elbows through a combustible wall. Once outside the structure, rather than 90-degree elbows. a 3” (76 mm) clearance should be maintained from the © 2022 United States Stove Company...
Page 258 Ceiling to any local building codes or regulations having Support jurisdiction before you have a qualified installer proceed with this installation. Support Bracket 3” to 6” Pipe Adapter 3” PL Vent Clean Out Tee © 2022 United States Stove Company...
Page 259 B. Heat Range Arrow Buttons to allow almost any fuel quality to burn effectively by • These buttons when pushed will set the pellet feed following the procedures detailed in the remainder of this © 2022 United States Stove Company...
Page 260 When adjusting the Draft Fan setting, try only 1 setting above or below the heat setting. It is better to leave the stove in the automatic mode. © 2022 United States Stove Company...
Page 261 T’Stat requires more heat, the unit will begin to feed pellets at the preselected heat setting ranging from “1” to “5”. Use 18 gauge, 2 conductor wire © 2022 United States Stove Company...
Page 262 BEGIN TO MOVE AT ANY TIME WHILE THE STOVE Your pellet stove is designed to burn premium hardwood IS PLUGGED IN. pellets that comply with the Pellet Fuels Institute (PFI) standard (minimum of 40 lbs density per cubic ft, 1/4” to © 2022 United States Stove Company...
Page 263 If the fire doesn’t start in 12 minutes, press “On/Off”, wait • KEEP HOPPER LID CLOSED AT ALL TIMES EXCEPT a few minutes, clear the burn pot, and start the procedure WHEN REFILLING. again. • DO NOT OVERFILL HOPPER. © 2022 United States Stove Company...
Page 264 In particular, it is advisable to clean out the holes in the burn pot to remove any build up that may prevent air from moving through the burn pot freely. © 2022 United States Stove Company...
Page 265 Clean as also recommended that before each heating season the needed. entire system be professionally inspected, cleaned and, if necessary, repaired. To clean the chimney, disconnect the vent from the stove. © 2022 United States Stove Company...
Page 266 6. Never use substitute materials for the glass. season) Vacuumed DO NOT abuse the door glass by striking, slamming, or similar trauma. Do not operate the stove with the glass removed, cracked, or broken. © 2022 United States Stove Company...
Page 267 ATTENTION: THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. IT IS AGAINST FEDERAL REGULATIONS TO OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. © 2022 United States Stove Company...
Page 268 FACTORY DEFAULTS To return the control to its original factory default settings, press and hold the AUX UP and AUX DOWN buttons together for three seconds. © 2022 United States Stove Company...
Page 269 Door Handle Kit 88118 Ignitor Flange Gasket IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING USSC PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM USSC. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY. © 2022 United States Stove Company...
Page 270 Part numbers and descriptions can be found in the “Repair Parts” section of this manual. Once this information has been gathered you can contact customer service by phone 1-800-750-2723 Ext 5051 or Email parts@usstove.com. Model Information Model Number Serial Number © 2022 United States Stove Company...
Page 271 Engineer Name: _____________________________________ Engineer Name: _____________________________________ License No.: ________________________________________ License No.: ________________________________________ Company: ___________________________________________ Company: ___________________________________________ Telephone No.: ______________________________________ Telephone No.: ______________________________________ Stove Inspected: Chimney Swept: Stove Inspected: Chimney Swept: Items Replaced: _____________________________________ Items Replaced: _____________________________________ © 2022 United States Stove Company...
Page 297 Repair or replacement of parts that are subject to normal wear and tear during WARRANTOR the warranty period. These parts include: paint, pellet, and the discoloration The warrantor of record is United States Stove Company, PO Box 151, 227 of glass. Industrial Park Road, South Pittsburg, Tennessee 37380. Phone number: (800)- •...
Page 298 • Composants d’évacuation des gaz, composants de l’âtre ou accessoires utilisés oblitéré, un reçu de vente, etc., de United States Stove Company (« USSC ») ou d’un avec l’appareil et qui n’ont pas été fournis par USSC. détaillant autorisé, comme suit: •...
Page 299 Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts include: paint, pellet, and the discoloration The warrantor of record is United States Stove Company, PO Box 151, 227 of glass.
Page 300 • Composants d’évacuation des gaz, composants de l’âtre ou accessoires utilisés oblitéré, un reçu de vente, etc., de United States Stove Company (« USSC ») ou d’un avec l’appareil et qui n’ont pas été fournis par USSC. détaillant autorisé, comme suit: •...
Page 301 Dry Gas Meter Calibration Meter Manufacturer: Apex Model: XC-50-DIR Lab ID #: Serial #: 1906005 Calibration Date: 10/5/2021 Calibration Expiration: 4/5/2022 Barometric Pressure: 29.71 in. Hg Reference Standard DGM Unit Under Test Previous Calibration Manufacturer: Apex Date 3/15/2021 Model: SK25DA γ...
Page 302 Pressure Gauge Calibration Work Sheet Gauge Manufacturer: Apex Maximum Range (inH Instrument ID #: 129 (dH) Calibration Date: 10/7/2021 Calibration Expiration: 10/7/2022 Barometric Pressure: 30.03 in. Hg Reference Standard Gauge Manufacturer: Dwyer Model: 477AV-1 Instrument ID#: 174 Calibration Expiration Date: 10/8/2021 Reference Gauge Pressure Gauge Difference...
Page 303 Pressure Gauge Calibration Work Sheet Gauge Manufacturer: Apex Maximum Range (inH Instrument ID #: 129 (dP) Calibration Date: 10/7/2021 Calibration Expiration: 10/7/2022 Barometric Pressure: 30.03 in. Hg Reference Standard Gauge Manufacturer: Dwyer Model: 475 Instrument ID#: 76 Calibration Expiration Date: 8/3/2022 Reference Gauge Pressure Gauge Difference...
Page 304 Dry Gas Meter Calibration Meter Manufacturer: Apex Model: XC-50-DIR Lab ID #: Serial #: 1906006 Calibration Date: 10/5/2021 Calibration Expiration: 4/5/2022 Barometric Pressure: 29.71 in. Hg Reference Standard DGM Unit Under Test Previous Calibration Manufacturer: Apex Date 3/15/2021 Model: SK25DA γ...
Page 305 Pressure Gauge Calibration Work Sheet Gauge Manufacturer: Apex Maximum Range (inH Instrument ID #: 130 (dH) Calibration Date: 10/7/2021 Calibration Expiration: 10/7/2022 Barometric Pressure: 30.03 in. Hg Reference Standard Gauge Manufacturer: Dwyer Model: 477AV-1 Instrument ID#: 174 Calibration Expiration Date: 10/8/2021 Reference Gauge Pressure Gauge Difference...
Page 306 Pressure Gauge Calibration Work Sheet Gauge Manufacturer: Apex Maximum Range (inH Instrument ID #: 130 (dP) Calibration Date: 10/7/2021 Calibration Expiration: 10/7/2022 Barometric Pressure: 30.03 in. Hg Reference Standard Gauge Manufacturer: Dwyer Model: 475 Instrument ID#: 76 Calibration Expiration Date: 8/3/2022 Reference Gauge Pressure Gauge Difference...
Page 307 Dry Gas Meter Calibration Meter Manufacturer: Apex Model: Apex-AK-600 Lab ID #: Serial #: 810016 Calibration Date: 10/8/2021 Calibration Expiration: 10/8/2022 Barometric Pressure: 29.91 in. Hg Reference Standard DGM Unit Under Test Previous Calibration Manufacturer: Apex Date 3/31/2021 Model: SK25DA γ...
Page 310 JJ Calibrations, Inc. Certificate of Calibration 7724 SE Aspen Summit Drive Portland, OR 97266-9217 Certificate Number: 743897 Phone 503.786.3005 FAX 503.786.2994 PFS TECO 11785 SE Hwy 212 1033 Suite 305 Clackamas, OR 97015 0723.01 Order Date: 03/08/2021 Calibration Authorized By: Property #: Calibrated on: 03/18/2021...
Page 313 Bulletin D-57 Model 1430 Microtector Electronic Point Gage ® Installation and Operating Instructions Model 1430 Microtector ® Portable • Three-point mounting, dual leveling Electronic Point Gage combines mod- adjustment, and circular level vial assure rapid setup ern, solid-state integrated circuit elec- •...
Page 314 PRESSURE FLUID LEVEL Microtector Gage ® Precision Pressure Measurement On indication of contact, the operator stops The Microtector ® Gage combines the time- lowering the point and reads the micrometer proven principles of the Hook Gage type which indicates one half the applied pressure. manometer and modern solid-state integrat- By interpolating eight divisions (each being ed circuit electronics.
Page 315 After making contact, turn the point out of the Fluid Level fluid by turning the micrometer barrel counter- Level the gage by adjusting the two front lev- clockwise to a reading of .010 or more. Again, eling screws (Item 8 on drawing) until the bub- watch the meter and, this time, lower the ble in the spirit level is centered in the small point by turning the micrometer barrel.
Page 316 When the readings are complete, the pres- (2) If the meter operation continues to be sure should be removed and the zero setting sluggish, replace the size AA, 1.5 volt battery. of Microtector ® Gage rechecked. Any change (Replace the battery at least once a year to in the zero position will indicate inaccurate avoid deterioration of battery and damage to readings.
Page 317 JJ Calibrations, Inc. Certificate of Calibration 7724 SE Aspen Summit Drive Portland, OR 97266-9217 743892 Certificate Number: Phone 503.786.3005 FAX 503.786.2994 PFS TECO 11785 SE Hwy 212 1033 Suite 305 03/08/2021 Order Date: Clackamas, OR 97015 0723.01 Authorized By: Calibration Property #: Calibrated on: 03/18/2021...
Page 320 Calibration Certificate ID 072731-240-041621-ACC-USI Accredited by the American Association Mettler Toledo for Laboratory Accreditation (A2LA) Service Business Unit Industrial CALIBRATION CERT #1902.01 1900 Polaris Parkway Columbus, OH 43240 ISO 17025 Registered 1-800-523-5123 ANSI/NCSL Z540-1 Accredited Accuracy Calibration Certificate Customer Company: PFS-TECO Address: 11785 SE Hwy 212;...
Page 321 Calibration Certificate ID 072731-240-041621-ACC-USI Measurement Results Repeatability Test Load: 500 lb As Found As Found As Left As Left 500.00 lb 500.00 lb 500.00 lb 500.00 lb 500.02 lb 500.02 lb Standard 0.010 lb Deviation The "d" in the graph represents the readability of the range/interval in which the test was performed.
Page 322 Calibration Certificate ID 072731-240-041621-ACC-USI Error of Indication As Found Reference Value Indication Error of Indication Expanded Uncertainty 0 lb 0.00 lb 0.00 lb 2 ¹ 250 lb 250.00 lb 0.00 lb 500 lb 500.00 lb 0.00 lb 3 ¹ 750 lb 750.00 lb 0.00 lb 4 ¹...
Page 323 Calibration Certificate ID 072731-240-041621-ACC-USI Test Equipment All weights used for metrological testing are traceable to national or international standards. The weights were calibrated and certified by an accredited calibration laboratory. Weight Set 1: NIST NIST-F Weight Set No.: 182 50's & 25's Date of Issue: 25-Jun-2019 Certificate Number:...
Page 324 Calibration Certificate ID 072731-240-041621-ACC-USI Measurement Uncertainty of the Weighing Instrument in Use Stated is the expanded uncertainty with k=2 in use. The formula shall be used for the estimation of the uncertainty under consideration of the errors of indication. The value R represents the net load indication in the unit of measure of the device. Temperature coefficient for the evaluation of the measurement uncertainty in use: 10.0 ·...
Page 325 Attachment to Calibration Certificate: 072731-240-041621-ACC-USI Handbook 44 Tolerance Assessment Handbook 44 Tolerance Assessment (Acceptance) Assessment done without considering measurement uncertainty. The measurements from the attached calibration certificate were assessed against the Tolerances defined by NIST Handbook 44. The range of measurements for both Eccentricity and Repeatability (if performed) tests is assessed against Maintenance Tolerances. As Found As Left = Passed...
Page 326 2020 PM emission limit of ≤ 2.0 g/hr using pellet fuel per ASTM E2779 W/EPA ALT-146, ASTM E2515. Efficiency calculated per CSA B415.1-10 The average emissions for the KP5522 pellet heater is 1.5 g/hr with an average efficiency of 76%. Average CO emissions are 0.15 g/min.
Page 327 Revision History Date: March 29, 2022 – Original Issue Date: May 17, 2022 – The following to the report were reviewed: B415 Calculations page was included in Appendix A, see page 73 of Non-CBI report. Adjusted CO emissions values on page 8 to show 2 significant figures. PFS TECO is accredited by IAS to ISO 17020:2012 “Criteria For Bodies Performing Inspections, ISO 17025: 2005 “Requirements For Testing Laboratories”, and by Standards Council of Canada to ISO 17065: 2012 “Requirements For Bodies Operating Product Certification Systems”.
Page 328 APPLICATION FOR US EPA WOOD HEATER CERTIFICATION PURSUANT TO 40 CFR PART 60 SUBPARTS AAA AND QQQQ U.S. ENVIRONMENTAL PROTECTION AGENCY (EPA) 2015 Standards of Performance for New Residential Wood Heaters, New Residential Hydronic Heaters and Forced-Air Furnaces Application 40 CFR PART 60 SUBPARTS AAA AND QQQQ Disclaimer: The statutory provisions and the EPA regulations described in this document contain legally binding requirements.
Page 329: Application For A Certificate Of Compliance Pursuant To 40 Cfr Part 60 Subparts Aaa And Qqqq
Model Name and Design Number (The model name and design number must clearly distinguish one model from another. The name and design number cannot include the EPA symbol or logo or name or derivatives such as “EPA): KP5522, KP5522-P, KP5522-L, KP5522-W, US5522, US5522-P, US5522-L,US5522-W, AP5622, AP5622-P, AP5622-L, AP5622-W, VG5722, VG5722-P, VG5722-L, VG5722-W, SP1100, SP1100-W Physical Address (Street number and Address, not P.O.
Page 330: Epa-Approved Test Laboratory
APPLICATION FOR A CERTIFICATE OF COMPLIANCE PURSUANT TO 40 CFR PART 60 SUBPARTS AAA AND QQQQ 2015 STANDARDS OF PERFORMANCE FOR NEW RESIDENTIAL WOOD HEATERS, NEW RESIDENTIAL HYDRONIC HEATERS AND FORCED-AIR FURNACES EPA-APPROVED TEST LABORATORY Name of Test Laboratory: PFS-TECO Name of Person Authorized or Responsible for Conducting Compliance Test: Sebastian Button Position/Title: Laboratory Supervisor Address: 11785 Highway 212, Ste.
Page 331: Compliance Statements And Acknowledgements - Sections 60.533(B) And 60.5475(B)
COMPLIANCE STATEMENTS AND ACKNOWLEDGEMENTS – SECTIONS 60.533(B) AND 60.5475(B) INSTRUCTIONS: PLEASE READ THE BELOW STATEMENTS AND AFFIRMATIONS AND ADDRESS ACCORDINGLY. FOR EMISSIONS DATA SUMMARY TABLES SEE ATTACHMENTS Engineering Drawings Statement Engineering drawings and specifications of components that may affect emissions (including specifications for each component listed in paragraphs (k)(2), (3) and (4) of 60.533(b) and 60.5475(b).
Page 332 10. Approved laboratory/third party Statement A statement that the approved laboratory and approved third-party certifier are allowed to submit information on behalf of the manufacturer, including any claimed to be CBI. 11. Manufacturer’s Website Certification Test Reports Availability Statement A statement that the manufacturer will place a copy of the certification test report and summary on the manufacturer’s web site available to the public within 30 days after the Administrator issues a certificate of compliance.
Page 333 ☐Cordwood ☐Other: (Check one): Model Name(s) (as will appear on test report): KP5522, KP5522-P, KP5522-L, US5522, US5522-P, US5522-L, AP5622, AP5622-P, AP5622-L, VG5722, VG5722-P, VG5722-L, SP1100 Model Number(s) (as will appear on test report): KP5522, KP5522-P, KP5522-L, US5522, US5522-P, US5522-L, AP5622, AP5622-P, AP5622-L, VG5722, VG5722-P, VG5722-L, SP1100 Equipped with a catalytic combustor? ☐Yes ☒No...
Page 334 OMB Control No. 2060-0161 Approval expires 03/31/2019 OMB Control No. 2060-0693 Approval expires 03/31/2019 30-DAY NOTIFICATION 2015 CLEAN AIR ACT (CAA) STANDARDS OF PERFORMANCE FOR NEW RESIDENTIAL WOOD HEATERS, NEW RESIDENTIAL HYDRONIC HEATERS AND FORCED-AIR FURNACES 40 CFR PART 60 SUBPARTS AAA AND QQQQ The public reporting and recordkeeping burden for this collection of information is estimated to average 2 hours per response.
Page 335 OMB Control No. 2060-0161 Approval expires 03/31/2019 OMB Control No. 2060-0693 Approval expires 03/31/2019 30-DAY NOTIFICATION 2015 CLEAN AIR ACT (CAA) STANDARDS OF PERFORMANCE FOR NEW RESIDENTIAL WOOD HEATERS, NEW RESIDENTIAL HYDRONIC HEATERS AND FORCED-AIR FURNACES 40 CFR PART 60 SUBPARTS AAA AND QQQQ The public reporting and recordkeeping burden for this collection of information is estimated to average 2 hours per response.
Page 336 OMB Control No. 2060-0161 Approval expires 03/31/2019 OMB Control No. 2060-0693 Approval expires 03/31/2019 30-DAY NOTIFICATION 2015 CLEAN AIR ACT (CAA) STANDARDS OF PERFORMANCE FOR NEW RESIDENTIAL WOOD HEATERS, NEW RESIDENTIAL HYDRONIC HEATERS AND FORCED-AIR FURNACES 40 CFR PART 60 SUBPARTS AAA AND QQQQ The public reporting and recordkeeping burden for this collection of information is estimated to average 2 hours per response.
Page 337 According to the information provided, you seek an alternative test method for use when conducting testing on the United States Stove Company, Model KP5517 pellet heater. Currently, as required by section 60.534(a)(l)(i) of Subpart AAA, a manufacturer has the option to test their appliance in accordance with 40 CFR part 60, Appendix B, Method 28R for a crib fuel appliance or ASTM E2779-10 “Standard Test Method for Determining Particulate Matter Emissions from...
Page 338 the position(s) as needed to achieve a burn rate that is ≤ 50% of the maximum burn rate.” Table 1 of ASTM E2779-10 also notes that the Medium Burn Rate Category test must be ≤ 50% of the maximum burn rate. The memorandum states that this is incorrect as it assumes that zero is the other bound for determining half of the maximum burn rate, and that the correct approach in determining the Medium Burn Rate Category should be at a level below 50% of the span between the Maximum Burn Rate and the Low Burn Rate (a non-zero value).
Page 339 Group Leader Measurement Technology Group Angelina Brashear – EPA/OAQPS/AQAD Chuck French – EPA/OAQPS/SPPD Rafael Sanchez – EPA/OECA Robert Scinta – EPA/OECA Michael Toney – EPA/OAQPS/AQAD Nathan Topham – EPA/OAQPS/SPPD John Voorhees – United States Stove Company Chet Wayland – EPA/OAQPS/AQAD...
Page 340 02/02/2022 MEMORANDUM SUBJECT: Appropriate calculation of Medium Burn Rate Category in ASTM E-2779 Testing FROM: Steffan Johnson Digitally signed by STEFFAN Group Leader STEFFAN JOHNSON Date: 2022.02.02 Measurement Technology Group JOHNSON 08:28:07 -05'00' Air Quality Assessment Division Robert Scinta, P.E. Chief, Air Branch Monitoring, Assistance, and Media Programs Division Office of Compliance, Office of Enforcement and Compliance Assurance...
Page 341 The correct application of this requirement would be to determine the Medium Burn Rate Category at a level below 50% of the span between the Maximum Burn Rate and the Low Burn Rate (a non-zero value). Ergo, the correct calculation for finding that midpoint of 50% is defined For example, if the Maximum Burn rate of an appliance is 1.79 kg/hr and the minimum is 1.23 kg/hr, the method would currently place the 50% requirement at 0.895 kg/hr.
Page 342: Summary Results - Pellet Heaters
Attachments Instructions: Please complete the section applicable to your certification request. You may substitute your own data tables in lieu of the ones shown below provided that all the information is captured. A. SUMMARY RESULTS – PELLET HEATERS EPA Application Table Overall Heat 1st Hr...

United States Stove Company KP5522 Manual

Quick Links

Related Manuals for United States Stove Company KP5522

Summary of Contents for United States Stove Company KP5522

Table of Contents
