Error messages
Remove the embroidery frame and replace the
17 bobbin. OK to move the embroidery carriage to its
previous position?
Remove the embroidery positioning mark.
18
The bobbin thread is almost empty.
* Use the "Reinforcement Stitch" button to sew a
single stitch repeatedly and tie off the stitching.
19 * Use the move frame key to move the embroidery
carriage so the embroidery frame can be removed or
installed. Afterward, the carriage moves back to its
previous position.
The bobbin winder safety device has activated. Is the
20
thread tangled?
The pattern extends out of the pattern area. Change
position of the pattern and scan the new area.
21
The safety device has been activated. Is the thread
22
tangled? Is the needle bent?
This file cannot be used.
23
This file exceeds the data capacity and cannot be
24 used. Use a suitable size file.
This key cannot be used at this time.
25
This USB media cannot be used.
26
Turn off the machine before attaching or removing
27
the needle plate.
USB media error
28
Cause/solution
This message is displayed when replacing the embroidering bobbin thread.
(page 52)
This message is displayed when the machine has recognized the embroidery
position mark. Remove the embroidery positioning sticker and touch
to continue. To remove the embroidery positioning sticker more easily, touch
. (page 47)
This message is displayed when the bobbin thread is running out. Although a
few stitches can be sewn when the "Start/Stop" button is pressed, replace
with a wound bobbin immediately. (page 52)
This message is displayed when the bobbin is being wound, and the motor
locks because the thread is tangled, etc.
This message appears when the built-in camera is being used to align the
embroidery position, but the embroidery positioning sticker is too near an
edge or the pattern extends from the embroidery frame.
Change the positioning of the embroidery position sticker, and then try
aligning the position again. Refer to page 45.
This message is displayed when the motor locks due to tangled thread or for
other reasons related to thread delivery.
This message appears if the file format is incompatible with this machine.
Check the list of compatible file formats. Refer to "SPECIFICATIONS" in the
Instruction and Reference Guide (Sewing).
This message is displayed when the file size exceeds the data capacity of the
machine. Confirm the file size and format. Refer to "SPECIFICATIONS" in the
Instruction and Reference Guide (Sewing).
This message is displayed when you touch [Sewing Guide] in the screen other
than the utility stitch, or touch [Pattern Explanation] in the screen other than
the utility stitch or character/decorative stitch.
This message is displayed when you try to use incompatible media. For a list
of compatible USB media, visit " www.babylock.com ".
This message is displayed when the needle plate is removed with the machine
on or when the machine is turned on and embroidery mode is selected.
This message is displayed when an error occurs with the USB media. For a
list of compatible USB media, visit " www.babylock.com ".
ERROR MESSAGES
5
199
